ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 INTRODUCTION I
WORKSHOP MANUAL
ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
IIą INTRODUCTION ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 INTRODUCTION III
Figure 1
174CU01
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
IVą INTRODUCTION ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 INTRODUCTION V
SECTIONS
ENGINE 3 from 1 to 52
SUSPENSION 14 from 1 to 10
BODY 20 from 1 to 4
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
VIą INTRODUCTION ADT 25
PARTS
Figure 2
1 3 2
4 6 9 5 7 10 8
174CU02
1. Cab
2. Body
3. Central joint
4. Engine
5. Transmission
6. Front axle
7. Intermediate axle
8. Rear axle
9. Suspension cylinder
10. Tipper cylinder
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 INTRODUCTION VII
engine
automatic transmission
front axle
intermediate axle
rear axle
suspension cylinder
tipper cylinder
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
VIIIą INTRODUCTION ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 1.1
CONDITIONS OF USE
ADT 25 SECTION 1.1 CONDITIONS OF USEą1
CONTENTS
Page Page
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąCONDITIONS OF USE SECTION 1.1 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.1 CONDITIONS OF USEą3
INTRODUCTION
This technical handbook contains a series of repair
procedures relating to the articulated dump trucks.
Read this handbook carefully before carrying out any
repairs on the vehicle.
Scrupulous observance of the rules and instructions
herein will ensure that repairs are carried out safely and
efficiently.
Copyright
The copyrights of this handbook belong to the vehicle
manufacturer.
The text, drawings and illustrations contained in this
handbook cannot be circulated or given to third
parties, totally or partially, without the written consent
of the vehicle manufacturer.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąCONDITIONS OF USE SECTION 1.1 ADT 25
CONFORMITY MARKING
This vehicle was made in compliance with Community Figure 1
Directive 98/37/EEC and amendments (Machinery
Directive).
All parts of the vehicle comply with the aforesaid
directive, as shown by the CE marking.
The plate is located in the position shown in the figure
and must be legible at all times.
LEVEL OF NOISE
Noise outside the vehicle:
Lwa = 108 dB (A)
174CU01A
Noise at driver's seat:
Lpa = 76 dB (A)
Figure 2
measured on identical vehicle, in accordance with
Directive 86/662/EEC.
Figure 3
174CU02
174CU03
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.1 CONDITIONS OF USEą5
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąCONDITIONS OF USE SECTION 1.1 ADT 25
Units of measure
International System (SI) units of measure as used in
this handbook.
Imperial System values are expressed in brackets.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.1 CONDITIONS OF USEą7
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąCONDITIONS OF USE SECTION 1.1 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.1 CONDITIONS OF USEą9
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
10ąCONDITIONS OF USE SECTION 1.1 ADT 25
Disassembly preparation
To save unnecessary labour, make sure that the
equipment, area and space on the shelves is available,
according to the specific type of disassembly to be 1730101
carried out, and clean the area beforehand.
D Use an appropriate jig and do not try to force them.
During disassembly
Removal of parts
D Before removing parts, check the assembly
conditions and front/rear, left/right and up/down
relations and the removal procedures
D Make sure there are the relevant mating marks
indicating the mounting positions and if necessary
mark clearly to avoid errors during reassembly.
D Use the special disassembly tools where specified.
D If it is difficult to remove a part even after the
mounting screws have been removed, do not force
it, but check the part to find where the problem lies.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.1 CONDITIONS OF USEą11
Operate each control lever several times to When using detergents, make sure you fully
relieve any pressure in the lines to be understand the use instructions and take
removed. care not to bring them into contact with the
Open the air bleeder cap of the hydraulic eyes or skin. Dispose of used detergents
tank. correctly.
Figure 5 Cleaning
D Clean the disassembled parts and arrange them in
order. Completely remove sludge and dust from the
oil ports of each part.
D To clean more efficiently, divide the detergent into
two containers; one to remove the dirt and one for
finishing. When cleaning more important parts,
divide the containers further to avoid using dirty
detergent.
D When cleaning large castings, such as the cylinder
head or block, , immerse them in a container for 5
to 10 minutes with a pH 10-12 detergent, at a
temperature of 50 °C and 70 °C (122Ą÷Ą158 °F),
then rinse thoroughly.
1730102
D To disconnect a rigid tube from another one, or a Rust and dust prevention
rigid tube from a hose, grasp the male end with a D Cover clean parts to avoid rusting.
wrench and loosen the female nut side. D Place caps on the ends of tubes and hoses.
D Plug the end of the removed tube or hose and the D If it will be some time before assembly, use rust
oil port on the part, to prevent foreign matter from inhibitor.
entering.
D Since the tube or hose to be removed contains oil, During assembly
pour this off into a suitable container.
D Clean up any oil spills in the working area. Installing the parts
D Attach a tag with an appropriate marking to each D Before starting to assemble, clean all the
tube, hose and hydraulic component line components and repair any damage. Dirt and dust
connection for easier reassembly. have adverse effects on moving parts and can
shorten the machine life, so take all precautions to
limit their penetration.
D Before assembly, remove the layer of rust inhibitor
if present on new parts.
D Parts with mating marks are to be mounted so that
the marks are correctly aligned.
D Use a press and appropriate tools when installing
bearings, bushings, oil gaskets etc. When
mounting special parts, use the specific special
tools.
D Coat the surface of press-fit parts with
molybdenum disulphate grease or other specific
lubricant, where prescribed.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
12ąCONDITIONS OF USE SECTION 1.1 ADT 25
Figure 8
1730103
Figure 7
1730105
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.1 CONDITIONS OF USEą13
Interchangeable parts
Figure 10
Gaskets
D As a rule, replace all gaskets with new ones.
D Apply sealing liquid to the sealing gaskets of certain
parts.
D Remove all flaws, dust, paint, oil or previously used
seal liquids.
D Apply an even coating of the specified sealing liquid
and allow to dry for a few minutes.
D When the liquid is dry to the touch, mate the
gaskets.
O-rings
D If the O-rings have become hardened after long
1730107
storage, discard them even if they have never been
used. D When assembling oil seal gaskets, apply some
D Use only the O-rings indicated in the spare parts grease to prevent initial dry friction.
lists. For the engine, in particular, O-rings of
special material, like silicone rubber are used for a. Single lip type oil seal gasket
their resistance to heat and deterioration. Do not Apply the grease evenly over the entire external
use substitutes. border of the side opposite to the sealing part of
D Before installation, apply a coating of oil to the the lip (arrow), taking care that there is no build
O-ring to prevent cracking. Silicone rubber tears up.
easily and must therefore be handled with care. b. Double lip type oil seal gasket
Apply grease to 40-60% of the external border of
Oil seal gaskets (oil seal rings) the section between the lips (arrow).
Figure 11
1730106
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
14ąCONDITIONS OF USE SECTION 1.1 ADT 25
D When an adhesive product is applied to the external D Bearings to be mated with large interference values
part of the gasket, take care that none drops onto are to be inserted by shrink fitting. To avoid
the lip surfaces. Since the adhesive remaining on damaging the heat treatment hardening, keep the
the assembly tools could easily pass onto the lips, temperature below 120 °C (248 °F).
use clean guides and assembly jigs.
Figure 13
Bearings
D Since dust adversely affects bearing wear, when
disassembling and reassembling, care must be
taken to protect them from dust.
D Handle the bearings with care when cleaning and
do not allow them to spin in compressed air.
D When installing, do not knock on the bearing inner
or outer ring, as this could cause indentations on
the rolling surfaces.
Figure 12
1730110
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.1 CONDITIONS OF USEą15
Welding on the chassis D turn over and weld as specified in the previous step;
Before starting these operations, disconnect the allow the side members to cool slowly and evenly;
negative terminal of the battery and connect the welder do not use jets of air or other methods, immediately
earth directly onto the piece to be welded. remove excess material by grinding;
Work on plastic tubes is only to be carried out by skilled
Figure 15
experts, using the appropriate equipment and
performed with perfect workmanship.
Figure 14
1730112
A = 0.3 H
1730111 B = H .175 mm (7 in)
S = (0.8 ć 1) S1
Remove the paint and any oxidation from the parts to
be welded. On the yield point, on the internal part of the D apply internal corner reinforcements in steel having
side member and along the entire length of the part the same characteristics as the chassis (minimum
involved, make a 60° chamfer. indicative dimensions are shown on the figure);
D they should be fixed only to the vertical rib of the side
Cuts on the side member are not allowed
member and welding beads can be used. The
that correspond to the stress variation section and length of the weld bead is to be
zones, furthermore the line of separation is adequate to transmit the section bending and
not to involve the existing holes on the side cutting moments.
member. D After welding the part involved is to be efficiently
The operating instructions for correct welding follow protected with a rust inhibitor.
below:
D heat all around the zone to be welded; make the arc
welding passing several times using carefully dried
basic tips , or MIG-MAG procedures with a suitable
filling material; avoid current overloads; the welding
is to be free of border incisions and spatter;
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
16ąCONDITIONS OF USE SECTION 1.1 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 1.2
SAFETY INSTRUCTIONS
ADT 25 SECTION 1.2 SAFETY INSTRUCTIONSą1
CONTENTS
Page Page
USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąSAFETY INSTRUCTIONS SECTION 1.2 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.2 SAFETY INSTRUCTIONSą3
INTRODUCTION
The instructions and warnings given in this handbook
illustrate the fundamental safety principles for
operating articulated dump trucks.
Figure 1
156NS01
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąSAFETY INSTRUCTIONS SECTION 1.2 ADT 25
General instructions
Arrange a first aid kit in the vehicle. Check and Figure 3
replenish regularly (Figure 2).
Figure 2
156NS03
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.2 SAFETY INSTRUCTIONSą5
PREVENTING FIRES
Keep a suitably sized fire extinguisher in the vehicle. Stop the engine before refuelling. Do not refuel in
Check it regularly (Figure 4). closed places.
Check for leakage or residues of fuel, lubricants and
Figure 4 fluids which could cause minor fires before starting the
engine.
Short circuits can cause fires (Figure 7).
Figure 7
174NS09
The portable fire extinguisher can only be used by
skilled personnel.
Vehicle personnel must be familiar with the basic
156NS07
techniques for dealing with fire.
Fuel and most lubricants and fluids are flammable Regularly check conditions of battery terminals, wires
(Figure 5). and electrical devices.
Do not store flammable substances in places which are
Figure 5 not suitable for the purpose. Do not pierce or burn
pressurised container or cylinders. Do not pile up
materials soaked in flammable substances.
Be careful where you leave rags and/or replaced
materials which may contain flammable residues.
156NS05
Figure 6
156NS06
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąSAFETY INSTRUCTIONS SECTION 1.2 ADT 25
Put out all smouldering materials and naked flames Stay away from the vehicle if a small fire occurs in the
before starting any maintenance operation. brake or tyre areas. The tyres could explode.
Do not smoke during maintenance operations Never stand in front of the sidewall. Keep a safety
(Figure 8). distance of at least 15 metres (16,5 yd) from the thread
(Figure 10).
Figure 8
Figure 10
156NS08
Figure 9
156NS10
Stay away from the vehicle for a few hours after putting
out the fire to allow the tyres to cool down. Approach
the vehicle protected by a crawler loader bucket, for
example.
156NS09
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.2 SAFETY INSTRUCTIONSą7
OVERTURNING ACCIDENTS 1
Prevention
Always check the limits for height and width during all
stages of loading/unloading, and make sure they are
within the prescribed limits (1).
Keep the wheels perpendicular to the slope when
driving up or down a gradient.
Do not make a U-turn on a gradient to prevent turning
over.
Respect the transverse gradient permitted for the
loaded and unloaded vehicle. 156NS19
Respect the values for maximum slope when unloaded
and loaded (2).
Check that the hammer for breaking the specially 2
treated glass is always kept in the cab.
174NS07
174NS08
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąSAFETY INSTRUCTIONS SECTION 1.2 ADT 25
Figure 12
156NS12
156NS13
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.2 SAFETY INSTRUCTIONSą9
Figure 14
156NS15
Figure 16
156NS14
Start the engine while you are sitting in the driver's seat.
Do not start the engine by short-circuiting the starter
motor wires.
Two people are required to start the engine with a
battery charger or auxiliary battery: one person will sit
in the driver's seat and the other person will stand near
the battery charger or auxiliary battery.
Do not carry out this operation if the flat battery is 156NS16
frozen. It could explode.
Respect cable connection procedure and polarity to Never leave the vehicle with the engine running.
prevent the risk of the batteries exploding or projecting Do not park with the parking brake applied and the
electrolyte. gear engaged, also if you are sitting in the driver's seat.
Always wear gloves and protective glasses when Before leaving the vehicle parked in a suitable area
approaching the batteries. where it is not a hindrance, make sure that the parking
brake is applied and that the keys have been removed
from the control panel.
Always apply the parking brake in the following cases:
D when the vehicle is parked for a long or short time;
D when loading/unloading the vehicle.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
10ąSAFETY INSTRUCTIONS SECTION 1.2 ADT 25
Figure 19
156NS17A
Figure 20
156NS18
Check the ground surrounding the vehicle before
reversing to make sure there are no people or
obstacles.
Do not transport people in the cab or in other parts of
the vehicle, with exception of the emergency seat.
Respect signs, especially speed limits. Never exceed
the speed limit.
Never drive at speeds which are forbidden and
dangerous for yourself or others.
Switch the lights on at night and when visibility is poor
(dust, fog, rain). Slow down. 156NS20
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.2 SAFETY INSTRUCTIONSą11
Ideally, a person should be asked to signal when No-one should ever stand in the loading and
reversing. This person will be able to observe the unloading area of the vehicle (Figure 22).
approach from a more favourable position with respect
to the driver. Figure 22
Do not move the vehicle to loading position while the
bucket of loader or excavator is moving overhead.
Stay inside the cab while loading the vehicle.
Make sure that the maximum capacity of the vehicle is
not exceeded during loading operations (Figure 21).
Figure 21
156NS22
156NS23
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
12ąSAFETY INSTRUCTIONS SECTION 1.2 ADT 25
156NS24
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.2 SAFETY INSTRUCTIONSą13
MAINTENANCE INSTRUCTIONS
Introduction
Personnel in charge of repairs must be aware of all the Always lock the tipped body (Figure 26) when
procedures described in this handbook. The operating in such conditions.
procedures advise against adopting work methods
which could cause injuries and/or affect integrity of the Figure 26
vehicle.
The procedures are not comprehensive. The
Manufacturer cannot account for and evaluate all the
possible methods of operation or the possible
consequences.
Keep the place of work clean and dry. Do not smoke
during the operations. Wear all the required personal
protection devices before starting maintenance
operations.
Carry out the scheduled maintenance operations.
Carry out all the operations which are required for
correct and safe use of the vehicle.
Always apply notice boards warning that operations
are being carried out on the vehicle.
Do not allow unqualified personnel to carry out
maintenance or repair operations on the vehicle.
Carry out maintenance and repair operations with the
utmost care.
Only use the specific tools or wrenches expressly
specified for replacement, checking and maintenance
operations. 174NS02
Never tamper with valves, regulators or other devices, Proceed as follows:
unless specified in the handbook, to prevent damage a. fully tip the body and remove the pin;
to vehicle components and consequent hazards for b. turn the tie-rod forwards;
persons. c. insert the pin in the slot on the rear chassis.
Always lock joint (Figure 25); in safety position unless
otherwise specified.
Figure 25
156NS25
Proceed as follows:
a. align the vehicle and remove the pin
b. turn the tie-rod forwards;
c. insert the pin in the slot on the front chassis.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
14ąSAFETY INSTRUCTIONS SECTION 1.2 ADT 25
Make absolutely sure that the electrical power is Use the specific steps and handles for getting on and
disconnected before working directly or indirectly on off the side platform (Figure 29).
electrical system parts by operating the battery
disconnect switch (Figure 27). Figure 29
Figure 27
174NS03A
174NS05
Proceed as follows: Keep the steps and handles clean to avoid slipping.
a. to connect power: turn switch to vertical position; Do not use flexible parts or controls as handles. They
b. to disconnect power: turn switch to horizontal could break or get damaged.
position. Face the vehicle while you are getting on and off. Have
three points of contact (steps and handles) at any time.
Preventing injuries Do not jump on or off the vehicle.
Use the specific steps and handles for getting on and Do not get on or off while the vehicle is moving.
off the front platforms (Figure 28).
Figure 28
174NS04
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.2 SAFETY INSTRUCTIONSą15
Figure 30
156NS31
Figure 31
156NS32
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
16ąSAFETY INSTRUCTIONS SECTION 1.2 ADT 25
156NS35
156NS33
Ensure adequate ventilation to prevent the
Avoid prolonged, repeated contacts of fuel, lubricant accumulation of toxic vapours while cleaning and
and fluids with skin to prevent skin problems and other replacing filters.
syndromes (Figure 35). Do not weld in closed areas or areas which are not
suitably ventilated.
Figure 35 Do not weld on or near painted surfaces to prevent
developing toxic vapours.
Remove the paint with suitable products, wash the
surfaces and leave to dry.
Do not breathe dust and toxic residues while grinding
and sand-blasting. Protect your eyes with masks and
goggles.
Use a suitable vacuum cleaner to remove dusty
residues from the vehicle or place of work.
Do not play with compressed air. Keep compressed air
guns away from people.
Wear protective goggles with side guards and a mask
when using compressed air to clean filters, to prevent
injury caused by particles of dust. You are advised to
carry out the cleaning operations in a ventilated area.
Be very careful before removing caps or covers from
reservoirs, radiators or cylinders: turn the part slowly to
discharge any residual pressure.
Stand at a side during bleeding operations and always
wear protective goggles. Loosen the bleeder slowly by
a few turns to let out condense and fluid.
156NS34
Discharge pressure from the circuits before carrying
Do not swallow fuel, lubricant or fluids. In the event of out operations.
accidental contact with eyes, wash the concerned part Never use your hands to feel for leakage of pressurised
thoroughly with water. fluid.
Pressurised fluid leakage can penetrate under the skin
and in the eyes, causes very severe injuries.
Never use naked flames to feel for leakage of air
conditioning system. It could generate phosgene, a
very dangerous gas.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 1.2 SAFETY INSTRUCTIONSą17
Figure 39
156NS15
Figure 38
156NS37
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
18ąSAFETY INSTRUCTIONS SECTION 1.2 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 2
GENERAL SPECIFICATIONS
ADT 25 SECTION 2 GENERAL SPECIFICATIONSą1
CONTENTS
Page Page
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąGENERAL SPECIFICATIONS SECTION 2 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 2 GENERAL SPECIFICATIONSą3
VEHICLE COMPOSITION
GROUPS DESCRIPTION
ENGINE
GEARBOX
ÊÊ
ZF 6 WG 210
FRONT AXLE
ZF AP9
INTERMEDIATE AXLE
ZF AP9
REAR AXLE
ZF AP9
LAYOUT
TRANSMISSION
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąGENERAL SPECIFICATIONS SECTION 2 ADT 25
174DT01A
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 2 GENERAL SPECIFICATIONSą5
HORIZONTAL CENTRE OF GRAVITY (during transport with unladen vehicle) [mm (ft)]
2665 (8.74)
174DT02
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąGENERAL SPECIFICATIONS SECTION 2 ADT 25
174DT15
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 2 GENERAL SPECIFICATIONSą7
PERFORMANCE
Gear Gearbox ratio Total ratio Speed km/h (mph) Max. gradient
(*) (%)
(*) speed that can be reached with engine running at 2200 rpm and tyre rolling circle of 4.825 mm (189.96 in).
Minimum speed at maximum torque in 1st gear: 3.3 km/h (2.0 mph)
Max. speed (theoretical): 47.6 km/h (29.6 mph)
Maximum gradient in 1st gear (theoretical): 35%
Maximum gradient in 1st gear (with converter on-theoretical) 50%
Weight/power ratio: 155.769 kg/CV (347.9 lb/HP)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąGENERAL SPECIFICATIONS SECTION 2 ADT 25
Rolling resistance
Ground conditions kg for each ton of gross weight %
asphalt - concrete 15 1.5
hard packed soil 20 2.0
soft soil 30 3.0
mud on packet soil 40 4.0
packed snow 25 2.5
soft snow 45 4.5
sand - gravel 100 10.0
SPEED (Km/h)
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75
600
G 130
500 R 60 110
400 A 50 100
D 40 90
R 80
I 300 E
30 70
M
P (%) 60
U 50
200
L 20
L 40 R
I
(kN) 30 M
P
100 U
90 1st 10
L
9 20
80 8 L
70 100 2nd 7
60 80 (lbf x
6 1000)
50 60 3rd 5
10
40 4 9
40
4th 8
30 3 7
6
5th
20 5
20 2
4
6th
C B
D 7th
3
10 10 1
9 9 2
8 8 8th
7 7
6 6
5 5
1
4 4 0.9
0.8
3 3 0.7
0.6
G 0.5
2 2 R
A 0.4
D
E 0.3
1 1 (%)
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 SPEED
(Km/h)
G.V.W.
(Kg x 1000) 10
0 5 10
20
15
E 20 30
25
40
30
50
35
60 70
40
80 90
45
100
SPEED
(mile/h)
G.V.W. 22 30 40 50 60 70 80 90 100 110 120 140 160 180 200 220
(lb x 1000)
A
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 2 GENERAL SPECIFICATIONSą9
Figure 1
The chassis number is punched on the right-hand side of the vehicle (Arrow).
Chassis number
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
10ąGENERAL SPECIFICATIONS SECTION 2 ADT 25
Cab
Figure 2
Gear shift
Figure 5
Chassis
Figure 3
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 2 GENERAL SPECIFICATIONSą11
Figure 6 Figure 8
FRONT
INTERMEDIATE
Tipper cylinder
Figure 7
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
12ąGENERAL SPECIFICATIONS SECTION 2 ADT 25
Engine
Main characteristics:
Injection system:
Adjustments:
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 2 GENERAL SPECIFICATIONSą13
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
14ąGENERAL SPECIFICATIONS SECTION 2 ADT 25
Tipping system
System with gear pump controlled from gearbox (see
Hydraulic system).
Two multi-stage, double acting hydraulic cylinders
mounted on ball joints inside the chassis to allow body
tipping and return.
Tipping angle: 68°
Body
Flat bottom steel structure with box type stiffening, with
supporting flexible pads. Walls and bottom in high
abrasion resistance steel.
Capacity:
- straight (SAE 1:1): 10.6 m3 (13.9 yd3)
- heaped to brim (SAE 2:1): 13.3 m3 (17.4 yd3)
Electrical system
Voltage: 24 V
Alternator: 28 V 70 A
Starter motor: 4.8 kW
Batteries (n. 2): 12 V 140 Ah
(connected in series)
Chassis
The chassis consists of two independent structures
jointed together in the middle.
The front and rear parts of the chassis are connected
with a central bearing and a heavy duty pin joint and
taper roller bearings that allow the parts to rotate and
oscillate.
It is built of boxed parts made of highly-resistant steel
(Hardox 400), and plates that weld them together.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 2 GENERAL SPECIFICATIONSą15
CAPACITIES
Capacity Required
Parts to be supplied
l (US Gal) kg (Ib) specifications
Engine
ACEA E3
SAE 15W40 oil 22 (5.8) 19.2 (42.7) MIL L 2104E lev.
API GF 4
Engine cooling
Protective anti-freeze
anti freeze Engine only
9 8 (2
9.8 (2.6)
6) 9 8 (21
9.8 (21.6)
6) ASTM D336
mixture/water Complete circuit
Bonnet lifting circuit
Hydraulic fluid 2 (0.5) 1.7 (3.8) ATF DEXRON II
Fuel tank
Diesel 325 (85.8) 260 (573.2) ASTM D-975
Gear shift
ACEA E3
SAE 15W40 oil 26 (6.8) 22.8 (50.7) MIL L 2104E lev.
API GF 4
Axles + final reduction
Front
20 (5.3) 17.5 (38.9)
Intermediate MIL L 2105D
SAE 85W140 oil 21.5 (5.7) 18.8 (41.8)
API GL 5
Rear
20 (5.3) 17.5 (38.9)
Suspension
Hydraulic fluid 1.6 (0.4) 1.4 (3) ATF DEXRON II
Hydraulic circuit
ISO VG 46
Hydraulic fluid 250 (65
(65.8)
8) 218 8 (486
218.8 (486.2)
2)
DIN 51524/51525
Climate control system
Refrigerant fluid R134a
Greasing
Lubricating grease (lithium base) - - N.L.G.I. 2
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
16ąGENERAL SPECIFICATIONS SECTION 2 ADT 25
5 1
7 6 3
4
8 9
18
13 14 17
12 15
19 1
7
11
5
10
16 17
9 6 8
EUROPEAN VERSION
Pos. 1 Towing eye plate Pos. 2 Battery throw off plate
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 2 GENERAL SPECIFICATIONSą17
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
18ąGENERAL SPECIFICATIONS SECTION 2 ADT 25
Pos. 12 CE plate
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 2 GENERAL SPECIFICATIONSą19
Warning plate
INSIDE ENGINE HOOD PLATE
Warning plate
Emergency exit
Warning plate
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
20ąGENERAL SPECIFICATIONS SECTION 2 ADT 25
Lubrication plate
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 2 GENERAL SPECIFICATIONSą21
U.S.A. VERSION
Pos. 1 Towing eye plate Pos. 5 Keep clear of prop shaft plate
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
22ąGENERAL SPECIFICATIONS SECTION 2 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 2 GENERAL SPECIFICATIONSą23
Warning plate
Warning plate
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
24ąGENERAL SPECIFICATIONS SECTION 2 ADT 25
Warning plate
Emergency exit
Warning plate
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 2 GENERAL SPECIFICATIONSą25
Lubrication plate
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
26ąGENERAL SPECIFICATIONS SECTION 2 ADT 25
Conversion:
Power in kW (kilowatt) 1 kg/cm2 = 1 Atm
Other units in use: 1 kg/cm2 = 98.1 kPa
CV (Metric Horsepower) 1 kg/cm2 = 0.981 bar
HP (Horsepower) 1 kg/cm2 = 1 bar *
1 kg/cm2 = 14.22 psi
Conversion: 1 bar = 100 kPa
1 kW = 1.36 CV 1 bar = 1.02 kg/cm2
1 kW = 1.34 HP 1 bar = 14.51 psi
1 CV = 0.736 kW 1 psi = 6.9 kPa
1 CV = 0.986 HP 1 psi = 0.069 bar
1 HP = 0.746 kW 1 psi = 0.0703 kg/cm2
1 HP = 1.014 CV 1 kPa = 0.145 psi
1 kPa = 0.0102 kg/cm2
1 kPa = 0.01 bar
Torque in Nm (Newton meter)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 2 GENERAL SPECIFICATIONSą27
3 x 0.5 0.12 0.12 0.11 0.09 0.17 0.16 0.15 0.13 0.21 0.19 0.18 0.15
4 x 0.7 0.28 0.26 0.24 0.20 0.39 0.37 0.34 0.29 0.47 0.44 0.41 0.35
5 x 0.8 0.56 0.52 0.48 0.40 0.79 0.74 0.67 0.57 0.94 0.88 0.80 0.68
6x1 1.0 0.9 0.8 0.7 1.3 1.3 1.2 1.0 1.6 1.5 1.4 1.2
8 x 1.25 2.3 2.2 2.0 1.7 3.3 3.1 2.8 2.3 3.9 3.7 3.3 2.8
8x1 2.5 2.4 2.1 1.8 3.5 3.3 3.0 2.5 4.3 4.0 3.6 3.0
10 x 1.5 4.7 4.4 4.0 3.3 6.5 6.1 5.6 4.7 7.9 7.4 6.7 5.6
10 x 1.25 5.0 4.7 4.2 3.5 7.0 6.5 5.9 4.9 8.4 7.9 7.1 5.9
12 x 1.75 8.0 7.5 6.8 5.7 11.3 10.6 9.6 8.0 13.6 12.7 11.5 9.6
12 x 1.25 9.0 8.4 7.5 6.2 12.6 11.8 10.6 8.7 15.1 14.1 12.7 10.4
14 x 2 12.8 12.0 10.9 9.1 18.0 16.9 15.3 12.8 21.6 20.2 18.4 15.3
14 x 1.5 14.1 13.1 11.9 9.7 19.8 18.5 16.7 13.6 23.8 22.2 20.0 16.4
16 x 2 19.8 18.5 16.8 13.9 27.9 26.1 23.6 19.5 33.5 31.3 28.3 23.4
16 x 1.5 21.5 20.0 18.0 14.6 30.2 28.2 25.3 20.6 36.3 33.8 30.4 24.7
18 x 2.5 27.2 25.4 23.1 19.2 38.2 35.8 32.4 27.0 45.8 42.9 38.9 32.4
18 x 1.5 31.4 29.2 26.2 21.1 44.1 41.1 36.8 29.7 53.0 49.3 44.2 35.7
20 x 2.5 38.4 36.1 32.7 27.0 54.3 50.8 46.0 38.0 65.2 61.0 55.2 45.6
20 x 1.5 43.9 40.9 36.5 29.4 61.7 57.5 51.4 41.3 74.1 68.9 61.6 49.5
22 x 2.5 53.9 49.0 44.6 36.2 75.9 68.8 62.8 51.0 91.0 82.6 75.3 61.1
22 x 1.5 59.0 54.8 48.9 39.1 82.9 77.1 68.8 55.0 99.5 92.5 82.6 66.1
24 x 3 66.7 62.4 56.4 46.6 93.8 87.7 79.3 65.5 112.5 105.2 95.2 78.6
24 x 2 74.2 69.1 61.9 50.0 104.4 97.2 87.1 70.3 125.3 116.7 104.5 84.4
27 x 3 98.7 92.2 83.1 68.2 138.8 129.6 116.9 95.9 166.5 155.5 140.2 115.0
27 x 2 108.4 100.8 90.1 72.4 152.4 141.8 126.7 101.8 182.9 170.2 152.1 122.2
30 x 3.5 133.7 124.9 112.7 92.8 188.0 175.6 158.5 130.5 225.6 210.7 190.2 156.5
30 x 2 151.6 141.0 125.8 100.6 213.2 198.2 176.9 141.5 255.9 237.9 212.2 169.8
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
28ąGENERAL SPECIFICATIONS SECTION 2 ADT 25
3 x 0.5 0.88 0.88 0.81 0.66 1.25 1.18 1.10 0.96 1.55 1.40 1.33 1.11
4 x 0.7 2.06 1.92 1.77 1.47 2.88 2.73 2.51 2.14 3.47 3.24 3.02 2.58
5 x 0.8 4.13 3.83 3.54 2.95 5.83 5.46 4.94 4.20 6.93 6.49 5.90 5.01
6x1 7.37 6.64 5.90 5.16 9.59 9.59 8.85 7.37 11.80 11.06 10.32 8.85
8 x 1.25 16.96 16.22 14.75 12.54 24.34 22.86 20.65 16.96 28.76 27.29 24.34 20.65
8x1 18.44 17.70 15.49 13.27 25.81 24.34 22.12 18.44 31.71 29.50 26.55 22.12
10 x 1.5 34.66 32.45 29.50 24.34 47.94 44.99 41.30 34.66 58.26 54.57 49.41 41.30
10 x 1.25 36.87 34.66 30.97 25.81 51.62 47.94 43.51 36.14 61.95 58.26 52.36 43.51
12 x 1.75 59.00 55.31 50.15 42.04 83.34 78.17 70.80 59.00 100.30 93.66 84.81 70.80
12 x 1.25 66.37 61.95 55.31 45.72 92.92 87.02 78.17 64.16 111.36 103.99 93.66 76.70
14 x 2 94.4 88.50 80.39 67.11 132.75 124.64 112.84 94.40 159.30 148.97 135.70 112.84
14 x 1.5 103.99 96.61 87.76 71.54 146.02 136.44 123.16 100.30 175.52 163.72 147.50 120.95
16 x 2 146.02 136.44 123.90 102.51 205.76 192.49 174.05 143.81 247.06 230.84 208.71 172.57
16 x 1.5 158.56 147.50 132.75 107.67 222.72 207.97 186.59 151.92 267.71 249.27 224.20 182.16
18 x 2.5 200.60 187.32 170.36 141.60 281.72 264.02 238.95 199.12 337.77 316.39 286.89 238.95
18 x 1.5 231.57 215.35 193.22 155.61 325.24 303.11 271.40 219.03 390.87 363.59 325.97 263.29
20 x 2.5 283.20 266.24 241.16 199.12 400.46 374.65 339.25 280.25 480.85 449.87 407.10 336.30
20 x 1.5 323.76 301.64 269.19 216.82 455.03 424.06 379.07 304.59 546.49 508.14 454.30 365.06
22 x 2.5 397.51 361.37 328.92 266.97 559.76 507.40 463.15 376.12 671.12 609.17 555.34 450.61
22 x 1.5 435.12 404.15 360.64 288.36 611.39 568.61 507.40 405.62 733.81 682.19 609.17 487.48
24 x 3 491.91 460.20 415.95 343.67 691.77 646.79 584.84 483.06 829.69 775.85 702.10 579.67
24 x 2 547.22 509.61 456.51 368.75 769.95 716.85 642.36 518.46 924.09 860.66 770.69 622.45
27 x 3 727.91 679.97 612.86 502.97 1023.65 955.80 862.14 707.26 1227.94 1146.81 1033.97 848.12
27 x 2 799.45 743.40 664.48 533.95 1123.95 1045.77 934.41 750.77 1348.89 1255.22 1121.74 901.22
30 x 3.5 986.04 921.14 831.16 684.40 1386.50 1295.05 1168.94 962.47 1663.80 1553.91 1402.72 1154.18
30 x 2 1118.05 1039.87 927.77 741.92 1572.35 1461.72 1304.64 1043.56 1887.26 1754.51 1564.97 1252.27
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 3
ENGINE
ADT 25 SECTION 3 ENGINEą1
CONTENTS
Page Page
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąENGINE SECTION 3 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą3
Figure 1
1730301C
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąENGINE SECTION 3 ADT 25
Figure 2
1730302B
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą5
Figure 3
17303160
1. Air intake
2. Air cleaner
3. Sleeve between cleaner and fuel tank
4. Piping inside fuel tank
5. Sleeve between fuel tank and turbo charger
6. Intake manifold
7. Turbo charger to exhaust gas
8. Intake valve
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąENGINE SECTION 3 ADT 25
Figure 4
17303161
1. Exhaust valve
2. Exhaust manifold
3. Turbo charger to exhaust gas
4. Piping between turbo charger and muffler
5. Muffler
6. Piping between muffler and exhaust pipe
7. Exhaust pipe
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą7
Figure 5
17303162
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąENGINE SECTION 3 ADT 25
Figure 6
17303163
1. Engine
2. Thermostat
3. Pump
4. Radiator
5. Operator compartment heater
6. Gearbox oil exchanger
7. Expansion tank
A: thermostat closed: the cold coolant is completely returned into the engine without passing through the radiator.
