PERFORMANCE
HIGH PERFORMANCE
Brembo S.p.A.
Via Brembo 25
24035 Curno (BG) - Italy
Tel.: +39 035 605 1111
Fax: +39 035 605 2766
HighPerformance@brembo.it
MBK19-A
www.brembo.com
www.moto.brembo.com
Introduzione 2
Introduction
Istruzioni 4
Installation instructions
Pinze 10
Calipers
Pompe 82
Master Cylinders
Dischi 126
Discs
Pastiglie 140
Pads
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 1 19/09/18 13:19
INTRODUZIONE
INTRODUCTION
I UK D
Brembo è il Fleader
E
deiDK
freni
Brembo è leader mondiale dei sistemi frenanti per auto, moto,
veicoli industriali e commerciali. È attiva in 3 continenti, con
stabilimenti produttivi in 15 paesi e distribuzione in 70 paesi del mondo.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 2 19/09/18 13:19
I UK D F
Brembo, #1 Efor brakes
DK
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 3 19/09/18 13:19
ISTRUZIONI
INSTALLATION
INSTRUCTIONS
I UK D F E DK I UK D F E DK
1. SCOPO 1. SCOPE
Descrivere le corrette procedure per il montaggio e l’uso To show the correct procedures for the mounting and use
degli impianti frenanti dedicati alle competizioni. of BREMBO front braking systems for racing motorcycles.
2. SERBATOIO OLIO 2. RESERVOIR
2.1. Scelta del serbatoio 2.1. Reservoir’s Choice
La capacità del serbatoio deve essere tale da garantire che il The capacity of the reservoir must be such that when the
livello del fluido freno sia compreso fra MIN e MAX, anche in brake fluid is between the MIN and MAX levels (with the cover
caso di consumo massimo sia delle pastiglie che del disco. in a horizontal position) the volume is at least equal to that
2.2. Montaggio serbatoio required by the brake pistons in case of maximum pad and
a. Il serbatoio deve essere montato in maniera tale da risultare rotor wear.
verticale quando la motocicletta si trova in posizione di 2.2. Reservoir fitting
marcia. a. The reservoir must be mounted on the motorcycle in such a
b. Con la motocicletta in ordine di marcia, la tacca di MIN del way that with the motorcycle in a vertical position, the
serbatoio deve trovarsi al di sopra del punto d’ingresso olio reservoir upper border in horizontal.
nella pompa. b. With the motorcycle in a vertical position, the MIN level
2.3. Ispezione indication on the reservoir must be higher than the master
Verificare che l’olio possa liberamente fluire attraverso il cylinder fluid inlet pipe fitting.
serbatoio. Può accadere che il passaggio aria permesso dalla 2.3. Inspection
membrana posta sotto il tappo s’interrompa, generando così Verify that the brake fluid can flow freely within the reservoir,
una sorta di “effetto vuoto” che impedisce questo passaggio. from the upper border down to the MIN level. This happens
Attenzione alle classiche bande in spugna poste sul serbatoio when air can flow from the exterior to the inside of the
stesso: queste non devono essere poste troppo vicine al reservoir membrane (if this air flow is hampered, a vacuum
tappo di chiusura, potrebbero impedire all’aria di entrare. could be created and this would not allow fluid to flow
3. POMPA FRENO downwards). The popular bands that are usually wrapped
3.1. Montaggio around brake fluid reservoirs (if they are too close to the
a. Montare la pompa sul manubrio verificando che non ci reservoir cover) could hamper this “breathing” of the reservoir
siano impedimenti alla possibilità di ruotarla ed adeguarla and thus the master-cylinder would not be fed properly.
alle necessità del pilota. 3. BRAKE MASTER-CYLINDER
b. Regolare la distanza della leva dal manubrio, agendo 3.1. Fitting
sull’apposito registro, in modo che il pilota abbia il giusto a. Mount the master-cylinder to the handlebar keeping in
feeling con il freno. mind that it can be positioned in any manner requested by
3.2. Ispezione the driver.
Azionare la leva freno a fondo, fino a farla toccare contro il b. Adjust the lever distance from the handlebar by turning the
manubrio, in modo da verificare che il pistoncino della pompa adjusting nut either clockwise or anticlockwise according to
faccia tutta la corsa con movimento “morbido”, senza the driver’s requirements; it must be noted that the lever
impuntamenti di sorta. positioning must allow the driver to generate the pressure
4. DISCHI IN ACCIAIO necessary to stop the motorcycle.
4.1. Montaggio 3.2. Inspection
a. Controllare che non ci siano bave o altri residui di Pull the lever until it touches the grab handle on the handlebar
lavorazione tra le facce d’accoppiamento della ruota e della and verify that the master-cylinder piston stroke is smooth.
campana del disco. 4. STEEL BRAKE DISCS
b. Il disco deve montare sulla ruota facilmente. 4.1. Fitting
c. I fori di fissaggio del disco devono avere un diametro a. Verify that the disc bell and wheel mounting faces are free
adeguato alla vite, le viti devono essere della qualità e della from burrs and dents, otherwise these surfaces should be
lunghezza adeguata al lavoro che devono svolgere ed il loro reconditioned.
serraggio effettuato con una chiave dinamometrica, tarata b. The disc must fit onto the wheel easily.
in maniera corretta. c. The disc must be mounted onto the wheel by using bolts
d. È consigliabile applicare le vernici termoviranti in modo da having a diameter which corresponds to the holes in the
controllare la temperatura d’esercizio. mounting bell; the bolts must be of the quantity and length
4.2. Ispezione 2/7 as prescribed by the motorcycle manufacturer and
Il disco deve poter flottare liberamente dopo il montaggio. Il must be tightened at the appropriate torque.
gioco minimo deve essere di 0,2 mm. d. It is suggested to apply thermal paints on the disc outer
4.3. Note circumference in order to monitor operating temperatures.
Il disco non deve essere stato soggetto a shock meccanici 4.2. Inspection
oppure contaminato da liquidi corrosivi, olio o grasso. The disc must be “floating” even after it has been mounted
onto the wheel: axial clearance between disc and bell must be
0,2 mm MIN.
4.3. Note
The discs must not be subjected to mechanical shock, and
must not be contaminated with liquids, oil and grease.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 4 19/09/18 13:19
5. PINZE 5. CALIPERS
5.1. Montaggio 5.1. Fitting
a. Montare le pinze in modo che la freccia marcata sulla parte a. Mount the caliper onto the fork such that the arrow marked
esterna della pinza coincida con il senso di rotazione della on the outer half-caliper corresponds to the forward
ruota (nel caso di pistoni differenziati il disco deve “entrare” direction of rotation of the brake disc (the disc must enter
dal lato del pistoncino di diametro inferiore e, the caliper through the side corresponding to the smaller
conseguentemente, uscire da quello di diametro maggiore). piston and exit through the other side corresponding to the
b. La pinza deve essere montata in modo che il suo asse di larger piston).
mezzeria corrisponda con quello del disco (vedi figura 1). È b. The caliper must be mounted in a symmetrical position with
ammesso un disallineamento MAX di 0,15 mm. respect to the disc center line: Misalingment must be 0,15
c. La distanza tra il diametro esterno del disco e i lati della mm MAX (see fig. 1).
pinza deve essere almeno di 2 mm (vedi figura 2). c. The clearance between disc outer circumference and
d. Le viti di fissaggio della pinza devono essere serrate con la caliper bridge must be 2 mm MIN (see fig. 2).
chiave dinamometrica alla coppia prescritta. d. The caliper mounting bolts must be tightened to the
e. Applicare all’interno della pinza (vedi figura 3) gli adesivi prescribed torque.
indicatori della temperatura MAX raggiunta (Thermotape), in e. Apply thermal tape on the internal half-caliper in order to
modo da monitorare la temperatura d’esercizio. monitor operating temperatures: these can be supplied by
f. Le pinze portate in sovratemperatura devono essere BREMBO under part number R 02.5168.11/12 (for the
revisionate. application area see fig. 3).
