F1CE
F1CE
* I riferimenti originali e le immagini sono riportati unicamente a titolo indicativo * The OE references and pictures are given for the purpose of explanation only *
confronti dei suoi clienti, mette a disposizione l’intera
gamma di prodotti necessari per il ripristino dei motori della
famiglia F1CE.
I componenti proposti sono raccolti per semplificare la
ricerca su di un unico catalogo dedicato, riportando
riferimenti OEM, riferimenti Mec Diesel, descrizioni,
applicazioni, tipo motore e specifiche tecniche, fornendo i
dati necessari per identificare il corretto particolare e
garantire la miglior funzionalità del motore stesso.
La MEC DIESEL S.p.A, da sempre attenta alle esigenze di
mercato, vi ringrazia per la collaborazione in termini di
segnalazioni, necessarie per l’aggiornamento gamma
prodotti.
MEC DIESEL S.p.A.
MEC DIESEL S.p.A, the engine spare parts leader, in order to provide a complete service to
its customers, offers a full range of products required to rebuild F1CE engines.
This catalogue is meant to simplify products requests for our Valued Customers, providing
OEM references, Mec Diesel references, descriptions, applications, engine types and
technical specifications, in order to identify the correct spare part and ensure the best
functionality of the engine.
MEC DIESEL S.p.A, always focused on market’s needs, thanks you in advance for your co-
operation required to update the product lines.
MEC DIESEL S.p.a.
OE FIAT 4832141
MEC 101390
TESTA CILINDRI
Cylinder Head
OE IVECO 504384837
MEC 12000
ALBERO MOTORE
Crankshaft
MEC 342030
ELETTROINIETTORE - EURO 5
Injector - Euro 5
* I riferimenti originali e le immagini sono riportati unicamente a titolo indicativo * The OE references and pictures are given for the purpose of explanation only *
Tipo motore F1A / F1C
Engine type
OE IVECO 5801455560
OE FIAT 504014269, 504074464
OE CITROEN 0903H9, 0903J9
MEC 41000
BIELLA
Con Rod
OE IVECO 504341496
OE FIAT 504113130
MEC 383300
MEC DESCRIZIONE OE
382830 Tendicatena 5801514998
382980 Comando pompa alta pressione 504161356
900670 Pattini + vite fissaggio 504084528
960600 Guarnizione coperchio ant. basamento 504380259
967230 Guarnizione pompa olio 504081697
520580 Paraolio 504056152
MEC 140281
POMPA OLIO
Oil Pump
Alternatore Alternator
432033 432033M IVECO 504087183 Alternatore Ducato/Daily 3.0 hpi Euro 4/Euro 5 110A/12V
Alternator
Basamento Crankcase
Bronzina Bearing
163001 843061 IVECO 2996628 Serie biella +010 F1CE0481a - Daily 35c14 3.0
Conrod bearing set + 010
163030 843070 IVECO 500054637 Serie banco STD F1CE0481 - Daily 35c14 3.0 hpi
Main bearing set std
163031 843071 IVECO 500054638 Serie banco +010 F1CE0481 - Daily 35c14 3.0 hpi
Main bearing set + 010
* I riferimenti originali e le immagini sono riportati unicamente a titolo indicativo * The OE references and pictures are given for the purpose of explanation only *
Cambio Gear Box
Cinghie Belts
Coperchio Cover
902920 IVECO 42560782 Regolatore common rail Ducato/ Daily 3.0 F1CE0481
Pressure control valve, common rail system