B: thermostat in intermediate position: part of the coolant is sent to the radiator and the other part is taken in by
the pump and then sent into the engine.
C: thermostat open: the hot coolant is sent to the radiator, the cold coolant is taken in by the pump and sent into
the engine.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą9
Figure 7
17303164
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
10ąENGINE SECTION 3 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą11
DIAGNOSTIC
1. The engine does not start
2. The engine either does not crank or cranks slowly
3. The engine starts and then stops
4. The engine either stops suddenly or when decelerating
5. The engine does not reach nominal ratio
6. The engine does not stop
7. Excessive engine vibrations
8. Excessive engine noise
9. Excessive engine noise - Knock
10. Poor engine power
11. Irregular engine operation when idling and misfiring
12. The alternator either does not charge or charges insufficiently
13. Coolant leakage - External
14. Excessive coolant temperature - Gradual overheating
15. Excessive coolant temperature - Sudden overheating
16. Coolant temperature too cold
17. Excessive gas in crankcase (blow-by)
18. Poor acceleration or slow engine response
19. The engine decelerates slowly
20. Excessive fuel consumption
21. Fuel in coolant
22. Fuel in lubricant oil
23. Excessive air temperature in intake manifold
24. Pressure in intake manifold (turbo) too low
25. Excessive lubricant oil consumption
26. Contaminated lubricant oil
27. Excessive lubricant oil pressure
28. Low lubricant oil pressure
29. Too much sludge in lubricant oil in crankcase
30. Excessive lubricant oil temperature
31. Lubricant oil in coolant
32. Excessive black smoke in exhaust
33. Excessive white smoke in exhaust
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
12ąENGINE SECTION 3 ADT 25
The engine does not start Battery connections deteriorated Clean, check and fasten terminal
and/or disconnected nuts and/or replace them, if they are
damaged
The starter motor turns but the enĆ Check integrity of electrical system
gine does not start (according to wiring diagram)
Water in the fuel feed circuit Check and bleed water in the sysĆ
tem
Air in the fuel feed circuit Check and bleed air in the system
The engine either does not crank Battery wires and/or connections Check efficiency of battery wires
or cranks slowly loose, broken or corroded and connections
(excessive resistance)
Lubricant oil temperature too low Fit an oil sump heater and fill the sysĆ
tem with hot oil
The engine starts and then stops Low fuel level in tank Fill the fuel tank. See the service
manual
Air in fuel feed circuit Check for air in the feeding circuit.
Fasten or replace connections,
pipes, primer pipe and fuel filters, as
required
Fuel filter or fuel intake manifold obĆ Replace the fuel filter. Check fuel inĆ
structed take manifold for obstructions
Fuel starts congealing due to the Check the fuel heater, where fitted.
cold temperature A fuel heater may be required in
certain climates
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą13
The engine starts and then stops Poor quality fuel or fuel unsuitable Feed engine from a high quality fuel
(Cont.d) for the application tank
The air intake system is excessively Clean or replace air cleaner and inĆ
restricted take pipe, as required
The engine either stops suddenly Fuel intake obstructed Eliminate obstructions from fuel inĆ
or when decelerating take manifold
Air in fuel feed circuit Check for air in the feeding circuit.
Fasten or replace connections,
pipes, primer pipe and fuel filters, as
required
Fuel switch off valve (FSOV) closed Check for disconnected wires.
Check whether fuel switch off valve
solenoid is powered
Poor quality fuel or fuel unsuitable Feed engine from a high quality fuel
for the application tank
The engine does not reach Excessive load with reference to Reduce vehicle load or shift to a
nominal ratio nominal engine power lower gear
Poor quality fuel or fuel unsuitable Feed engine from a high quality fuel
for the application tank
Incorrect head unit adjustment Gauge and adjust valves and injecĆ
tors
The engine does not stop Ignition key circuit failure Check ignition key circuit
Fumes are taken into the engine Check air intake manifolds. Locate
through the air vents and isolate source of fumes. Repair,
as required
Excessive engine vibrations Low fuel level in tank Fill the fuel tank
Air in fuel feed circuit Check for air in the feeding circuit.
Fasten or replace connections,
pipes, primer pipe and fuel filters, as
required
Fuel filter or fuel intake manifold obĆ Replace the fuel filter. Check fuel inĆ
structed take manifold for obstructions
Fuel starts congealing due to the Check the fuel heater, where fitted.
cold temperature A fuel heater may be required in
certain climates
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
14ąENGINE SECTION 3 ADT 25
Excessive engine vibrations Fuel switch off valve closed Check for disconnected wires.
(Cont.d) Check whether fuel switch off valve
solenoid is powered
Excessive engine noise Lubricant oil pressure too low Check oil pressure. If low, see Low
lubricant oil pressure"
Excessive engine noise - Knock Engine is running in a cold environĆ Check shutter, choke and air vent
ment under the bonnet
Poor quality fuel or fuel unsuitable Feed engine from a high quality fuel
for the application tank
Poor engine power The altitude is high Engine power decreases at higher
altitudes
The air intake system is excessively Clean or replace air cleaner and inĆ
restricted take pipe, as required
Fuel filter or fuel intake manifold obĆ Replace the fuel filter. Check fuel inĆ
structed take manifold for obstructions
Lubricant oil level over specified Check oil level. Check dipstick caĆ
level libration and sump capacity. Fill
system to the specified level
Air in fuel feed circuit Check for air in the feeding circuit.
Fasten or replace connections,
pipes, primer pipe and fuel filters, as
required
Poor quality fuel or fuel unsuitable Feed engine from a high quality fuel
for the application tank
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą15
Poor engine power (Cont.d) Excessive fuel temperature at pump Fill fuel tank, either switch or cut off
intake fuel heaters and check fuel cooling
device
Irregular engine operation when Engine mounts worn, damaged or Check engine mounts
idling and misfiring of the incorrect type
Air in fuel feed circuit Check for air in the feeding circuit.
Fasten or replace connections,
pipes, primer pipe and filters
Poor quality fuel or fuel unsuitable Feed engine from a high quality fuel
for the application tank. Use fuel, as required
Incorrect head unit adjustment Gauge and adjust valves and injecĆ
tors
The alternator either does not Alternator belt loose Check alternator belt tension
charge or charges insufficiently
ins fficiently
Battery wires or connections loose, Check battery wires and connecĆ
broken or corroded (excessive reĆ tions
sistance)
Coolant leakage - External Coolant level exceeding specificaĆ Check coolant level
tions
Filling pipe or breather pipe either Check breather pipe and filling pipe
partially or completely obstructed, for correct arrangement and obĆ
or arranged incorrectly structions
Coolant filling pipe either partially or Check whether the coolant filling
completely obstructed pipe is either partially or completely
obstructed
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
16ąENGINE SECTION 3 ADT 25
Excessive coolant temperature - Coolant level lower than specified Check engine and cooling system
Gradual overheating for external leakage of coolant. ReĆ
pair, if required. Top up coolant
Lubricant oil level over or under Check oil level. Remove or add oil,
specified level. if required
Coolant level over than specified or Check level. Check antifreeze conĆ
excessive antifreeze concentration centration
Excessive coolant temperature - Coolant level lower than specified Check engine and cooling system
Sudden overheating for external leakage of coolant. ReĆ
pair, if required. Top up coolant
Filling pipe or breather pipe either Check breather pipe and filling pipe
partially or completely obstructed, for correct arrangement and obĆ
or arranged incorrectly structions
Coolant temperature too cold Coolant temperature gauge or senĆ Check operation of gauge and senĆ
sor faulty sor. Repair or replace, if required
Excessive gas in crankcase Crankcase ventilation system obĆ Check and clean breather and
(blow-by) structed crankcase ventilation tube
Poor acceleration or slow engine Engine is running in a cold environĆ Warm the engine up before deĆ
response ment manding power
Excessive fuel temperature Fill the fuel tank. Either switch or cut
off the fuel heater, where fitted
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą17
Poor acceleration or slow engine Poor quality fuel or fuel unsuitable Feed engine from a high quality fuel
response (Cont.d) for the application tank
Engine is running in a warm environĆ Feed external air to the turbo comĆ
ment pressor at high temperatures
The engine decelerates slowly Accelerator pedal jammed Release the accelerator pedal
Lubricant oil level over specified Check oil level. Check dipstick caĆ
level libration and sump capacity. Fill sysĆ
tem to the specified level
The air intake system is excessively Check air intake manifold for obĆ
restricted. structions. Clean or replace air
cleaner and intake pipe, as reĆ
quired.
Fuel in coolant Coolant feed contaminated Check coolant feed. Drain coolant
and change it using non contamiĆ
nated fluid. Replace the coolant
filters
Fuel heater faulty (where fitted) Check fuel heater and replace it, if
required
Fuel in lubricant oil Oil feed contaminated Check oil feed. Drain oil and change
it using non contaminated oil. ReĆ
place the oil filters
Excessive air temperature in inĆ The vehicle speed is too low to allow Reduce engine load. Increase enĆ
take manifold adequate cooling with respect to the gine ratio (fan) by shifting down
engine load
Either fan box damaged or missing Inspect box and recirculation flaps.
or air recirculation flaps damaged or Repair, replace or install, if required
missing
Accessory belt broken or loose Check the belt. Replace the belt, if
required
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
18ąENGINE SECTION 3 ADT 25
Excessive air temperature in Intercooler air cooling radiator fins, Check intercooler, air conditioner
intake manifold (Cont.d) radiator fins or air conditioner conĆ condenser and radiator fins.
denser fins damaged or obstructed. Clean, if required
Pressure in intake manifold Turbo compressor faulty Replace the turbo compressor
(turbo) too low
Intake or exhaust leakage Check for loose or damaged pipes
or missing caps. Check turbo comĆ
pressor and exhaust manifold
fastening
Excessive lubricant oil consump- Check actual oil consumption Check amount of oil added with reĆ
tion spect to distance driven
Lubricant oil leakage (external) Check for leakage of oil from the enĆ
gine. Fasten the bolts, pipe caps
and fittings. Replace the seals, if reĆ
quired
Lubricant characteristics are not Change oil and filters. Use oil of the
suitable for conditions of operation specified type
of the engine
Contaminated lubricant oil Identify source of oil contamination Analyse the oil to determine the conĆ
taminating substances
Oil feed contaminated Check oil feed. Drain oil and change
it using non contaminated oil. ReĆ
place the oil filters
Too much sludge in lubricant oil See Too much sludge in lubricant
oil in crankcase"
Excessive lubricant oil pressure Pressure switch, lubricating oil Check operation and position of
gauge or sensor failure or incorrectĆ pressure switch, gauge and sensor
ly positioned
Lubricant characteristics are not Change oil and filters. Use oil of the
suitable for conditions of operation specified type
of the engine
Low lubricant oil pressure Lubricant oil level over or under Check oil level. Remove or add oil,
specified level. if required
Lubricant oil leakage (external) Check for leakage of oil from the enĆ
gine. Fasten the bolts, pipe caps
and fittings. Replace the seals, if reĆ
quired
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą19
Low lubricant oil pressure Lubricant characteristics are not Change oil and filters. Use oil of the
(Cont.d) suitable for conditions of operation specified type
of the engine
Too much sludge in lubricant oil in Oil feed contaminated Check oil feed. Drain oil and change
crankcase it using non contaminated oil. ReĆ
place the oil filters
Lubricant characteristics are not Change oil and filters. Use oil of the
suitable for conditions of operation specified type
of the engine
Poor quality fuel or fuel unsuitable Feed engine from a high quality fuel
for the application tank
Excessive lubricant oil temperaĆ Lubricant oil level over or under Check oil level. Remove or add oil,
ture specified level if required
Lubricant oil in coolant Coolant contaminated Drain coolant and change it using
non contaminated fluid. Replace the
coolant filters
Excessive black smoke in Turbo compressor impeller out of Check bearing radial play and end
exhaust specifications play. Inspect the turbo compressor.
Replace the turbo compressor, if reĆ
quired
Poor quality fuel or fuel unsuitable Feed engine from a high quality fuel
for the application tank
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
20ąENGINE SECTION 3 ADT 25
Poor quality fuel or fuel unsuitable Feed engine from a high quality fuel
for the application tank
Incorrect head unit adjustment Gauge and adjust valves and injecĆ
tors
TIGHTENING TORQUE
Fastening screws front engine supports Ą65 Nm (48 lb ft)
Fastening screws rear engine supports Ą80 Nm (60 lb ft)
Rocker arm adjustment valves lock nut Ą24 Nm (18 lb ft)
Engine idle adjustment screw lock nut ĄĄ8 Nm ( 5.9 lb ft)
Turbocharger mounting nut Ą45 Nm (33 lb ft)
Injection pump control gear mounting nut 105 Nm (77 lb ft)
Fuel high pressure line unions Ą24 Nm (18 lb ft)
Fuel exhaust manifold on injectors union ĄĄ9 Nm ( 6.6 lb ft)
Turbo charger oil delivery union on exchanger Ą15 Nm (11 lb ft)
Turbocharger oil delivery union on turbine Ą35 Nm (26 lb ft)
Injection pump timing pin cap Ą15 Nm (11 lb ft)
Engine oil pressure regulator cap Ą80 Nm (60 lb ft)
Engine oil thermostat Ą50 Nm (37 lb ft)
Tappets cover screw Ą24 Nm (18 lb ft)
Aftercooler mounting screw Ą24 Nm (18 lb ft
Intake manifold cover mounting screw Ą24 Nm (18 lb ft)
Injector brackets mounting screw Ą24 Nm (18 lb ft)
Belt tightener mounting screw Ą43 Nm (32 lb ft)
Alternator lower mounting screw Ą43 Nm (32 lb ft)
Injection pump front mounting screws Ą43 Nm (32 lb ft)
Exhaust manifold mounting screws Ą43 Nm (32 lb ft)
Oil-water exchanger cover mounting screws Ą24 Nm (18 lb ft)
Turbocharger to turbine body mounting screws Ą11 Nm ( 8 lb ft)
Starter motor mounting screws Ą43 Nm (32 lb ft)
Water pump mounting screws Ą24 Nm (18 lb ft)
Thermostat mounting screws Ą24 Nm (18 lb ft)
Turbocharger oil discharge line mounting screws Ą24 Nm (18 lb ft)
Alternator lower mounting screws Ą24 Nm (18 lb ft)
Injection pump rear mounting screws Ą24 Nm (18 lb ft)
Alternator upper mounting screws Ą43 Nm (32 lb ft)
Fuel supply pump unions mounting screws/nuts Ą24 Nm (18 lb ft)
SPECIAL TOOLS
Gear for manual engine rotation 3824591
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą21
ENGINE REMOVAL-REFIT
. Before starting any type of operation make Figure 9
sure all the necessary safety precautions
have been taken and fully explained to those
involved in the operations.
Read the relevant instructions in SECTION
1.2 of this manual.
If in doubt, contact someone with more exĆ
perience.
Always observe all the general recommenĆ
dations to carry out maintenance jobs corĆ
rectly.
Removal
To remove proceed as follows: 1730304
D bring the vehicle onto a suitable flat, solid surface,
D disconnect the propeller shaft as described in SECĆ
switch off the engine, remove the ignition key, enĆ
TION 10;
gage the parking brake and apply the warning signĆ
D bring the heater tap to maximum, then open the filler
boards.
cap on the reservoir;
D cut off the battery isolator switch or disconnect the
D prepare a suitable container, then remove the
terminals from the battery to avoid the risk of short
sleeve from the exchanger to the intake pump and
circuits;
drain off the coolant;
D lock knuckle with the steering lock bar following the
instructions in SECTION 1.2; Never dispose of residual coolant in unauĆ
thorised dumps or by pouring it into the
Figure 8 sewers.
Figure 10
174CU01
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
22ąENGINE SECTION 3 ADT 25
D prepare a suitable container, then drain off the hyĆ D appropriately shape and prepare a rear hooking
draulic fluid as described in SECTION 16; bracket (7) and mount it in the holes provided;
D using suitable lifting equipment apply the chains to
Never dispose of residual fluid in unauthoĆ
the assembly brackets (7) and (8) and take up the
rised dumps or by pouring it into the sewers.
slack, checking that the load is evenly balanced;
D remove the bolts that secure the front (5) and rear
Figure 11 (6) engine mountings from both sides;
D check very carefully:
- that all electrical connections have been disconĆ
nected;
- all the piping has been disconnected;
- all the securing straps have been released;
D lift the assembly with care, taking it out from above.
1730306
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą23
Figure 12
1730307C
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
24ąENGINE SECTION 3 ADT 25
Figure 13
1730308B
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
26ąENGINE SECTION 3 ADT 25
RADIATOR REMOVAL-REFIT
. Before starting any type of operation make D remove the engine cowl as described in SECTION
18;
sure all the necessary safety precautions
D bring the heater tap to maximum, then open the filler
have been taken and fully explained to those
cap on the reservoir;
involved in the operations.
D prepare a suitable container, then remove the
Read the relevant instructions in SECTION
sleeve connecting the exchanger to the pump inĆ
1.2 of this manual.
take (4) and drain off the coolant;
If in doubt, contact someone with more exĆ
perience. Never dispose of residual coolant in unauĆ
Always observe all the general recommenĆ thorised dumps or by pouring it into the
dations to carry out maintenance jobs corĆ sewers.
rectly.
D disconnect /remove the following engine coolant piĆ
pes:
Removal - from engine to radiator (2);
- from radiator to exchanger (5);
Wait until the engine temperature drops - bleeder from radiator to reservoir (7);
below 50 °C (122 °F) before starting this
operation. During these operations some coolant may
spill out.
To remove proceed as follows:
D bring the vehicle onto a suitable flat, solid surface,
switch off the engine, remove the ignition key, enĆ
gage the parking brake and apply the warning signĆ
boards.
D cut off the battery isolator switch or disconnect the
terminals from the battery to avoid the risk of short
circuits;
D lock knuckle with the steering lock bar following the
instructions in SECTION 1.2;
Figure 14
7 2
4 5 4
1730309
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą27
Figure 15 Figure 17
1730312
1730310
D unlock the mounting screws and move aside the D unlock the mounting screws and remove the fan
water-hydraulic fluid exchanger, taking care not to guards;
bend the pipes;
Figure 18
Figure 16
1730313
1730311
D use suitable equipment to support the radiator, unĆ
D unlock the upper mounting screws, turn over the lock the tie-rod and pad mounting screws and reĆ
conditioner radiator, release it from the lower pins move the radiator;
and move it aside taking care not to bend the pipes; D handle the radiator with care, without putting presĆ
sure on the radiator core fins as they could easily beĆ
come damaged.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
28ąENGINE SECTION 3 ADT 25
Figure 19 Figure 20
156NM61
174NM01B
ÄÄÄ
water
D prepare a mixture with 50% water and 50% of the
anti-freeze
specific anti-freeze fluid then slowly pour the mixĆ
ture through the filler cap. Do not close the cap;
Check the percentage of anti-freeze in the engine
D start the engine and leave it idling, at the same time
coolant using an appropriate refractometer.
pour in the mixture until the circuit is completely de-
aerated, continuing this operation for at least 15
minutes;
. A densimeter should not be used since it is
not sufficiently accurate.
D close the filler cap.
If special additives are used, always comply
Check that the pressure control valve in the to the mixing instructions of the Supplier.
cooling system incorporated in the cap is
working. If it is not, replace the cap.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą29
Removal
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
30ąENGINE SECTION 3 ADT 25
Figure 22
156NM11
D out the dip stick and check that the level is between
156NM20 the two marks H (maximum) and L (minimum) enĆ
graved on the stick. If necessary top up.
D clean the cap area, unscrew the drainage cap and Do not use the vehicle if the level is not withĆ
drain out all the oil, leaving it sufficient time to empty; in the correct range;
Too much or too little lubricant can damage
Do not unscrew the side cap as this will not
the engine.
allow the sump to empty completely.
D clean the thread, close the discharge cap and
tighten to the specified torque;
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą31
Proceed as follows:
156NM26
D shut off the hot engine and wait until the temperaĆ
ture of the coolant reaches 60 °C (140 °F);
D screw down the cartridge by hand until the gasket
D open the engine cowl;
comes into contact with the support, then tighten
Figure 25 further by 3/4 of a turn;
156NM24
Figure 26
156NM25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
32ąENGINE SECTION 3 ADT 25
Preliminary operations
D bring the vehicle onto a suitable flat, solid surface,
switch off the engine, remove the ignition key, enĆ 1730316
gage the parking brake and apply the warning signĆ
boards; D Remove the air intake sleeve.
D cut off the battery isolator switch or disconnect the
terminals from the battery to avoid the risk of short Figure 30
circuits;
D open the engine cowl (see USE AND MAINTENĆ
ANCE MANUAL).
Valves clearance
Figure 28
1730317
Figure 31
1730315
1730318
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą33
Figure 32 Figure 34
1730319 1730321
1730322
Figure 36
1730320
1730323
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
34ąENGINE SECTION 3 ADT 25
Figure 39
1730324
Try inserting a thickness gauge that is 0.03 D Install the new O-rings on the bolts.
mm (0.001 in) thicker between the valve and D Refit the disassembled components working in reĆ
the rocker pad. If this is possible there is too verse order.
much valve clearance. D Tighten the cover mounting screws to the tightening
torque.
D After all the operations are finished, restore the veĆ
Figure 38
hicle to operating condition.
1730325
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą35
Tension check
Figure 40
174NM08
174NM09
174NM07
D remove the belt;
D If in doubt as to the actual belt tension, use the D fit the new belt, then release the tightener;
special measuring equipment and the relevant tenĆ
sioning table. Never turn a belt on the pulley to fit it into the
groove, nor prise it with a tool (such as a
screwdriver). This could cause damage and
premature breakage;
The belts have not to touch the bottom of the
grooves or rub against adjacent parts.
D start the engine running for ten minutes, shut off,
wait for it to cool down, then check the belt tension.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
36ąENGINE SECTION 3 ADT 25
174NM72
D manually press the longer stretch (1) and check that
the yield is within the specified range.
yield: 9.5P12.5 mm (0.37P0.49 in)
Figure 45
174NM73
D with the engine off and cold, release the pin nut and
the securing nut, then adjust the compressor (2) to
regulate the tension;
D tighten both the nuts to the specified tightening torĆ
que.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą37
These checking operations require the use These checking operations require the use
of the vehicle: be very cautious and observe of the vehicle: be very cautious and observe
general safety conditions. general safety conditions.
Proceed as follows: Proceed as follows:
Figure 46 Figure 47
B
1730328
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
38ąENGINE SECTION 3 ADT 25
Preliminary operations
1730330
D bring the vehicle onto a suitable flat, solid surface,
switch off the engine, remove the ignition key, enĆ D unlock the mounting screws and remove the pump
gage the parking brake and apply the warning signĆ from the crankcase.
boards.
Refit
D cut off the battery isolator switch or disconnect the
terminals from the battery to avoid the risk of short To refit carry out the same operations in reverse order,
circuits; paying particular attention to:
D open the engine cowl (see USE AND MAINTENĆ D clean the sealing surface of the monobloc.
ANCE MANUAL).
Figure 50
Water pump
Wait until the engine temperature drops
below 50 °C (122 °F) before starting this
operation.
Removal
Proceed as follows:
D drain off the engine cooling circuit as described in
the Chapter RADIATOR REMOVAL-REFIT;
Never dispose of residual coolant in unauĆ
thorised dumps or by pouring it into the
sewers. 1730331
D remove the belt as described in the relevant ChapĆ D install a new O-ring in the water pump groove.
ter;
Figure 51
Figure 48
1730332
1730329 D install the water pump and alternator support and
D unlock the mounting screw and move aside the alĆ tighten the mounting screws to the specified torque.
ternator supporting bracket; D assemble the belt as described in the relevant
Chapter.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą39
Coolant thermostat
Figure 54
Wait until the engine temperature drops
below 50 °C (122 °F) before starting this
operation.
Removal
Proceed as follows:
D remove the belt as described in the relevant paraĆ
graph;
D drain off about 2 litres of engine coolant following
the instructions in the Chapter RADIATOR REĆ
MOVAL-REFIT;
Never dispose of residual coolant in unauĆ
thorised dumps or by pouring it into the 1730335
sewers.
D Remove the thermostat body / tightener assembly.
Figure 52 Figure 55
1730333
1730336
D Unlock the alternator upper and lower mounting D Remove the thermostats and clean the gasket surĆ
screws and lower it. faces.
D Remove the flexible sleeve from the radiator output
union. When cleaning the gasket surfaces, take
care that dirt does not fall into the thermostat
Figure 53 cavity.
1730334
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
40ąENGINE SECTION 3 ADT 25
Tightener
Proceed as follows:
D open the engine cowl (see USE AND MAINTENĆ
ANCE MANUAL);
D remove the belt as described in the relevant ChapĆ
ter;
Figure 59
1730337
D Install new thermostats in the thermostat body.
D Fit a new gasket on the thermostats.
Figure 57
1730340
1730338
D Position the thermostat body / tightener on the therĆ
mostats and on the gasket, insert the mounting
screws and tighten them by hand.
Figure 58
1730339
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą41
Figure 62
1730341
Figure 61
. Protect the injector inlets and delivery valves
from the entry of dirt.
Figure 63
1730342
1730345
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
42ąENGINE SECTION 3 ADT 25
Figure 67
1730346
Figure 66
1730349
1730347
D Refit the high pressure fuel ducts and tighten the
unions to the specified torque.
D After all the operations are finished, restore the veĆ
hicle to operating condition.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą43
Figure 69 Refit
Figure 72
1730350
Figure 70
1730353
Figure 71
1730354
D Install and fasten the timing pin with the access cap.
1730352
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
44ąENGINE SECTION 3 ADT 25
Figure 74 Figure 76
1730355 1730357
D Check that the filler hole (A) and flange (B) O-rings D Install the injection pump retaining nut and washer.
are mounted correctly on the injection pump and D For the moment tighten the mounting nut to a torque
that they are not damaged. of 15 Nm (11 ft lb).
Figure 78
1730356
D Insert the pump shaft in the driving gear and place 1730359
the pump flange on the mounting stud bolts.
D Tighten the mounting nuts to the specified torque. D Remove the pump timing pin cap and install the pin,
D Tighten the support bracket screws to the specified the sealing washer and the cap, tightening to the
torque. specified torque.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą45
Proceed as follows:
D Loosen the purging screw near the front panel from
the side nearest the engine.
D Start up the engine and let it run to bleed the air from
the fuel injection pump, then tighten the purging
screw.
D Purge all the high pressure lines.
Figure 80
1730361
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
46ąENGINE SECTION 3 ADT 25
Figure 82
1730364
Figure 84
1730363
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą47
Turbocharger Figure 87
Removal
Proceed as follows:
D Remove the air intake sleeve and the exhaust pipe.
D Disconnect the wastegate actuator signal pipe.
Figure 85
1730368
1730366 Figure 88
Figure 86
1730369
1730367 Refit
Proceed as follows:
D Remove oil delivery duct to the turbocharger asĆ
sembly. Figure 89
1730370
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
48ąENGINE SECTION 3 ADT 25
D Install the turbocharger and tighten the mountĆ D Install the lubricant delivery duct and tighten the uniĆ
ing nuts to the specified torque. ons to the specified torque.
The oil delivery duct must not come into
Figure 90
contact with the turbine body, otherwise it
could burn and cause serious injury or damĆ
age.
D Assemble the removed components working in reĆ
verse order to the removal.
Start up the engine and check there are no leaks.
After all the operations are finished, restore the veĆ
hicle to operating condition.
Removal
Proceed as follows:
1730371
D Remove the air intake sleeve and exhaust pipe
D If necessary, loosen the turbine body bolts and posiĆ D Remove the turbocharger as described in the relĆ
tion the bearing housing so that the turbocharger oil evant paragraph.
discharge pipe can be installed.