6. PASTIGLIE PER DISCHI IN ACCIAIO f. Overheated calipes should be overhauled.
6.1. Montaggio 6. PADS FOR STEEL DISCS
a. Le pastiglie devono poter essere inserite nella pinza senza 6.1. Fitting
interferenza e senza dover applicare una forza eccessiva. a. The pads must be inserted inside the caliper without any
b. Le pastiglie, una volta montate, non devono fuoriuscire interference and without requiring any excessive force.
oltre il diametro esterno del disco bensì starne al di sotto di b. The pads must not protrude from the disc; the disc may
circa 0,5 mm. Per ottenere questa posizione si sfrutta il protrude from the pads by 0,5 mm. MAX (see fig. 4 and fig.
gioco esistente tra i bulloni di fissaggio ed i fori sul 5); to obtain the correct positioning of the caliper, as
supporto (vedi figure 4/5). described above, it can be moved relative to the fork by
6.2. Ispezione using the existing clearance between the fixing holes and
Verificare che il perno di sostegno pastiglie e la copiglia di the caliper bolts.
ritegno siano correttamente montati. Suggeriamo di mettere i 6.2. Inspection
vari componenti in sicurezza utilizzando filo di ferro passato Verify that the pad pin and cotter pin have been correctly
negli appositi fori. installed; it is suggested to tie the pad pin to the caliper and
pads with iron wire through the appropriate holes.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 5 19/09/18 13:19
ISTRUZIONI
INSTALLATION
INSTRUCTIONS
7. COLLEGAMENTO SERBATOIO OLIO/POMPA 7. RESERVOIR / MASTER-CYLINDER HOSE
7.1. Scelta del tubo 7.1. Hose’s choice
Utilizzare il tubo in gomma nera compatibile con il fluido freni. Black rubber hose, compatible with brake fluid, could be
I tubi trasparenti sono raramente compatibili con il fluido freni used; transparent plastic hose could also be used: The rubber
e, se utilizzati, devono essere sostituiti periodicamente. hose is the better solution, but it is not possible to see
7.2. Montaggio through it, and so you could not see possible air bubbles; the
Il tubo deve collegare l’uscita del serbatoio con l’entrata della transparent plastic hose is better in this sense but since it is
pompa, appropriate fascette stringitubo devono essere not compatible with brake fluid, sweating could occur and so
utilizzate alle due estremità. it would have to be changed periodically.
8. COLLEGAMENTO POMPA/PINZA 7.2. Fitting
8.1. Scelta del tubo The hose must connect the reservoir outlet with the master-
a. Suggeriamo fortemente di utilizzare tubazioni con l’interno cylinder inlet; the appropriate hose clamps must be used at
in teflon e con l’esterno rivestito in maglia d’acciaio. both ends.
b. Il diametro della tubazione interna deve essere almeno di 3 mm. 8. MASTER-CYLINDER / CALIPER HOSE
8.2. Montaggio 8.1. Hose’s choice
a. I bocchettoni devono essere serrati con la coppia appropriata. a. It is suggested to use teflon flexible hose steel-braided
b. Le guarnizioni, sia in rame che in alluminio, devono essere covered.
utilizzate una sola volta. b. T he flexible hose must have an internal diameter of 3 mm
9. FLUIDO FRENI MIN.
9.1. Scelta 8.2. Fitting
a. Utilizzare esclusivamente DOT 4 ad alto punto d’ebollizione. a. Hose fittings must be tightened to the prescribed torque.
b. Utilizzare sempre fluido freni proveniente da confezioni nuove. b. The copper (or aluminium) washers can only be used once.
c. Sostituire il fluido freni prima d’ogni gara. 9. BRAKE FLUID
9.2 Note 9.1. The Choice
L’utilizzo di liquidi diversi dal fluido freno potrebbe provocare il a. Use only high boiling point DOT 4 brake fluids.
danneggiamento dei componenti dell’impianto frenante. b. Use only the brake fluid from a new and sealed container.
10. SPURGO IMPIANTO c. Change the brake fluid before each race.
10.1. Procedura 9.2. Notes
Per effettuare uno spurgo corretto procedere come segue: The use of other liquids will damage the braking system
a. Girare il manubrio fino a portare il bordo del serbatoio olio components.
in posizione orizzontale. 10. BRAKE SYSTEM BLEEDING
b. Riempire il serbatoio di fluido. Attenzione: durante tutta la 10.1. Procedure
procedura di spurgo il livello olio nel serbatoio non deve In order to bleed the system, proceed as follows:
mai scendere sotto il livello MIN. a. T urn the handlebar until the border of the reservoir is
c. Azionare più volte la leva freno per effettuare un parziale horizontal.
riempimento del circuito. b. F ill the reservoir with brake fluid. Attention: during bleeding
d. Inserire un tubo di gomma trasparente sulla vite di spurgo. avoid letting the brake fluid level go under the MIN level.
e. Spurgare l’impianto ripetendo quanto segue: c. A pply the brakes several times and fill-in the braking
• Tirare la leva freno completamente e mantenerla in questa system partially.
posizione. d. Insert a flexible transparent hose on the caliper bleed
• Svitare la vite spurgo e lasciare che l’olio misto ad aria screw.
fuoriesca dall’impianto. e. Bleed through one bleed screw at a time:
• Serrare delicatamente la vite spurgo. • Pull the completely the brake lever and keep it in this
• Ripetere questa serie di operazioni fi nchè dall’impianto position.
uscirà solamente olio. Ricordiamo di rabboccare il livello olio • Unscrew the bleed screw, let some brake fl uid flow out
nel serbatoio in modo che non scenda mai sotto il livello (initially only air will come out).
minimo. • Tighten the bleed screw (lightly).
f. Serrare la vite spurgo alla coppia corretta e riempire • Let go the brake lever, wait a few seconds and repeat the
definitivamente il serbatoio. above steps until no air bubbles will come out of the bleed
g. Verificare che non ci siano perdite nel circuito. Se screw.
l’operazione di spurgo è stata effettuata correttamente, non f. T
ighten the bleed screw to the prescribed torque and fill up
si avvertirà alla leva “l’effetto spugna”, indicante la the reservoir with brake fluid.
presenza d’aria nell’impianto. In quest’ultimo caso è g. V erify that there are no leakages from the various fittings
obbligatorio ripetere le operazioni di spurgo. and connections. If the braking system has been bleed
N.B.: properly, following the lever dead travel, you will feel the
• Il fluido freni è corrosivo. direct action of the fluid without any sponginess. Repeat
• Lo spurgo non elimina TUTTA l’aria all’interno del circuito, the complete procedure in case of different results.
qualche piccolissima bolla d’aria resterà necessariamente N.B.:
all’interno. Queste bollicine saranno eliminate • Brake fl uid corrodes the paints.
automaticamente durante la fase di primo utilizzo dei freni, • Bleeding will not eliminate completely the air inside the
come risultato si noterà un accorciamento della corsa leva. braking system; the small residual air bubbles that remain in
the braking system will be eliminated automatically during the
initial brake applications: this will result in a shorter lever travel
and less elastic feeling.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 6 19/09/18 13:19
10.2. Note 10.2. Notes
Qualora non si riesca ad eliminare l’effetto spugna nonostante If the lever seems too elastic following the bleeding
ripetute procedure di spurgo, effettuare la seguente operazione: procedure, proceed in the following manner:
a. Rimuovere una pastiglia freno dalla pinza. a. Remove one brake pad from a caliper.
b. Azionare la leva freno in modo da far uscire di 3/4 mm il b. Apply the brakes several times so as to push-out the
pistoncino dalla propria sede. pistons about 3/4 mm.
c. Spingere il pistoncino completamente in sede. c. Push back the pistons (avoid damaging the disc and the
d. Rimontare la pastiglia. pistons).
e. Ripetere l’operazione descritta applicandola a tutti i d. Put the brake pad back into the caliper.
pistoncini. e. Repeat the above steps on the other(s) pad(s) and/or
f. Verificare l’effetto di quest’operazione. caliper(s).
11. RODAGGIO PASTIGLIE E DISCHI IN ACCIAIO f. Verify whether brake lever travel has improved.
a. F atta eccezione per alcuni specifici materiali d’attrito, il 11. BEDDING-IN (BURNISH PROCEDURE)
rodaggio dovrebbe essere terminato dopo circa 5 giri di a. E xcept for particular instructions for specific friction
pista compiuti a velocità media, quando cioè almeno il 90% materials, running-in may be done after 5 laps at average
della superficie del materiale d’attrito è venuto a contatto speed; at least 90% of the pad surface must be in contact
con il disco. with the disc surface for running-in to be considered
b. Evitate di rodare le pastiglie mantenendo sia l’acceleratore complete.
che il freno azionati: così facendo si generano b. Avoid running under power with the brakes applied: this will
sovratemperature che possono portare a variazioni cause sudden temperature increases which may change
sostanziali delle caratteristiche del materiale d’attrito. the friction characteristics of the pads.
c. Rodare i dischi nuovi utilizzando pastiglie usate. Rodare le c. It is suggested to use used pads for new discs and used
pastiglie nuove utilizzando dischi usati. discs for new pads.