Filtri Filters
440505 IVECO 5801317093 Filtro aria F1CE3481 - Daily 3.0 Euro 4/Euro 5
Air filter
Frenante Breaks
Frizioni Clutch
Guarnizioni Gaskets
250025 T8002035 IVECO 2996892 Guarnizione smeriglio F1CE3481c Daily 35C17 2009-> g tc 1,20mm
Valve refacing gasket set
250490 IVECO 2995573 Guarn. smeriglio F1CE0481 - 35C14/C17/C15H - Euro 3 sp.1,20 con g.tc. 504082942
Valve refacing gasket set
* I riferimenti originali e le immagini sono riportati unicamente a titolo indicativo * The OE references and pictures are given for the purpose of explanation only *
284980 875036 IVECO 504093499
Cylinder head gasket
284981 875035 IVECO 504093500 Guarn.testa F1CE0481 Daily 3.0jtd Euro 4 sp.1,10 2tac. Peugeot Boxer / Citroen Jumper
Cylinder head gasket
284982 875037 IVECO 504093501 Guarn.testa F1CE0481 Daily 3.0jtd Euro 4 sp. 1,30 3tac. Peugeot Boxer / Citroen Jumper
Cylinder head gasket
910060 FIAT 504083813 Guarnizione coppa olio F1CE0481 - Daily 3000 16v
Gasket, oil sump
613141 FIAT 504053805 Guida valvole Daily/Ducato 2.3/3.0 - f1a/f1c in/ex diam. 10,10
Valve guide ø 10,10
613143 FIAT 504053806 Ingranaggio comando distribuzione Daily/Ducato 2.3/3.0 - f1a/f1c in/ex diam. 10,20
Valve guide ø 10,20
Ingranaggio Gear
782100 IVECO 500054581 Kit rettifica F1CE0481A/B/E/L(pist.mec) d.95,8 sofim hpi 3.0jtd 16v(vasc.50/67mm)
Engine repair kit with piston d.95,8 bowl 50/67mm
782105 782105 Kit rettifica F1CE0481A/B/E/L(pist.mec) c/v d.95,8 sofim hpi 3.0jtd 16v(vasc.50/67mm)
Engine repair kit with piston c/v d.95,8 bowl 50/67mm
782115 782115 Kit rett. F1CE0481A/B/E/L(pist.mec) c/v d.95,8+040sofim hpi 3.0jtd 16v(vasc.50/67mm)
Engine repair kit with piston c/v d.95,8+040 bowl 50/67mm
782200 782200 Kit rettifica motore F1CE0481D (pist.mec) d.95,8 sofim hpi 3.0jtd 16v(vasc.50/67mm)
Engine repair kit with piston d.95,8 bowl 50/67mm
782210 782210 Kit rettifica F1CE0481D (pist.mec) d.95,8+0,4sofim hpi 3.0jtd 16v(vasc.50/67mm)
Engine repair kit with piston d.95,8+0,4 bowl 50/67mm
782215 782215 Kit rettifica F1CE0481D (pist.mec) c/v d.95,8+0,4sofim hpi 3.0jtd 16v(vasc.50/67mm)
Engine repair kit with piston c/v d.95,8+0,4 bowl 50/67mm
782230 782230 Kit rettifica F1CE0481D (pist.iveco) d.95,8+0,4sofim hpi 3.0jtd 16v(vasc.50/67mm)
Engine repair kit with piston d.95,8+0,4 bowl 50/67mm
782730 782730 Kit rettifica F1CE0481H/F (pist.mec) d.95,8 sofim hpi 3.0jtd 16v(vasc.50/67mm)
Engine repair kit with piston d.95,8 bowl 50/67mm
782740 782740 Kit rettifica F1CE0481H/F (pist.mec) d.95,8+040sofim hpi 3.0jtd 16v(vasc.50/67mm)
Engine repair kit with piston d.95,8+040 bowl 50/67mm
782745 782745 Kit rettifica F1CE0481H/F (pist.mec) c/v d.95,8+040sofim hpi 3.0jtd 16v(vasc.50/67mm)
Engine repair kit with piston c/v d.95,8+040 bowl 50/67mm
782750 782750 Kit rettifica F1CE0481H/F (pist.iveco) d.95,8 sofim hpi 3.0jtd 16v(vasc.50/67mm)
Engine repair kit with piston d.95,8 bowl 50/67mm
782760 782760 Kit rettifica F1CE0481H/F (pist.iveco) d.95,8+040sofim hpi 3.0jtd 16v(vasc.50/67mm)