Figure 92
D Install the flexible hose and straps onto the turboĆ
charger oil discharge pipe without tightening them,
then refit the oil discharge pipe and the gasket on
the turbocharger;
D tighten the screws to the specified torque, then
tighten the straps;
D If previously loosened, tighten the turbine body
bolts to the specified torque;
Figure 91
1730373
Refit
Proceed as follows:
Figure 93
1730372
1730374
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą49
Figure 96
1730375
Figure 97
D Tighten the mounting screws in the order indicated
to the specified torque.
D Assemble the removed components working in reĆ
verse order to the removal.
D Start up the engine and check there are no leaks.
D After all the operations are finished, restore the veĆ
hicle to operating condition.
1730378
D Remove the lubrication oil thermostat.
D Clean and inspect the lubrication oil thermostat hole
before reassembling.
D Install the lubrication oil thermostat and tighten to
the specified torque.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
50ąENGINE SECTION 3 ADT 25
Lubrication oil heat exchanger element and gasket D Clean the sealing surfaces of the oil heat exchanger.
Figure 100
Removal and refit
Proceed as follows:
D drain off the engine cooling circuit as described in
the Chapter RADIATOR REMOVAL-REFIT;
Never dispose of residual coolant in unauĆ
thorised dumps or by pouring it into the
sewers.
D Remove the lubrication oil filter.
Figure 98
1730381
D Remove the turbocharger oil delivery duct from the Figure 101
head of the oil filter.
Figure 99
156NM26
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 3 ENGINEą51
Figure 104
1730382
Figure 103 D Remove the bolt (A) from the alternator knuckle.
D Remove the bolt (B) from the support bracket.
Figure 105
1730383
1730383
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
52ąENGINE SECTION 3 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 7
AUTOMATIC TRANSMISSION
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą1
CONTENTS
Page Page
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Input shaft disassembly . . . . . . . . . . . . . . . . . . . . . . . 61
GEARBOX AND GEAR DISASSEMBLY . . . . . . . . 35
Input shaft re-assembly . . . . . . . . . . . . . . . . . . . . . . 61
Preliminary operations . . . . . . . . . . . . . . . . . . . . . . . . 35
Differential disassembly . . . . . . . . . . . . . . . . . . . . . . . 62
Sensors and transmitters . . . . . . . . . . . . . . . . . . . . . 36
Differential re-assembly . . . . . . . . . . . . . . . . . . . . . . 63
Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Page Page
Differential lock disassembly . . . . . . . . . . . . . . . . . . . 64 Box cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Differential lock re-assembly . . . . . . . . . . . . . . . . . . 66 Drive input shaft (PTO shaft) . . . . . . . . . . . . . . . . . . . 75
Oil pressure pump disassembly . . . . . . . . . . . . . . . . 69 PTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Oil pressure pump re-assembly . . . . . . . . . . . . . . . 69 Differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Gearbox cover preparation . . . . . . . . . . . . . . . . . . . . 70 Converter counter pressure valve . . . . . . . . . . . . . . 78
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą3
DESCRIPTION
The ZF 6WG210 automatic transmission consists of Clutches: each shaft has a hydraulically controlled
these main parts: multiple disk clutch.
Torque converter: the torque converter has three Oil pressure pump: clamped onto the pump shaft, it
parts: the pump, the turbine and the stator. The pump is of the gear type and ensures the pressure required
is the input element and is controlled by the engine. for lubrication and hydraulic operation.
The turbine is the output element and is hydraulically Hydraulic assembly: this consists of a set of solenoid
controlled by the pump. The stator is the reaction eleĆ valves controlled by the gearbox control unit, and a seĆ
ment (torque multiplier). ries of channels to transmit the oil pressure in the apĆ
Lock up clutch: this is installed between pump and turĆ propriate points.
bine: when transmission reaches the turbine speed, it Power take-off activation. The power take-off conĆ
is close to that of the pump, the lock-up clutch beĆ trolled by the pump shaft (thus by the engine flywheel)
comes engaged so that the engine driving torque is is mounted on the rear side of the transmission case.
sent direct to the transmission with a ratio of 1:1. Gearbox control unit and wiring: the control unit reĆ
Shafts and gears: the forward gear ratios and the reĆ ceives the input signal and controls the output, so as
verse gear ratio are obtained by six shafts, each of to ensure correct transmission operation.
which has two or three helical tooth gears always enĆ
gaged.
Figure 1
1730710
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 2
1730711
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą5
AUTOMATIC TRANSMISSION
a. reversing shaft KR k. torque converter
b. driving torque input shaft AN l. lock-up clutch WK
c. forward gear shaft KV m. not used
d. 2nd gear shaft K2 n. 4th gear shaft K4
e. 3rd gear shaft K3 o. not used
f. not used p. 1st gear shaft K1
g. not used q. power take-off
h. driving torque output shaft Ab with splitter IN: motion input direction of rotation
i. gearbox oil pressure pump OUT A: forward travel direction of rotation
j. not used. OUT B: reverse output direction of rotation
Figure 3
1730712
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
BASIC COMPONENTS
Torque converter
The function of the torque converter is to hydraulically a multiplication ratio that ranges from a maximum of
transmit the engine driving torque to the gearbox, with approx. 2.5:1 to a minimum of 1:1 (top gear).
Figure 4
1730713
Operation
The pump is connected to the engine, and when it roĆ
tates, it transmits its energy to the oil. The centrifugal
force projects the oil toward the perimeter of the pump,
where it flows at high speed to the turbine. Here the kiĆ
nematic energy of the oil impresses a rotary motion to
the turbine, in the same direction as the pump.
At the turbine outlet the oil is deviated by the stator so
1730714
that its direction is the same as that of the turbine
blades. In this way the stator, which under normal conĆ The ratio between the torque acting on the turbine and
ditions is prevented from rotating by the free wheel, the driving torque is called the converter multiplication
supplies a torque reaction that is added to that of the ratio, and is proportional to the difference in speed beĆ
turbine. tween pump and turbine.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą7
Lock-up clutch
The lock-up clutch WK is a device that makes a meĆ
chanical coupling between pump and converter turĆ
bine when it is engaged.
With the lock-up clutch engaged there is no flow beĆ
tween pump P and turbine T, thus changing the gearĆ
box to a mechanical transmission, with the relevant reĆ
duction in friction loss in the converter and
consequently reduction in fuel consumption.
Figure 6
1730716
1730715
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Central splitter
The lockable central splitter has the purpose of dividing linkages are manually locked when there is a risk of
the driving torque between the two sides, unless the slipping on one of the two sides.
Figure 8
1730717
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą9
13
14
12
15
I I
11
Y6 10
Y5 9
Y4
16 Y3
8
7
Y2
Y1 -
B2/T-
17 EST-37 B1/T+
6
18 R
19 N
F
I I I I
5
4
20
21 3
22 2
23
1730718
1
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
10ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
OPERATION
Figure 10
1730719
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą11
Figure 11
1730720
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
12ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 12
1730721
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą13
Figure 13
1730722
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
14ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 14
1730723
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą15
Figure 15
1730724
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
16ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 16
1730725
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą17
Figure 17
1730726
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
18ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 18
1730727
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą19
Figure 19
1730728
Figure 20 Figure 21
A B
1730729 1730730
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
20ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
TORQUE CONVERTER
Max input power 210 kW 280 HP
Max turbine torque -input- 1150 Nm 849 lb ft
Max turbine torque -output- 1650 Nm 1218 lb ft
Stall torque ratio 1.77 : 1
Element phases 2
Stator Fix wheel (blade)
Lock-up cluch All gears
GEARBOX
Type Full power shift
Gear/clutch configuration Countershaft
Gear number - Front/rear 6 forward/3 reverse
PTO units speed 1.0 engine speed
Oil capacity approx. 26 liters 5.7 Imp gal
Weight (without oil) 470 kg 1037 lb
Oil level cold check temperature 15-45 °C 59-113° F
Oil level hot check temperature 80-104 °C 176-220 °F
Rolling bearing mounting maximum temperature 90 °C 194 °F
Interference mounting pieces maximum temp. 140° 284 °F
RATIOS
Forward
1st gear 5.562
2nd gear 3.615
3rd gear 2.255
4st gear 1.466
5st gear 0.942
6st gear 0.613
Reverse
1st gear 5.274
2nd gear 2.138
3nd gear 0.894
POWER TAKE-OFF
Available output 2
Max. torque 800 Nm 590 lb ft
Total weight - dry (kg) 590 kg 1330.8 lb
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą21
DIAGNOSTIC
a. Automatic transmission shifts at excessively fast speed
b. Automatic transmission shifts at excessively slow speed
c. Low main pressure in all gears
d. Main low pressure in one gear (normal in other gears)
e. The vehicle moves fast in first and reverse gear
f. Low lubrication pressure
g. Oil leakage from converter box (without PTO controlled by engine)
h. Transmission overheats in all gears
i. No transmission response when gear stick is shifted
j. Problematic gear shifts
k. Dirty oil
l. Leakage of oil from output shaft
m. Engine pick-up speed high with vehicle not moving
n. Engine pick-up speed high with vehicle not moving
o. Clutch slips in all forward gears
p. One specific gear slips
q. Oil leakage from filler pipe
r. Vibration or noise
Automatic transmission shifts at Regulator box jammed Clean or replace the regulator
excessively fast speed
Control valve spring excessively Adjust the spring
loaded
Automatic transmission shifts at Regulator box jammed, weak Clean or replace the regulator
excessively slow speed springs
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
22ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Main low pressure in one gear Loss of clutches of a certain gear in Replace or overhaul the distributor
(normal in other gears) actuating circuits
Excessive clutch piston seal leakĆ Overhaul the clutch and replace the
age for a certain gear seals
The vehicle moves fast in first and Engine idling speed too fast Adjust engine idling speed
reverse gear
Oil leakage from converter box Converter pump hub seal worn Replace the seal
Problematic gear shifts Modulator valve jammed; spring set Repair or replace the valves; loosen
excessively tight spring setting
Dirty oil Oil not changed at specified freĆ Change oil, fit new filtering element
quency
Leakage of oil from output shaft Output shaft flange seal worn or Replace the seal
damaged
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą23
Engine pick-up speed high with Oil missing Top up oil level
vehicle not moving
Clutch pressure missing See point 4
Engine pick-up speed low with Poor engine performance (not due Adjust or overhaul the engine
vehicle not moving to altitude)
Clutch slips in all forward gears Oil missing Top up oil level
One specific gear slips One specific clutch slips Overhaul the concerned parts
Oil leakage from filler pipe Level gauge clearance Fasten cap and replace it, if required
Vibration or noise Transmission bent or incorrectly balĆ Clean the transmission. Check conĆ
anced tact with surrounding elements. ReĆ
place the transmission if offset or
deformed. Remove and dynamiĆ
cally balance the transmission if it
does not work correctly (it vibrates).
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
24ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
TIGHTENING TORQUE
Screws fastening gearbox mounts to chassis 200 Nm 147 lb ft
Screws fastening front and rear cradle to gearbox 400 Nm 295 lb ft
Pipe plate differential pressure switch 30 Nm 22 lb ft
Screws fastening pipe plate to gearbox 23 Nm 17 lb ft
Screws fastening hydraulic control unit to gearbox 11 Nm 8 lb ft
M5 screws fastening converter clutch valve to mount 5.5 Nm 4 lb ft
Screws fastening converter clutch valve mount to plate 9.5 Nm 7 lb ft
Screw retaining converter clutch valve plate 18 Nm 13 lb ft
Converter clutch valve threaded sleeve 46 Nm 34 lb ft
Screws fastening converter clutch valve mount to bracket 23 Nm 17 lb ft
Screws fastening converter clutch valve bracket to gearbox 46 Nm 34 lb ft
M12 screws fastening hose fittings to gearbox 45 Nm 33 lb ft
M8 screws fastening hose fittings to gearbox 35 Nm 26 lb ft
Hose fastening to fittings 35 Nm 26 lb ft
Screws fastening filter head to pipe plate 23 Nm 17 lb ft
Gearbox cover M8 studs 9 Nm 6.6 lb ft
Gearbox cover M12 studs 23 Nm 17 lb ft
Gearbox threaded sleeve 46 Nm 34 lb ft
Gearbox threaded bushing 80 Nm 59 lb ft
KR/KV shaft stud 17 Nm 12.5 lb ft
K1/K2/K3/K4 shaft stud 17 Nm 12.5 lb ft
Differential cover fastening screws 68 Nm 50 lb ft
Differential guard fastening screws 23 Nm 17 lb ft
Gearbox cover fastening screws 46 Nm 34 lb ft
Oil delivery cover fastening nuts 23 Nm 17 lb ft
PTO box fastening nuts 79 Nm 58 lb ft
Screws fastening flange to rear output shaft 46 Nm 34 lb ft
Differential lock control cover fastening screws 23 Nm 17 lb ft
Differential lock engagement fork fastening pins 9.5 Nm 7 lb ft
Differential lock control switch 30 Nm 22 lb ft
Screws fastening bushing to front output shaft 32 Nm 23.5 lb ft
Screws fastening differential lock device to gearbox 79 Nm 58 lb ft
Oil pressure pump fastening screws 46 Nm 34 lb ft
Oil pressure pump M10 fastening screws 34 Nm 25 lb ft
Oil pressure pump M8 fastening screws 23 Nm 17 lb ft
Screws fastening converter bell to gearbox 68 Nm 50 lb ft
Screws fastening input shaft to membrane 115 Nm 85 lb ft
Screws fastening membrane to converter 115 Nm 85 lb ft
Screws fastening flange to input shaft 34 Nm 25 lb ft
Screws fastening converter cover to bell 46 Nm 34 lb ft
Cover fastening screws (emergency steering pump) 23 Nm 17 lb ft
Tachometer signal transmitter 30 Nm 22 lb ft
Sensors 30 Nm 22 lb ft
Sensor fastening screws 23 Nm 17 lb ft
Breather 12 Nm 9 lb ft
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą25
TOOLS
5870 350 000 assembly trolley unit with tipping mechanism
5870 350 063 bars (to be used with 5870 350 000)
5870 350 090 retainers (to be used with 5870 350 000)
5870 350 000 assembly trolley unit with tipping mechanism
5870 350 089 box cover fastening brackets (to be used with 5870 350 000)
5870 260 010 handles for fastening shafts to box cover
5873 001 000 base for removing KR/KV/K4 shaft taper roller bearings
5873 001 057 gripper (to be used with 5873 001 000)
5873 001 059 gripper (to be used with 5873 001 000)
5870 100 043 pressing tool (to be used with 5873 001 000)
5873 001 000 base for removing K1/K2/K3shaft taper roller bearings
5873 002 001 base for removing K1/K2/K3 shaft taper roller bearings
5873 001 059 gripper (to be used with 5873 001 000)
5870 100 043 pressing tool (to be used with 5873 001 000)
5873 002 038 gripper (to be used with 5873 001 000)
5870 345 088 clutch compression spring pre-load ring
5873 001 000 input shaft taper roller bearing removal base
5873 011 014 gripper (to be used with 5873 001 000)
5870 001 006 bushing (to be used with 5873 350 000)
5870 600 003 oil pipe assembly tool
5870 600 004 oil pipe assembly tool
5870 600 005 oil pipe assembly tool
5870 345 089 shaft manual rotation sleeve
5870 280 007 shaft manual rotation handwheel
5870 048 237 seal assembly pad
5870 506 142 rear output flange screws retainer plate assembly pad
5870 204 011 oil pressure pump box assembly guide screw
5870 058 023 differential output shaft roller bearing assembly guide bushing
5870 260 002 pads (to be used with 5870 350 000)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
26ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
REMOVAL-REFIT
Before starting any type of operation make Figure 23
sure all the necessary safety precautions
have been taken and fully explained to those
involved in the operations.
Read the relevant instructions in SECTION
1.2 of this manual.
If in doubt, contact someone with more exĆ
perience.
Always observe all the general recommenĆ
dations to carry out maintenance jobs corĆ
rectly.
Removal
1730701
To remove proceed as follows:
D bring the vehicle onto a suitable flat, solid surface,
D disconnect propeller shafts: (A) from the engine to
switch off the engine, remove the ignition key, enĆ
the gearbox, (B) from the gearbox to the front axle
gage the parking brake and apply the warning signĆ
and (C) from the gearbox to the intermediate mountĆ
boards;
ing following the instructions in SECTION 10;
D cut off the battery isolator switch or disconnect the
D prepare a suitable container and drain off the hyĆ
terminals from the battery to avoid the risk of short
draulic fluid as described in SECTION 16.
circuits;
D lock knuckle with the steering lock bar following the Never dispose of residual fluid in unauthoĆ
instructions in SECTION 1.2; rised dumps or by pouring it into the sewers.
Figure 22
1730303A
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą27
D Disconnect the electrical connections: D Remove the exhaust mufflers (8) and the respective
a. engine speed partition.
b. rotator speed D Use a suitable lifting device, apply chains to the asĆ
c. turbine speed sembly brackets and pull them, making sure that
d. lock-up clutch solenoid valve the weight is equally divided and that the assembly
e. electrical hydraulic control unit does not slant excessively to the side.
f. filter and oil circuit obstruction sensors D Remove the front and rear gearbox rubber mount
g. differential lock control. fastening screws (6) from both sides.
D Disconnect the pipes: D Check that all connections and pipes have been disĆ
- delivery (10) from main pump connected and that all the fastening clips have been
- suction (12) from hydraulic reservoir released.
- lubricant delivery from heat exchanger (1) D Lift the assembly carefully upwards.
- lubricant return from heat exchanger (5) D Remove the brackets supporting the front and rear
- differential lock control (16). gearbox.
D Remove the suction pipe (12) from hydraulic reserĆ
voir.
Figure 24
1730707A
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
28ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 25
1730706
Refit
To refit carry out the same operations in reverse order,
paying particular attention to:
D check the gearbox flexible mountings: if they are
damaged, replace them;
D check that the connecting pipes and associated
unions are perfectly intact;
D check the gearbox oil level and if necessary top up
or fill (see OPERATION AND MAINTENANCE
MANUAL).
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą29
Figure 26
156NM76
174NM32
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
30ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Changing oil
Collect and dispose of used lubricants and D fill the new cartridge with the specified lubricant and
fluids according to the laws in force. apply the same lubricant to the seal (Figure 31);
Figure 31
Proceed as follows:
D take a suitably sized container, clean the filler area,
loosen the handle by two or three turns and remove
the dipstick;
D remove both drain caps (Figure 29) and fully drain
the oil;
D clean the drain cap. Check that the threading is in
good condition. Apply sealing paste and close at
the specified torque;
drain cap: 140 Nm (103 lb ft)
D pour in the specified amount of lubricant through
the filler and reposition the dipstick by refastening
the handle;
D check the level again after a test drive. 156NM25
Figure 32
156NM77
Proceed as follows:
D with a cold engine, loosen the filtering cartridge Do not fasten the cartridge excessively. This
(Figure 30) using the specific tool and accurately could damage the seal. Observe the specifiĆ
clean housing and engine cations provided by the supplier.
Figure 30 D run the engine for a few minutes and check for leakĆ
age.
D check engine oil level and top up, if required.
156NM78
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą31
REPAIR OPERATIONS
Check that all precautions have been taken D Loosen the fastening screws and separate the filter
head from the pipe plate.
and that all aspects concerning safety of
personnel involved in the operations have Figure 35
been explained before started any operaĆ
tion.
Read the instructions provided in SECTION
1.2 of this manual.
In doubt, consult an expert.
Follow all the general recommendations for
correctly performing maintenance operaĆ
tions.
Removal
Proceed as follows:
1730743
Figure 33
D Remove the differential pressure switch (obstrucĆ
tion indicator).
Figure 36
1730741
Figure 37
1730742
1730745
D Remove the hoses.
D Loosen the fastening screws and separate the hyĆ
draulic control unit from the pipe plate.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
32ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 41
1730746
D Loosen the fastening screws and separate the pipe 1730749
plate from the gearbox.
D Fit the converter clutch solenoid valve and fasten
Figure 39 the screws at the specified torque.
Figure 42
1730747
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą33
Assembly Figure 45
Proceed as follows:
Figure 43
1730753
D Fit the seal.
1730751
Lubricate the seal to facilitate assembly.
D Fit the following components in the order shown:
1 = compression spring
2 = piston Figure 46
3 = Differential pressure switch (obstruction indiĆ
cator).
Figure 44
1730754
D Fasten the pipe plate and fasten the screws at the
specified torque.
Figure 47
1730752
1730755
D Fit two guide screws 5870 204 063 and fit the inner
seal.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
34ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 48 Figure 51
1730756
1730759
D Pay attention to the correct component assembly D Fit the hydraulic control unit and fasten the screws
sequence: at the specified torque.
1. Inner seal
Figure 52
2. Intermediate sheet
3. Outer seal
Figure 49
1730760
D Fit the seal.
D Fit the plate with converter clutch valve on the box
1730757 and fasten the screws at the specified torque.
D Fit the intermediate shim sheet.
Figure 53
Figure 50
1730761
1730758 D Fit the hoses (arrow) and fasten the fittings and the
D Fit the outer seal. screws at the specified torque.
D Remove the guide screws. Fit new seals.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą35
Preliminary operations
Figure 56
1730762
Figure 55
1730764
D Fasten the transmission to the supporting tools:
assembly trolley 5870 350 000
bars 5870 350 063
retainer 5870 350 090.
D Drain all lubricant oil.
D Remove the hoses, the filter unit, the hydraulic conĆ
trol unit, the pipe plate and the converter clutch
valve, as shown above.
Figure 57
1730763
D Fit the pipe plate head and fasten the screws at the
specified torque.
D Lubricate the filter seal.
D Fasten the filter until it comes into contact with the
seal surface and tighten it manually by 3/4 of a turn.
1730765
D Remove the PTO engagement box.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
36ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 58 Figure 60
1730768
1730766
D Remove the input flange fastening screws.
Figure 59 D Remove the input flange with an extractor.
Figure 61
1730767
1730769
1. Tachometer signal transmitter
2. Output shaft speed sensor D Mark the relative position of the cover on the gearĆ
3. Turbine shaft speed sensor box.
4. Internal input speed sensor D Loosen the connection screws.
5. Crankshaft shaft speed sensor
Figure 62
D Remove the tachometer signal transmitter (1).
D Loosen the fastening screws and remove the senĆ
sor (2).
D Remove the sensors (3), (4) and (5).
1730770
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą37
Figure 63 Figure 65
1730773
1730771
D Use a press to extract the input shaft and the conĆ D Remove the snap ring and remove the bearing from
verter from the gearbox cover. the cover.
D Remove the input shaft speed sensor.
Figure 64
Figure 66
1730774
Figure 67
1730772
1730775
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
38ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 68
1730779
D Loosen the fastening screws and remove the cover.
1730776
D Loosen all the fastening screws and remove both Differential lock control
the oil delivery flange and the oil pressure pump
from the gearbox. Figure 72
Figure 69
1730780
1730777 D Loosen the fastening screws and detach the differĆ
ential lock control by means of suitable levers.
D Detach the oil pressure pump from the oil delivery
flange. Figure 73
Figure 70
1730781
D Remove the snap ring and remove the shim and the
1730778 grooved gear.
D Remove the stator shaft.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą39
Figure 74 Figure 77
1730782 1730785
Figure 75
1730786
1730783 Figure 79
D Remove the shaft from the housing hole.
Figure 76
1730787
D Lift the cover from the gearbox with a suitable lifting
device and eyebolts.
1730784
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
40ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 83
1730788
Figure 81
1730791
Figure 84
1730789
Figure 82
1730792
1730790
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą41
Figure 85 Figure 88
1730793 1730796
D Lift the cover with shafts and respective clutches The figure shows the arrangement of the clutches in the
from the gearbox. box cover.
AN = Input
Figure 86 KV = Forward gear clutch
KR = Reverse gear clutch
K1 = 1st gear clutch
K2 = 2nd gear clutch
K3 = 3rd gear clutch
K4 = 4th gear clutch
Figure 89
1730794
D Fasten the cover by means of the supporting tools:
- assembly trolley 5870 350 000
- retainer 5870 350 089.
Figure 87
1730797
The various clutches can be recognised by the 10 digit
ZF catalogue part number.
The part number is engraved on the front end of the reĆ
spective clutch shaft (arrow).
…. 371 … = K1
…. 372 … = K2
…. 373 … = K3
…. 374 … = K4
…. 375 … = KV
…. 376 … = KR
1730795 Follow the sequence below to remove the
clutches:
D Turn the box cover by 180°. K1; K2; K3; K4; KV, KR and AN (together).
D Remove the handles.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
42ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 90 Figure 93
1730798
17307101
D Lift clutch K4 by means of suitable levers and reĆ D Lift the clutches KV and KR and remove the clutch
move the clutch K1. K4.
Figure 91 Figure 94
17307102
1730799
D Remove the clutch K2. D Remove the clutches KV, KR and the input shaft AB
at the same time.
Figure 92
Figure 95
17307100
17307103
D Remove the clutch K3.
D Remove the bearing outer rings from the box and
the cover (arrow).
The outer ring and inner ring mating must be
at least ensured by means of a suitable
marking when the taper roller bearings are
not replaced.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą43
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
44ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Lip seals
Make sure that the spring lip side is actually on the side
of the oil to be contained (towards the inside of the box):
apply high temperature resistant grease inside the seal
to protect it during shaft assembly and ensure lubricaĆ
tion at the beginning of operation.
Roller bearings
Heat the bearing on an electrical radiating plate or in an
oil bath (maximum temperature of approximately 90°C
(194°F)) to fit it on the shaft. Fit the bearing at the press.
Warm the bearings for a suitable time to obĆ
tain adequate dilatation.
Heating time depends of the dimensions of
the bearings. Approximately 45 minutes are
sufficient for the larger bearings.
Shrink-fitting
Shrink-fitting can be carried out by respectively heatĆ
ing and cooling the two parts. The female part can be
heated in an oven or oil bath (maximum temperature of
approximately 140°C (284°F), with the exception of
bearings) and the male part can be cooled in dry ice.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą45
Figure 96
17307106
Figure 99
17307104
Figure 97
17307107
Figure 100
17307105
17307108
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
46ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 101 D Fit both o-rings (1) and (2) in the piston grooves
and lubricate them.
D Check operation of the drain valve (arrow). The ball
should never be jammed.
Figure 104
17307109
Figure 105
17307110
Figure 103
17307113
D Use tool 5870 345 088 to load the reaction spring
and insert the snap ring in the plate holder ring
shaped groove (arrow).
17307111
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą47
Figure 106
KV and KR clutches
17307114
. The drawing shows the clutch components and the respective installation position.
The components of the KV and KR clutch plates are identical.
. The play between plates is defined by the thickness of the snap ring (6).
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
48ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 107
17307117
Completion D Fit the ball bearing and fasten it with the snap ring.
Proceed as follows: Figure 111
Figure 108
17307119
17307116
D Use a press to fully fit the intermediate gear.
D Align and centre the plate set with the intermediate
gear to simplify plate holder drum assembly.
D Remove the intermediate gear.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą49
17307120 17307122
D Heat the inner hole of the plate holder drum to D Check operation of the clutch with compressed air.
approximately 120 °C (248 °F).
D Fit the previously assembly plate holder drum fully. . The opening and closing of the clutch
should be clearly heard if the components
Figure 113 are fitted correctly.
D Fit both taper roller bearing inner rings.
17307121
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
50ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 115
17307125
Figure 116
17307126
Figure 119
17307124
D Remove the axial roller bearing (two ring cage).
17307127
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą51
17307128 17307129
D Use tool 5870 345 088 to load the reaction spring, D Fit the piston to the point of contact.
remove the snap ring, relieve the springs and reĆ D Fit the cup springs and the resting ring.
move the individual components. D Fit the resting ring with the groove facing upwards.
D Use compressed air to lift the piston and remove it. D Fit the cup spring as shown in the figure.
D Remove the inner and outer piston o-rings.
Figure 123
K1, K2 and K3 clutch assembly
Figure 121
17307130
17307111
D Use tool 5870 345 088 to load the reaction spring
and insert the snap ring in the plate holder ring
D Fit both o-rings (1) and (2) in the piston grooves shaped groove (arrow).
and lubricate them.
D Check operation of the drain valve (arrow). The ball
should never be jammed.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
52ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 124
K1 clutch
17307131
. The drawing shows the clutch components and the respective installation position.
. The play between plates is defined by the thickness of the snap ring (6).
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą53
Figure 125
K2 and K3 clutches
17307132
. The drawing shows the clutch components and the respective installation position.
The components of the K2 and K3 clutch plates are identical.
. The play between plates is defined by the thickness of the snap ring (6).
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
54ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
17307115 17307133
D Arrange a dial gauge with probe on the terminal D Refit the pawl with calibrated hole, if removed.
flange.
D Exert a force of approximately 100 N (22.5 lb) on the . The pawl only needs to be fitted on the K1
flange and reset the gauge. clutch shaft. K2 and K3 clutch shafts are not
D Use compressed air to move the piston so that the provided with a pawl.
flange moves against the snap ring and check that
D Refit the stud and fasten at the specified torque, if
the play between plates (gauge reading) is within
removed.
the specified range.
Play between plates: Figure 128
K1 clutch: 2.4 -2.6 mm (0.095ć0.0105 in)
K2 and K3 clutches: 1.8 -2.0 mm (0.070ć0.080 in)
D If this is not so, use a different sized snap ring.
17307134
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą55
Figure 129 Fit ring (1) with chamfer facing the cage.
All plates inside clutch K3 are certainly in
place only when the bearing ring is in conĆ
tact with the shaft collar.
Figure 132
17307135
D Fit the axial roller bearing - ring (1), cage (2) and
ring (3).
Fit ring (1) with chamfer facing the cage.
17307138
Figure 133
17307136
D Fit the intermediate gear so that all inner clutch
plates are in the correct position. 17307139
D Fit the radial roller bearing (2). D Check operation of the clutch with compressed air.
Figure 131
. The opening and closing of the clutch
should be clearly heard if the components
are fitted correctly.
D Fit both taper roller bearing inner rings.
17307137
D Fit the axial roller bearing - ring (1), cage (2) and
ring (3).
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
56ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 134
17307106
Figure 135
17307107
Figure 138
17307141
17307108
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą57
17307142 17307143
D Remove the intermediate gear. D Fit the piston to the point of contact.
The shaft cannot be separated from the gear D Fit the cup springs and the resting ring.
(forced shrink-fitting). Fit the resting ring with the groove facing upĆ
wards.
K4 clutch assembly Fit the cup spring as shown in the figure.
Proceed as follows:
Figure 142
Figure 140
17307111
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
58ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 143
K4 clutch
17307132
. The drawing shows the clutch components and the respective installation position.
. The clearance between plates is defined by the thickness of the snap ring (6).
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą59
Axial play test D Align and centre the plate set with the intermediate
Proceed as follows: gear to simplify plate holder drum assembly.
D Remove the intermediate gear.
Figure 144
Figure 146
17307115
17307146
D Arrange a dial gauge with probe on the terminal
flange. D Refit the stud and fasten at the specified torque, if
D Exert a force of approximately 100 N (22.5 lb) on the removed.
flange and reset the gauge.
Figure 147
D Use compressed air to move the piston so that the
flange moves against the snap ring and check that
the play between plates (gauge reading) is within
the specified range.