12. CONTROLLO FINALE 12. BRAKING SYSTEM FINAL INSPECTIONS
Dopo aver percorso alcuni giri di pista, è conveniente After running a few laps, it is necessary to carry out the
effettuare i seguenti controlli: following checks:
a. La ruota deve poter ruotare liberamente (la coppia residua a. The wheels must rotate freely without any brake drag.
deve essere quindi minima). b. There must not be any interference between disc and
b. Non ci deve essere alcun’interferenza tra disco e pinza caliper.
freno. c. T
he caliper temperature must not exceed 130°C (verify
c. La temperatura della pinza in esercizio non deve superare i through the thermotapes of the caliper see fig. 3).
130°C (fate riferimento alle Thermotapes descritte in figura 3). 13. BRAKE SYSTEM INSPECTION AFTER USE
13. ISPEZIONE COMPONENTI DOPO L’USO 13.1. Hose fi ttings
13.1. Raccordi tubazioni Verify that there are no leakages from the various components,
Verificare che non ci siano perdite dai vari componenti; se ci connections, or fittings. If a leak is found on one of the fittings,
fosse un trafilaggio dalle guarnizioni dei raccordi provare ad either increase the tightening torque, or replace the defective
aumentare leggermente il serraggio del bocchettone. Se la component.
perdita persistesse, sostituire il componente. 13.2. Steel discs
13.2. Dischi in acciaio a. The discs must be free from cracks of any kind (either
a. Il disco deve essere assolutamente privo di cricche (siano originating from the holes or from the borders) and must not
esse generate dai fori di pulizia pastiglie oppure dal bordo show anomalous wear or scratch marks.
del disco) e non devono presentare alcun consumo b. Thickness of the braking surfaces cannot be reduced by
anomalo. more than 0,5 mm with respect to the original thickness
b. Lo spessore minimo dei dischi in acciaio è di 0,5 mm (0,25 + 0,25 mm for each of the two braking surfaces).
inferiore allo spessore di partenza. La sostituzione del disco Defective or excessively worn discs should be changed.
freno comporta necessariamente anche la sostituzione di Keep in mind that when a disc has to be changed, the
tutto l’assieme disco/campana. whole disc-bell assembly must be changed.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 7 04/10/18 10:18
ISTRUZIONI
INSTALLATION
INSTRUCTIONS
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 8 19/09/18 13:19
LIMITAZIONI DI
RESPONSABILITÀ
LIMITED WARRANTY
I BREMBO
UK D S.p.A.
F (“Produttore”)
E DK garantisce I UK BREMBO
D F S.p.A.
E (“Manufacturer”)
DK guarantees to
all’utilizzatore originario che il Prodotto the original user that the Product meets the
corrisponde alle specifiche indicate nel catalogo specifications indicated in the catalogue and is
ed è privo di difetti nei materiali e nella lavorazione. free from defects in the materials and workmanship.
Nel caso vengano rilevati difetti nei materiali o nella If any defects in the materials or workmanship of the
lavorazione del Prodotto, il consumatore è onerato Product are detected, the consumer is required to
di denunciare al venditore il difetto di conformità nel report the lack of conformity to the vendor within
termine di due mesi dalla data in cui ha scoperto il two months from the date on which the defect was
difetto, ai termini ed alle condizioni previste nel discovered, under the terms and conditions set out
libretto di istruzioni del Prodotto stesso, fermo in the instruction booklet of the Product, without
restando che l’azione diretta a far valere il difetto si prejudice to the fact that direct action to allege the
prescrive nel termine di ventisei mesi dalla consegna defect is prescribed within the term of twenty-six
del bene. months from delivery of the goods.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 9 19/09/18 13:19
PINZE
CALIPERS
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 10 27/09/18 10:35
kW
F - Part Number R - Part Number
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 11 27/09/18 10:35
PINZE FRENO
BRAKE CALIPERS
I UK
PotenzaD e precisione
F E DK
da MotoGP
Le pinze freno Brembo combinano una stabilità senza paragoni con
una performance frenante da competizioni MotoGP. Realizzate con
tecnologie differenti secondo i vari modelli, le pinze garantiscono
un’altissima rigidità sotto sforzo, in grado di assicurare una frenata
precisa e costante nel tempo. Brembo mette a disposizione dei
motociclisti più esigenti tre tipologie di pinze freno capaci di soddisfare
qualunque esigenza, anche la più estrema. Tutte le pinze freno Brembo
sono intercambiabili sulle forcelle delle più diffuse motociclette europee,
giapponesi e americane, adattandosi perfettamente, secondo l’utilizzo,
sia a dischi di primo equipaggiamento sia a dischi Brembo Racing e
High Performance. Realizzate con diversi interassi di fi ssaggio (100
mm, 108 mm, “vari”), le pinze seguono lo standard delle motociclette
Racing e di quelle di serie.
I UK D F E DK
MotoGP power and precision
Brembo brake calipers combine incomparable stability with
MotoGP braking performance.
Different technologies are used depending on the various models;
all calipers ensure high stiffness under stress and ensure precise and
constant braking over time. Brembo offers discerning bikers three types
of brake caliper capable of satisfying even the most extreme
requirements.
All Brembo brake calipers are interchangeable on the forks of
the most popular European, Japanese and American
motorbikes, adapting perfectly - depending on the
application - to OEM discs and Brembo Racing and
High Performance discs. Available with several fi xing
dimensions (100 mm, 108 mm, “various”), these
calipers meets standards for Racing and production
series bikes.
12
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 12 19/09/18 13:20
I UK
Pinze D F
monoblocco E ricavate
DK dal
pieno
Le pinze monoblocco Brembo ricavate dal
pieno nascono dalla grande esperienza di
Brembo nelle competizioni che, trasferita in ogni fase
del processo produttivo, ha permesso di incrementare il
rapporto massa/rigidezza e le performance di frenata. Queste
pinze consentono di ottenere il più alto livello di performance
raggiungibile da una pinza moto e sono il frutto di accurati calcoli
progettuali, così come dell’impiego delle più evolute tecnologie nella
lavorazione dei metalli. Diversi modelli utilizzano una speciale fi nitura
superfi ciale mutuata dalla MotoGP: il riporto al Nickel ha permesso di
portare le pinze a nuovi livelli di prestazione grazie a un ulteriore
restringimento delle tolleranze di lavorazione.
I UK D F E DK
Billet-machined monobloc calipers
Brembo billet-machined monobloc calipers are the result of
Brembo’s extensive competition experience that, transferred to every
stage in the production process, has ensured improvements in the
mass/stiffness ratio and braking performance. These calipers ensure
the highest level of performance attainable by motorbike calipers and
are the result of accurate design calculations, as well as the use of the
most advanced metal processing technologies. Several models have a
special surface fi nishing treatment adapted from MotoGP applications:
the Nickel coating has made it possible to achieve new caliper
performance levels thanks to even tighter machining tolerances.
I UK
Pinze D 2 pezzi
in F E DK dal pieno
ricavate I UK Billet-machined
D F E DK
Il corpo pinza è ricavato totalmente dal pieno ed 2-pieces calipers
è composto da due pezzi collegati The caliper body is
meccanicamente. Particolare attenzione è stata machined entirely from the
dedicata alla ricerca di alti valori di potenza frenante billet and comprises two
e rigidezza, ottenuti grazie a una minuziosa mechanically linked parts. Special
progettazione, all’utilizzo di materie prime research attention was dedicated to achieve high
attentamente selezionate e all’uso degli ultimi braking power and rigidity values, which were
ritrovati tecnologici nella lavorazione dei metalli. achieved thanks to meticulous design and by using
Alcuni modelli adottano, per la prima volta, una fi carefully selected raw materials and the latest
nitura superfi ciale mutuata dalla MotoGP: il riporto metalworking technology. Some models, for the fi
al Nickel, oltre a donare un look decisamente rst time, have surface fi nishing borrowed from
accattivante, ha permesso di affi nare le già strette MotoGP bikes: the Nickel coating not only ensures
tolleranze di lavorazione, a tutto vantaggio delle an attractive look but also made it possible to
prestazioni e della precisione di funzionamento. perfect the already tight machining tolerances, to
the benefi t of operating performance and precision.