Engine repair kit with piston d.95,8+040 bowl 50/67mm
784730 784730 F1CE3481B/C/D/J/L e5(pist.mec) d.95,8+040sofim hpi 3.0jtd 16v my 2012 (vasc.50/67)
Engine repair kit with piston d.95,8+040 bowl 50/67mm
784735 784735 F1CE3481B/C/D/J/L e5(pist.mec) d.95,8+040sofim hpi 3.0jtd 16v my 2012 (v.50/67)cv
Engine repair kit with piston d.95,8+040 bowl 50/67mm
784740 784740 F1CE3481B/C/D/J/L Euro 5(pist.ive) d.95,8 sofim hpi 3.0jtd 16v my 2012 (vasc.50/67)
Engine repair kit with piston d.95,8 bowl 50/67mm
784750 784750 F1CE3481B/C/D/J/L Euro 5(pist.ive) d.95,8+040sofim hpi 3.0jtd 16v my 2012 (v50/67)
Engine repair kit with piston d.95,8+040 bowl 50/67mm
784755 784755 F1CE3481B/C/D/J/L e5(pist.ive) d.95,8+040sofim hpi 3.0jtd 16v my 2012 (vasc.50/67)cv
Engine repair kit with piston d.95,8+040 bowl 50/67mm
* I riferimenti originali e le immagini sono riportati unicamente a titolo indicativo * The OE references and pictures are given for the purpose of explanation only *
130165 IVECO 504060014
Suction strainer
132455 IVECO 504385754 Ugello spruzzatore F1CE0481 ugello + bocchettone 500370623 (132450)
Oil nozzle
760600 IVECO 504342503 Molla valvola F1CE0481 - Daily/Ducato - 3.0 jtd Euro 5
Valve spring
71080 IVECO 5801470458 Motore completo F1CE0481f*c - 35C15 m.y.2006 - 3.0 hpi
Complete engine
72077 FPT 504377544 Motore completo F1CE3481v* - canter 3.0 hpi - mits. Fusocon turbo 504371348
Complete engine with turbo
73750 FIAT 5801398219 Motore completo F1CE3481e - Ducato 3.0 hpi 2011->
Complete engine
74990 504379961 Mot.completo F1CE3481H* - canter 3.0 hpi - mits. Fuso con turbo 504360048 (biturbo)
Complete engine
76605 IVECO 5801397826 Motore completo F1CE3481k*b111 - Daily 3.0 hpi 170 cv
Complete engine
91510 FIAT 5801466143 Motore semicompleto F1CE3481e - Ducato 3.0 hpi 2011->
Long block
94980 FIAT 504148569 Mot. semicompl. F1CE0481d Ducato 3.0 jtd Euro 4 no catena senza distrib/camb.coppa
Long block without timing chain
Pistoni Pistons
120204 858564 IVECO 2996843 Pistone F1CE0481a - 35c14 3.0 jtd d.95,8+0,4Daily/Ducato 16 valvole
Piston ø 95,8 +0,4
123160 852550 IVECO 2996894 Pistone F1CE3481 - Daily Euro 5 - 2009 d.95,8
Piston ø 95,8
123164 852554 IVECO 500054560 Pistone F1CE3481 - Daily Euro 5 2009-> d.95,8+040
Piston ø 95,8 +0,4
Pompe Pumps
350620 350621 IVECO 504369725 Pompa acqua F1CE0481/3481 - Daily 3.0 jtd perno h.76perno h.76
Water pump - pin h76
350870 IVECO 504086476 Pompa acqua F1CE0481 Euro 5 3.0 hpi - dail y/multicar
Water pump
* I riferimenti originali e le immagini sono riportati unicamente a titolo indicativo * The OE references and pictures are given for the purpose of explanation only *
910290 910290
Turbo charger mounting kit
810324 IVECO 2995583 Segmenti pistoni F1CE0481a (2,5-2-2,5) 3.0 jtd d.95,8+0,4sofim hpi
Piston rings (2,5-2-2,5) ø 95,8 + 0,4
Sensori Sensors
943100 IVECO 504129943 Sensore albero motore Ducato 2.3 /3.0 hpi
Crankshaft sensor
Sterzo Steering
PS000291 IVECO 504243641 Pompa idraulica sterzo Daily 3.0 hpi - F1CE0481
Hydraulic pump, steering system