Play between plates:
1.4-1.6 mm (0.055ć0.065 in)
D If this is not so, use a different sized snap ring.
Completion
D Fit the axial roller bearing (two ring cage).
Proceed as follows:
Figure 145
. The two rings are interchangeable.
17307145
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
60ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
17307148
17307151
D Fit the radial roller bearing. D Fasten the plate holder drum by means of a snap
D Fit the intermediate gear. ring.
17307149
17307152
D Fit the axial roller bearing - ring (1), cage (2) and D Check operation of the clutch with compressed air.
ring (3).
Fit ring (1) with chamfer facing the cage.
. The opening and closing of the clutch
should be clearly heard if the components
are fitted correctly.
17307150
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą61
17307153 17307155
Figure 154
17307156
17307157
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
62ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 158
17307161
Figure 159
17307162
Figure 163
17307159
Figure 160
17307160 17307163
D Remove the snap ring. D Push the rubber pins away from the planet gears.
D Remove each planet gear shaft, retrieving rollers
and shims.
D Remove the sun gear and the respective shims.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą63
Figure 164
17307166
Figure 167
Figure 165
17307165 17307167
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
64ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 171
17307168
D Fit the gear set in the external gear with the long hub
side facing upwards. 17307171
Figure 169 D Loosen the fastening screws and remove the output
flange.
Figure 172
17307169
Figure 170 D Remove the shaft seal and remove the snap ring.
Figure 173
17307170
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą65
17307177
17307174
D Push the ball bearing out of the shaft with a press. D Loosen the fastening screws and remove the pins
and the control fork.
Figure 175
Figure 178
17307175
17307178
D Push the oil delivery ring out of the shaft with a
press. D Remove the switch and the lock pin.
17307179
17307176
D Loosen the fastening screws and remove the conĆ
D Remove the sliding sleeve. trol device components.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
66ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 180
17307182
17307181 17307183
D Refit the o-ring in the switch ring groove and lubriĆ
D Refit the o-ring in the piston ring groove and lubriĆ cate it
cate it. D Fit the switch and the lock pin. Fasten the screw at
D Fit the piston. the specified torque.
Pay attention to the radial position of the pisĆ Figure 184
ton. The lock pin contact surface must face
the guide hole (arrow).
17307184
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą67
17307185 17307188
D Fit both sliding rebounds (arrow) and fit the sliding D Fit the output shaft (fitting the sliding sleeve at the
sleeve. same time) then fit it completely.
17307186
Figure 187
17307189
17307187
D Push the ball bearing in completely.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
68ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
17307190
17307193
D Fit the bushing and the intermediate washer.
D Blow compressed air to move the sleeve: the resistĆ
Figure 191 ance value (measured with a multimeter) should
change if the switch is intact.
Figure 194
17307191
Figure 195
17307192
D Use pad 5870 048 237 to fit the shaft seal with the
lip (detail) facing inwards. 17307195
Different seals can be used according to the
version: D Lubricate the o-ring and fit it in the ring groove (arĆ
- rubber coated external diameter: dampĆ row).
en with alcohol.
- metallic external diameter: apply LOCĆ
TITE 574 sealant.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą69
17307196
Figure 197
17307198
Figure 199
17307197
D Remove the snap ring (1) and remove the seal (2)
and the roller bearings (3).
17307199
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
70ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
17307200 17307203
Figure 204
Figure 201
17307201
17307204
D Fit the internal rotor.
D Fit M8 and M12 studs applying LOCTITE 243 thread
The dent (arrow) should be facing upwards. locker if removed and fasten at the specified torque.
Figure 205
Figure 202
17307202 17307205
D Fit the cam plate and fasten it in radial direction by D Fit new o-rings on the threaded sleeve (1) and on
means of two screws. the threaded bushing (2), then fasten at the speciĆ
Do not tighten the screws. Fasten them by fied torque.
hand until they come into contact and loosĆ
en them by approximately half a turn.
Respect the assembly position of the cam
plate shown in the figure.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą71
Figure 207
17307207
Gearbox side
Figure 208
17307206
1 = oil intake
2 = pressurised oil delivery
3 = lubrication oil delivery
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
72ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
17307209 17307212
D Fit the box cover, the KR clutch, the AN input shaft D Arrange the K2 clutch.
and the KV clutch at the same time.
Figure 213
Figure 210
17307213
17307210
D Lift the K4 clutch and arrange the K1clutch.
D Lift the AN input shaft and position the K4 clutch. D Install, lubricate and align the seals.
17307211
17307214
D Refit the K3 clutch. D Fit the handles 5870 260 010 onto all the shafts so
to secure the shafts to the cover.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą73
17307217
17307215
Figure 216
17307218
Box cover
Figure 219
17307216
17307219
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
74ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
17307220 17307223
D Check smooth gear mechanism operation with the
D Apply LOCTITE 574 sealant on the assembly surĆ
hub 5870 345 089 and the handle 5870 280 007.
face making sure it is applied inside the holes (deĆ
tail). Correct interference of mobile parts (for exĆ
ample on the guard or on the oil pipes).
Figure 221
D Repeat the operation on all clutch shafts.
Figure 224
17307221
D Use a hoist to carefully fit the box cover on the gearĆ
box putting the parts into contact. 17307224
Make sure both oil pipes are aligned with the
holes on the gearbox cover. D Fasten the box cover and fasten the screws at the
specified torque.
Figure 222 Pay attention to the assembly position of the
fastening plate and clutch converter valve
support bracket (arrow).
17307222
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą75
Figure 225
17307227
D Fit the pump shaft until it comes into contact.
17307225
Figure 228
D Push the internal bearing half ring in completely.
The ball bearing presents four contact
points.
Figure 226
17307228
D Fasten the pump shaft by means of the snap ring.
Figure 229
17307226
17307229
D Fit the o-ring (arrow) in the oil delivery cover
groove.
D Fit the oil delivery covers fastening the nuts at the
specified torque.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
76ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 230
17307233
Figure 231
17307234
17307231 D Fit the output shaft until it comes into contact.
Figure 235
D Fit the PTO box and fasten the nuts at the specified
torque.
Differential
Figure 232
17307235
D Fasten the output shaft by means of the snap ring.
17307232
D Use pad 5870 058 023 and extension 5870 260 002
to carefully push the roller cage into the output shaft
completely.
D Lubricate the cage.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą77
17307238
17307236
D Use pad 5870 048 237 to fit the shaft seal with the D Insert the output flange until it comes into contact.
lip facing the oil sump.
Figure 239
. Different seals can be used according to the
version:
- rubber coated external diameter: dampĆ
en with alcohol.
- metallic external diameter: apply LOCĆ
TITE 574 sealant.
Figure 237
17307239
Figure 240
17307237
17307240
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
78ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
17307244
D Fit the previously assembled differential lock control
and fasten the screws at the specified torque.
Figure 242
17307245
D Fit each component in the order and direction
shown and fasten them by means of the safety
plate.
17307242 Fit the pressure plate (arrow) with the 6 mm
D Fit the hollow shaft completely. (0.235 in) diameter part facing the safety
plate.
Figure 243
17307243
D Fit the previously assembled differential lock control
and fasten the screws at the specified torque.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą79
Figure 246
17307249
17307247
D Fit the oil pressure pump housing.
Figure 248
17307250
17307248
D Fit the two guide screws and fit the stator shaft.
Pay attention to the radial position.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
80ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 251
17307253
Figure 252
17307254
Figure 255
17307252
D Fasten the membrane to the input shaft fastening
the screws at the specified torque.
D Apply LOCTITE 262 thread locker.
D Fasten the membrane to the converter and fasten
the screws at the specified torque.
17307255
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 7 AUTOMATIC TRANSMISSIONą81
17307256
17307258
D Install, lubricate and align the seal (arrow). D Fit the seal.
D Fit the cover and fasten the screws at the specified
Figure 257 torque.
17307257
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
82ąAUTOMATIC TRANSMISSION SECTION 7 ADT 25
Figure 259
17307261
17307260
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 10
PROPELLER SHAFT
ADT 25 SECTION 10 PROPELLER SHAFTą1
CONTENTS
Page Page
SPECIFIC MAINTENANCE . . . . . . . . . . . . . . . . . . . . 9
General the propeller shaft joints . . . . . . . . . . . . . . . . 9
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąPROPELLER SHAFT SECTION 10 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 10 PROPELLER SHAFTą3
DESCRIPTION
The vehicle transmission line consists of the following: The shafts are all of the telescopic type, with a shank
A. a propeller shaft between the engine and the that has a grooved coupling that slides in the seat inĆ
gearbox side the actual shaft: this permits a certain variation in
B. a double universal joint between the gearbox and the length of the shaft, caused by the movement of the
the front axle movement output and input units.
C. a propeller shaft between the gearbox and interĆ Furthermore, each shaft has two universal joints inĆ
mediate axle, divided into three sections and fitted stalled one on each end, that allow the rotation of the
with two intermediate supports ends with a certain degree of inclination and ensure the
D. a propeller shaft between the intermediate axle homogeneity of the rotation (no angular speed pulsing)
and the rear axle between the movement input and output.
Figure 1
1 2
A
4
B
3 C
C
5 D 6
1731009
1. engine
2. gearbox
3. front differential
4. transfer
5. intermediate differential
6. rear differential
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąPROPELLER SHAFT SECTION 10 ADT 25
DIAGNOSTIC
1. Vibration or noise
2. Excessive wear of mounts
Vibration or noise Deformed drive shafts Clean the transmission. Check conĆ
tact with surrounding elements. ReĆ
place propeller shaft if deformed
Excessive wear of mounts Deformed drive shafts Clean the transmission. Check conĆ
tact with surrounding elements. ReĆ
place propeller shaft if deformed
Flange fork badly aligned and/or Check alignment, offset and balĆ
fork offset ance of fork/flange. Repair or reĆ
place, if required
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 10 PROPELLER SHAFTą5
TIGHTENING TORQUE
Screws fastening CV joint to propeller shaft-gearbox (A): 67 Nm ( 49 lb ft)
Propeller shafts CV joint plate fastening screws
(excluding propeller shaft-gearbox) (B): 155 Nm (114 lb ft)
Intermediate shaft journal fastening nuts (C): 600 Nm (442 lb ft)
Figure 2
B C B
A
B C B
A B C
1731007
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąPROPELLER SHAFT SECTION 10 ADT 25
REMOVAL-REFIT
Before starting any operation, make sure Figure 3
that all necessary precautions have been
taken and all aspects have been made clear
regarding the safety of those involved in the
operation.
Read the relevant instructions in SECTION
1.2 of this handbook.
If in doubt consult someone with more exĆ
perience.
Removal
For the removal proceed as follows:
D bring the vehicle onto a suitable flat, solid surface,
switch off the engine, remove the ignition key, enĆ 1731002
gage the parking brake and apply the warning signĆ
boards. D unscrew the two screws that fasten the universal
joint crosshead plate to the shaft on both sides of
The disassembly of the transmission line beĆ
the joint;
tween the gearbox and the intermediate axle
D repeat the operation from the other side of the shaft,
renders the parking brake out of action.
then withdraw the shaft, cautiously lowering the liftĆ
In his case place suitable chocks under the
ing unit;
wheels in both travel directions to avoid unĆ
controlled movement of the vehicle during Figure 4
the disassembly operations.
1731003
Refit
To refit follow the removal operations in reverse:
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 10 PROPELLER SHAFTą7
Figure 7
1731000
D disassemble the shaft into the two parts and take off
the sealing gasket.
Crosshead disassembly
Figure 6
1731006
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąPROPELLER SHAFT SECTION 10 ADT 25
Figure 8
1 3 4 2
1731010
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 10 PROPELLER SHAFTą9
SPECIFIC MAINTENANCE
Greasing the propeller shaft joints . Two or three shots are sufficient to guaranĆ
The cardan joints and the supports are fitted with greaĆ tee proper lubrication.
sers.
Proceed as follows:
Remove the pebble guard cover to get at the lower part
D clean the relevant union;
of the gearbox output shaft and its supports (detail).
D inject the specified grease into the unions indicated.
Only use a hand pump for greasing, never a high presĆ
sure greaser.
Figure 9
174NM75
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
10ąPROPELLER SHAFT SECTION 10 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 12.1
FRONT AXLE
ADT 25 SECTION 12.1 ąFRONT AXLEą1
CONTENTS
Page Page
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąFRONT AXLE SECTION 12.1 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą3
DESCRIPTION
The axle is a dual reduction bearing type. mountings to connect to the chassis and housings for
It consists of a box type structure that contains the the bearings, as well as the brake calliper mounting
bevel gear pair with the differential, the axle shafts and flange.
hubs with the end reduction. The structure has
Figure 1
1891201
1. Axle
2. Suspension cylinder attachments 1891201
3. Driving torque input flange
4. Brake calliper
5. Swivel hinge support
6. Swivel pipe
7. Support securing bracket on axle
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąFRONT AXLE SECTION 12.1 ADT 25
Figure 2
3
4
16
5 A
15 6
13
B
12 11 10 9 8
1.731.213A 1.731.213B
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą5
The differential is self-locking. coefficient and thus holds the braking torque constant
It has a multiple disk clutch inserted between the for the whole useful life of the differential.
differential gear box (train carrier) and the crown The thrust on the disks is ensured by the sloped
wheels on each side. contact between the shaft and the pressure plate:
The multiple disk clutch includes the external disks therefore a greater radial peripheral thrust on the train
connected to the differential gear box and internal carrier shaft (from the ring bevel gear) will cause a
disks connected to the crown wheel gears by greater axial thrust on the disks.
appropriate pressure plates. The thrust on the disks generates a stall torque that
The internal disk friction surfaces have a patented acts on the crown wheel.
molybdenum coating that ensures a constant friction
Figure 3
1731214
1. Crown wheel
2. Differential gear box
3. Differential cover
4. Crown wheel gear
5. Side pinion
6. Differential gear carrier shaft
7. Bevel pinion
8. Pressure plate (quantity: 2)
9. Multiple disk clutch ć external disk
10. Multiple disk clutch ć internal disk
11. Shoulder
12. Pressure plate rings sloped surfaces
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąFRONT AXLE SECTION 12.1 ADT 25
1731215
Right wheel with road grip the same as the left one
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą7
If the two wheels do not have the same grip, the stall In fact, the multiple disk clutches automatically
torque generated by the multiple disk clutches partially compensate the grip variations of the wheels from the
locks the crown wheel on the side with less grip and left and right sides of the vehicle, without the need of
increases the torque delivered by the crown wheel on any operation on the part of the driver. It is therefore
the side with stronger grip. In other words, the braking possible to apply a much higher driving force during
torque replaces the reaction torque that is lacking on the use of the vehicle, and avoid slipping when one of
the side of the wheel with less grip. the wheels runs on a surface with poor grip.
In this way, looking at the example given beforehand of For example, with a locking ratio of 45%, 72.5% of the
a wheel that loses grip, this can no longer freewheel driving torque may be transferred to a rear axle shaft
and therefore the other wheel will still be able to (instead of 50% as in normal cases), whereas the other
transmit part of the driving torque, ensuring at least in axle shaft only receives 27.5%.
part the axle traction. The differential effect produced when steering the
vehicle is caused by an overlay of the effect coming
Figure 5 from the difference in the wheel speeds at the locking
action depending on the load.
1731216
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąFRONT AXLE SECTION 12.1 ADT 25
Figure 6
8 9 10 12 15
6 4 3 2
1.731.217A 1731217B
1. Axle Operation
2. Hub support The driving torque coming from the differential is
3. Internal taper roller bearing transmitted through a floating axle shaft to the crown
4. External taper roller bearing gear by means of a grooved shank.
5. Wheel mounting bolt
The four side pinion gears rotate in the opposite
6. Epicyclic train crown gear
direction to the crown gear, whereas the crown wheel
7. Pivoting roller bearing
is integral to the hub support and therefore does not
8. Epicyclic train carrier
9. Epicyclic train side pinion gear turn. This makes the train carrier turn in the opposite
10. Epicyclic train crown gear direction to the side pinions, therefore in the same
11. Grooved shank connecting axle shaft-crown direction as the axle shafts.
wheel Since the train carrier is integral to the wheel hub, the
12. Hub wheel turns in the same direction as the axle shaft.
13. Brake disk
14. Seal ring
15. Axle shaft
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą9
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
10ąFRONT AXLE SECTION 12.1 ADT 25
DIAGNOSTIC
1. Vibrations
2. Continuous noise
3. Noise when accelerating
4. Noise when decelerating
5. Noise when cornering
6. Harsh knocks when accelerating or decelerating
7. Lubricant leakage
Vibrations Broken and/or damaged gear Replace damaged gear and gear
teeth meshing with it
Wheels not fitted correctly Remove wheels and refit them corĆ
rectly
Satellite gear set or flange box exĆ Remove, repair or replace the
cessively offset faulty component
Noise when cornering Incorrect operation of self-locking Use suitable oil with anti-slipping
differential additives
Satellite gear set axis worn and/or Replace satellite gear set
damaged
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą11
TIGHTENING TORQUES
AXLE
1. Nut fastening bracket to rocker arm and to axle 470 Nm (346 lb ft)
2. Side vertical screws fastening rocker arm to axle 600 Nm (442 lb ft)
3. Rotating hinge cap fastening nuts 525 Nm (387 lb ft)
4. Journal bushing guide sleeve fastening screws 115 Nm ( 85 lb ft)
5. Screws fastening reaction arm pin to chassis 255 Nm (188 lb ft)
6. Screws fastening reaction arm pin to axle 255 Nm (188 lb ft)
7. Short horizontal screws fastening rocker arm to axle 600 Nm (442 lb ft)
8. Long horizontal screws fastening rocker arm to axle 530 Nm (391 lb ft)
1891205
1891207
1891203
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
12ąFRONT AXLE SECTION 12.1 ADT 25
DIFFERENTIAL
Motion input flange mounting nut: 600 Nm (441 lb ft)
Bolts securing ring bevel gear to differential half-box: 125 Nm ( 92 lb ft)
Calibrated bolts securing differential half-boxes: 110 Nm ( 81 lb ft)
Screws securing differential bearing support caps: 295 Nm (217 lb ft)
Oil level cap 150 Nm (110 lb ft)
Oil drainage cap 150 Nm (110 lb ft)
TOOLS
DIFFERENTIAL
5870 024 004: Extractor to remove differential bearing inner track (differential side)
5870 024 005: Extractor to remove differential bearing inner track (crown side)
5870 405 003: Riveting kit complete
to use only with drill 5870 101 007
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą13
AXLE REMOVAL-REFIT
. Before starting any type of operation make D disconnect the central lubrication system unions
(arrow);
sure all the necessary safety precautions
D raise the vehicle to have the wheels off the ground,
have been taken and fully explained to those
then place two supporting trestles under the front
involved in the operations.
chassis, without touching the axle (1);
Read the relevant instructions in SECTION
D remove both wheels following the instructions in
1.2 of this manual.
SECTION 13.1;
If in doubt, contact someone with more
D put under the front axle place an appropriate
experience.
hydraulic jack that allows lowering at removal;
Always observe all the general
recommendations to carry out maintenance
jobs correctly. Figure 7
Removal
To remove proceed as follows:
D bring the vehicle onto a suitable flat, solid surface,
switch off the engine, remove the ignition key,
engage the parking brake and apply the
maintenance in progress" signboards.
D cut off the battery isolator switch or disconnect the
terminals from the battery to avoid the risk of short
circuits;
D lock knuckle with the steering lock bar following the
instructions in SECTION 1.2;
1891208
Refit
To refit follow the removal operations in reverse order.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
14ąFRONT AXLE SECTION 12.1 ADT 25
Figure 8
1731203
Figure 9
1731204A
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą15
Figure 10
1731205
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
16ąFRONT AXLE SECTION 12.1 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą17
Figure 11
1891210
Figure 12
1891211
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
18ąFRONT AXLE SECTION 12.1 ADT 25
SPECIFIC MAINTENANCE
Checking axle/transfer case oil level Figure 15
Proceed as follows:
D move the reference mark of a hub to the horizontal
position;
Figure 13
156NM81
156NM80B
D clean the cap area and open cap. Lubricant should
drip out of the hole;
D if necessary, top up the level as indicated in the next
paragraph;
D close the filler cap and fasten at the specified
torque;
Figure 14
156NM80A
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą19
Proceed as follows:
Dumping
Figure 16
156NM123
D fill partially with the specified lubricant until it
overflows from the filler cap hole (b), then replace
the seal, apply sealant paste on the cap and tighten
it to the specified torque;
Figure 19
156NM82A
D transfer cases: take the drain cap on one hub to the
lowest position;
D arrange a suitably sized container, clean the cap
areas and remove the cap; drain all the lubricant;
D repeat the procedure on the other hub;
Figure 17
156NM80B
D bring the reference mark on a hub to the horizontal
position, fill with the remaining amount of lubricant
until it overflows from the cap hole;
D Close the cap, do a test run and recheck the level,
topping up if necessary until it overflows;
D Replace the seal, apply sealant paste on the cap
and tighten it to the specified torque.
156NM83
D axle: arrange a suitably sized container, clean the
cap areas and remove the filler cap (b) and the drain
cap (a), drain all the lubricant;
D clean the drain caps. Check that the threading is in
good condition. Apply sealant to both caps and
close them at the specified torque.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
20ąąFRONT AXLE SECTION 12.1 ADT 25
Removal
Proceed as follows:
Figure 20
1891240
Figure 21
1891250
The hub may be fitted with three different solutions for
locking the bearings.
VERSION A
1. lock nut
2. stop plate
3. pre-load adjustment spacer
1891241
VERSION B
D Loosen the screws securing the hub to the axle. 1. lock nut
Then use a suitable lifting device and remove the 2. counter lock nut
hub by sliding it carefully from the axle to avoid 3. pre-load adjustment spacer
damaging the axle shaft.
VERSION C
1. pre-load adjustment ring nut
2. counter lock nut
(spacer not included)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą21
Disassembly
Figure 26
Figure 23
1891245
1891242 D Remove the differential gear carrier plate assembly
D Fasten the unit to the supporting tools: and take it to the work bench.
- assembly trolley 5870 350 000
- retainer 5870 350 055. Figure 27
Figure 24
1891246
Figure 25
1891247
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
22ąąFRONT AXLE SECTION 12.1 ADT 25
Figure 29 Figure 31
1891251
1891248
D version A loosen the fastening screw and remove D Versions A and B: remove the spacer.
the stop plate.
Figure 32
Figure 30
1891252
1891249
D Remove the crown gear from the grooved bushing.
D Version A using tools 5870 656 005 and 5870 912
012, remove the ring nut securing the inner toothed Figure 33
gear wheel.
The ring nut is locked with thread locker.
Heat the threading to about 120 °C before
unscrewing to avoid damage.
D Versions B and C: using tools 5870 656 005 and
5870 912 012, remove both ring nuts securing the
inner toothed gear wheel.
The ring nut is locked with thread locker.
Heat the threading to about 120 °C before
unscrewing to avoid damage.
1891253
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą23
Figure 34 Figure 36
1731228 1731231
D Remove the retaining snap ring and separate the D Remove the sealing ring from the hub support.
gear wheel from its flange. D Remove the taper roller bearing inner track , axle
side.
Figure 35
Figure 37
1731232
1891255
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
24ąąFRONT AXLE SECTION 12.1 ADT 25
Axle shafts
D check the condition of the axle shafts, replace them
if there are signs of strain on the end grooves and/or
over the whole length;
Final reductions
1891256
D check the condition of the gear teeth: replace if
D Using a suitable plug and a press, remove the brake there are signs of pitting, cracks and/or sinking;
disk from the hub. D check that the side pinions and needle bushings
D If necessary remove the stud bolts that fasten the function correctly;
wheels from the hub, using a press. D check the thread on the bearing lock ring nut:
ensure there is no denting, strain and/or seizure;
Figure 40
Re-assembly
Proceed as follows:
1891257 Figure 41
D Remove the grooved bushing (1) and the spacer
ring (2) from the hub.
1891260
D If they have been removed, refit the wheel stud bolts
on the hub, using tools 5870 610 001 and 5870 610
002.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą25
Figure 42 Figure 44
1891263
D Fit the brake disk on the hub and centre it using the
double dowel pins.
D Fit the bolts without tightening.
The pins must be fitted with the cut
1891261 positioned as shown in the figure (cuts
D If they have been removed, refit the two dowels staggered by 180° and positioned along the
(detail). circumference).
D Fit the spacer ring in the hub.
Figure 45
Centre the spacer ring on the two dowels.
Figure 43
1891264
D Block the hub with a press and tighten the bolts to
the specified torque.
1891262
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
26ąąFRONT AXLE SECTION 12.1 ADT 25
Figure 46 Figure 48
1891267
D Using tools 5870 260 004 and 5870 051 029 fit the
sealing ring.
Apply sealant on the outer diameter of the
sealing ring.
Respect the positioning of the ring shown in
the figure.
The use of the tool makes it possible to fit the
ring in the correct axial position.
Figure 49
1891265
D Using the tools 5870 260 004 and 5870 050 003 or
5870 050 009 fit respectively the outer ring of the
taper roller bearing on the axle side (A) and the
wheel side (B).
Figure 47
1891268
D Use appropriate lifting equipment to support the
hub assembly and ensure it is centred correctly,
then slide it gently to the end of the hub support.
1891266
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą27
Figure 53
1891269
Figure 54
1731242
1891270
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
28ąąFRONT AXLE SECTION 12.1 ADT 25
Versions A and B
Figure 57
Figure 55
1891273
1891273
D Using tools 5870 656 005 and 5870 912 012 tighten
D Bed in the hub bearings as follows: the lock nut to the specified tightening torque, and
- using tools 5870 656 005 and 5870 912 012 simultaneously turn the hub forwards and
tighten the lock nut to the specified bedding-in backwards, while hitting it with a plastic hammer to
torque of 500 Nm; bed in the bearings:
- simultaneously turn the hub forwards and bearing lock nut: 1000 Nm
backwards while hitting it with a plastic hammer
to bed in the bearings; Figure 58
- bring the hub to the horizontal position, then
loosen and remove the ring nut.
Figure 56
1891272
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą29
Version C
Figure 59
Figure 61
1891275 1891273
D version A: after adjusting the bearing pre-load, D Bed in the hub bearings as follows:
lock the ring nut with the plate and locking screw. - using tools 5870 656 005 and 5870 912 012
tighten the adjustment nut to the specified
Figure 60
bedding-in torque of 500 Nm;
- simultaneously turn the hub forwards and
backwards, while hitting it with a plastic hammer
to bed in the bearings;
- bring the hub to the horizontal position, then
loosen the ring nut.
Figure 62
1891276
D version B: after adjusting the bearing pre-load,
lock the ring nut by tightening the counter ring nut
to the specified tightening torque:
bearing counter lock nut: 400 Nm
D secure the ring nuts with the stop tabs.
1891276
D Using tools 5870 656 005 and 5870 912 012 tighten
the adjustment nut to the specified tightening
torque, and simultaneously turn the hub forwards
and backwards, while hitting it with a plastic
hammer to bed in the bearings:
bearing lock nut: 100 Nm
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
30ąąFRONT AXLE SECTION 12.1 ADT 25
Figure 65
1891272
Figure 64
1731278
Figure 67
1891276
D after adjusting the bearing pre-load, lock the ring
nut by tightening the counter ring nut to the
specified tightening torque:
bearing counter lock nut: 1000 Nm
D secure the ring nuts with the stop tabs.
1731279
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą31
Figure 68 Figure 69
1731250 1731251
D Determine distance between the differential gear D Determine distance b between the hub surface and
carrier plate surface and the installed thrust spacer: the crown wheel gear surface.
dimension a
straightedge 100.00 mm
value measured 85.10 mm
distance a 14.90 mm.
dimension b
straightedge 100.00 mm
value measured 85.40 mm
distance b 14.60 mm.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
32ąąFRONT AXLE SECTION 12.1 ADT 25
Figure 70 Figure 72
1891280 1891281
D Fit the crown wheel. D Apply sealant to the contact surfaces, fit the unit to
the axle ensuring that the axle shaft correctly mates
Figure 71 with the grooves of the grooved bushing.
D Tighten the screws to the specified torque.
Figure 73
1891282
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą33
DIFFERENTIAL
Before starting any type of operation make D Using appropriate lifting equipment support the
sure all the necessary safety precautions differential external box assembly, and with a
have been taken and fully explained to those suitable screw extractor remove the assembly from
involved in the operations. the axle.
Read the relevant instructions in SECTION D Place the assembly on a supporting stand with the
1.2 of this manual. appropriate adjusting elements.
If in doubt, contact someone with more
experience. Figure 76
Always observe all the general
recommendations to carry out maintenance
jobs correctly.
Removal
Proceed as follows:
D Remove the axle shafts from the axle as described
in the previous paragraph.
Figure 74
1731255
D Remove the safety wire from the cap support
mounting screws and the ring nut locking plates.
D Remove the locking plates from both bearing
pre-load adjustment ring nuts.
1731254
D Loosen the screws that secure the differential
external box to the axle.
mark the position between box and axle
(arrow).
Figure 75
1731255
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
34ąFRONT AXLE SECTION 12.1 ADT 25
Figure 79
1731257
Figure 78
1731259
D Using special tools 5870 024 005 and 5870 002 404
1731258
remove the taper roller bearing outer track from the
D Loosen the mounting screws and remove both differential half-boxes on the crown wheel side (C)
support caps. and side pinion side (D).
mark each support cap and corresponding
Figure 80
external box (arrows).
1731260
D Loosen all the mounting screws and remove the
differential half-box.
Mark both differential half-boxes before
this operation (arrows).
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą35
Figure 81 Figure 83
1731261 1731263
D remove the thrust ring, the driven /driving disks, the D Remove the crown wheel gear, the crown wheel
crown wheel backing plate and the crown wheel backing plate, the driven and driving disks and the
gear. thrust ring.
Do not invert the position of the disks. Do not invert the position of the disks.
Pinion disassembly
Proceed as follows:
Figure 84
1731262
D Remove the side pinions group.
1731264
D Remove the split pin and loosen the crown nut with
tool 587024002.
D Remove the flange using a commercial extractor.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
36ąFRONT AXLE SECTION 12.1 ADT 25
Bearings
- check the condition of the bearings replace them
if they have blue contours, cracks and/or signs of
wear;
Side pinions
- check the state of the teeth: replace if there are
signs of pitting, cracks and/or sinking;
1731265
- check the mating surfaces with the pins;
D Remove the oil seal ring from its housing. Even if only one element is found damaged,
the complete gears assy must be replaced.
Figure 86
Crosshead pins
- check the mating surfaces with the side pinions.