13
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 13 19/09/18 13:20
I UK
Pinze D F
monoblocco E fuseDK
Con le pinze monoblocco fuse, Brembo rende disponibile a tutti gli
appassionati la tecnologia, utilizzata con successo in MotoGP, che
consente di ricavare il corpo pinza da un unico pezzo di alluminio fuso e
garantire così una rigidità ottimale. La pinza, intercambiabile su tutte le
forcelle delle maxisportive, concentra le più avanzate tecnologie di
fusione e lavorazione per ottenere un corpo pinza monolitico di assoluta
leggerezza, con valori di rigidezza e precisione di funzionamento senza
eguali. Particolare attenzione è stata dedicata all’idraulica e alla forma
del corpo pinza, entrambe oggetto di un attento lavoro di affi namento
tecnico.
I UK D F E DK
Cast monobloc calipers
Brembo cast monobloc calipers offers to all enthusiasts the same
technology used successfully in MotoGP whereby the caliper body is
machined from a single cast aluminium workpiece to ensure optimal
rigidity. The calipers are interchangeable on all forks of maxi-sports
models and combines the most advanced casting and processing
technologies to achieve an impressively lightweight monobloc caliper
body, with unmatched stiffness and operating precision. Special
attention was paid to hydraulics and the shape of the caliper body -
they were involved in detailed technical perfection work.
14
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 14 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
220.A885.10
R P
100mm Radial M50 Cast Caliper Kit
C
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
30
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Maggior rigidezza del corpo Geometrie evolute nella
pinza grazie al triplo ponte. progettazione del corpo pinza.
H. fascia freno mm
32 - 34 Increased caliper body stiffness Advanced geometries used in
Disc height mm thanks to the triple bridge. caliper body design.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
15
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 15 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
220.9885.50
R P
100mm Radial M4 Cast Caliper Kit
C
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Maggior rigidezza del corpo
pinza grazie al triplo ponte.
H. fascia freno mm
32 - 34 Increased caliper body stiffness
Disc height mm thanks to the triple bridge.
16 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 16 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
220.9885.30
R P
100mm Radial M4 Cast Caliper Kit
C
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Maggior rigidezza del corpo
pinza grazie al triplo ponte.
H. fascia freno mm
32 - 34 Increased caliper body stiffness
Disc height mm thanks to the triple bridge.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
17
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 17 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
220.B010.20
R P
100mm “GP4-RX”
Radial Billet Caliper Kit
C
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
32
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Maggior rigidezza del corpo Geometrie evolute nella
pinza grazie al triplo ponte. progettazione del corpo pinza.
H. fascia freno mm
32 - 34 Increased caliper body stiffness Advanced geometries used in
Disc height mm thanks to the triple bridge. caliper body design.
18 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 18 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
220.A168.10
R P
100mm Radial Billet Caliper Kit
M
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
30 - 34
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Dettaglio della lavorazione Perni pastiglia con molla
dal pieno per alleggerimento anti rumore.
H. fascia freno mm
32 - 34 corpo pinza. Brake pads with
Disc height mm Detail of billet processing to noise-reduction spring.
reduce caliper body weight.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
19
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 19 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
220.B473.10
P
100mm “.484 Café Racer”
Radial Billet Caliper Kit
C
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
32
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Logo Brembo lavorato Montaggio a mano e
in bassorilievo dipinto a mano. oggettivazione delle coppie
H. fascia freno mm
32 - 34 Low-relief machined Brembo di serraggio delle viti.
Disc height mm logo. Hand painted finishing. Hand assembly
and objectification of screw
tightening torques.
20 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 20 19/09/18 13:20
1
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
21
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 21 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XA7.G2.A0
R
100mm Radial Billet Caliper
O
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
32 - 36
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Lavorazione del corpo pinza Anodizzazione dura
monoblocco. per la protezione superficiale
H. fascia freno mm
30 Monobloc caliper body dell’alluminio.
Disc height mm machining. Hard anodizing for aluminium
surface protection.
22 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 22 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XA7.89.10
R
100mm Radial Billet Caliper
M
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
30 - 34
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Dettaglio della lavorazione Perno con clip di sicurezza.
dal pieno per alleggerimento Pin with safety clip.
H. fascia freno mm
32 - 34 corpo pinza.
Disc height mm Detail of billet processing to
reduce caliper body weight.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
23
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 23 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
220.C783.10
R P 108mm “GP4-RS”
Radial Cast Caliper Kit
C
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
30
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Maggior rigidezza del corpo Geometrie evolute nella
pinza grazie al triplo ponte. progettazione del corpo pinza.
H. fascia freno mm
32 - 34 Increased caliper body stiffness Advanced geometries used in
Disc height mm thanks to the triple bridge. caliper body design.
24 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 24 19/09/18 13:20
1
Alettature di raffreddamento di
derivazione MotoGP.
Cooling fins derived from
MotoGP.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
25
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 25 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
220.B010.10
R P
108mm “GP4-RX”
Radial Billet Caliper Kit
C
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
32
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Maggior rigidezza del corpo Montaggio a mano e
pinza grazie al triplo ponte. oggettivazione delle coppie
H. fascia freno mm
32 - 34 Increased caliper body stiffness di serraggio delle viti.
Disc height mm thanks to the triple bridge. Hand assembly
and objectification of screw
tightening torques.
26 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 26 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
220.A397.10
R P
108mm Radial Cast Caliper Kit
C
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Maggior rigidezza del corpo
pinza grazie al triplo ponte.
H. fascia freno mm
32 - 34 Increased caliper body stiffness
Disc height mm thanks to the triple bridge.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
27
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 27 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
220.B473.20
P
108mm “.484 Cafe’ Racer”
Radial Billet Caliper Kit
C
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
32
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Logo Brembo lavorato
in bassorilievo dipinto a mano.
H. fascia freno mm
32 - 34 Low-relief machined Brembo
Disc height mm logo. Hand painted finishing.
28 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 28 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
220.A016.10
R P
108mm Radial Billet Caliper Kit
M
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
30 - 34
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Dettaglio della lavorazione Perni pastiglia con molla
dal pieno per alleggerimento anti rumore.
H. fascia freno mm
32 - 34 corpo pinza. Brake pads with
Disc height mm Detail of billet processing to noise-reduction spring.
reduce caliper body weight.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
29
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 29 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XB6.E5.10/11
R P
108mm “GP4-PR” Radial Billet Caliper
Q
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
32 - 36
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Dettaglio della lavorazione Dettaglio lavorazione del
dal pieno per alleggerimento senso di rotazione.
H. fascia freno mm
30 corpo pinza. Detail of rotation direction
Disc height mm Detail of billet processing to processing.
reduce caliper body weight.
30 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 30 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XA9.33.A0
R
108mm “GP4-RR” Radial Billet Caliper Kit
O
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
32 - 36
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Dettaglio della lavorazione Dettaglio lavorazione del
dal pieno per alleggerimento senso di rotazione.
H. fascia freno mm
30 corpo pinza. Detail of rotation direction
Disc height mm Detail of billet processing to processing.
reduce caliper body weight.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
31
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 31 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XA3.J7.F0/F1
R
108mm Radial Billet Caliper
Q
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
34 - 38
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Maggior rigidezza del corpo Geometrie evolute nella
pinza grazie al triplo ponte. progettazione del corpo pinza.
H. fascia freno mm
30 Increased caliper body stiffness Advanced geometries used in
Disc height mm thanks to the triple bridge. caliper body design.
32 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 32 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XA8.D1.E0/E1
R
108mm Radial Billet Caliper
Q
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
34 - 38
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Maggior rigidezza del corpo Geometrie evolute nella
pinza grazie al triplo ponte. progettazione del corpo pinza.
H. fascia freno mm
30 Increased caliper body stiffness Advanced geometries used in
Disc height mm thanks to the triple bridge. caliper body design.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
33
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 33 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XB2.P7.20/21
R
108mm “Endurance 24”
Radial Billet Caliper
H
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
30 - 34
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Logo Brembo lavorato Dettaglio della lavorazione
in bassorilievo dipinto a mano. dal pieno per alleggerimento
H. fascia freno mm
30 Low-relief machined Brembo corpo pinza.
Disc height mm logo. Hand painted finishing. Detail of billet processing to
reduce caliper body weight.