989992 IVECO 500301568 Tappo intr. Olio Daily 3.0 hpi f1c/8140
Oil cap
COD.MEC OE DESCRIPTION
382830 5801514998 Tendicatena
382980 504161356 Comando pompa alta pressione
Componenti 900670 504084528 Pattini + vite fissaggio
Components
960600 504380259 Guarnizione coperchio ant. Basamento
967230 504081697 Guarnizione pompa olio
520580 504056152 Paraolio
COD.MEC OE DESCRIPTION
382995 504294672 Tendicatena
382835 5801628694 Comando albero a camme
Componenti 900680 504310252 Pattini + vite fissaggio
Components
968100 504334326 Guarnizione pompa olio
520580 504056152 Paraolio
960600 504380259 Guarnizione coperchio ant. basamento
382830 IVECO 5801514998 Kit catena com.distrib. F1CE04 distrib. Caten.com.alb.camme 61maglie/ingr.inf.24denti
Timng chain control kit 61 mails / lower gear 24 teeth
382835 IVECO 5801628694 Kit catena com.distrib. F1CE34 distrib. Catena com.alb.camme(ingran.infer. 20 denti)
Timing chain kit / camshaft lower gear control 20 teeth
382980 FIAT 504161356 Kit catena com.distrib. F1CE04 aliment. Com. pompa alta pressione(ingr.30/25denti)
Timing chain kit / camshaft lower gear control 30/25 teeth
382995 IVECO 504294672 Kit catena com.distrib. F1CE34 aliment. Com. pompa alta pressione(ingr.25/25denti)
Timing chain kit / camshaft lower gear control 25/25 teeth
* I riferimenti originali e le immagini sono riportati unicamente a titolo indicativo * The OE references and pictures are given for the purpose of explanation only *
900250 FIAT 504189626
Timing pump bearing
900670 IVECO 504084528 Pattino distribuzione F1CE0481 Daily 3.03 pezzi ( 2 pattini+vite fissaggio )
Timing chain kit 2 sliders + bolts
900680 FIAT 504310252 Pattino distribuzione F1CE3481 Daily 3.03 pezzi ( 2 pattini+vite fissaggio )
Timing chain kit 2 sliders + bolts
Termostati Thermostat
101100 IVECO 504110672 Testa cilindri F1CE0481a - Daily 3.0jtd e3 se nza EGR sostituibile con 101300 + gt
Cylinder head
101300 101301 FIAT 504213159 Testa cilindri F1CE0481a-Daily/Ducato 3.0jtd e4 con EGRsofim hpi - 16 valvole
Cylinder head
101390 101391 IVECO 504384837 Testa cil. F1CE3481 - Daily - 3.0 jtd e5 bi-turbo 2012-> per versioni con turbina doppia
Cylinder head
101400 101401 IVECO 504385398 Testa cil. F1CE3481 - Daily/Ducato - 3.0 jtd Euro 52012-> per versioni con turbina sing.
Cylinder head
Thermal System
COD.MEC ALTERNATIVES OE DESCRIPTION
700130 504253934 Compress.condizionatore Ducato
Thermal system
Turbosoffianti Turbocharger
533400 IVECO 5801601316 F1CE3481C - Daily 35C14/C17 e5 my 2012 turbina principale della biturbo 504360048
Turbocharger
533405 IVECO 5801601355 F1CE3481C - Daily 35C14/C17 e5 my2012 turbina minore della biturbo 504360048
Turbocharger
940884 IVECO 504317811 Valvola EGR F1CE3481 Euro 5 - 3.0 Daily v F1CE3481J/C/D
Egr valve
940886 IVECO 504264089 Corpo valvola EGR Daily 3.0 dal 2006 al 2009
Egr valve body
940888 IVECO 504121701 Valvola ricircolo gas scarico F1CE0481 EGR - Ducato/Daily/Multicar 3.0 hpi
Egr valve
Volani Flywheel
181400 181401 IVECO 504196244 Volano F1CE0481 - Daily 35C17 - doppia massa
Flywheel