Thrust rings
- check the state of the rings: replace them if they
have blue contours, cracks and/or signs of wear;
Ring nuts
- check the thread on the bearing locking ring nut:
ensure there is no denting, strain and /or seizure:
there must be no denting, strain and/or seizure;
External box
1731267
- check the bearing housings: to ensure there are no
D Using 587002600+5870026014 remove the inner signs of strain and/or ovalising;
ring of the pinion internal bearing (B). - check that the sealing surfaces and threads are
D Remove both outer tracks of the taper roller intact and are not dented or damaged.
bearings from the external box.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą37
Figure 88
1731268
Break-down drawing of self-locking differential
1. Ring bevel gear and differential half-box
2. Thrust ring
3. Driving disks (internal grooving)
4. Driven disks (external grooving)
5. Crown wheel backing plate
6. Crown wheel
7. Side pinions shaft
8. Side pinion
9. Differential half-box
10. Mounting screw
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
38ąFRONT AXLE SECTION 12.1 ADT 25
Figure 89
1731269
Break-down drawing of pinion
1. Split pin
2. Notched nut
3. Washer
4. Motion transmission flange
5. Protection ring
6. Seal ring
7. External taper roller bearing (B)
8. Bearing pre-load spacer S2
9. Pinion
10. Internal taper roller bearing (A)
11. Pinion axial position spacer S1
12. External box
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą39
Re-assembly Figure 90
When reassembling, bear in mind the
following general rules:
- heat the bearings and gears that are
assembled by pressure in an oven at
905C (194 °F);
- accurately centre the seal rings and
bearings and use the specific tool or
hammer to assemble them;
- lubricate ring nuts and bearings.
Figure 91
1731271
First operation
D Insert tools 5870500001 + 5870500006 the Example:
differential support seats and tools 5870351000 + dimension a+b: 191.80 mm (7.55 in)
5870351005 in the pinion seats.
dimension b is to be found using a thickness
D Determine distance H between the resting surfaces
gauge
of internal bearing (A) and centre of the differential
support. dimension c: 15.00 mm (15.24 mm)
(1/2 diameter of measuring shaft)
dimension H= a+b+c: 206.80 mm (8.15 in)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
40ąFRONT AXLE SECTION 12.1 ADT 25
Figure 94
1731272
1731274
Second operation
D Fit correctly sized spacer S1 in the box as previously
D Find thickness S of the internal taper roller bearing described.
(A).
Example: Figure 95
Dimension d: 90.00 mm (3.54 in)
Value measured e: 43.90 mm (1.72 in)
Bearing thickness S=d - e: 46.10 mm (1.82 in)
Figure 93
1731273
Third operation
D Find the required value depending on pinion
assembly dimension X
D Read value V engraved on the surface of the pinion
(arrow) and add it to thickness S of the bearing.
Example:engraved value V 159.90 mm (6.30 in)
Bearing thickness S 46.10 mm (1.8 in)
dimension X =V+S: 206.00 mm (8.11 in)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą41
Figure 96 Figure 98
1731278
1731276
Proceed as follows: D Position measuring tool 5870034001 on the pinion
shoulder.
Figure 97
The spring pins are to face the grooved part
of the pinion (arrow).
Make sure that the pins protrude sufficiently
so that the overall thickness of the tool is
more than the presumed thickness of
spacer S2 to be found.
Figure 99
1731277
D Heat the inner track of bearing (A) to about 90°C
(194 °F) and fit it on the pinion. Make sure it is up
against the shoulder of the pinion.
1731279
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
42ąFRONT AXLE SECTION 12.1 ADT 25
1731280 1731282
D Lock the control flange on the pinion groove. D Remove and measure the thickness of the
D Fit the slashed nut and tighten it to the specified measuring tool 587034001 using a micrometer.
torque using tool 5870240002 D The thickness found will be that for spacer S2.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą43
1731284
D Heat the taper roller bearing inner track to about
90°C (194 °F) and fit it tightly onto the differential
half-box.
Figure 105
1731283
Proceed as follows:
D Check that the contact area between crown wheel
and differential half-box is clean and free of grease.
Use only original components supplied as
spare parts.
1731285
D Tighten the bolts to the specified torque.
D At the end of the operations temporarily assemble D Position the shoulder ring with the grooved surface
the other half-box, arrange the group between the facing downwards (arrow).
two points and with a dial gauge, check that the
eccentricity is within the specified values.
maximum eccentricity: 0.08 mm (0.003 in)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
44ąFRONT AXLE SECTION 12.1 ADT 25
1731288
Figure 109
1731286
Figure 107
1731289
D Assemble the shafts and side pinion gears and fit
them on the crown wheel gear.
Figure 110
1731287
D Fit the crown wheel shoulder plate with the flat side
downwards on the top of the internally grooved
disk.
1731290
D Fit the other crown wheel gear onto the side pinion
gear assembly.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą45
Figure 113
1731291
First operation
D Find the value a between the box mounting plane
and the internally grooved plate.
Figure 114
1731294
1731292
Second operation
D Fit an internally grooved disk (driving disk) and an D Find dimension b between box and cover mounting
externally grooved disk (driven disk) alternately until plane
all the disks have been mounted. Example:
The first disk is a driving disk. dimension a: 6.00 mm (0.236 in)
dimension b: 5.80 mm (0.228 in)
Difference a ć b: 0.20 mm (0.0078 in)
(disk axial clearance)
D Check that it is within the specified values.
disk pack axial clearance
0.20P0.80 mm (0.0078P0.031 in)
D the clearance can be corrected by installing disks of
different thicknesses, providing the thickness of the
disk pack is the same on both sides.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
46ąFRONT AXLE SECTION 12.1 ADT 25
Figure 117
1731295
Figure 116 D Position spacer S2 onto the pinion shoulder, then fit
the assembled pinion in the differential box.
D Fit the bearing inner ring (B).
Figure 118
1731296
D Heat the taper roller bearing inner track to about
90Ă°C (194Ă°F) and position it against the differential
half-box until it comes into contact.
1731298
D Apply LOCTITE thread stop to the calibrated bolts.
D Join the two half-boxes and tighten the calibrated D Apply LOCTITE sealant on the outer diameter of the
bolts to the specified torque. seal ring
D Using tool 5870055074 insert the seal ring into the
Use only new calibrated bolts. differential box.
The seal ring lip is to face inwards.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą47
1731299 17312101
D Mount the flange onto the pinion. D Apply MOLYKOTE to the thread of the adjustment
D Position the washer and tighten the slashed nut to ring nut.
the specified torque using tool 587024002. D Tighten both ring nuts by hand.
D Lock the slashed nut in its seat with a split pin.
Figure 122
Finding the differential bearing pre-load
Proceed as follows:
Figure 120
17312102
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
48ąFRONT AXLE SECTION 12.1 ADT 25
Figure 125
17312103
Figure 124
17312104
Figure 126
1731281
D Using suitable tools, check that the rolling torque is
within the specified values.
total rolling torque:
1.8P2.7 Nm (1.3P2 lb ft)
The rolling torque measured includes the
torque of the pinion bearings.
D The rolling torque can be corrected by varying the
two adjustment ring nuts by the same number of
notches.
D In detail: 17312105
- loosen the ring nuts to decrease the rolling
torque;
- tighten the ring nuts to increase the rolling
torque;
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.1 ąFRONT AXLEą49
Figure 129
17312106
D cover about a dozen crown teeth with Prussian blue,
lubricated red lead or other paint or marking that
can easily be removed.
D Rotate the crown by hand in the direction shown in
the figure.
D When the teeth mesh, the paint is sent out by the
17312111B
contact of the teeth, leaving an exposed zone with
the exact dimension, shape and location of the D Support the complete external box suitable lifting
contact area (see figure on next page). equipment.
D Apply LOCTITE sealant along the joining surfaces.
D Mount the complete external box assembly onto the
axle attaining to the reference marks made when
disassembling.
D Tighten the mounting screws and lock to the
specified torque.
D Fill the axle with the indicated quantity of prescribed
lubricant up to the control oil level.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
50ąFRONT AXLE SECTION 12.1 ADT 25
Figure 130
a a a
b b b
1 2 3
1731208 1731209 1731210
156NM123
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 12.2
INTERMEDIATE AXLE
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą1
CONTENTS
Page Page
Differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Checking the dismantled parts . . . . . . . . . . . . . . . . . 40
TOOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Lockable splitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Epicyclical reduction gears . . . . . . . . . . . . . . . . . . . . 14
Self-locking differential . . . . . . . . . . . . . . . . . . . . . . . 42
Differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Location of spacers/adjustment ring nuts and
AXLE REMOVAL-REFIT . . . . . . . . . . . . . . . . . . . . . 15 relative bearings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Re-assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Refit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Finding the thickness of spacer S1 for pinion
Axle-rocker arm support-parking brake axial position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
strip down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Pinion bearing axial pre-load: nil . . . . . . . . . . . . . . 48
SPECIFIC MAINTENANCE . . . . . . . . . . . . . . . . . . . 18 Shape and position of contact area . . . . . . . . . . . . . 58
Checking axle/transfer case oil level . . . . . . . . . . . . 18
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą3
DESCRIPTION
The axle is a dual reduction bearing type. the bearings, as well as the brake caliper mounting
It consists of a box type structure that contains the flange.
bevel gear pair with the differential, the axle shafts and The axle also includes a trasnfer unit upstream of the
hubs with the end reduction. The structure has differential.
mountings to connect to the chassis and housings for
Figure 1
1891213
1. Axle
2. Axle support
3. Transfer unit
4. Brake caliper
5. Tie rod fastening bracket
6. Rocher lever fastening bracket
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 2
A B
1891230A 1891230B
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą5
The differential is self-locking. coefficient and thus holds the braking torque constant
It has a multiple disk clutch inserted between the for the whole useful life of the differential.
differential gear box (train carrier) and the crown The thrust on the disks is ensured by the sloped
wheels on each side. contact between the shaft and the pressure plate:
The multiple disk clutch includes the external disks therefore a greater radial peripheral thrust on the train
connected to the differential gear box and internal carrier shaft (from the ring bevel gear) will cause a
disks connected to the crown wheel gears by greater axial thrust on the disks.
appropriate pressure plates. The thrust on the disks generates a stall torque that
The internal disk friction surfaces have a patented acts on the crown wheel.
molybdenum coating that ensures a constant friction
Figure 3
1731214
1. Crown wheel
2. Differential gear box
3. Differential cover
4. Crown wheel gear
5. Side pinion
6. Differential gear carrier shaft
7. Bevel pinion
8. Pressure plate (quantity: 2)
9. Multiple disk clutch ć external disk
10. Multiple disk clutch ć internal disk
11. Shoulder
12. Pressure plate rings sloped surfaces
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Operation
The driving torque coming from the propeller shaft is Under these conditions there is no relative motion
transmitted by a universal joint to the bevel pinion. between the two crown wheels and therefore the side
From here the torque passes to the ring bevel gear, pinions do not turn around their shaft which is integral
which is integral to the differential gear box. to the differential gear box.
The differential is a gear for which the box represents When the resistance of one wheel is greater than that
the train carrier, that carries the differential gear carrier of the other, or when the speed of the two wheels is not
shafts and receives the driving torque, whereas the two the same (vehicle on a road with bends) the crown
side gears, which represent the crown wheels, both of wheel gears have a different rotation speed: the
which rotate, receive the driving torque and transmit it relevant motion is permitted by the side pinions, that
to the axle shafts. now turn around their shafts in directions opposite to
When both wheels are subject to the same stall torque each other.
or have the same speed (vehicle being driven on a Obviously at a lower crown wheel rotation speed the
straight road), the ring bevel gear and the differential transmitted driving torque is greater, and vice versa.
gear box rotate as one, transmitting the torque in equal Therefore when the differential is operating, the wheel
parts to the two crown wheels, and from here to the two with a lower speed can transmit a greater torque,
axle shafts, that rotate at the same speed: the wheels whereas the wheel with a higher speed can transmit a
transmit the same driving torque. lower torque.
Under certain conditions it may happen that the slower
Figure 4 wheel loses its grip completely, since the torque is
exceeded that can be transmitted to the ground, and
therefore meets practically no resistance: in this case,
the standard differential causes the wheel that slips to
freewheel, and stops the wheel that still has grip: the
axle traction is reduced to nothing.
To avoid this problem the self-locking differential is
used, which can generate a stall torque on each crown
wheel, which is no longer free to rotate in relation to the
differential gear box, but is braked in proportion to the
torque that the differential is to transmit.
This stall torque , that depends on the thrust applied to
the multiple disk clutch, always has a fixed ratio with the
input torque, that is called the locking ratio".
The locking ratio is the maximum difference between
the transmittable torque on the two axle shafts, in
percentage.
1731215
Right wheel with road grip the same as the left one
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą7
If the two wheels do not have the same grip, the stall In fact, the multiple disk clutches automatically
torque generated by the multiple disk clutches partially compensate the grip variations of the wheels from the
locks the crown wheel on the side with less grip and left and right sides of the vehicle, without the need of
increases the torque delivered by the crown wheel on any operation on the part of the driver. It is therefore
the side with stronger grip. In other words, the braking possible to apply a much higher driving force during
torque replaces the reaction torque that is lacking on the use of the vehicle, and avoid slipping when one of
the side of the wheel with less grip. the wheels runs on a surface with poor grip.
In this way, looking at the example given beforehand of For example, with a locking ratio of 45%, 72.5% of the
a wheel that loses grip, this can no longer freewheel driving torque may be transferred to a rear axle shaft
and therefore the other wheel will still be able to (instead of 50% as in normal cases), whereas the other
transmit part of the driving torque, ensuring at least in axle shaft only receives 27.5%.
part the axle traction. The differential effect produced when steering the
vehicle is caused by an overlay of the effect coming
Figure 5 from the difference in the wheel speeds at the locking
action depending on the load.
1731216
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 6
8 9 10 12 15
6 4 3 2
1.731.217A 1731217B
1. Axle Operation
2. Hub support The driving torque coming from the differential is
3. Internal taper roller bearing transmitted through a floating axle shaft to the crown
4. External taper roller bearing gear by means of a grooved shank.
5. Wheel mounting bolt The four side pinion gears rotate in the opposite
6. Epicyclic train crown gear direction to the crown gear, whereas the crown wheel
7. Pivoting roller bearing is integral to the hub support and therefore does not
8. Epicyclic train carrier turn. This makes the train carrier turn in the opposite
9. Epicyclic train side pinion gear direction to the side pinions, therefore in the same
10. Epicyclic train crown gear direction as the axle shafts.
11. Grooved shank connecting axle shaft-crown Since the train carrier is integral to the wheel hub, the
wheel wheel turns in the same direction as the axle shaft.
12. Hub
13. Brake disk
14. Seal ring
15. Axle shaft
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą9
Transfer unit
The divider unit consists of a hollow shaft" differential The output shaft from the transfer transmits the motion
and a pair of cylindrical wheels. to the rear axle, whereas the pair of wheels (with ratio
1:1) transmit the motion to the differential pinion.
Figure 7
1891231A
1. Drive input flange 11. Motion output shaft flange to rear axle
2. Drive input shaft/splitter carrier 12. Taper roller bearing
3. Bearing 13. Gear transmitting movement to pinion
4. Drive output shaft from splitter to rear axle 14. Taper roller bearing
5. Toothed coupling locking splitter 15. Crown wheel (splitter motion output to
6. Pinion taper roller bearing intermediate axle)
7. Gear transmitting movement to pinion 16. Splitter locking device
8. Pinion taper roller bearing 17. Differential gear carrier shaft
9. Bevel pinion 18. Side pinion
10. Bearing 19. Crown wheel (splitter motion output to rear axle)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
10ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 8
1891231B
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą11
Operation
The driving torque coming from the propeller shaft is When the resistance of one axle is more than that of the
transmitted by means of a universal joint to the input other, or when the speed of the two axles is no longer
shaft. the same (vehicle on a road with bends) the side gears
From here the torque passes to the transfer box. have a different rotation speed: as a consequence at a
The divider is a wheelwork in which the box is the lower side gear rotation speed a greater driving torque
train-carrier that carries the differential gear carrier is transmitted, and vice-versa.
shafts and receives the driving torque, whereas the two Therefore, when the differential is operating, the axle
side gears represent the crown wheels, both of which that has less speed can transmit a higher torque,
rotate, receive the driving torque and transmit it to the whereas that with a higher speed transmits a lesser
coaxial axle shafts. torque.
The operation is exactly the same as that of a To avoid the possibility that with a loss of grip one of the
differential between the wheels. two axles freewheels, cancelling the traction of both
When both axles are subject to the same stall torque or axles, there is a locking device of the transfer that can
have the same speed ( vehicle being driven on a be engaged.
straight road), the transfer distributes the driving torque With this device engaged, the box is integral with the
in equal parts between the axles. external side gear: in this way the entire box - side
gears - side pinions assembly rotates as a single unit
and the torque is by force divided equally between the
axles.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
12ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
DIAGNOSTIC
1. Vibrations
2. Continuous noise
3. Noise when accelerating
4. Noise when decelerating
5. Noise when cornering
6. Harsh knocks when accelerating or decelerating
7. Lubricant leakage
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą13
TIGHTENING TORQUES
AXLE
1. Hex head screws securing tie rod anchoring plate on axle 380 Nm (280 ft lb)
2. Allen screws securing tie rod anchoring plate on axle 580 Nm (428 ft lb)
3. Screws securing support and rocker bracket on axle 600 Nm (443 ft lb)
4. Rocker joint pin nut 1000 Nm (738ft lb)
5. Nut securing rocker securing bracket 600 Nm (443 ft lb)
6. Screws securing tie rod to bracket 600 Nm (443 ft lb)
Figure 9
1891215
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
14ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
TOOLS
DIFFERENTIAL
5870 024 004: Extractor to remove differential bearing inner track (differential side)
5870 024 005: Extractor to remove differential bearing inner track (crown side)
5870 027 000: Extractor base to remove bevel pinion bearing inner track
5870 027 004: Extractor to remove bevel pinion bearing inner track (to be used with 5870 027 000)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą15
AXLE REMOVAL-REFIT
. Before starting any type of operation make D disconnect the central lubrication system unions
(arrow);
sure all the necessary safety precautions
D raise the vehicle to have the wheels off the ground,
have been taken and fully explained to those
then place two supporting trestles under the rear
involved in the operations.
chassis, without touching the axles;
Read the relevant instructions in SECTION
D remove both wheels following the instructions in
1.2 of this manual.
SECTION 13.1;
If in doubt, contact someone with more
D under the intermediate and rear axles place an
experience.
appropriate hydraulic jack that allows lowering at
Always observe all the general
removal, so that at this stage the two axles remain
recommendations to carry out maintenance
more or less horizontal;
jobs correctly.
D disconnect hydraulic union of the service (30) and
parking (31) brake system;
Removal D disconnect the hydraulic (32) and electrical (35)
To remove proceed as follows: connections of the distributing differential lock
D bring the vehicle onto a suitable flat, solid surface, between the axles;
switch off the engine, remove the ignition key, D remove the input (10) and output (not shown)
engage the parking brake and apply the propeller shafts as described in Section 10;
maintenance in progress" signboards. D loosen the screws (a) securing the bracket to the tie
D cut off the battery isolator switch or disconnect the rod (2);
terminals from the battery to avoid the risk of short D on both sides, remove the split pin (b) and loosen
circuits; the fastening nut (5) of the rocker arm pin;
D lock knuckle with the steering lock bar following the D remove the rocker arm pin (4), picking up the
instructions in SECTION 1.2; washers and the bushings (6), then remove the
bearing (7), clearing the rocker arm from the axle;
D very carefully lower the axle(1) and remove it from
the vehicle.
Refit
To refit follow the removal operations in reverse order.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
16ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 10
1891216
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą17
Figure 11
1891218
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
18ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 12
156NM81
156NM80B
D clean the cap area and open cap. Lubricant should
drip out of the hole;
D if necessary, top up the level as indicated in the next
paragraph;
D close the filler cap and fasten at the specified
torque;
. Simply check one of the transfer cases on
each axle.
Figure 13
156NM80A
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą19
Proceed as follows:
Dumping
Figure 15
156NM120A
156NM82A
D transfer cases: take the drain cap on one hub to the
lowest position;
D arrange a suitably sized container, clean the cap
areas and remove the cap; drain all the lubricant;
D repeat the procedure on the other hub;
Figure 16
156NM83
D axle: arrange a suitably sized container, clean the
cap areas and remove the filler cap (b) and the drain
cap (a), drain all the lubricant;
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
20ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Filling Figure 20
Figure 18
156NM80B
156NM120A
D fill with approximately 1.5 litres of the specific
lubricant through the differential cap hole (b), then
replace the seal, apply sealant paste on the cap and
tighten it to the specified torque;
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą21
Removal
Proceed as follows:
Figure 21
1891240
Figure 22
1891250
The hub may be fitted with three different solutions for
locking the bearings.
VERSION A
1. lock nut
2. stop plate
3. pre-load adjustment spacer
1891241
VERSION B
D Loosen the screws securing the hub to the axle. 1. lock nut
Then use a suitable lifting device and remove the 2. counter lock nut
hub by sliding it carefully from the axle to avoid 3. pre-load adjustment spacer
damaging the axle shaft.
VERSION C
1. pre-load adjustment ring nut
2. counter lock nut
(spacer not included)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
22ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Disassembly
Figure 27
Figure 24
1891245
1891242 D Remove the differential gear carrier plate assembly
D Fasten the unit to the supporting tools: and take it to the work bench.
- assembly trolley 5870 350 000
- retainer 5870 350 055. Figure 28
Figure 25
1891246
Figure 26
1891247
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą23
Figure 30 Figure 32
1891251
1891248
D version A loosen the fastening screw and remove D Versions A and B: remove the spacer.
the stop plate.
Figure 33
Figure 31
1891252
1891249
D Remove the crown gear from the grooved bushing.
D Version A using tools 5870 656 005 and 5870 912
012, remove the ring nut securing the inner toothed Figure 34
gear wheel.
The ring nut is locked with thread locker.
Heat the threading to about 120 °C before
unscrewing to avoid damage.
D Versions B and C: using tools 5870 656 005 and
5870 912 012, remove both ring nuts securing the
inner toothed gear wheel.
The ring nut is locked with thread locker.
Heat the threading to about 120 °C before
unscrewing to avoid damage.
1891253
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
24ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 35 Figure 37
1731228 1731231
D Remove the retaining snap ring and separate the D Remove the sealing ring from the hub support.
gear wheel from its flange. D Remove the taper roller bearing inner track , axle
side.
Figure 36
Figure 38
1731232
1891255
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą25
Axle shafts
D check the condition of the axle shafts, replace them
if there are signs of strain on the end grooves and/or
over the whole length;
Final reductions
1891256
D check the condition of the gear teeth: replace if
D Using a suitable plug and a press, remove the brake there are signs of pitting, cracks and/or sinking;
disk from the hub. D check that the side pinions and needle bushings
D If necessary remove the stud bolts that fasten the function correctly;
wheels from the hub, using a press. D check the thread on the bearing lock ring nut:
ensure there is no denting, strain and/or seizure;
Figure 41
Re-assembly
Proceed as follows:
1891257 Figure 42
D Remove the grooved bushing (1) and the spacer
ring (2) from the hub.
1891260
D If they have been removed, refit the wheel stud bolts
on the hub, using tools 5870 610 001 and 5870 610
002.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
26ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 43 Figure 45
1891263
D Fit the brake disk on the hub and centre it using the
double dowel pins.
D Fit the bolts without tightening.
The pins must be fitted with the cut
1891261 positioned as shown in the figure (cuts
D If they have been removed, refit the two dowels staggered by 180° and positioned along the
(detail). circumference).
D Fit the spacer ring in the hub.
Figure 46
Centre the spacer ring on the two dowels.
Figure 44
1891264
D Block the hub with a press and tighten the bolts to
the specified torque.
1891262
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą27
Figure 47 Figure 49
1891267
D Using tools 5870 260 004 and 5870 051 029 fit the
sealing ring.
Apply sealant on the outer diameter of the
sealing ring.
Respect the positioning of the ring shown in
the figure.
The use of the tool makes it possible to fit the
ring in the correct axial position.
Figure 50
1891265
D Using the tools 5870 260 004 and 5870 050 003 or
5870 050 009 fit respectively the outer ring of the
taper roller bearing on the axle side (A) and the
wheel side (B).
Figure 48
1891268
D Use appropriate lifting equipment to support the
hub assembly and ensure it is centred correctly,
then slide it gently to the end of the hub support.
1891266
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
28ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 54
1891269
Figure 55
1731242
1891270
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą29
Versions A and B
Figure 58
Figure 56
1891273
1891273
D Using tools 5870 656 005 and 5870 912 012 tighten
D Bed in the hub bearings as follows: the lock nut to the specified tightening torque, and
- using tools 5870 656 005 and 5870 912 012 simultaneously turn the hub forwards and
tighten the lock nut to the specified bedding-in backwards, while hitting it with a plastic hammer to
torque of 500 Nm; bed in the bearings:
- simultaneously turn the hub forwards and bearing lock nut: 1000 Nm
backwards while hitting it with a plastic hammer
to bed in the bearings; Figure 59
- bring the hub to the horizontal position, then
loosen and remove the ring nut.
Figure 57
1891272
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
30ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Version C
Figure 60
Figure 62
1891275 1891273
D version A: after adjusting the bearing pre-load, D Bed in the hub bearings as follows:
lock the ring nut with the plate and locking screw. - using tools 5870 656 005 and 5870 912 012
tighten the adjustment nut to the specified
Figure 61
bedding-in torque of 500 Nm;
- simultaneously turn the hub forwards and
backwards, while hitting it with a plastic hammer
to bed in the bearings;
- bring the hub to the horizontal position, then
loosen the ring nut.
Figure 63
1891276
D version B: after adjusting the bearing pre-load,
lock the ring nut by tightening the counter ring nut
to the specified tightening torque:
bearing counter lock nut: 400 Nm
D secure the ring nuts with the stop tabs.
1891276
D Using tools 5870 656 005 and 5870 912 012 tighten
the adjustment nut to the specified tightening
torque, and simultaneously turn the hub forwards
and backwards, while hitting it with a plastic
hammer to bed in the bearings:
bearing lock nut: 100 Nm
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą31
Figure 66
1891272
Figure 65
1731278
Figure 68
1891276
D after adjusting the bearing pre-load, lock the ring
nut by tightening the counter ring nut to the
specified tightening torque:
bearing counter lock nut: 1000 Nm
D secure the ring nuts with the stop tabs.
1731279
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
32ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 69 Figure 70
1731250 1731251
D Determine distance between the differential gear D Determine distance b between the hub surface and
carrier plate surface and the installed thrust spacer: the crown wheel gear surface.
dimension a
straightedge 100.00 mm
value measured 85.10 mm
distance a 14.90 mm.
dimension b
straightedge 100.00 mm
value measured 85.40 mm
distance b 14.60 mm.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą33
Figure 71 Figure 73
1891280 1891281
D Fit the crown wheel. D Apply sealant to the contact surfaces, fit the unit to
the axle ensuring that the axle shaft correctly mates
Figure 72 with the grooves of the grooved bushing.
D Tighten the screws to the specified torque.
Figure 74
1891282
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
34ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Removal
Proceed as follows:
D Follow the instructions described in the relevant
chapter, and remove the final reduction units from
the axle, then the axle shafts. 1891291
Figure 77
1891292
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą35
Differential disassembly
Figure 78
Proceed as follows:
Figure 80
1891293
Figure 79
1731259
1731260
D Loosen all the securing screws and remove the difĆ
ferential half-box.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
36ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 82 Figure 84
1731261 1731263
D Remove the thrust ring, the driven/driving disks, the D Remove the crown wheel gear, the crown wheel
crown wheel backing plate, and the crown wheel. backing plate, the driven and driving disks and the
thrust ring.
. Do not invert the position of the disks.
. Do not invert the position of the disks.
Figure 83 D If necessary, remove the hex-head screws securĆ
ing the crown gear.
D Knock lightly to separate the ring bevel gear from
the differential half-box.
Splitter disassembly
Proceed as follows:
Figure 85
1731262
D Remove the side pinions group.
1891295
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą37
Figure 86 Figure 89
1891296
Figure 87
1891299
D Make a reference mark on the splitter half-boxes.
D Loosen the securing screws, separate the two
splitter half-boxes and remove the components:
(1) carrier with side pinions and thrust washers (2)
crown wheel (3) with thrust washer.
Figure 90
1891297
Figure 88
18912100
1891298
D Remove the splitter assembly from the adapter box.
D Remove the support flange complete with bearing
from the splitter.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
38ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 91 Figure 93
18912101
18912103
D Remove the gearbox fork and the control rod.
D Remove the taper roller bearing inner ring (1) and
. During this operation, push the control rod spacer (2).
gently downwards to disengage the fork.
Figure 94
D Remove the sliding collar.
Figure 92
18912104
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą39
Figure 95 Figure 97
18912107
D Loosen the securing screws and remove the cover
on the bevel pinion securing nut.
18912105 Figure 98
D Loosen the internal (detail) and external securing
screws and separate the adapter box from the difĆ
ferential box housing.
Figure 96
18912107A
Figure 99
18912106
18912108
D Using tool 5870 000 065, extract the support flange
complete with bevel pinion from the box.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
40ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Crown wheels
- check the state of the teeth: replace if there are
signs of pitting, cracks and/or sinking;
Side pinions
- check the state of the teeth: replace if there are
signs of pitting, cracks and/or sinking;
- check the mating surfaces with the pins;
Damage to even one element means that the
18912109 whole gear assembly must be replaced.
D Recover the taper roller bearing inner ring (1) and
spacer (2). Crosshead pins
Figure 101 - check the mating surfaces with the side pinions;
Thrust rings
- check the state of the rings: replace them if they
have blue contours, cracks and/or signs of wear;
Ring nuts
- check the thread on the bearing lock nut: there must
be no denting, strain and/or seizure;
External box
- check the bearing seats: to ensure there are no
signs of strain and/or ovalising;
- check that the sealing surfaces and threads are inĆ
tact and are not dented or damaged.
18912111
D Using the tool 5870 027 000 and 5870 027 004, exĆ
tract the taper roller bearing inner ring from the
bevel pinion.
D Remove both outer tracks of the taper roller bearĆ
ings from the external box.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą41
Lockable splitter
Figure 103
1. Motion input flange 14. Driving spur gear
2. Ball bearing support flange 15. Splitter support outer bearing (F)
3. Ball bearing 16. Splitter bearings lock nut
4. Differential half-box 17. Bevel pinion bearing lock nut
5. Crown wheel 18. Bevel pinion outer bearing (B)
6. Side pinion 19. Splitter box
7. Side pinion shaft 20. Driven spur gear
8. Splitter lock control fork 21. Bevel pinion bearing support flange
9. Splitter lock control device 22. Bevel pinion inner bearing (A)
10. Splitter lock sliding sleeve 23. Bevel pinion
11. Crown wheel (shaft) 24. Motion output flange ball bearing
12. Splitter support inner bearing (E) 25. Seal
13. Splitter housing 26. Motion output flange shaft
18912112
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
42ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Self-locking differential
Figure 104
1. Differential half-box 10. Securing screw
2. Thrust ring 11. Differential carrier
3. Driving disks (internal splines) 12. Ring bevel gear
4. Driven disks (external splines) 13. Differential bearing on crown gear side (C)
5. Crown wheels backing plate 14. Adjustment ring nut
6. Crown wheel 15. Differential bearing on side opposite crown gear
7. Side pinions shaft (D)
8. Side pinion 16. Support cap
9. Differential half-box
18912113
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą43
Figure 105
S1 spacer for bevel pinion axial position A. Bevel pinion inner bearing
S2: spacer for bevel pinion taper roller bearing B. Bevel pinion outer bearing
pre-load C. Differential bearing crown gear side
S3: spacer for splitter taper roller bearing pre-load D. Differential bearing on side opposite crown
S4: spacer for splitter end play gear
GH: ring nuts for taper roller bearing pre-load/ring E. Splitter support inner bearing
bevel gear axial position F. Splitter support outer bearing
18912114
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
44ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Re-assembly D Use tools 5870 500 001 and 5870 500 021 to
measure the distance A from the differential axis to
When reassembling, bear in mind the followĆ the flange surface.
ing general rules: D Measure distance B from the flange surface to the
D heat the bearings and gears that are presĆ bearing contact surface.
sure-assembled in an oven at 90°C; D Measure bearing width C.