34 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 34 19/09/18 13:20
1
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
35
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 35 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XA3.B8.30/31
R
108mm Radial Billet Caliper
N
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
32 - 36
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Pistoni in titanio. Montaggio a mano e
Titanium pistons. oggettivazione delle coppie
H. fascia freno mm
30 di serraggio delle viti.
Disc height mm Hand assembly and
objectification of screw
tightening torques.
36 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 36 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XA3.B8.60/61
R
108mm Radial Billet Caliper
N
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
32 - 36
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Perno con clip di sicurezza.
Pin with safety clip.
H. fascia freno mm
30
Disc height mm
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
37
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 37 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XA6.95.10
R
108mm Radial Billet Caliper
M
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
30 - 34
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Dettaglio della lavorazione
dal pieno per alleggerimento
H. fascia freno mm
32 - 34 corpo pinza.
Disc height mm Detail of billet processing to
reduce caliper body weight.
38 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 38 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
220.B011.30
R P
130mm “GP4-RX”
Radial Billet Caliper Kit
C
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
32
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Maggior rigidezza del corpo Montaggio a mano e
pinza grazie al triplo ponte. oggettivazione delle coppie
H. fascia freno mm
32 - 34 Increased caliper body stiffness di serraggio delle viti.
Disc height mm thanks to the triple bridge. Hand assembly and
objectification of screw
tightening torques.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
39
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 39 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XA8.Y3.10/11
R
130mm “Yamaha R1 ’07 > ’14”
Radial Billet Caliper
Q
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
34 - 38
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Maggior rigidezza del corpo Logo Brembo lavorato
pinza grazie al triplo ponte. in bassorilievo dipinto a mano.
H. fascia freno mm
30 Increased caliper body stiffness Low-relief machined Brembo
Disc height mm thanks to the triple bridge. logo. Hand painted finishing.
40 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 40 04/10/18 10:18
PINZE FRENO • BRAKE CALIPERS
20.4756.52/62
R P
40mm Axial Billet Caliper
D
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
30 - 34
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Montaggio a mano e
oggettivazione delle coppie
H. fascia freno mm
32 - 34 di serraggio delle viti.
Disc height mm Hand assembly
and objectification of screw
tightening torques.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
41
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 41 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
120.B814.69/79
P
69,1mm “Custom Logonero”
Axial Billet Caliper
C
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
32
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Dettaglio del fissaggio assiale Logo Brembo lavorato
alle forcelle. in bassorilievo.
H. fascia freno mm
32 - 34 - 46 Detail of axial fitting to the Low-relief machined Brembo
Disc height mm forks. logo.
42 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 42 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
120.B814.71/81
P
69,1mm “Custom Logopuro”
Axial Billet Caliper
C
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
32
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Dettaglio del fissaggio assiale Logo Brembo lavorato
alle forcelle. in bassorilievo.
H. fascia freno mm
32 - 34 - 46 Detail of axial fitting to the Low-relief machined Brembo
Disc height mm forks. logo.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
43
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 43 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XA8.88.A0
R
60mm “Moto3”
Radial Billet Caliper Kit
R
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty Viteria in titanio. Logo Brembo lavorato
Titanium hardware. in bassorilievo dipinto a mano.
H. fascia freno mm
30 Low-relief machined Brembo
Disc height mm logo. Hand painted finishing.
44 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 44 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
45
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 45 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XA8.88.20/21
R
60mm “Moto3”
Radial Billet Caliper
R
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty Viteria in alluminio. Logo Brembo lavorato
Aluminium hardware. in bassorilievo dipinto a mano.
H. fascia freno mm
30 Low-relief machined Brembo
Disc height mm logo. Hand painted finishing.
46 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 46 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
X10.17.40/41
R
40mm Axial Billet Caliper
O
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
MONOBLOC
Caliper Body
Ø Pistoni mm
32 - 36
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Pistoni in titanio. Dettaglio del fissaggio assiale
Titanium pistons. alle forcelle.
H. fascia freno mm
30 Detail of axial fitting to the
Disc height mm forks.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
47
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 47 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
X10.48.13/14
R
40mm Axial Billet Caliper
N
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
32 - 36
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Montaggio a mano e
oggettivazione delle coppie
H. fascia freno mm
30 di serraggio delle viti.
Disc height mm Hand assembly
and objectification of screw
tightening torques.
48 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 48 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XQ2.13.61
R
95mm Floating Billet Caliper
V
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
FLOATING
Caliper Body
Ø Pistoni mm
28
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty Staffa di adattamento
specifica forgiata.
H. fascia freno mm
28 Specific forged caliper bracket.
Disc height mm
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
49
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 49 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
122.A990.XX *
R
95mm Floating Billet Caliper
V
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
FLOATING
Caliper Body
Ø Pistoni mm
24
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty Staffa di adattamento
specifica forgiata.
H. fascia freno mm
28 Specific forged caliper bracket.
Disc height mm
*
Disponibili le staffe dedicate alle Available the specific brackets for
principali moto giapponesi. Per the major Japanese motorbikes.
dettagli, prego riferirsi alla tabella For details, please refer to the chart
“caratteristiche tecniche” (pag.76). “technical features” (page 76).
50 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 50 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XB7.B8.XX *
R P
Oversize Off-Road
Floating Cast Caliper
V
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Corpo Pinza
FLOATING
Caliper Body
Ø Pistoni mm
24
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty Staffa di adattamento
specifica forgiata.
H. fascia freno mm
28 Specific forged caliper bracket.
Disc height mm
*
Disponibili le staffe dedicate alle Available the specific brackets for
principali moto giapponesi. Per the major Japanese motorbikes.
dettagli, prego riferirsi alla tabella For details, please refer to the chart
“caratteristiche tecniche” (pag.76). “technical features” (page 76).
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
51
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 51 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
120.A441.11/16
R P
84mm Axial Rear Billet Caliper Kit
S
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty
H. fascia freno mm
35
Disc height mm
52 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 52 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
120.A441.10
R P
84mm Axial Rear Billet Caliper
S
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty Marcatura lotto di produzione Logo Brembo lavorato
per la rintracciabilità. in bassorilievo dipinto a mano.
H. fascia freno mm
35 Production batch marking Low-relief machined Brembo
Disc height mm for traceability. logo. Hand painted finishing.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
53
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 53 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
120.A441.31/36
R P
84mm Axial Rear Billet Caliper Kit
S
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty
H. fascia freno mm
35
Disc height mm
54 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 54 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
120.A441.30
P R
84mm Axial Rear Billet Caliper
S
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty Marcatura lotto di produzione Logo Brembo lavorato
per la rintracciabilità. in bassorilievo dipinto a mano.
H. fascia freno mm
35 Production batch marking Low-relief machined Brembo
Disc height mm for traceability. logo. Hand painted finishing.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
55
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 55 04/10/18 10:18
PINZE FRENO • BRAKE CALIPERS
120.A441.41/46
R P
84mm Axial Rear Billet Caliper Kit
1
Staffa di adattamento specifica
lavorata dal pieno.
Specific billet-machined caliper
bracket.
S
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty
H. fascia freno mm
35
Disc height mm
56 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 56 04/10/18 10:19
PINZE FRENO • BRAKE CALIPERS
120.A441.40
P R
84mm Axial Rear Billet Caliper
S
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty Marcatura lotto di produzione Logo Brembo lavorato
per la rintracciabilità. in bassorilievo dipinto a mano.
H. fascia freno mm
35 Production batch marking Low-relief machined Brembo
Disc height mm for traceability. logo. Hand painted finishing.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
57
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 57 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
120.B278.11/16
R P
84mm Axial Rear Cast Caliper Kit
S
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty
H. fascia freno mm
35
Disc height mm
58 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 58 04/10/18 10:19
PINZE FRENO • BRAKE CALIPERS
120.B278.10
P R
84mm Axial Rear Cast Caliper
S
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty Logo Brembo lavorato al laser.
Laser etched Brembo logo.
H. fascia freno mm
35
Disc height mm
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
59
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 59 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
X20.60.01
R
64mm Axial Rear Billet Caliper
X
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
24
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty Montaggio a mano e
oggettivazione delle coppie
H. fascia freno mm
24 di serraggio delle viti.
Disc height mm Hand assembly
and objectification of screw
tightening torques.
60 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 60 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
X20.61.01
R
64mm Axial Rear Billet Caliper
W Y
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
24
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Viteria in titanio.
Titanium hardware.
H. fascia freno mm
24 - 30
Disc height mm
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
61
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 61 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
X20.61.21
R
64mm Axial Rear Billet Caliper
W Y
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
24
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Pistoni in titanio. Montaggio a mano e
Titanium pistons. oggettivazione delle coppie
H. fascia freno mm
24 - 30 di serraggio delle viti.
Disc height mm Hand assembly and
objectification of screw
tightening torques.
62 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 62 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
X98.88.70
R
64mm Axial Rear Billet Caliper
W Y
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty Viteria in titanio.
Titanium hardware.
H. fascia freno mm
24 - 30
Disc height mm
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
63
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 63 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XA1.J0.40
R
64mm Axial Rear Billet Caliper
W Y
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
30
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty Viteria in titanio.
Titanium hardware.
H. fascia freno mm
24 - 30
Disc height mm
64 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 64 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XB4.S5.20
R
64mm Axial Rear Billet Caliper
W Y
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
30
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty Viteria in titanio.
Titanium hardware.
H. fascia freno mm
24 - 30
Disc height mm
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
65
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 65 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XB4.S5.50
R
64mm Axial Rear Billet Caliper
W Y
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
34
Ø Pistons mm
Numero pistoni
2
Pistons Q.ty Viteria in titanio.
Titanium hardware.
H. fascia freno mm
24 - 30
Disc height mm
66 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 66 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XQ2.13.90
R
119mm Floating Billet Caliper
Z
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
FLOATING
Caliper Body
Ø Pistoni mm
26
Ø Pistons mm
Numero pistoni
1
Pistons Q.ty Dettaglio della lavorazione
dal pieno per alleggerimento
H. fascia freno mm
31 corpo pinza.
Disc height mm Detail of billet processing to
reduce caliper body weight.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
67
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 67 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
XB4.L4.20
R
119mm P224 Axial Cast Caliper
Z
Caratteristiche Tecniche
Technical Features
Posizione
REAR
Position
Corpo Pinza
FLOATING
Caliper Body
Ø Pistoni mm
26
Ø Pistons mm
Numero pistoni
1
Pistons Q.ty Dettaglio della lavorazione
dal pieno per alleggerimento
H. fascia freno mm
31 corpo pinza.
Disc height mm Detail of billet processing to
reduce caliper body weight.
68 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 68 19/09/18 13:20
PINZE FRENO • BRAKE CALIPERS
220.B765.10
P
100mm “Yamaha T-Max ’09 > ’11”
Axial Billet Caliper Kit
D
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Staffa di adattamento specifica
Corpo Pinza lavorata dal pieno.
2-PIECES
Caliper Body Specific billet-machined
Ø Pistoni mm caliper bracket.
30 - 34
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty
H. fascia freno mm
32 - 34
Disc height mm
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
69
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 69 19/09/18 13:21
PINZE FRENO • BRAKE CALIPERS
220.B766.10
P
100mm “Yamaha T-Max ’09 > ’11”
Axial Cast Caliper Kit
D
Caratteristiche Tecniche
Technical Features
Posizione
FRONT
Position
Staffa di adattamento specifica
Corpo Pinza lavorata dal pieno.
2-PIECES
Caliper Body Specific billet-machined
Ø Pistoni mm caliper bracket.
30 - 34
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty
H. fascia freno mm
32 - 34
Disc height mm
70 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 70 19/09/18 13:21
PINZE FRENO • BRAKE CALIPERS
120.B765.20
50mm “Kawasaki Ninja 250 ’08 > R P
and Ninja 300 ’14 >”
Axial Billet Caliper Kit
D
Caratteristiche Tecniche
Technical Features
Staffa di adattamento
Posizione specifica lavorata dal pieno.
FRONT Specific billet-machined
Position
caliper bracket.
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
30 - 34
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty
H. fascia freno mm
32 - 34
Disc height mm
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
71
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 71 19/09/18 13:21
PINZE FRENO • BRAKE CALIPERS
120.B766.20
R P
50mm “Kawasaki Ninja 250 ’08 >
and Ninja 300 ’14 >”
Axial Cast Caliper Kit
D
Caratteristiche Tecniche
Technical Features
Staffa di adattamento
Posizione specifica lavorata dal pieno.
FRONT Specific billet-machined
Position
caliper bracket.
Corpo Pinza
2-PIECES
Caliper Body
Ø Pistoni mm
30 - 34
Ø Pistons mm
Numero pistoni
4
Pistons Q.ty Finto
H. fascia freno mm
32 - 34
Disc height mm
72 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 72 19/09/18 13:21
73
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 73 19/09/18 13:21
PINZE FRENO • BRAKE CALIPERS
220.A885.10 220.9885.50 220.9885.30 220.B010.20 220.A168.10 220.B473.10
* in progress
KBA-ABE NO NO NO NO NO NO
CARATTERISTICHE TECHICHE • TECHNICAL FEATURES
INTERASSE FISSAGGIO (mm) • FIXING DIMENSION (mm) 108 108 108 108 108 108
POSIZIONE • POSITION FRONT FRONT FRONT FRONT FRONT FRONT
CORPO PINZA • CALIPER BODY MONOBLOC MONOBLOC MONOBLOC MONOBLOC 2-PIECES 2-PIECES
FISSAGGIO • FIXING RADIAL RADIAL RADIAL RADIAL RADIAL RADIAL
NUMERO PISTONI • PISTONS 4 4 4 4 4 4
DIAMETRO PISTONI (mm) • PISTON DIAMTERS (mm) 32 - 36 34 - 38 34 - 38 30 - 34 32 - 36 32 - 36
ALTEZZA FASCIA FRENO (mm) • DISC HEIGHT (mm) 30 30 30 30 30 30
MATERIALE • MATERIAL B.AL B.AL B.AL B.AL B.AL B.AL
PROTEZIONE SUPERFICIALE • SURFACE PROTECTION HA NI NI HA HA HA
NUMERO PONTI • BRIDGES 3 3 3 2 2 2
MATERIALE MINUTERIA • HARDWARE MATERIAL TI TI TI TI TI ST
MATERIALE PISTONI • PISTON MATERIAL TI TI TI TI TI AL
PESO SENZA PASTIGLIE (g) • WEIGHT W/O PADS (g) 578 640 615 815 600 659
FORMA PASTIGLIA • PAD SHAPE O Q Q H N N
PASTIGLIE INCLUSE • PADS INCLUDED NO NO NO NO NO NO
OFFSET (mm) • OFFSET (mm) 22,5 22,5 22,5 22,5 22,5 22,5
FLUIDO FRENI • BRAKE FLUID DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4
NOTE
endurance caliper
“.20” left caliper “.F0“ left caliper “.E0” left caliper “.30” left caliper “.60” left caliper
“.20” left caliper
“.21” right caliper “.F1“ right caliper “.E1” right caliper “.31” right caliper “.61” right caliper
“.21” right caliper
74
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 74 19/09/18 13:21
XA7.G2.A0 XA7.89.10 220.C783.10 220.B010.10 220.A397.10 220.B473.20 220.A016.10 XB6.E5.10/11
NO YES NO NO NO NO NO NO
75
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 75 19/09/18 13:21
PINZE FRENO • BRAKE CALIPERS
X10.17.40/41 X10.48.13/14 XQ2.13.61 122.A990.XX XB7.B8.XX
KBA-ABE NO NO NO NO NO
CARATTERISTICHE TECHICHE • TECHNICAL FEATURES
INTERASSE FISSAGGIO (mm) • FIXING DIMENSION (mm) 40 40 95* 78 / 102 78 / 102
POSIZIONE • POSITION FRONT FRONT FRONT FRONT FRONT
CORPO PINZA • CALIPER BODY MONOBLOC 2-PIECES FLOATING FLOATING FLOATING
FISSAGGIO • FIXING AXIAL AXIAL AXIAL + BRACKET AXIAL + BRACKET AXIAL + BRACKET
NUMERO PISTONI • PISTONS 4 4 2 2 2
DIAMETRO PISTONI (mm) • PISTON DIAMTERS (mm) 32 - 36 32 - 36 28 24 24
ALTEZZA FASCIA FRENO (mm) • DISC HEIGHT (mm) 30 30 28 28 28
MATERIALE • MATERIAL B.AL B.AL B.AL B.AL C.AL
PROTEZIONE SUPERFICIALE • SURFACE PROTECTION HA HA HA HA SI.AO
NUMERO PONTI • BRIDGES 2 2 N.A. N.A. N.A.