D accurately centre the sealing rings and D Calculate distance X between pinion and differential
bearings, and fit them with the specific tool axis by using the following formula:
or hammer; X = A+B-C
D lubricate ring nuts and bearings. D Read value V cut in the pinion surface (arrow).
D Calculate the thickness of spacer S1 by using the
following formula:
Carry out all the measuring procedures indiĆ S1 = X - V
cated with the utmost precision.
Incorrect measurements can lead to poor Example:
functioning of the unit.
Distance A 164.20 mm
Distance B 25.75 mm
Finding the thickness of spacer S1 for pinion axial Bearing width C 37.05 mm
position Gives X = A+B-C = 152.90 mm
Proceed as follows: Value V 151.80 mm
D Fit the differential bearing support cap according to Gives S1 = X-V = 1.10 mm
the reference marks made during disassembly.
Figure 106
18912115
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą45
18912116 18912118
D Install shim S1, determined according to the forĆ D Fit the bearing pre-assembled support on the
mula, and the outer track of bearing (A) in the supĆ bevel pinion.
port flange.
Wear protective gloves when handling hot
Figure 108 components.
D Heat the driven spur gear and fit it.
Position the gear with the chamfered side
facing the pinion.
Figure 110
18912117
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
46ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 111
18912121
D Measure the end play G of the bevel pinion with a
dial gauge.
D Find the thickness S2 definitive of the spacer by apĆ
plying the following formula:
S2definitive= S2trial ć (G + 0.02/0.04) mm
to obtain the value of the specified axial pre-load:
18912119 Pinion bearing axial pre-load: 2ć3 Nm
D Fit the selected spacer, then tighten the hexagonal
D Install the pre-load adjustment spacer (1) with
nut to the specified torque.
thickness S2trial so as to give a certain end play.
Splitter assembly
Wear protective gloves when handling hot
components. Proceed as follows:
D Fit both outer rings of bearings (E) and (F) in the
D Heat the inner ring (2) of bearing (B) and fit it. housing.
Figure 112 Figure 114
18912120 18912122
D Fit the hexagonal nut and tighten it to the specified D Insert the driving spur gear with the long hub facing
torque. downwards.
Position the gear with the long hub facing
downwards - output flange side.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą47
Figure 117
18912123
D Apply sealant to the mounting surface taking care
to apply it to the outside of the holes. 18912125
D Install the housing on the box. D Install the pre-load adjustment spacer (1) with
D Tighten the outer and inner (detail) securing screws thickness S3trial so as to give a certain end play.
to the specified tightening torque.
Apply thread-lock to the securing screws. Wear protective gloves when handling hot
components.
Figure 116 D Heat the inner ring (2) of bearing (F) and fit it.
Figure 118
18912124
18912126
Wear protective gloves when handling hot
components. D Fit the hexagonal nut and tighten it to the specified
torque.
D Heat the inner ring of bearing (E) and fit it on the
crown wheel (shaft).
D Fit the crown wheel (shaft) and mate with driving
gear.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
48ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Splitter completion
Figure 119
Proceed as follows:
Figure 120
18912127
18912129
D Fit the gearbox fork inserting the sliding pads in the
gearbox collar.
Figure 122
18912130
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą49
18912100
Figure 126
18912131
18912133
D Check that the play for the side pinion group is withĆ
in the specified values.
Side pinion group play: 0.15 - 0.20 mm.
D If it is not, use thrust washers with a suitable thickĆ
ness.
D Observing the reference marks made during disasĆ
sembly, refit the second splitter half-box and
tighten the securing screws to the specified torque.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
50ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Proceed as follows:
D Fit the ball bearing in the support flange.
Figure 127
18912134
18912135
D Measure distance A between the cover resting
surface and the bearing shoulder.
D Measure distance B between the flange resting
surface and the bearing side.
D Find the thickness of spacer S4 with the following
formula:
S4 = A ć B - 0.20 mm
to obtain the specified value of the end play.
Splitter end play: 0.20 mm
Example:
Distance A 6.5 mm
Distance B 5.0 mm
Gives S4 = A-B-0.20 mm = 1.30 mm
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą51
18912140 18912142
D Install the seal on the cover using a suitable pad in D Fit the differential lock adjustment screw.
the direction indicated. D Activate the lock with compressed air and simultaĆ
neously tighten the adjustment screw until contact
Figure 130 is made with the control rod. From this point, tighten
the adjustment screw another 1/3 of a turn, approx.
and lock it with a lock nut.
Apply thread-lock to the adjustment screw.
Figure 132
S4
18912141
D Insert spacer S4, selected previously, in the cover.
D Install the cover according to the reference marks
and tighten the securing screws.
18912143
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
52ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 133
1731284
D Heat the inner track of the taper roller bearing at apĆ
18912144
prox. 90°C and fit it completely in the differential
Proceed as follows: half-box.
D Check that the contact area between gear wheel
and differential half-box is clean and free of grease. Figure 135
D Tighten the bolts to the specified torque.
D At the end of the operations temporarily fit the other
half-box, arrange the group between the two
points and with a dial gauge, check that the eccenĆ
tricity is within the specified values.
maximum eccentricity: 0.08 mm
1731285
D Position the thrust ring with the splined surface
facing downwards (arrow).
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą53
1731288
Figure 139
1731286
D Fit an externally splined disk (driven disk) and an inĆ
ternally splined disk (driving disk) alternately until all
the disks have been mounted.
The last disk is a driving disk.
Figure 137
1731289
D Assemble the shafts and side pinion gears and fit
them on the crown wheel.
Figure 140
1731287
D Fit the crown wheel backing plate with the flat side
downwards on the top of the internally splined disk.
1731290
D Fit the other crown wheel gear onto the side pinion
gear group.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
54ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 143
1731291
D Fit the other crown wheel backing plate with the flat
side upwards. 1731293
Figure 144
1731294
D Measure distance b between the box and the cover
attachment surface
1731292 Example:
distance a: 6.00 mm
D Fit an internally splined disk (driving disk) and an exĆ distance b: 5.80 mm
ternally splined disk (driven disk) alternately until all Difference a ć b: 0.20 mm (disk end play)
the disks have been mounted. D Check that the end play is within the specified vaĆ
lues.
The first disk is a driving disk.
disk pack end play: 0.20-0.80 mm
D the play can be corrected by installing disks of differĆ
ent thicknesses, providing the thickness of the disk
pack is the same on both sides.
It is recommended to keep as close as possĆ
ible to the lowest value.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą55
Figure 147
1731295
Figure 148
1731296
D Heat the inner track of the taper roller bearing at apĆ 18912146
prox. 90°C and move it towards the differential
half-box until it comes into contact. D Position both outer tracks of the taper roller bearing.
D Apply LOCTITE thread-lock to the calibrated bolts. D Fit the differential in the relative box.
D Join the two half-boxes and tighten the calibrated
Figure 149
bolts to the specified torque.
Use only new calibrated bolts.
18912147
D Apply MOLYKOTE to the threading of the adjustĆ
ment ring nuts.
D Tighten both adjustment ring nuts by hand.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
56ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
18912150
18912148
D If this is not the case, adjust by means of the adjustĆ
D Align the reference marks and fit the bearing supĆ ment ring nuts.
port cap on crown gear side. D ù The play can be adjusted without altering the
D Tighten the securing screws to the specified torque. bearings pre-load, by unscrewing one adjustment
ring nut by a certain number of notches and then
Figure 151
screwing the opposite adjustment ring nut by the
same number of notches.
In particular:
- to decrease the play tighten the ring nut (GH1)
and loosen the ring nut (GH2);
- to increase the play loosen the ring nut (GH1)
and tighten the ring nut (GH2).
D Tighten the adjustment ring nut by two notches on
the side opposite the crown gear in order to apply
a pre-load of 3 - 4 Nm.
D The pre-load can be corrected by adjusting both
adjustment ring nuts by the same number of
notches.
In particular:
18912149
- to decrease the pre-load loosen the ring nuts;
- to increase the pre-load tighten the ring nuts.
D Fit a dial gauge at a right angle to the outer diameter
of the crown gear flank and sway the crown forĆ
wards and backwards taking care not to move the
pinion.
D Check that the play between crown and pinion is
within the specified values.
crown-pinion play: 0.25-0.35 mm
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.2 INTERMEDIATE AXLEą57
Figure 153
18912152
18912151 D Apply LOCTITE sealant along the joining surfaces.
D cover a dozen teeth of the crown gear with Prussian D Fit the cover of the nut securing the pinion and
blue, lubricated minium or any other paint or dye tighten the securing screws to the specified torque.
that is easily removable.
Figure 155
D Rotate the crown by hand in the direction shown in
the figure.
D When the teeth mesh, the paint is expelled by the
contact of the teeth, leaving an exposed zone with
the exact dimension, shape and location of the conĆ
tact area (see figure on next page).
D Once all the adjustments and configurations are
correct, secure both adjustment ring nuts.
D Lock the screws securing the bearing support cap
with safety wire.
18912153
D Support the complete external box with suitable liftĆ
ing equipment.
D Apply LOCTITE sealant along the joining surfaces.
D Mount the complete external box assembly onto the
axle keeping to the reference marks made when
disassembling.
D Tighten the securing screws and tighten to the
specified torque.
D Fill the axle with the indicated quantity of prescribed
lubricant up to the control oil level.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
58ąINTERMEDIATE AXLE SECTION 12.2 ADT 25
Figure 156
18912154
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 12.3
REAR AXLE
ADT 25 SECTION 12.3 REAR AXLEą1
CONTENTS
Page Page
DIAGNOSTIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
TIGHTENING TORQUE . . . . . . . . . . . . . . . . . . . . . . 11
Checking the dismantled parts . . . . . . . . . . . . . . . . . 22
Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Re-assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Epicyclical reduction gears . . . . . . . . . . . . . . . . . . . . 12
Differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 DIFFERENTIAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
TOOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Checking the dismantled parts . . . . . . . . . . . . . . . . . 34
Epicyclical reduction gears . . . . . . . . . . . . . . . . . . . . 12
Break-down drawing of self-locking
Differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
AXLE REMOVAL-REFIT . . . . . . . . . . . . . . . . . . . . . 13 Break-down drawing of pinion . . . . . . . . . . . . . . . . 36
Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Re-assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Refit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Axle-knuckle hinge strip down . . . . . . . . . . . . . . . . 15
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąREAR AXLE SECTION 12.3 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 REAR AXLEą3
DESCRIPTION
The axle is a dual reduction bearing type. mountings to connect to the chassis and housings for
It consists of a box type structure that contains the the bearings, as well as the brake calliper mounting
bevel gear pair with the differential, the axle shafts and flange.
hubs with the end reduction. The structure has
Figure 1
1891221
1. Axle
2. Axle support
3. Driven torque input flange
4. Brake caliper
5. Tie rod fastening bracket
6. Rocher lever fastening bracket
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąREAR AXLE SECTION 12.3 ADT 25
Figure 2
3
4
16
5 A
15 6
13
B
12 11 10 9 8
1731213A 1731213B
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 REAR AXLEą5
The differential is self-locking. coefficient and thus holds the braking torque constant
It has a multiple disk clutch inserted between the for the whole useful life of the differential.
differential gear box (train carrier) and the crown The thrust on the disks is ensured by the sloped
wheels on each side. contact between the shaft and the pressure plate:
The multiple disk clutch includes the external disks therefore a greater radial peripheral thrust on the train
connected to the differential gear box and internal carrier shaft (from the ring bevel gear) will cause a
disks connected to the crown wheel gears by greater axial thrust on the disks.
appropriate pressure plates. The thrust on the disks generates a stall torque that
The internal disk friction surfaces have a patented acts on the crown wheel.
molybdenum coating that ensures a constant friction
Figure 3
1731214
1. Crown wheel
2. Differential gear box
3. Differential cover
4. Crown wheel gear
5. Side pinion
6. Differential gear carrier shaft
7. Bevel pinion
8. Pressure plate (quantity: 2)
9. Multiple disk clutch ć external disk
10. Multiple disk clutch ć internal disk
11. Shoulder
12. Pressure plate rings sloped surfaces
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąREAR AXLE SECTION 12.3 ADT 25
1731215
Right wheel with road grip the same as the left one
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 REAR AXLEą7
If the two wheels do not have the same grip, the stall In fact, the multiple disk clutches automatically
torque generated by the multiple disk clutches partially compensate the grip variations of the wheels from the
locks the crown wheel on the side with less grip and left and right sides of the vehicle, without the need of
increases the torque delivered by the crown wheel on any operation on the part of the driver. It is therefore
the side with stronger grip. In other words, the braking possible to apply a much higher driving force during
torque replaces the reaction torque that is lacking on the use of the vehicle, and avoid slipping when one of
the side of the wheel with less grip. the wheels runs on a surface with poor grip.
In this way, looking at the example given beforehand of For example, with a locking ratio of 45%, 72.5% of the
a wheel that loses grip, this can no longer freewheel driving torque may be transferred to a rear axle shaft
and therefore the other wheel will still be able to (instead of 50% as in normal cases), whereas the other
transmit part of the driving torque, ensuring at least in axle shaft only receives 27.5%.
part the axle traction. The differential effect produced when steering the
vehicle is caused by an overlay of the effect coming
Figure 5 from the difference in the wheel speeds at the locking
action depending on the load.
1731216
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąREAR AXLE SECTION 12.3 ADT 25
Figure 6
8 9 10 12 15
6 4 3 2
1731217A 1731217B
1. Axle Operation
2. Hub support The driving torque coming from the differential is
3. Internal taper roller bearing transmitted through a floating axle shaft to the crown
4. External taper roller bearing gear by means of a grooved shank.
5. Wheel mounting bolt The four side pinion gears rotate in the opposite
6. Epicyclic train crown gear direction to the crown gear, whereas the crown wheel
7. Pivoting roller bearing is integral to the hub support and therefore does not
8. Epicyclic train carrier turn. This makes the train carrier turn in the opposite
9. Epicyclic train side pinion gear direction to the side pinions, therefore in the same
10. Epicyclic train crown gear direction as the axle shafts.
11. Grooved shank connecting axle shaft-crown Since the train carrier is integral to the wheel hub, the
wheel wheel turns in the same direction as the axle shaft.
12. Hub
13. Brake disk
14. Seal ring
15. Axle shaft
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 REAR AXLEą9
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
10ąREAR AXLE SECTION 12.3 ADT 25
DIAGNOSTIC
1. Vibrations
2. Continuous noise
3. Noise when accelerating
4. Noise when decelerating
5. Noise when cornering
6. Harsh knocks when accelerating or decelerating
7. Lubricant leakage
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 REAR AXLEą11
TIGHTENING TORQUES
AXLE
1. Hex head screws securing tie rod anchoring plate on axle 380 Nm (280 ft lb)
2. Allen screws securing tie rod anchoring plate on axle 580 Nm (428 ft lb)
3. Screws securing support and rocker bracket on axle 600 Nm (443 ft lb)
4. Rocker joint pin nut 1000 Nm (738 ft lb)
5. Nut securing rocker securing bracket 600 Nm (443 ft lb)
6. Screws securing tie rod to bracket 600 Nm (443 ft lb)
Figure 7
1891223
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
12ąREAR AXLE SECTION 12.3 ADT 25
DIFFERENTIAL
Motion input flange mounting nut: 600 Nm (441 lb ft)
Bolts securing ring bevel gear to differential half-box: 125 Nm ( 92 lb ft)
Calibrated bolts securing differential half-boxes: 110 Nm ( 81 lb ft)
Screws securing differential bearing support caps: 295 Nm (217 lb ft)
Oil level cap 150 Nm (110 lb ft)
Oil drainage cap 150 Nm (110 lb ft)
TOOLS
DIFFERENTIAL
5870 024 004: Extractor to remove differential bearing inner track (differential side)
5870 024 005: Extractor to remove differential bearing inner track (crown side)
5870 405 003: Riveting kit complete
to use only with drill 5870 101 007
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 REAR AXLEą13
AXLE REMOVAL-REFIT
. Before starting any type of operation make D remove both wheels following the instructions in
SECTION 13.1;
sure all the necessary safety precautions
D under the front axle place an appropriate hydraulic
have been taken and fully explained to those
jack that allows lowering at removal;
involved in the operations.
D disconnect the braking system hydraulic union (30);
Read the relevant instructions in SECTION
D remove the propeller shaft (10) as described in
1.2 of this manual.
Section 10;
If in doubt, contact someone with more
D loosen the screws (a) securing the bracket to the tie
experience.
rod (2);
Always observe all the general
D on both sides, remove the split pin (b) and loosen
recommendations to carry out maintenance
the fastening nut (5) of the rocker arm pin;
jobs correctly.
D remove the rocker arm pin (4), picking up the
washers and the bushings (6), then remove the
Removal bearing (7), clearing the rocker arm from the axle;
To remove proceed as follows: D very carefully lower the axle(1) and remove it from
D bring the vehicle onto a suitable flat, solid surface, the vehicle.
switch off the engine, remove the ignition key,
engage the parking brake and apply the warning Refit
signboards. To refit follow the removal operations in reverse order.
D cut off the battery isolator switch or disconnect the
terminals from the battery to avoid the risk of short
circuits;
D lock knuckle with the steering lock bar following the
instructions in SECTION 1.2;
D disconnect the central lubrication system unions
(arrow);
D raise the vehicle to have the wheels off the ground,
then place two supporting trestles under the front
chassis, without touching the axle (1);
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
14ąREAR AXLE SECTION 12.3 ADT 25
Figure 8
1731209
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 REAR AXLEą15
Figure 9
1891226
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
16ąREAR AXLE SECTION 12.3 ADT 25
Figure 10
156NM81
156NM80B
D clean the cap area and open cap. Lubricant should
drip out of the hole;
D if necessary, top up the level as indicated in the next
paragraph;
D close the filler cap and fasten at the specified
torque;
. Simply check one of the transfer cases on
each axle.
Figure 11
156NM80A
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 REAR AXLEą17
Proceed as follows:
Dumping
Figure 13
156NM120A
156NM82A
D transfer cases: take the drain cap on one hub to the
lowest position;
D arrange a suitably sized container, clean the cap
areas and remove the cap; drain all the lubricant;
D repeat the procedure on the other hub;
Figure 14
156NM83
D axles: arrange a suitably sized container, clean the
cap areas and remove the filler cap (b) and the drain
cap (a), drain all the lubricant;
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
18ąąREAR AXLE SECTION 12.3 ADT 25
Removal
Proceed as follows:
Figure 16
1891240
Figure 17
1891250
The hub may be fitted with three different solutions for
locking the bearings.
VERSION A
1. lock nut
2. stop plate
3. pre-load adjustment spacer
1891241
VERSION B
D Loosen the screws securing the hub to the axle. 1. lock nut
Then use a suitable lifting device and remove the 2. counter lock nut
hub by sliding it carefully from the axle to avoid 3. pre-load adjustment spacer
damaging the axle shaft.
VERSION C
1. pre-load adjustment ring nut
2. counter lock nut
(spacer not included)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą19
Disassembly
Figure 22
Figure 19
1891245
1891242 D Remove the differential gear carrier plate assembly
D Fasten the unit to the supporting tools: and take it to the work bench.
- assembly trolley 5870 350 000
- retainer 5870 350 055. Figure 23
Figure 20
1891246
Figure 21
1891247
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
20ąąREAR AXLE SECTION 12.3 ADT 25
Figure 25 Figure 27
1891251
1891248
D version A loosen the fastening screw and remove D Versions A and B: remove the spacer.
the stop plate.
Figure 28
Figure 26
1891252
1891249
D Remove the crown gear from the grooved bushing.
D Version A using tools 5870 656 005 and 5870 912
012, remove the ring nut securing the inner toothed Figure 29
gear wheel.
The ring nut is locked with thread locker.
Heat the threading to about 120 °C before
unscrewing to avoid damage.
D Versions B and C: using tools 5870 656 005 and
5870 912 012, remove both ring nuts securing the
inner toothed gear wheel.
The ring nut is locked with thread locker.
Heat the threading to about 120 °C before
unscrewing to avoid damage.
1891253
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą21
Figure 30 Figure 32
1731228 1731231
D Remove the retaining snap ring and separate the D Remove the sealing ring from the hub support.
gear wheel from its flange. D Remove the taper roller bearing inner track , axle
side.
Figure 31
Figure 33
1731232
1891255
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
22ąąREAR AXLE SECTION 12.3 ADT 25
Axle shafts
D check the condition of the axle shafts, replace them
if there are signs of strain on the end grooves and/or
over the whole length;
Final reductions
1891256
D check the condition of the gear teeth: replace if
D Using a suitable plug and a press, remove the brake there are signs of pitting, cracks and/or sinking;
disk from the hub. D check that the side pinions and needle bushings
D If necessary remove the stud bolts that fasten the function correctly;
wheels from the hub, using a press. D check the thread on the bearing lock ring nut:
ensure there is no denting, strain and/or seizure;
Figure 36
Re-assembly
Proceed as follows:
1891257 Figure 37
D Remove the grooved bushing (1) and the spacer
ring (2) from the hub.
1891260
D If they have been removed, refit the wheel stud bolts
on the hub, using tools 5870 610 001 and 5870 610
002.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą23
Figure 38 Figure 40
1891263
D Fit the brake disk on the hub and centre it using the
double dowel pins.
D Fit the bolts without tightening.
The pins must be fitted with the cut
1891261 positioned as shown in the figure (cuts
D If they have been removed, refit the two dowels staggered by 180° and positioned along the
(detail). circumference).
D Fit the spacer ring in the hub.
Figure 41
Centre the spacer ring on the two dowels.
Figure 39
1891264
D Block the hub with a press and tighten the bolts to
the specified torque.
1891262
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
24ąąREAR AXLE SECTION 12.3 ADT 25
Figure 42 Figure 44
1891267
D Using tools 5870 260 004 and 5870 051 029 fit the
sealing ring.
Apply sealant on the outer diameter of the
sealing ring.
Respect the positioning of the ring shown in
the figure.
The use of the tool makes it possible to fit the
ring in the correct axial position.
Figure 45
1891265
D Using the tools 5870 260 004 and 5870 050 003 or
5870 050 009 fit respectively the outer ring of the
taper roller bearing on the axle side (A) and the
wheel side (B).
Figure 43
1891268
D Use appropriate lifting equipment to support the
hub assembly and ensure it is centred correctly,
then slide it gently to the end of the hub support.
1891266
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą25
Figure 49
1891269
Figure 50
1731242
1891270
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
26ąąREAR AXLE SECTION 12.3 ADT 25
Versions A and B
Figure 53
Figure 51
1891273
1891273
D Using tools 5870 656 005 and 5870 912 012 tighten
D Bed in the hub bearings as follows: the lock nut to the specified tightening torque, and
- using tools 5870 656 005 and 5870 912 012 simultaneously turn the hub forwards and
tighten the lock nut to the specified bedding-in backwards, while hitting it with a plastic hammer to
torque of 500 Nm; bed in the bearings:
- simultaneously turn the hub forwards and bearing lock nut: 1000 Nm
backwards while hitting it with a plastic hammer
to bed in the bearings; Figure 54
- bring the hub to the horizontal position, then
loosen and remove the ring nut.
Figure 52
1891272
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą27
Version C
Figure 55
Figure 57
1891275 1891273
D version A: after adjusting the bearing pre-load, D Bed in the hub bearings as follows:
lock the ring nut with the plate and locking screw. - using tools 5870 656 005 and 5870 912 012
tighten the adjustment nut to the specified
Figure 56
bedding-in torque of 500 Nm;
- simultaneously turn the hub forwards and
backwards, while hitting it with a plastic hammer
to bed in the bearings;
- bring the hub to the horizontal position, then
loosen the ring nut.
Figure 58
1891276
D version B: after adjusting the bearing pre-load,
lock the ring nut by tightening the counter ring nut
to the specified tightening torque:
bearing counter lock nut: 400 Nm
D secure the ring nuts with the stop tabs.
1891276
D Using tools 5870 656 005 and 5870 912 012 tighten
the adjustment nut to the specified tightening
torque, and simultaneously turn the hub forwards
and backwards, while hitting it with a plastic
hammer to bed in the bearings:
bearing lock nut: 100 Nm
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
28ąąREAR AXLE SECTION 12.3 ADT 25
Figure 61
1891272
Figure 60
1731278
Figure 63
1891276
D after adjusting the bearing pre-load, lock the ring
nut by tightening the counter ring nut to the
specified tightening torque:
bearing counter lock nut: 1000 Nm
D secure the ring nuts with the stop tabs.
1731279
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą29
Figure 64 Figure 65
1731250 1731251
D Determine distance between the differential gear D Determine distance b between the hub surface and
carrier plate surface and the installed thrust spacer: the crown wheel gear surface.
dimension a
straightedge 100.00 mm
value measured 85.10 mm
distance a 14.90 mm.
dimension b
straightedge 100.00 mm
value measured 85.40 mm
distance b 14.60 mm.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
30ąąREAR AXLE SECTION 12.3 ADT 25
Figure 66 Figure 68
1891280 1891281
D Fit the crown wheel. D Apply sealant to the contact surfaces, fit the unit to
the axle ensuring that the axle shaft correctly mates
Figure 67 with the grooves of the grooved bushing.
D Tighten the screws to the specified torque.
Figure 69
1891282
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą31
DIFFERENTIAL
Before starting any type of operation make D Using appropriate lifting equipment support the
sure all the necessary safety precautions differential external box assembly, and with a
have been taken and fully explained to those suitable screw extractor remove the assembly from
involved in the operations. the axle.
Read the relevant instructions in SECTION D Place the assembly on a supporting stand with the
1.2 of this manual. appropriate adjusting elements.
If in doubt, contact someone with more
experience. Figure 72
Always observe all the general
recommendations to carry out maintenance
jobs correctly.
Removal
Proceed as follows:
D Remove the axle shafts from the axle as described
in the previous paragraph.
Figure 70
1731255
D Remove the safety wire from the cap support
mounting screws and the ring nut locking plates.
D Remove the locking plates from both bearing
pre-load adjustment ring nuts.
1731254
D Loosen the screws that secure the differential
external box to the axle.
mark the position between box and axle
(arrow).
Figure 71
1731255
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
32ąREAR AXLE SECTION 12.3 ADT 25
Figure 75
1731257
Figure 74
1731259
D Using special tools 5870 024 005 and 5870 002 404
1731258
remove the taper roller bearing outer track from the
D Loosen the mounting screws and remove both differential half-boxes on the crown wheel side (C)
support caps. and side pinion side (D).
mark each support cap and corresponding
Figure 76
external box (arrows).
1731260
D Loosen all the mounting screws and remove the
differential half-box.
Mark both differential half-boxes before
this operation (arrows).
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą33
Figure 77 Figure 79
1731261 1731263
D remove the thrust ring, the driven /driving disks, the D Remove the crown wheel gear, the crown wheel
crown wheel backing plate and the crown wheel backing plate, the driven and driving disks and the
gear. thrust ring.
Do not invert the position of the disks. Do not invert the position of the disks.
Pinion disassembly
Proceed as follows:
Figure 80
1731262
D Remove the side pinions group.
1731264
D Remove the split pin and loosen the crown nut with
tool 587024002.
D Remove the flange using a commercial extractor.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
34ąREAR AXLE SECTION 12.3 ADT 25
Bearings
- check the condition of the bearings replace them
if they have blue contours, cracks and/or signs of
wear;
Side pinions
- check the state of the teeth: replace if there are
signs of pitting, cracks and/or sinking;
1731265
- check the mating surfaces with the pins;
D Remove the oil seal ring from its housing. Even if only one element is found damaged,
the complete gears assy must be replaced.
Figure 82
Crosshead pins
- check the mating surfaces with the side pinions.
Thrust rings
- check the state of the rings: replace them if they
have blue contours, cracks and/or signs of wear;
Ring nuts
- check the thread on the bearing locking ring nut:
ensure there is no denting, strain and /or seizure:
there must be no denting, strain and/or seizure;
External box
1731267
- check the bearing housings: to ensure there are no
D Using 587002600+5870026014 remove the inner signs of strain and/or ovalising;
ring of the pinion internal bearing (B). - check that the sealing surfaces and threads are
D Remove both outer tracks of the taper roller intact and are not dented or damaged.
bearings from the external box.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą35
Figure 84
1731268
Break-down drawing of self-locking differential
11. Ring bevel gear and differential half-box
12. Thrust ring
13. Driving disks (internal grooving)
14. Driven disks (external grooving)
15. Crown wheel backing plate
16. Crown wheel
17. Side pinions shaft
18. Side pinion
19. Differential half-box
20. Mounting screw
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
36ąREAR AXLE SECTION 12.3 ADT 25
Figure 85
1731269
Break-down drawing of pinion
13. Split pin
14. Notched nut
15. Washer
16. Motion transmission flange
17. Protection ring
18. Seal ring
19. External taper roller bearing (B)
20. Bearing pre-load spacer S2
21. Pinion
22. Internal taper roller bearing (A)
23. Pinion axial position spacer S1
24. External box
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą37
Re-assembly Figure 86
When reassembling, bear in mind the
following general rules:
- heat the bearings and gears that are
assembled by pressure in an oven at
905C (194 °F);
- accurately centre the seal rings and
bearings and use the specific tool or
hammer to assemble them;
- lubricate ring nuts and bearings.
Figure 87
1731271
First operation
D Insert tools 5870500001 + 5870500006 the Example:
differential support seats and tools 5870351000 + dimension a+b: 191.80 mm (7.55 in)
5870351005 in the pinion seats.
dimension b is to be found using a thickness
D Determine distance H between the resting surfaces
gauge
of internal bearing (A) and centre of the differential
support. dimension c: 15.00 mm (15.24 mm)
(1/2 diameter of measuring shaft)
dimension H= a+b+c: 206.80 mm (8.15 in)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
38ąREAR AXLE SECTION 12.3 ADT 25
Figure 90
1731272
1731274
Second operation
D Fit correctly sized spacer S1 in the box as previously
D Find thickness S of the internal taper roller bearing described.
(A).
Example: Figure 91
Dimension d: 90.00 mm (3.54 in)
Value measured e: 43.90 mm (1.72 in)
Bearing thickness S=d - e: 46.10 mm (1.82 in)
Figure 89
1731273
Third operation
D Find the required value depending on pinion
assembly dimension X
D Read value V engraved on the surface of the pinion
(arrow) and add it to thickness S of the bearing.
Example:engraved value V 159.90 mm (6.30 in)
Bearing thickness S 46.10 mm (1.8 in)
dimension X =V+S: 206.00 mm (8.11 in)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą39
Figure 92 Figure 94
1731278
1731276
Proceed as follows: D Position measuring tool 5870034001 on the pinion
shoulder.
Figure 93
The spring pins are to face the grooved part
of the pinion (arrow).