MATERIALE MINUTERIA • HARDWARE MATERIAL TI TI TI ST ST
MATERIALE PISTONI • PISTON MATERIAL TI TI TI AL AL
PESO SENZA PASTIGLIE (g) • WEIGHT W/O PADS (g) 660 680 595 716 541
FORMA PASTIGLIA • PAD SHAPE O N V V V
PASTIGLIE INCLUSE • PADS INCLUDED NO NO YES YES YES
OFFSET (mm) • OFFSET (mm) 26,5 26,5 17,7 - 17,95 17,95 - 18,15 20 - 21
FLUIDO FRENI • BRAKE FLUID DOT 4 DOT 4 DOT 4 DOT 4 DOT 4
NOTE Caliper provided Caliper provided
with bracket:
caliper provided “.21” KTM bracket with bracket:
“.40” left caliper “.13” left caliper “.44” Yamaha bracket
with bracket “.54” Yamaha bracket “.45” Suzuki bracket
“.41” right caliper “.14” right caliper “.55” Suzuki bracket
(* = bracket fixing dim.) “.56” Honda bracket “.46” Honda bracket
“.47” Kawasaki bracket
“.57” Kawasaki bracket
KBA-ABE NO NO NO NO NO
CARATTERISTICHE TECHICHE • TECHNICAL FEATURES
INTERASSE FISSAGGIO (mm) • FIXING DIMENSION (mm) 64 64 64 64 64
POSIZIONE • POSITION REAR REAR REAR REAR REAR
CORPO PINZA • CALIPER BODY 2-PIECES 2-PIECES 2-PIECES 2-PIECES 2-PIECES
FISSAGGIO • FIXING AXIAL AXIAL AXIAL AXIAL AXIAL
NUMERO PISTONI • PISTONS 2 4 4 2 2
DIAMETRO PISTONI (mm) • PISTON DIAMTERS (mm) 24 24 24 34 30
ALTEZZA FASCIA FRENO (mm) • DISC HEIGHT (mm) 24 24 - 30 24 - 30 24 - 30 24 - 30
MATERIALE • MATERIAL B.AL B.AL B.AL B.AL B.AL
PROTEZIONE SUPERFICIALE • SURFACE PROTECTION HA HA HA HA HA
NUMERO PONTI • BRIDGES 2 2 2 2 2
MATERIALE MINUTERIA • HARDWARE MATERIAL TI TI TI TI TI
MATERIALE PISTONI • PISTON MATERIAL TI TI TI TI TI
PESO SENZA PASTIGLIE (g) • WEIGHT W/O PADS (g) 198 262 262 394 348
FORMA PASTIGLIA • PAD SHAPE X W/Y W/Y W/Y W/Y
PASTIGLIE INCLUSE • PADS INCLUDED NO NO NO NO NO
OFFSET (mm) • OFFSET (mm) 16,5 16,5 18,5 16,5 16,5
FLUIDO FRENI • BRAKE FLUID DOT 4 DOT 4 DOT 4 DOT 4 DOT 4
NOTE for rear
W pad for 24mm ventilated disc; W pad for 24mm W pad for 24mm
rotor height; W pad for 24mm rotor height; rotor height;
Y pad for 30mm rotor height; Y pad for 30mm Y pad for 30mm
rotor height Y pad for 30mm rotor height rotor height
rotor height
76
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 76 19/09/18 13:21
120.A441.11/16 120.A441.10 120.A441.31/36 120.A441.30 120.A441.41/46 120.A441.40 120.B278.11/16 120.B278.10
NO NO NO NO NO NO NO NO
84 84 84 84 84 84 84 84
REAR REAR REAR REAR REAR REAR REAR REAR
2-PIECES 2-PIECES 2-PIECES 2-PIECES 2-PIECES 2-PIECES 2-PIECES 2-PIECES
AXIAL + BRACKET AXIAL AXIAL + BRACKET AXIAL AXIAL + BRACKET AXIAL AXIAL + BRACKET AXIAL
2 2 2 2 2 2 2 2
34 34 34 34 34 34 34 34
35 35 35 35 35 35 35 35
B.AL B.AL B.AL B.AL B.AL B.AL C.AL C.AL
HA HA BL.HA BL.HA NI NI TI.AO TI.AO
2 2 2 2 2 2 2 2
ST ST ST ST ST ST ST ST
AL AL AL AL AL AL AL AL
581 581 581 581 581 581 465 465
S S S S S S S S
YES YES YES YES YES YES YES YES
10 10 10 10 10 10 16 16
DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4
Fits only with Marchesini wheels. Fits only with Marchesini wheels. Fits only with Marchesini wheels.
Fits only with Marchesini wheels. Caliper provided with bracket; Caliper provided with bracket; Caliper provided with bracket;
Caliper provided with bracket; Dedicated to european “.11” Honda bracket Dedicated to european “.11” Honda bracket Dedicated to european “.11” Honda bracket Dedicated to european
“.11” Honda bracket
“.12” Suzuki bracket Sportsbike with Brembo OE “.12” Suzuki bracket Sportsbike with Brembo OE “.12” Suzuki bracket Sportsbike with Brembo OE “.12” Suzuki bracket Sportsbike with Brembo OE
“.13” Kawasaki bracket “.13” Kawasaki bracket “.13” Kawasaki brack.
“.13” Kawasaki bracket rear caliper “.14” Yamaha bracket rear caliper “.14” Yamaha bracket rear caliper “.14” Yamaha bracket rear caliper
“.14” Yamaha bracket “.16” Suzuki bracket “.16” Suzuki bracket “.16” Suzuki bracket
NO NO NO NO NO NO NO NO
77
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 77 19/09/18 13:21
PINZE FRENO • BRAKE CALIPERS
CAPPUCCIO SPURGO • BLEED SCREW COVER 05150220 05150220 05150220 05150210 05150210 05150210
VITE SPURGO • BLEEDING SCREW 105338752 105338752 105338752 105281228 05144011 05144011
BANDE TERMOSENSIBILI • THERMOTAPES 88°C - 127°C 02516811 02516811 02516811 02516811 02516811 02516811
BANDE TERMOSENSIBILI • THERMOTAPES 132°C - 171°C 02516812 02516812 02516812 02516812 02516812 02516812
CAPPUCCIO SPURGO • BLEED SCREW COVER 05150220 05150220 05150220 05150220 05150220 05150220
VITE SPURGO • BLEEDING SCREW 05281233 05281221 05281213 05281233 05281213 05281221
MOLLA • SPRING
BANDE TERMOSENSIBILI • THERMOTAPES 88°C - 127°C 02516811 02516811 02516811 02516811 02516811 02516811
BANDE TERMOSENSIBILI • THERMOTAPES 132°C - 171°C 02516812 02516812 02516812 02516812 02516812 02516812
78
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 78 19/09/18 13:21
XA7.G2.A0 XA7.89.10 220.C783.10 220.B010.10 220.A397.10 220.B473.20 220.A016.10 XB6.E5.10/11
06222838
06222838 06222838
79
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 79 19/09/18 13:21
PINZE FRENO • BRAKE CALIPERS
MOLLA • SPRING
BANDE TERMOSENSIBILI • THERMOTAPES 88°C - 127°C 02516811 02516811 02516811 02516811 02516811
BANDE TERMOSENSIBILI • THERMOTAPES 132°C - 171°C 02516812 02516812 02516812 02516812 02516812
CAPPUCCIO SPURGO • BLEED SCREW COVER 05150210 05150210 05150210 05150210 05150210
MOLLA RITENZIONE PASTIGLIE • PAD RETAINER X988819 X988819 X988819 X988818 XA1J046
BANDE TERMOSENSIBILI • THERMOTAPES 88°C - 127°C 02516811 02516811 02516811 02516811 02516811
BANDE TERMOSENSIBILI • THERMOTAPES 132°C - 171°C 02516812 02516812 02516812 02516812 02516812
80
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 80 19/09/18 13:21
120.A441.11/16 120.A441.10 120.A441.31/36 120.A441.30 120.A441.41/46 120.A441.40 120.B278.11/16 120.B278.10
84 84 84 84 84 84 84 84
120A44170 120A44170
XA1J046 XA1J046
122474614 122474614
120468327 120468331
122508932 122508932
81
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 INTRO + 1 PINZE ES.indd 81 19/09/18 13:21
POMPE FRENO
MASTER CYLINDERS
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 82 27/09/18 10:36
kW
F - Part Number R - Part Number
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 83 27/09/18 10:36
POMPE FRENO
MASTER CYLINDERS
I UK D
Tecnologia F E DK
d’avanguardia per prestazioni I UK Corsa
RCS D F
CortaE DK
racing La RCS CORSA CORTA si presenta come un’ulteriore
Brembo offre una vasta gamma di pompe radiali e leve evoluzione del concetto di pompa radiale che abbina
regolabili per sostituire e migliorare l’impianto originale. Le numerose novità alle soluzioni tecniche adottate nelle
pompe freno Brembo Racing e High Performance sono pompe utilizzate in MotoGP. La novità principale consiste
realizzate con procedure e lavorazioni d’avanguardia, nella possibilità offerta al pilota di adattare la posizione del
garantendo funzionamento e prestazioni d’eccellenza. Le punto di attacco della frenata, “bite point”, al feeling di
pompe freno Brembo Racing e High Performance sono guida desiderato, attraverso un selettore posto sulla parte
disponibili in due versioni - Radiali e Radiali RCS - superiore della pompa e per questo facilmente accessibile.