Make sure that the pins protrude sufficiently
so that the overall thickness of the tool is
more than the presumed thickness of
spacer S2 to be found.
Figure 95
1731277
D Heat the inner track of bearing (A) to about 90°C
(194 °F) and fit it on the pinion. Make sure it is up
against the shoulder of the pinion.
1731279
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
40ąREAR AXLE SECTION 12.3 ADT 25
Figure 96 Figure 98
1731280 1731282
D Lock the control flange on the pinion groove. D Remove and measure the thickness of the
D Fit the slashed nut and tighten it to the specified measuring tool 587034001 using a micrometer.
torque using tool 5870240002 D The thickness found will be that for spacer S2.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą41
1731284
D Heat the taper roller bearing inner track to about
90°C (194 °F) and fit it tightly onto the differential
half-box.
Figure 101
1731283
Proceed as follows:
D Check that the contact area between crown wheel
and differential half-box is clean and free of grease.
Use only original components supplied as
spare parts.
1731285
D Tighten the bolts to the specified torque.
D At the end of the operations temporarily assemble D Position the shoulder ring with the grooved surface
the other half-box, arrange the group between the facing downwards (arrow).
two points and with a dial gauge, check that the
eccentricity is within the specified values.
maximum eccentricity: 0.08 mm (0.003 in)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
42ąREAR AXLE SECTION 12.3 ADT 25
1731288
Figure 105
1731286
Figure 103
1731289
D Assemble the shafts and side pinion gears and fit
them on the crown wheel gear.
Figure 106
1731287
D Fit the crown wheel shoulder plate with the flat side
downwards on the top of the internally grooved
disk.
1731290
D Fit the other crown wheel gear onto the side pinion
gear assembly.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą43
Figure 109
1731291
First operation
D Find the value a between the box mounting plane
and the internally grooved plate.
Figure 110
1731294
1731292
Second operation
D Fit an internally grooved disk (driving disk) and an D Find dimension b between box and cover mounting
externally grooved disk (driven disk) alternately until plane
all the disks have been mounted. Example:
The first disk is a driving disk. dimension a: 6.00 mm (0.236 in)
dimension b: 5.80 mm (0.228 in)
Difference a ć b: 0.20 mm (0.0078 in)
(disk axial clearance)
D Check that it is within the specified values.
disk pack axial clearance
0.20P0.80 mm (0.0078P0.031 in)
D the clearance can be corrected by installing disks of
different thicknesses, providing the thickness of the
disk pack is the same on both sides.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
44ąREAR AXLE SECTION 12.3 ADT 25
Figure 113
1731295
Figure 112 D Position spacer S2 onto the pinion shoulder, then fit
the assembled pinion in the differential box.
D Fit the bearing inner ring (B).
Figure 114
1731296
D Heat the taper roller bearing inner track to about
90Ă°C (194Ă°F) and position it against the differential
half-box until it comes into contact.
1731298
D Apply LOCTITE thread stop to the calibrated bolts.
D Join the two half-boxes and tighten the calibrated D Apply LOCTITE sealant on the outer diameter of the
bolts to the specified torque. seal ring
D Using tool 5870055074 insert the seal ring into the
Use only new calibrated bolts. differential box.
The seal ring lip is to face inwards.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą45
1731299 17312101
D Mount the flange onto the pinion. D Apply MOLYKOTE to the thread of the adjustment
D Position the washer and tighten the slashed nut to ring nut.
the specified torque using tool 587024002. D Tighten both ring nuts by hand.
D Lock the slashed nut in its seat with a split pin.
Figure 118
Finding the differential bearing pre-load
Proceed as follows:
Figure 116
17312102
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
46ąREAR AXLE SECTION 12.3 ADT 25
Figure 121
17312103
Figure 120
17312104
Figure 122
1731281
D Using suitable tools, check that the rolling torque is
within the specified values.
total rolling torque:
1.8P2.7 Nm (1.3P2 lb ft)
The rolling torque measured includes the
torque of the pinion bearings.
D The rolling torque can be corrected by varying the
two adjustment ring nuts by the same number of
notches.
D In detail: 17312105
- loosen the ring nuts to decrease the rolling
torque;
- tighten the ring nuts to increase the rolling
torque;
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 12.3 ąREAR AXLEą47
Figure 125
17312106
D cover about a dozen crown teeth with Prussian blue,
lubricated red lead or other paint or marking that
can easily be removed.
D Rotate the crown by hand in the direction shown in
the figure.
D When the teeth mesh, the paint is sent out by the
17312111B
contact of the teeth, leaving an exposed zone with
the exact dimension, shape and location of the D Support the complete external box suitable lifting
contact area (see figure on next page). equipment.
D Apply LOCTITE sealant along the joining surfaces.
D Mount the complete external box assembly onto the
axle attaining to the reference marks made when
disassembling.
D Tighten the mounting screws and lock to the
specified torque.
D Fill the axle with the indicated quantity of prescribed
lubricant up to the control oil level.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
48ąREAR AXLE SECTION 12.3 ADT 25
Figure 126
a a a
b b b
1 2 3
1731208 1731209 1731210
156NM123
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 13.1
BRAKES
ADT 25 SECTION 13.1 BRAKESą1
CONTENTS
Page Page
DIAGNOSTIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Refit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
TIGHTENING TORQUES . . . . . . . . . . . . . . . . . . . . . . 7
PARKING BRAKE CALIPER
SERVICE BRAKE CALIPER
REMOVAL-REFIT . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
REMOVAL-REFIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Refit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Refit and air bleed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
PARKING BRAKE DISK REMOVAL-REFIT . . . . 20
BRAKE CALIPER OVERHAUL . . . . . . . . . . . . . . . . 10
Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Refit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Dismantled parts check . . . . . . . . . . . . . . . . . . . . . . . 11
Reassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąBRAKES SECTION 13.1 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 13.1 BRAKESą3
DESCRIPTION
Principle
The vehicle is fitted with the following braking systems, The parking brake consists of a disk mounted on a the
all hydraulically controlled: rear propeller shaft with two reverse hydraulic control
D service brake with disk brakes on all the wheels; calipers.
D parking brake with disk brake on the transmission, The fluid required to activate the actuators is obtained
The service brake consists of disk brakes fitted with from the single hydraulic system of the vehicle.
floating calipers with two pistons.
Figure 1
2 3
1
9 6
11
5
7
10 10
8
12 13
1891301
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąBRAKES SECTION 13.1 ADT 25
Operation
Service brake Parking brake
Figure 2 Figure 4
1731317 1731319
With the brake pedal released, the pressure does not With the parking brake control released, the pressure
operate on the pistons (Figure 2). Therefore the disks operates on the internal piston (Figure 4) compressing
are free to rotate as they are not pressed by the brake the spring and freeing the pad from the brake.
pads.
Figure 5
Figure 3
1731320
1731318
When the control is activated, the parking brake disĆ
With the pedal pressed, pressure is sent by the disĆ tributor discharges the pressure, so that the spring can
tributor to the pistons (Figure 3) that compress the operate on the pads (Figure 5) and lock the disk.
pads pressing the disk. To allow a correct distribution of the braking force on
The amount of braking action depends on how hard the the two sides of the disk, the caliper is of the floating
driver presses on the brake pedal. type, with a piston on one side only.
As there are pistons on both sides of the caliper, both
the disk and the caliper are the fixed type.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 13.1 BRAKESą5
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąBRAKES SECTION 13.1 ADT 25
DIAGNOSTIC
1. Brakes either do not work or do not develop much braking power
2. Uneven brake action
3. Brakes are jammed
Pump intake pipe leakage Check for leakage and replace pipe,
if required
Brakes are jammed Brake caliper incorrectly adjusted Adjust brake calipers
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 13.1 BRAKESą7
TIGHTENING TORQUE
Screws fastening service brake caliper to axle: 295 Nm (217 lb ft)
Service brake centring pin fastening screws: 25 Nm ( 18 lb ft)
Hub support fastening screws: 460 Nm (339 lb ft)
Service brake disc fastening screws: 295 Nm (217 lb ft)
Parking brake caliper fastening screws: 120 Nm ( 88 lb ft)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąBRAKES SECTION 13.1 ADT 25
Figure 6
1731301A
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 13.1 BRAKESą9
1731302A
D remove the dust cover cap, then insert a transparent
section of hose onto the breather valve and dip one
end of the pipe into a vessel containing a certain
quantity of oil;
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
10ąBRAKES SECTION 13.1 ADT 25
Disassembly
D Proceed as follows:
Figure 9
Figure 8
1731304
Figure 10
1731303
D remove the cover (1) and the gasket (2), then presĆ
sing on the inner side of the caliper, remove the pisĆ
ton (3), after which remove the dust cover (4), the
gasket (5) and the shoulder ring (6) from the caliper.
D repeat these operations for all the caliper pistons.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 13.1 BRAKESą11
1731306
1731308
D mount the shoulder ring (1), gasket (2) and dust
cover (3) in the seat on the caliper; D refit the plate (1) and tighten the mounting screw (2)
to the specified torque;
D fit the new pads working in reverse order to the disĆ
assembly.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
12ąBRAKES SECTION 13.1 ADT 25
Replacement
To replace, proceed as follows: Figure 15
Figure 14
1731310
D fit the new pads, inserting them from the caliper end
without indexing pins, sliding them along the disk
surface and fitting them onto the smaller diameter
indexing pins (arrow);
1731309
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 13.1 BRAKESą13
1731311
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
14ąBRAKES SECTION 13.1 ADT 25
Removal
To remove proceed as follows: 1731221
D bring the vehicle onto a suitable flat, solid surface,
D Mark the reciprocal positions of the gear carrier
switch off the engine, remove the ignition key, enĆ
plates and the hub (arrows).
gage the parking brake and apply the warning signĆ
D Using the appropriate screw extractor remove the
boards;
gear carrier plate from the hub.
D cut off the battery isolator switch or disconnect the
terminals from the battery to avoid the risk of short Figure 19
circuits;
D lock knuckle with the steering lock bar following the
instructions in SECTION 1.2;
D remove the caliper associated to the brake being
serviced following the instructions in the relevant
Chapter;
D drain off the lubricant oil as described in the relevant
paragraph;
Figure 17
1731222
D Remove the gear carrier plate assembly.
Figure 20
1731220
D Loosen all the hexagon head screws.
1731224
D Remove the crown wheel gear from the grooved
bushing.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 13.1 BRAKESą15
Figure 21 Figure 24
1731226 1731230
D Unscrew the mounting screws, remove the locking D Support the hub with the brake disk by means of
plate, then remove the internal toothed ring nut suitable lifting equipment and knocking it lightly,
using tool 5870656005. cautiously withdraw it from the hub support. Take it
to the work bench.
Figure 22 D Remove the seal ring from the hub support.
Figure 25
1731227
D Remove the internally toothed wheel from the hub
by hand. 1731233
D Loosen the mounting screws and remove the brake
Figure 23 disk.
1731229
D Remove the outer bearing inner track (B) from the
hub support.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
16ąBRAKES SECTION 13.1 ADT 25
Refit
Figure 28
. Bear in mind the following during the refit:
- heat the bearings and gears to be thrust
into place in an oven at a temperature of
90°C (194 °F);
- accurately centre the seal rings and bearĆ
ings, using the special tool or a hammer
to assemble them;
- lubricate ring nuts and bearings.
Proceed as follows:
Figure 26
1731240
D Suitably support the hub assembly, so as to ensure
correct centring, the gently slide it on the end of the
hub support until it comes up against the internal
bearing.
Figure 29
1731237
D Fit the brake disk on the hub and tighten the screws
to the specified torque.
B
Figure 27
1731241
D Install the external bearing inner track to come into
contact.
A
1731239
D Use a suitable plug to assemble the seal ring then
the bearing inner ring onto the hub support.
Apply sealant on the outer diameter of the
seal ring.
The lip of the seal ring is to face inwards.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 13.1 BRAKESą17
Figure 30 Figure 32
1731243 1731247
D Slide the complete toothed wheel with internal
D Using a cable and a commercial torque wrench
toothing onto the hub support groove.
check that the rolling torque of the hub bearings
D Assemble the crown wheel gear.
(pre-load) is within the specified values.
To determine the hub bearing pre-load Rolling torque:
re-used bearings 6.0 to 9.0 Nm (4.4 to 6.63 lb ft)
D Proceed as follows:
D Otherwise change the tightness of the ring nuts.
Figure 31
Figure 33
1731246
1731248
D Apply MOLYKOTE to the hub support thread and to
D After adjusting the bearing pre-load lock the ring
the thread and contact area of the ring nut.
nut with the plate and locking screws.
D Assemble the locking ring nut and tighten to the
specified torque using tool 5870656005.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
18ąBRAKES SECTION 13.1 ADT 25
Figure 34 Figure 35
1731225
D Assemble the brake caliper tightening the mountĆ
ing screws to the specified torque.
D Check the clearance between the brake disk and
1731252 the pad guide pins, following the instructions in the
relevant paragraph.
D Apply sealant to the contact surfaces, assemble the D Continue by connecting the hydraulic coupling and
differential gear carrier plate assembly into the hub bleeding the air from the circuit as described in the
and tighten the mounting screws to the specified relevant paragraph.
torque. D Fill the hub with the required quantity of specified luĆ
bricant up to the oil check level.
. Match the reference made at disassembly.
Pay attention to the radial position of the oil
drainage cap.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 13.1 BRAKESą19
Removal 1731313
To remove proceed as follows: D unscrew the mounting screws and remove the caliĆ
D bring the vehicle onto a suitable flat, solid surface, per with the bracket from the housing on the axle
switch off the engine, remove the ignition key, enĆ taking care not to bend the pipe;
gage the parking brake and apply the warning signĆ
boards. . When handling the caliper never put your
fingers or hand in the space between the
Apply suitable chocks to the wheels to avoid pads.
uncontrolled vehicle movement when the
calipers are removed. D place a piece of hard wood 10-12 mm (0.39-0.47
in) thick between the pads to simulate the presence
D cut off the battery isolator switch or disconnect the of the disk, then discharge the hydraulic pressure,
terminals from the battery to avoid the risk of short disconnect the manual pump coupling and free the
circuits; caliper;
D lock knuckle with the steering lock bar following the D if necessary dismantle the caliper from its bracket;
instructions in SECTION 1.2; D repeat the operation for the other caliper.
Figure 36
Refit
To refit reverse the removal operations.
Continue bleeding off the air in the circuit as indicated
in the Chapter HYDRAULIC OIL REPLACEMENT.
1731312
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
20ąBRAKES SECTION 13.1 ADT 25
Figure 38
1891302
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 13.2
CONTENTS
Page
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
DIAGNOSTIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
TIGHTENING TORQUES . . . . . . . . . . . . . . . . . . . . . . 4
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąWHEELS AND TYRES SECTION 13.2 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 13.2 WHEELS AND TYRESą3
DESCRIPTION
The vehicle is fitted with tubeless tyres mounted on removable rims.
Figure 1
1731321
The rim is the rigid structure of the wheel and consists The tyre has to perform these tasks
of the following parts: D absorb the impacts caused by rough ground;
1. side flanges D transmit the engine driving torque to the ground;
2. rim (channel) D transmit the braking force applied to the brakes to
3. retaining ring the ground;
4. O-ring D ensure side grip round bends
5. inflation valve unit
Also the tyre is identified by these dimensions (in inĆ
It has the following dimensions (in inches): ches):
D keying diameter, measured on the base of the cirĆ D keying diameter, measured on the base of the cirĆ
cumference groove (the resting surface of the tyre cumference groove (the resting surface of the tyre
bead); bead);
D width of sipe (distance between the flange side surĆ D tyre width (distance between the tyre sidewalls).
faces).
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąWHEELS AND TYRES SECTION 13.2 ADT 25
DIAGNOSTIC
1. Air leakage from tyre
Air leakage from tyre Valve faulty Fasten components. Replace damĆ
aged and/or worn components
Rim or welding cracked Replace faulty components. Do not
attempt to repair
O-ring deformed and/or damaged Replace o-ring
Cuts and grooves in tyre Repair the tyre and replace it, if reĆ
quired
Holes punched in bead area Replace the tyre
Bead cover leakage Clean the rim and check if leakage
persists. Change tyre, if required
TIGHTENING TORQUE
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 13.2 WHEELS AND TYRESą5
Disassembly
D bring the vehicle (preferably unladen) onto a flat surĆ
face, switch off the engine and engage the parking
brake;
Figure 2
174NU57A
Figure 5
174NU60
174NU58A
D work on the valve making sure that the wheel to be
replaced is completely deflated;
D The vehicle can be lifted by a crane or an overhead
Figure 3 travelling crane or other appropriate lifting equipĆ
ment using suitable steel cables hooked to the slots
provided for the purpose.
A. lifting points/front hooking
B. lifting points/rear hooking
D hook the wheel to a crane or other lifting equipment
and position the lifting trolley under the wheel;
Figure 6
174NU61
174NU62
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąWHEELS AND TYRES SECTION 13.2 ADT 25
Assembly Checks
D clean the threads of the nuts and bolts and the rim
and hub seatings; Tyre
Make these checks periodically:
Figure 7 D check the external surface of the tyre looking for
deep cuts or breaks that could jeopardise the road
grip;
D remove any stones lodges in the tread;
D in the case of disassembly and reuse of the tyre;
check the condition of the bead and remove any
foreign matter from the tyre;
D check the inflation pressure.
The inflation pressure is to be check with the
tyres cold.
Figure 8
5 1
11 9
3 8
7 4
10 12
2 6
174NU64
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 13.2 WHEELS AND TYRESą7
Rim
Make these checks periodically:
D check the entire circumference of the rim and the
disk, paying special attention to the zone where it is
secured to the hub;
D check there are no signs distortion, wear, corrosion
or breaks: if there are, replace;
D check that the seal rings and valves are in good
condition;
D if necessary, touch up the paint, first removing the
previous coat and any oxidising, and applying a
suitable ground coat;
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąWHEELS AND TYRES SECTION 13.2 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 14
SUSPENSION
ADT 25 SECTION 14 SUSPENSIONą1
CONTENTS
Page Page
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąSUSPENSION SECTION 14 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 14 SUSPENSIONą3
DESCRIPTION
The front suspension consists of a pair of hydro-pneuĆ The axle can sway around its longitudinal axis (x-x),
matic elements (2) pivoted below onto the front axle (1) whereas the connecting rods absorb the longitudinal
and fixed above to the vehicle chassis. thrust, and the centre knuckle the transverse and vertiĆ
The axle in its turn is articulated to the chassis by two cal thrusts.
longitudinal reaction connecting rods (3).
The axle is rigidly restrained to a supporting structure
with a circular knuckle (4) in the centre position.
Figure 1
1891402
1. Front axle
2. Hydro-pneumatic elements
3. Longitudinal reaction connecting rods
4. Support with central knuckle
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąSUSPENSION SECTION 14 ADT 25
Hydro-pneumatic element
The hydro-pneumatic element consists of a co-axial the return stroke, whereas the pneumatic chamber,
shock absorber with a pneumatic chamber. filled with nitrogen, acts as the flexible suspension
The hydraulic shock absorber uses the hydraulic fluid element during the compression stroke.
contained in the cylinder for hydraulic braking during
Figure 2
1731403
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 14 SUSPENSIONą5
DIAGNOSTIC
1. Suspension often reaches end of stroke
Suspension often reaches end of Nitrogen or oil pressure loss Check tightness of seals under caps
stroke and valves; restore pressure; reĆ
store oil level
Nitrogen pressure low and/or miniĆ Restore pressure; restore oil level
mum oil level
TIGHTENING TORQUE
Nuts fastening wheels to hub: 590 Nm (435 lb ft)
Upper bolt fastening cylinder 80 Nm ( 59 lb ft)
Lower bolt fastening cylinder 80 Nm ( 59 lb ft)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąSUSPENSION SECTION 14 ADT 25
Figure 3
1731401
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 14 SUSPENSIONą7
SPECIALISED MAINTENANCE
. The operations described are to be carried Figure 5
out by experts using the appropriate equipĆ
ment.
Use only and exclusively the specific equipĆ
ment essentially required for the suspenĆ
sion inflation operations.
The operations described are to be carried
out on both suspension elements in parallel.
Figure 4
174NM35
174NM36
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąSUSPENSION SECTION 14 ADT 25
Figure 8
174NM37
Figure 7
D unscrew the protection cap on the element;
Figure 9
174NM36
D assemble the checking tool (A) into the seat, then
connect the inflation equipment (B) to the checking
174NM36
tool (A);
D assemble the checking equipment (A) into the seat,
D check that both the inlet tap IN and the bleed tap
then connect the inflation equipment (B) to the
OUT on the inflation equipment (B) are both well cloĆ
checking tool (A);
sed;
D check that both the inlet tap IN and the bleed tap
D slowly tighten the knurled flywheel of the checking
OUT on the inflation equipment (B) are both well cloĆ
tool (A) and check that the pressure on the gauge
sed;
(E) is within the specified values:
suspension element pressure:
68+2 bar (957 to 1015 psi)
D loosen the flywheel of the checking tool (A) and reĆ
move all the equipment, then close the protection
cap.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 14 SUSPENSIONą9
D slowly tighten the knurled flywheel of the checking Suspension element oil replacement
tool (A) and read the pressure on the gauge (E); The oil replacement is carried out after removing the
D open the nitrogen bottle tap (b) then the inlet tap IN element from the vehicle.
to allow the nitrogen to enter the suspension elĆ Proceed as follows:
ement (a); D place the element on the work bench, and secure
D introduce nitrogen up to a pressure of about 75-80 it;
bar (1088-1161 psi), then close the inlet tap IN then
the bottle tap; Figure 10
D adjust the suspension element pressure to the
specified value using the bleed tap OUT:
suspension element pressure:
68+2 bar (957 to 1015 psi)
D close the bleed tap OUT, loosen the checking tool
flywheel (A) and remove all the equipment, then
close the protection cap.
1891403
D unscrew the protection cap on the element;
D assemble the checking tool (A) into the seat on the
element;
D slowly tighten the checking tool knurled flywheel
and allow the nitrogen to discharge outwards;
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
10ąSUSPENSION SECTION 14 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 15
STEERING SYSTEM
ADT 25 SECTION 15 STEERING SYSTEMą1
CONTENTS
Page
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Principle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
DIAGNOSTIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąSTEERING SYSTEM SECTION 15 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 15 STEERING SYSTEMą3
DESCRIPTION
Principle
The vehicle steering is obtained by directing the front The fluid needed to activate the actuators is obtained
part of the vehicle in relation to the rear part, around the from the only hydraulic system on the vehicle.
vertical axis found by the steering pins through two The steering circuit diagram consists of these compoĆ
double action hydraulic cylinders mounted sideways to nents:
the rear chassis.
Figure 1
1731501A
1. tank
2. main pump
3. high pressure filter
4. steering valve
5. hydraulic cylinders
6. flow amplifier
7. emergency pump
8. emergency pump switch
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąSTEERING SYSTEM SECTION 15 ADT 25
Operation
The steering wheel operates on a steering valve that supplies the hydraulic fluid under pressure to the cylinders.
Figure 2
SX DX
1731502
Right-hand steering
The oil under pressure flows out from the steering valve (R), reaches the flow amplifier and continues to the
chambers:
- rear left-hand cylinder (sx) ⇒ the cylinder lengthens
- front right-hand cylinder (dx): ⇒ the cylinder shortens.
Figure 3
SX DX
1731503
Left-hand steering
The oil under pressure flows out from the steering valve (L), reaches the flow amplifier and continues to the
chambers:
- front left-hand cylinder (sx): ⇒ the cylinder shortens
- rear right-hand cylinder (dx): ⇒ the cylinder lengthens.
As the cylinders are double action, the oil returning from the chambers not involved with the pressure returns to
the tank through the steering valve.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 15 STEERING SYSTEMą5
Figure 4 The steering wheel, when turned, moves the rod that,
by means of appropriately arranged channelling, alĆ
lows the oil to flow into the cavity where the lobe gears
are housed.
The rotation of the rod also pulls with it the camshaft
where the internal gear is clamped. As this turns eccenĆ
trically it pushes the oil under pressure toward the delivĆ
ery duct, according to the direction of rotation given by
the steering wheel:
- duct R for right-hand steering;
- duct L for left-hand steering.
Right and left are intended as seen from the
vehicle driver's seat.
1731504
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąSTEERING SYSTEM SECTION 15 ADT 25
DIAGNOSTIC
1. The steering wheel is not centred
2. Apparent impossibility to steering when the steering wheel is turned slowly
3. Slow/hard steering
4. Opposite steering
5. The steering wheel rocks backwards and forwards
6. The steering wheel keeps turning
The steering wheel is not centred Steering column valve seizure Align
Apparent impossibility to steering Presence of dirt in system Bleed and wash the system. Fill with
when the steering wheel is turned clean oil
slowly
Opposite steering Pipes incorrectly fastened Check and connect tubes correctly
The steering wheel keeps turning Burring on tie-rod or stem Remove and repair. Replace the
damaged components, if required
Presence of dirt in system Bleed and wash the system. Fill with
clean oil
Sleeve and stem jammed together Remove and repair. Replace the
damaged components, if required
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 16
HYDRAULIC SYSTEM
ADT 25 SECTION 16 HYDRAULIC SYSTEMą1
CONTENTS
Page Page
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąHYDRAULIC SYSTEM SECTION 16 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą3
HYDRAULIC SYSTEM
DESCRIPTION
The system is divided into three main hydraulic systems; steering, tipping and braking system. The groups operĆ
ate with the same hydraulic fluid, coming from a single tank that serves them all.
Figure 1
1731601
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąHYDRAULIC SYSTEM SECTION 16 ADT 25
Front lay-out
STEERING-TIPPING
Figure 2
C K
D J
E
I
H
G
1891610
A. Steering emergency electro-pump
B. Oil filter inside tank
C. Hydraulic oil tank
D. Flow amplifier
E. Cargo body tipping control distributor
F. System pressure control intakes
G. High pressure oil filter
H. Connection plate
I. Main hydraulic pump
J. Differential locking control electro- distributor
K. Power steering
L. Heat exchanger
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą5
Rear lay-out
STEERING-TIPPING
Figure 3
O
M
1731611
M. Steering cylinder
N. Tipping cylinder
O. Rear chassis connection group (with counterbalancing valve)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąHYDRAULIC SYSTEM SECTION 16 ADT 25
DESCRIPTION OF COMPONENTS
A.ąSTEERING EMERGENCY ELECTRO-PUMP
Figure 4
2
1
1731604
Figure 5
2
3
4
1731605
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą7
C.ąHYDRAULIC TANK
Figure 6
1731606
1. Filler cap
2. Oil level gauge
3. Inspection cover
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąHYDRAULIC SYSTEM SECTION 16 ADT 25
D.ąFLOW AMPLIFIER
Figure 7
6 5 4 3 2
A B
7 8 9 10 1
1891612
Figure 8 Figure 9
VIEW A VIEW B
1731608 1731609
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą9
Figure 10
2
1
4 3
1731610
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
10ąHYDRAULIC SYSTEM SECTION 16 ADT 25
3 2 1 4
1731611
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą11
H.ąCONNECTION PLATE
Figure 12
1 2 3 4 5 6 7
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
12ąHYDRAULIC SYSTEM SECTION 16 ADT 25
Figure 13
1
1731613
Figure 14
5 3
4
2
1731614
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą13
K.ąPOWER STEERING
Figure 15
2 1 3 4 5
1891614
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
14ąHYDRAULIC SYSTEM SECTION 16 ADT 25
L.ąHEAT EXCHANGER
Figure 16
1 2
1731616
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą15
M.ąSTEERING CYLINDER
Figure 17
1 2
1731617
LH CYLINDER: RH CYLINDER:
1. LH steering control pipe 1. RH steering control pipe
2. RH steering control pipe 2. LH steering control pipe
N.ąTIPPING CYLINDER
Figure 18
2
1731618
Figure 19
1891615
1. Tipper down control pipe
2. Tipper down RH cylinder control pipe
3. Tipper down LH cylinder control pipe
4. Tipper up RH cylinder control pipe
5. Tipper up LH cylinder control pipe
6. LH steering control pipe
7. RH steering control pipe
8. Tipper up control pipe
9. Parking brake control pipe
10. Rear brakes control pipe
11. Differential lock control pipe
12. Rear brakes pressure point
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą17
General lay-out
BRAKES
Figure 20
1891616
A. Brakes pump
B. Oil filter (brake system)
C. Accumulators
D. Parking brake electro-distributor
E. Recharging valve
F. Brakes control valve
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
18ąHYDRAULIC SYSTEM SECTION 16 ADT 25
DESCRIPTION OF COMPONENTS
A.ąBRAKE PUMP
Figure 21
2 3 1731621
Figure 22
1
1891617
1. Solenoid valve
2. Return pipe to tank
3. Delivery pipe to accumulators recharging valve
4. Delivery pipe dalla pump
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą19
C.ąACCUMULATORS
Figure 23
1 7 2 3 4 5 6
1891618
1. Parking brake electro-distributor supply line
2. Supply line from one-way valve on recharging valve
3. Supply line from tap A1 of accumulator recharging valve
4. Supply line to tap P (upper) of modulator
5. Supply line from tap A2 of accumulator recharging valve
6. Supply line to tap P (lower) of modulator
7. Check valve
D.ąPARKING BRAKE ELECTRO-DISTRIBUTOR
Figure 24
4 1891619
1. Supply line from accumulator for parking brake
2. Parking brake control pipe
3. Return pipe to tank
4. Control valve
5. Pressure sensor
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
20ąHYDRAULIC SYSTEM SECTION 16 ADT 25
E.ąRECHARGING VALVE
Figure 25
A 6
1731625
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą21
Figure 26
1891620
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
22ąHYDRAULIC SYSTEM SECTION 16 ADT 25
DIAGNOSTIC
1. Slow hydraulic functions
2. Hydraulic system oil overheats
3. Emulsified oil
4. Low or missing oil pressure
5. No hydraulic function (noisy pumps)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą23
Low or missing oil pressure Oil not correct The oil used is not suitable. Drain
the reservoir and use oil of the corĆ
rect type
Pressure relief valve incorrectly caliĆ Check operation of valve and reĆ
brated place it, if required
No hydraulic function (noisy Hydraulic pump not working and/or Replace the pump
pumps) worn
No oil in system Add oil to reach indicated level
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
24ąHYDRAULIC SYSTEM SECTION 16 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
26ąHYDRAULIC SYSTEM SECTION 16 ADT 25
. the values indicated below are specific to the individual components (plate data)
Tipper cylinders
Length of stroke, extension 1736 mm (68.34 in)
Length of stroke, withdrawal 930 mm (36.61 in)
Power steering
Displacement 200 cm3/rev (43.9 cm3/rev)
Max. pressure 185 bar (2684 psi)
Counterbalancing valve
Pressure setting 100 bar (1451 psi)
Capacity 240 l/min (52.7 Imp gal/min)
Flow amplifier
Nominal capacity 400 l/min (87.9 Imp gal/min)
Drive pressure relief pressure 185 bar (2684 psi)
Damping valves relief pressure 230 bar (3482 psi)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą27
MAINTENANCE
Changing hydraulic oil Replacing high pressure oil filter (pump outlet)
Proceed as follows:
Collect and dispose of used lubricants and D drain the reservoir as shown in the respective paraĆ
fluids, according to the laws in force. graph;
D with the engine stopped, loosen the filtering carĆ
Proceed as follows:
tridge (Figure 29) with a hexagonal wrench and
D take a suitably sized container, clean the filler cap
accurately clean the housing;
and drain cap areas and remove the filler cap
(Figure 27); Figure 29
Figure 27
156NM90
156NM91
156NM89 D fill the new cartridge with the specified fluid and
apply the same fluid to the seals;
D clean the drain cap. Check that the threading is in
D fasten the cartridge by hand until the seal comes
good condition. Close at the specified torque;
into contact with the housing, then turn by another
drain cap: 100 Nm (73 lb ft)
3/4th of a turn;
D pour in the specified amount of fluid through the filler
and close it; Do not fasten the cartridge excessively. This
D bleed the system. could damage the seal. Observe the specifiĆ
cations provided by the supplier.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
28ąHYDRAULIC SYSTEM SECTION 16 ADT 25
Replacing inner hydraulic oil filter (intake) Changing hydraulic brake oil filter
Proceed as follows: Proceed as follows:
D drain the reservoir as shown in the respective paraĆ D drain the reservoir as shown in the respective paraĆ
graph; graph;
D remove the flange (Figure 31); D with the engine stopped, loosen the filtering carĆ
tridge (Figure 33) and accurately clean the housing;
Figure 31
Figure 33
156NM92
174NM33
D loosen the cartridge removing it from the flange
housing (Figure 32); D fill the new cartridge with specific fluid and apply
fluid to the seals;
Figure 32 D fasten the cartridge by hand until the seal comes
into contact with the housing, then turn by another
3/4th of a turn;
Do not fasten the cartridge excessively. This
could damage the seal. Observe the specifiĆ
cations provided by the supplier.
D fill the reservoir as shown in the specific paragraph;
D run the engine for a few minutes and check for leakĆ
age.
D bleed the system.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą29
1731302A
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
30ąHYDRAULIC SYSTEM SECTION 16 ADT 25
Description
Figure 35
1891601
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą31
Figure 36
1731629F
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
32ąHYDRAULIC SYSTEM SECTION 16 ADT 25
Figure 37
1731630F
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą33
Figure 38
3
1731630F
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
34ąHYDRAULIC SYSTEM SECTION 16 ADT 25
MAIN PUMP REMOVAL-REFITTING D lock knuckle with the steering lock bar following the
instructions in SECTION 1.2;
. Before starting any type of operation make D drain the hydraulic fluid from the reservoir into a suitĆ
sure all the necessary safety precautions able receptacle as specified in the appropriate paraĆ
have been taken and fully explained to those graph;
involved in the operations. D disconnect the intake union (2) and the delivery
Read the instructions provided in SECTION union (3) from the pump by loosening the securing
1.2 of this manual. screws and removing the O-rings;
If in doubt, consult an expert.
Hydraulic fluid may leak out during these
Follow all the general recommendations for
correctly performing maintenance operĆ operations.
ations. D support the pump (1) adequately; loosen the securĆ
ing screws then remove the pump and its gasket.
Removal Refitting
To remove proceed as follows: To refit follow the removal operations in reverse order.
D position the vehicle on a flat surface, switch the enĆ Fill the hydraulic oil reservoir as indicated in the apĆ
gine off, remove the ignition key, apply the parking propriate paragraph.
brake and attach the warning notices. Bleed the air in the circuit as described in the appropriĆ
D cut off the battery isolator switch or disconnect the ate paragraph.
terminals from the battery to avoid the risk of short
circuits;
Figura 39
2 3
1731636
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą35
BRAKE PUMP REMOVAL-REFITTING D lock knuckle with the steering lock bar following the
instructions in SECTION 1.2;
. Before starting any type of operation make D drain the hydraulic fluid from the reservoir into a suitĆ
sure all the necessary safety precautions able receptacle as specified in the appropriate paraĆ
have been taken and fully explained to those graph;
involved in the operations. D disconnect the intake union (2) and the delivery
Read the instructions provided in SECTION union (3) from the pump by removing the O-rings;
1.2 of this manual.
Hydraulic fluid may leak out during these
If in doubt, consult an expert.
Follow all the general recommendations for operations.
correctly performing maintenance operĆ D support the pump (1) adequately, loosen the securĆ
ations. ing screws and remove the pump.
Refitting
Removal To refit follow the removal operations in reverse order.
To remove proceed as follows: Fill the hydraulic oil reservoir as indicated in the apĆ
D position the vehicle on a flat surface, switch the enĆ propriate paragraph.
gine off, remove the ignition key, apply the parking Bleed the air in the circuit as described in the appropriĆ
brake and attach the warning notices. ate paragraph.
D cut off the battery isolator switch or disconnect the
terminals from the battery to avoid the risk of short
circuits;
Figura 40
1731637
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
36ąHYDRAULIC SYSTEM SECTION 16 ADT 25
EMERGENCY STEERING PUMP REĆ D cut off the battery isolator switch or disconnect the
MOVAL-REFITTING terminals from the battery to avoid the risk of short
circuits;
. Before starting any type of operation make D access the front left mudguard compartment housĆ
ing the pump;
sure all the necessary safety precautions
D disconnect the electrical power supply connections
have been taken and fully explained to those
(4) and the control relay (5);
involved in the operations.
D disconnect the intake union (2) and the delivery
Read the instructions provided in SECTION
union (3) from the pump by removing the O-rings;
1.2 of this manual.
If in doubt, consult an expert. Hydraulic fluid may leak out during these
Follow all the general recommendations for
operations.
correctly performing maintenance operĆ
ations. D loosen the securing screws and remove the pump
(1).
Refitting
Removal
To refit follow the removal operations in reverse order.
To remove proceed as follows:
Fill the hydraulic oil reservoir as indicated in the apĆ
D position the vehicle on a flat surface, switch the enĆ
propriate paragraph.
gine off, remove the ignition key, apply the parking
Bleed the air in the circuit as described in the appropriĆ
brake and attach the warning notices.
ate paragraph.
Figura 41
5
2
1731638
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą37
RATE OF FLOW AMPLIFIER REMOVAL- D disconnect all the unions from the valve (1) and reĆ
REFITTING move the O-rings and gaskets:
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
38ąHYDRAULIC SYSTEM SECTION 16 ADT 25
3
4
5
8 6
7
10
11
12
1731639
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą39
STEERING VALVE REMOVAL-REFITTING D lock knuckle with the steering lock bar following the
instructions in SECTION 1.2;
. Before starting any type of operation make D drain the hydraulic fluid from the reservoir into a suitĆ
sure all the necessary safety precautions able receptacle as specified in the appropriate paraĆ
have been taken and fully explained to those graph;
involved in the operations. D diconnect all the unions from the valve and remove
Read the instructions provided in SECTION the gaskets
1.2 of this manual. (2) return to the reservoir
If in doubt, consult an expert. (T) return to the flow amplifier
Follow all the general recommendations for (L) left-hand steering control
correctly performing maintenance operĆ (P) delivery from flow amplifier
ations. (R) right-hand steering control
Figura 42
T
L
P
R
1731640
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
40ąHYDRAULIC SYSTEM SECTION 16 ADT 25
TILT VALVE REMOVAL-REFITTING D drain the hydraulic fluid from the reservoir into a suitĆ
able receptacle as specified in the appropriate paraĆ
. Before starting any type of operation make graph;
sure all the necessary safety precautions D disconnect all the unions from the valve (1) and reĆ
have been taken and fully explained to those move the O-rings and gaskets;
involved in the operations. (2) return to the reservoir
Read the instructions provided in SECTION (3) down tilt control
1.2 of this manual. (4) up tilt control
If in doubt, consult an expert. (5) delivery to the flow amplifier
Follow all the general recommendations for (6) power supply for differential lock distributor
correctly performing maintenance operĆ pressure check socket connection
ations. D adequately support the valve (1), loosen the securĆ
ing screws and remove it.
Removal Refitting
To remove proceed as follows: To refit follow the removal operations in reverse order.
D position the vehicle on a flat surface, switch the enĆ Fill the hydraulic oil reservoir as indicated in the apĆ
gine off, remove the ignition key, apply the parking propriate paragraph.
brake and attach the warning notices. Bleed the air in the circuit as described in the appropriĆ
D remove the protective bulkhead on the left-hand ate paragraph.
side;
D if deemed necessary to aid operations, remove the
front left wheel as described in the relevant Section;
Figura 43
4 3 2
5
8
7
1731641
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą41
Figura 44
6
4
1 6
3
6
7 5
1731642
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
42ąHYDRAULIC SYSTEM SECTION 16 ADT 25
a b
Removal
1731902
To remove proceed as follows: D position a suitable receptacle, disconnect the two
D disconnect the central lubrication system unions unions, fluid input (a) and output (b), then plug them
(arrow); appropriately to prevent the circuit emptying;
D turn the steering wheel to the right and then left as
far as possible to release the hydraulic pressure in Figura 46
the cylinders;
D lock knuckle with the steering lock bar following the
instructions in SECTION 1.2;
D drain the hydraulic fluid from the reservoir into a suitĆ
able receptacle as specified in the appropriate paraĆ
graph;
1731903
D support the cylinder (1) with suitable lifting equipĆ
ment, loosen the upper securing bolt (4) and reĆ
move the guide pin (5), then lower the cylinder and
free it from the bucket attachment;
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 16 HYDRAULIC SYSTEMą43
Figura 47
1731904
Refitting
To refit follow the removal operations in reverse order.
Fill the hydraulic oil reservoir as indicated in the apĆ
propriate paragraph.
Bleed the air in the circuit as described in the appropriĆ
ate paragraph.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
44ąHYDRAULIC SYSTEM SECTION 16 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 17
ELECTRICAL SYSTEM
ADT 25 SECTION 17 ELECTRICAL SYSTEMą1
CONTENTS
Page Page
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąELECTRICAL SYSTEM SECTION 17 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 17 ELECTRICAL SYSTEMą3
TECHNICAL DATA
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąELECTRICAL SYSTEM SECTION 17 ADT 25
Colour code 1st ring 2nd ring 3rd ring Multiplier Tolerance
Silver ± 10%
Gold ± 5%
Black 0 0 1 ± 20%
Brown 1 1 1 10 ± 1%
Red 2 2 2 102 ± 2%
3 3 3 103
Orange
4 4 4 104
Yellow
5 5 5 105
Green
6 6 6
Blue 7 7 7
Violet 8 8
Grey 9 9
White
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 17 ELECTRICAL SYSTEMą5
GENERAL INSTRUCTIONS
General precautions
Never disconnect the batteries or open the D Never connect or disconnect cable connector from
knife switch with the external-combustion electronic control modules with powered supply.
engine started. D Remove the electronic control modules when operĆ
never start up the engine without having ations involve temperatures exceeding 80 °C (176
connected the batteries PERMANENTLY. °F) (drying oven).
D During the connection stage, screw connector flap
D Before carrying out any servicing operation on the
nuts (temperature and pressure sensors, etc.) to
vehicle, chock the wheels securely to prevent the
the prescribed torque only.
truck from moving on its own.
D Measurements on electronic modules controlling
D Starting from the engine compartment should only
plugs, plug connections and electrical component
be performed with the cab securely fixed in its maxiĆ
connections can be only performed on suitable test
mum opening position, parking brake on, transĆ
lines with proper plugs and bushes.
mission in neutral, wheels properly chocked.
Never use improper tools such as metallic wires,
D Avoid aiming water/other fluid jets at the rear bulkĆ
screwdrivers, clips and equivalent.
head junction block.
Short circuits can occur and plug connections could
D Do not use quick charging devices to start the enĆ
be damaged causing successive contact troubles.
gine. Engine starting should be performed only by
means of separate batteries or a suitable trolley. Always disconnect the batteries and conĆ
D While performing electrical welding on the chassis, nectors from electronic control modules
disconnect connectors from electronic control modĆ when performing electric welding operĆ
ules and disconnect the terminals from the battery. ations on the vehicle.
D In case of fuse change, in order to avoid damages
to electric plant of the vehicle, use fuses only of the Before replacing a fuse, check always the
same power as indicated by the producer.
cause of its blowout. Circuit operation can
D Check for exact battery terminal polarity during start
be reset only after having removed the fault.
up from auxiliary truck.
D When disconnecting the batteries from the system,
always disconnect first the chassis ground cable of
the negative battery terminal.
D Check system perfect insulation before disconnectĆ
ing the batteries.
D Incorrect supply voltage polarisation of the elecĆ
tronic control modules (e.g. incorrect battery polaĆ
risation) can cause module breakage.
D Add a fly-fuse between the negative battery terĆ
minal and the chassis ground cable during troubleĆ
shooting of a circuit fault (main current switch conĆ
nected).
D Disconnect the ground cable from the negative batĆ
tery terminal before removing electronic compoĆ
nents.
D Electrical measurements on electronic components
must be performed using suitable instruments only.
D Do not power electronic control unit components
with vehicle voltage rating.
D Ensure that electronic device wirings (length, type
of wire, location, shielding continuity, if required,
grounding, etc.) comply with the manufacturer sysĆ
tem and that wirings are suitably reset after overĆ
hauling or repair operations.
D Disconnect the batteries from the system during reĆ
charging with external equipment.
D Disconnect the external battery charger from the
civil network before removing its plug-in contacts
from the battery terminals.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąELECTRICAL SYSTEM SECTION 17 ADT 25
Figure 1 Figure 3
D Insulate the system before disconnecting the conĆ D Do not fit tester prods into electronic module conĆ
nector from an electronic module. nector plugs.
D Never cause sparks to check if the circuit is powĆ D Measurements shall be performed with multimeter.
ered. D Do not install additional electric and/or electronic
D Do not touch connector plugs of electronic modules equipment not provided by manufacturer or by the
with your hands. local laws.
D Do not connect negative components of additional
Figure 2 equipment to negative components of electronic
modules.
Figure 4
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 17 ELECTRICAL SYSTEMą7
Figure 5
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąELECTRICAL SYSTEM SECTION 17 ADT 25
Practical hints
Connection between a component and an earthing
point must be as short as possible. Conductors
converging in an earthing point (cab and/or chassis)
must be star-connected between themselves
accurately avoiding overlappings in order to minimise
contact resistance (Figure 6, ref. B).
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 17 ELECTRICAL SYSTEMą9
Figure 6
SHIELDING OF THE CABLE OF AN ELECTRONIC COMPONENT BY MEANS OF A BRAIDED WIRE – C. CONNECTOR – d. GAP ³ 0
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
10ąELECTRICAL SYSTEM SECTION 17 ADT 25
Figure 7
CODE COLOUR BASIC FUNCTION To enable its practical application, the wiring system
1111 Light blue Optical and audible signals has been split into ten main funcions (associated with
2222 White Illumination by headlights ten cable colours), each of them including more speĆ
3333 Yellow Parking lights/side marker
cific functions. Each function is identified by a four-figĆ
lamps ure code number.
4444 Grey Internal lighting Obviously, each function includes more specific sub-
functions.
The first number indicates the basic function of the
cable and identifies always the basic colour of the cable
(the matching of number and colour is indicated in the
table on the side).
The other numbers identify the specific function of the
cable.
Summing up, we can say that:
D a number consisting of four identical figures indiĆ
cates a main function and a single-colour cable;
D a number consistin of four partially or totally different
figures indicates a specific function.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 17 ELECTRICAL SYSTEMą11
7 7777 Red Main supply and pertaining accessories not excluded by the ignition
switch
8 8888 Green Secondary supply and pertaining accessories not excluded by the igniĆ
tion switch
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
12ąELECTRICAL SYSTEM SECTION 17 ADT 25
INTERCONNECTION
CONTROL UNIT
TRANSMISSION
CONTROL UNIT
VIEW A"
RIGHT BACK CAB
(TOP VIEW)
CONTROL UNIT HOUSING
E.C.U.
Gear shift
INTERCONNECTION
VIEW A"
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 17 ELECTRICAL SYSTEMą13
Figure 10
SIDE INSTRUMENT
PANEL
DRIVER SEAT
CENTRAL HOUSING
INTERCONNECTION
CONTROL UNIT
41
42
43
44
46
45
Fu s
Fu s
Fu s
Fu s
Fu s
Fu s
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
14ąELECTRICAL SYSTEM SECTION 17 ADT 25
FUSES
174DT17
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 17 ELECTRICAL SYSTEMą15
TELERUPTORS
Figure 11
1731704Z
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
16ąELECTRICAL SYSTEM SECTION 17 ADT 25
TELERUPTORS
Figure 12
1731705Z1
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 17 ELECTRICAL SYSTEMą17
TELERUPTORS
Figure 13
1731706Z
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
18ąELECTRICAL SYSTEM SECTION 17 ADT 25
Legend
001 12 V batteries
002 Isolator
003 Alternator
004 Starter motor
005 Ignition switch
006 Fuse holder and relay control unit
007 Starter relay
008 Emergency steering pump
009 Emergency steering pump relay
010 Emergency steering pressure switch
011 Current general relay
012
013
014 Park brake switch
015 Idling switch
016
017 Outside lights switch
018 Stalk unit ć flashing lever
019 Stalk unit ć traffic beam ć main beam lever
020 Stalk unit ć turn lights lever
021 Stalk unit ć windscreen wiper lever
022 Stalk unit ć window washer button
023 Stalk unit ć horn button
024 Side and overall lights
024/c Front LH light
024/b
024/c RH side light
024/d
024/e
024/f
024/g RH taillight
025 Side and overall lights
025/c Front RH light
025/b
025/c LH side light
025/d
025/e
025/f
025/g LH taillight
026 LH traffic beam
027 RH traffic beam
028 LH main beam
029 RH main beam
030 Rear fog light switch
031 Reversing switch
032 Brake lights switch
033 Rotating lamps switch
034 Hazard lights switch
035 Lamps test button
036
037 LH map lights switch
038 RH map lights switch
039 Turn light flashing
040 Rear fog light
041 Reversing light
042 Brake lights
043 Turn lights
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 17 ELECTRICAL SYSTEMą19
legend
044 Turn lights
045 Turn lights
046 Turn lights
047 LH adjustable map light
048 RH adjustable maplight
049 Rotating lamps
050 Horns
051 Frame with 10 visual indicators
052 Frame with 10 visual indicators
053 Frame with 10 visual indicators
054
055 Speedometer
056 Rev. counter
057 Engine water temperature gauge
058 Diesel level gauge
059 Engine oil pressure gauge
060 Gearbox oil temperature gauge
061 Hour counter
062 Buzzer
063 Cigar lighter
064 Windscreen wiper
065 Window washer pump
066 Heater unit
067
068 Impulse sender on engine flywheel
069
070 Impulse sender for speedometer
071
072 Engine water high temperature switch
073 Engine water thermostat
074 Engine oil gauge sender
075 Engine oil low temperature switch
076 Fuel level sender
077 Gearbox oil thermostat
078 Clogged brake oil filter vacuum switch
079 Clogged air cleaner vacuum switch
080
081 Accumulator pressure
082
083
084 Parking brake activation pressure
085 Rear differential lock pressure
086 Park-brake pressure (enable idling gear)
087
088
089
090 Cargo body raised microsw.
091
092
093 Heated mirrors switch
094 RH heated mirror
095 LH heated mirror
096
097 Bonnet opening button (chassis)
098 Bonnet opening electric pump
099
100
101 Starting brake oil drainage sol. valve
102 Motor driven mirrors control
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
20ąELECTRICAL SYSTEM SECTION 17 ADT 25
legend
103 LH motor driven mirror
104 RH motor driven mirror
105 ć
106 ć
107 Idling gear relay
108
109
110 D+ signal relay
111 Horns relay
500 Automatic transmission electronic control unit
501 Kick down switch
502 Park brake solenoid valve
503 Jake brake switch (retarder 6WG 260 ZF)
504 Transfer locking switch
505 Jake brake (solenoid A - ADT 30)
506 Jake brake (solenoid B - ADT 30)
507 Park brake switch
508 Gearbox oil high temperature warning light
509 Retarder switch
510 Gearbox oil temperature gauge
511 Retarder solenoid valve
512
513
514 Front work light switch
515 Front work lights
516 ć
517 Oil high temperature warning buzzer
518 Gearbox oil high temperature switch
519 Side window washer/wiper pump
520 LH side wiper
521 RH side wiper
522 Side wiper button
523 Side window washer button
524 Tip-up control lever
525 Cargo body tip-up solenoid valve
526 Switch control lever (ejector)
527 Solenoid valve (ejector side board)
528 Cargo body up end-of travel switch
529 Fuel pump switch
530 24/12 V voltage reducer
531 Additional 12 V current tap
532 Air conditioner switch
533 Air conditioner switch
534 Air conditioner compressor
535 Transfer lock switch
536 TV monitor
537 TV switch
538 ZF display
539 Low temperature start button
540 Low temperature start relay
541 Heater
542 Presetting Tip-up timer
543 24/12 V voltage reducer
544 Additional 12 V current tap
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 17 ELECTRICAL SYSTEMą21
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
22ąELECTRICAL SYSTEM SECTION 17 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 17 ELECTRICAL SYSTEMą23
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
24ąELECTRICAL SYSTEM SECTION 17 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 17 ELECTRICAL SYSTEMą25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
26ąELECTRICAL SYSTEM SECTION 17 ADT 25
Legend
1. Batteries
2. General switch
3. Generator
4. Starter motor
5. Starter relais
6. Emergency pump
7. Emergency pump relais
8. Fuel gauce
9. Horn
10. RH headlight
11. LH headlight
12. Washer
13. Washer (Lateral wiper)
14. Switch kick-down
15. Front diff. lock (Light)
16. Switch tip (Optional)
17. Junction box
18. Reverse
19. Rearfog
20. RH rearlight
21. External buzzer
22. LH rearlight
23. Conn. rear articulation
24. Conn. front articulation
25. Switch tip
26. Intermediate axle
27. Water temperature
28. Engine oil press. (Light)
29. Engine oil pressure
30. Switch park-brake
31.
32. Air cond. (Switch)
33. Solenoid starter
34. Air cond. (Compressor)
35. Transmission temperature
36. E.V. park-brake
37. Stop sender
38. Accumulator sender
39. Emergency switch
40. Pwg tail
41. Push or body
42. Axle disconnect
43. Park-brake solenoid
44. Brake oil filter (light)
45. Tachometer
46. RH intermediate light
47. LH intermediate light
48. Braking oil outlet (Start)
49. Bonnet tipping pump (Opt.)
50. Bonnet tipping switch (Opt.)
51. Low temperature start engine (Opt.)
52. Low temperature start relay (Opt.)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 17 ELECTRICAL SYSTEMą27
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
28ąELECTRICAL SYSTEM SECTION 17 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 17 ELECTRICAL SYSTEMą29
Legend
1. Relay body hoist
2. Relay EMG
3. Relay reverse
4. Diode
5. Relay start
6. Body tipping timer (Opt.)
7. Relay park-brake (Neutral)
8. Buzzer front diff. lock & emg. pump
9. Air filter
10. E.C.U. Astra
11. Tipping
12. Fuses
13. Fuses (Transmission)
14. Lighter
15. Radio 12 V
16. LCD TV
17. R-work-light
18. L-work-light
19. Beacon
20. Lateral wiper motor
21. Wiper motor
22. Switch (Lat. wiper)
23. Switch (Lat. washer)
24. Switch (Heated mirror opt.)
25. Switch (Hazard)
26. Switch (Beacon)
27. Switch (Fwk lights)
28. Switch (Test)
29. Switch (Rearfog)
30. Switch (Tv)
31. Switch (Park-brake)
32. Switch (Lights)
33. Switch (Differential lock)
34. Switch (Jake-brake or retarder)
35. Relay Jake-brake A
36. Relay Jake-brake B
37. Ejector
38. Converter 24/12
39. Flash module
40. Internal light
41. Relay hour meter
42. Relay RH lat. wiper
43. Relay LH lat. wiper
44. Relay lat. washer
45. Relay TV
46. Relay air cond.
47. El. seat
48. Hour meter
49. Coupling air cond.
50. -
51. Tachometer
52. Engine speed indicator
53. Instrument board
54. Warning lights
55. Plug 12 V
56. Remote control mirrors
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
30ąELECTRICAL SYSTEM SECTION 17 ADT 25
57. -
58. Steering column switch
59. Ignition switch
60. Cab/transmission interface
61. -
62. RH heated-motorized mirror
63. LH heated-motorized mirror
64. RH heated mirror
65. LH heated mirror
66. Bonnet tipping relay (Opt.)
67. Low temp. start timer (Opt.)
68. Low temp. start switch (opt.)
69. -
70. Relay jake brake-retarder
71. Relay diff. long. lock
72. Relay emg. pump (Buzzer)
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 18
CONTENTS
Page Page
Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Refit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąCAB AND CHASSIS SECTION 18 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 18 CAB AND CHASSISą3
DESCRIPTION
Central bearing
The vehicle has a central articulation of the chassis, ots on taper roller bearings for movement around the
consisting of a large size central bearing for the moveĆ vertical axis.
ments around the horizontal axis, and two rotating pivĆ
Figure 1
1731801
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąCAB AND CHASSIS SECTION 18 ADT 25
Figure 2
1731802
The articulation around the horizontal axis is obtained In this way the position between the supporting ring
by the use of a large diameter bearing (ball bearing hub and the forked end of the rear chassis is vertically
centre plate) with the outer ring flanged to the front part restrained.
of the chassis. The bearings of the upper pivot, also mounted in X arĆ
Onto the inner ring of the ball bearing centre plate a rangement are axially free in relation to the supporting
supporting ring is flanged. This ring has two hubs - ring hub, to avoid overloading by thermal expansion
lower and upper- into which two pivots are inserted by Both pairs of bearings are pre-loaded to ensure the
means of two adjustable taper roller bearings for each necessary inflectional stiffness of the chassis.
pivot. The latter are integral with the fork shaped end The tightness against dust and water is ensured by
of the rear part of the chassis. special sliding gaskets.
The bearings of the lower pivot are mounted in X arĆ
rangement: both the outer rings are fitted up against a
fixed shoulder inside the hub.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 18 CAB AND CHASSISą5
1891801
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
6ąCAB AND CHASSIS SECTION 18 ADT 25
Figure 3
1731823
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 18 CAB AND CHASSISą7
Figure 4
1731824
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
8ąCAB AND CHASSIS SECTION 18 ADT 25
Figure 5
1731825
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 18 CAB AND CHASSISą9
Figure 6
1731826
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
10ąCAB AND CHASSIS SECTION 18 ADT 25
Figure 7
1731827
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 18 CAB AND CHASSISą11
Figure 8
1731828
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
12ąCAB AND CHASSIS SECTION 18 ADT 25
Figure 9
1731803A
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 18 CAB AND CHASSISą13
D suitable support the knuckle hinge (1), then workĆ D working from above (3) unscrew the mounting
ing from below (2) unscrew the mounting screw (a) screws (a) and remove the spacer (b),the adjustĆ
and remove the spacer (b), the adjustment shims ment shims (c) and the pivot (d);
(c) and the pivot (d); D remove the knuckle hinge from the rear chassis (4);
Figure 10
1731804
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
14ąCAB AND CHASSIS SECTION 18 ADT 25
Figure 11 Figure 13
1731806 1731808
D remove the seal rings (3) and bearings (1) and (2) D assemble the seal rings (3), the taper roller bearings
from the lower seat of the knuckle hinge; (1) and (2) and the spacer (4) from the upper seats
of the knuckle hinge;
Figure 12
. The spacer (4) is fitted between the two
bearings.
Figure 14
1731807
D remove the seal rings (3), bearings (1) and (2) and
the spacer (4) from the upper seat of the knuckle
hinge;
1731809
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 18 CAB AND CHASSISą15
Figure 15
1731810
D from below assemble the pivot (d), then insert (arĆ D select from the available spare parts, the adjustĆ
row) a piece of copper wire, assemble the stop ring ment shims (c) with a thickness S that ensures the
(b) without adjustment shims and tighten the specified bearing pre-load:
screw (a) to the specified torque; S = X ć 0.12 mm (0.005 in)
D remove the screws and the stop ring and measure
thickness X of the copper wire;
Figure 16
1731811
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
16ąCAB AND CHASSIS SECTION 18 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 18 CAB AND CHASSISą17
Figure 19 D Use two shims (1) of the same thickness and of a size
that permits a cord to be stretched throught the straight
length of the lower or upper edge plate of the side
member.
D Measure the distance of the side member from the
cord at 1 metre intervals.
D Different cord distance shows position and entity of
actual side member bending
Figure 22
1731932
Figure 20
1731835
Figure 23
1731833
Figure 21
1731836
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
18ąCAB AND CHASSIS SECTION 18 ADT 25
REPAIR OPERATIONS
Figure 26
Precautions
Figure 24
1731839
Figure 25
1731840
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 18 CAB AND CHASSISą19
Removal
To remove proceed as follows: 1731813
D bring the vehicle onto a suitable flat, solid surface, D Remove conditioner unit compressor connecting
switch off the engine, remove the ignition key, enĆ pipes;
gage the parking brake and apply the warning signĆ D unlock the mounting screws and move aside the
boards. coolant reservoir (7) without overturning it;
D cut off the battery isolator switch or disconnect the D disconnect the engine coolant inlet pipes and the
terminals from the battery to avoid the risk of short cab heating outlet pipes (8);
circuits;
D lock knuckle with the steering lock bar following the . During these operations some coolant may
instructions in SECTION 1.2; spill out.
Figure 28 D from inside the cab, partially remove the rubber mat,
loosen the fastening screws and carefully lower the
pedal board (3) on the chassis, being careful not to
damage the wiring or the pipes;
D raise the boot, loosen the fastening screws and
carefully lower the steering valve (4) on the chassis,
being careful not to damage the pipes;
D remove the hydraulic fitting plate (5) fastening bolts
from the respective silent-block mounts and lower
then plate on the chassis, being careful not to damĆ
age the pipes;
D remove the pipe (6) connecting the engine exhaust
to the exhaust muffler;
D disconnect the electrical connections:
1731812 - chassis-utility connection
D remove the engine hood as described in the ChapĆ - automatic gearbox connection
ter ENGINE HOOD REMOVAL-REFIT; - engine-gearbox connection
D discharge the air conditioning system as described - cab power wire.
in the Chapter AIR CONDITIONER SYSTEM;
Do not discharge R134a into the atmoĆ
sphere. Even if its ozone impoverishment
property is zero, it still has overall heating
properties.
Recovery and recycling are legally conĆ
trolled.
Always use type tested coolant recovery and
recharging equipment.
Never mix different types of coolants in the
same equipment.
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
20ąCAB AND CHASSIS SECTION 18 ADT 25
Figure 30
1891803
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 18 CAB AND CHASSISą21
1731815
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
22ąCAB AND CHASSIS SECTION 18 ADT 25
Figure 32
1731821
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT 25 SECTION 18 CAB AND CHASSISą23
Figure 33
1731822
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
24ąCAB AND CHASSIS SECTION 18 ADT 25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
SECTION 20
BODY
ADT25 SECTION 20 BODYą1
CONTENTS
Page Page
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
2ąBODY SECTION 20 ADT25
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
ADT25 SECTION 20 BODYą3
Figure 1
174DT01
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
4ąBODY SECTION 20 ADT25
1731901
For the personnel and vehicle safety, read carefully the SAFETY INSTRUCTIONS contained in this handbook