facilmente applicabili a tutte le più diffuse motociclette, Il selettore, mediante un dispositivo ad eccentrico,
dalle Maxisportive giapponesi ed europee alle Custom, permette di operare una scelta fra le tre differenti mappe di
dalle Cafè Racer alle Off-Road. feeling disponibili:
mappa NORMAL – identificata dalla lettera N, permette di
garantire una fase iniziale più graduale ed è quindi adatta
I UK D
Radiale F E DK alla guida in città, o a frenate in condizioni di scarsa
La pompa freno radiale Brembo consente una aderenza.
maggiore prontezza e una frenata più modulabile in tutte Mappa SPORT – identificata dalla lettera S, permette di
le condizioni di utilizzo. Il risultato è un’eccellente linearità accorciare la fase iniziale, rispetto all’impostazione N,
tra la forza applicata dal pilota alla leva e la risposta proponendo quindi una risposta più dinamica e una guida
frenante, così da ottenere un feeling unico e inimitabile con più sportiva.
la frenata. Il corpo pompa in lega d’alluminio può essere Mappa RACE – identificata dalla lettera R, consente di
ottenuto tramite forgiatura, e poi lavorato con macchine a accorciare ulteriormente la fase inziale, portandola ad un
controllo numerico, oppure lavorato completamente dal valore minimo pari a quello delle pompe utilizzate in
pieno per la massima espressione tecnologica e di MotoGP. Questa terza mappa ben si abbina ad una guida
prestazione. Per la finitura superfi ciale è stata scelta con forte appeal racing, che lima i centesimi in frenata.
l’ossidazione normalmente utilizzata in MotoGP e
Superbike. Le pompe radiali Brembo sono disponibili con
pistoni di differenti diametri e con diversi interassi leva così
da rispondere alle necessità “su misura” del pilota.
Sempre per avere il massimo feeling, anche le leve sono
disponibili, nelle varianti STD e pieghevoli, di diverse
lunghezze.
I UK D RCSF
Radiale E DK regolare l’interasse
La pompa freno radiale Brembo RCS permette di della pompa,
scegliere tra una frenata potente o modulabile, secondo ruotando di 180° il
le condizioni della strada, del meteo, della propria sensibilità registro posto sul
e del feeling che si ha con la moto. Grazie all’innovativo fronte della leva
sistema di regolazione, questa pompa freno brevettata, di guida. Da ciò deriva
derivazione diretta da quella in uso nella MotoGP, consente una differente
di adeguare la medesima pompa freno ai differenti utilizzi distribuzione della forza
dei motociclisti, anche di quelli più esigenti. Nata con il frenante che non modifi ca la potenza pura.
preciso intento di trasferire la tecnologia MotoGP e Il pistoncino, le guarnizioni e il puntalino delle pompe RCS
Superbike al vasto pubblico degli appassionati, la pompa sono i medesimi delle pompe utilizzate dalla quasi totalità
radiale Brembo RCS rappresenta, in termini di contenuti dei piloti della MotoGP e della Superbike, caratterizzati da
tecnici e di stile, una nuova frontiera nell’ambito dei ridottissime tolleranze di lavorazione e ottima scorrevolezza.
componenti freno ad elevate prestazioni. Il sistema RCS La pompa radiale RCS è disponibile in due versioni: con
consiste in un registro con il quale è possibile modifi care pistone diametro 19 mm oppure 15 mm. La 19RCS deve
l’interasse leva su 18 o 20 mm, in modo da raggiungere il essere impiegata su impianti bidisco 4 pistoncini ma non fl
feeling ideale tra pilota e moto. Variando l’interasse, infatti, è ottanti, mentre la 15RCS può essere montata su impianti
possibile rendere l’impianto frenante più reattivo e pronto monodisco con pinza a 4 pistoncini oppure bidisco, ma con
(20 mm) o più modulabile (18mm). Il cambio di pinze di tipo fl ottante. Per l’utilizzo stradale della pompa
configurazione è rapidissimo: con il sistema a eccentrico freno, è stato predisposto uno specifi co microswitch per
(rosso sui 18 mm, nero sui 20 mm), basta un cacciavite per l’accensione della Luce Stop (freno).
84
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 84 19/09/18 14:37
I UK D F E DK
Cutting-edge technology for racing
performance
Brembo offers a wide range of radial master cylinders
and adjustable levers to replace and improve the original
braking systems. Brembo Racing and High Performance
brake master cylinders are manufactured thanks to
cutting-edge procedures and processes to ensuring
excellent operation and performance. Brembo Racing
and High Performance brake master cylinders are
available in two versions - Radial and Radial RCS - that
can easily be fi tted to all the most common bikes, from
Japanese and European Maxi-Sport models to Custom,
Cafè Racer and Off-Road models.
I UK D F E DK
Radial involves the oxidation
The Brembo radial brake master cylinder process normally used in
ensures event faster response and more MotoGP and Superbike
adjustable braking in all conditions of use. The sectors. Brembo radial
result is excellent linearity between the force master cylinders are
applied to the lever by the driver and brake available with pistons
response, thereby achieving a unique and having different diameters
incomparable feeling of braking control. The and several lever ratio in
aluminium alloy master cylinder body can be order to meet the customised
forged and then worked on NC machines, or needs of riders. And the best
billet-machined for maximum technological driving comfort is also ensured by STD
expression and performance. The surface fi nish and FL levers in various lengths.
I UK D F
Radial RCS E DK modular (18 mm). The change of confi guration is
The Brembo RCS radial brake master cylinder very quick: with the eccentric system (red on 18
offers a choice between powerful or adjustable mm, black on 20 mm), a simple screwdriver can
braking, depending on road conditions, the adjust lever ratio by turning the locator on the
weather, personal preferences and driving front guide lever by 180°. This gives rise to a
sensations. Thanks to its innovative adjustment different distribution of braking force that does
system, this patented brake master cylinder not affect raw power. The small piston, seals and
(derived directly from MotoGP versions) means cap of RCS master cylinders are the same as for
that the same brake master cylinder can be the master cylinders used by almost all MotoGP
adapted to different and highly demanding driver and Superbike riders, characterised by very tight
applications. Developed with the precise machining tolerances and optimal smoothness.
intention of transferring MotoGP and Superbike The RCS radial master cylinder is available in two
technology to the wider audience of enthusiasts, versions: 19 mm or 15 mm diameter piston. The
the Brembo RCS radial master cylinder, in terms 19RCS must be used on twin disc systems with
of technical content and style, is a new frontier 4 non-fl oating small pistons, while the 15RCS
for high performance brake components. The can be mounted on single-disc units with a
RCS system comprises a locator whereby it is 4-piston caliper, or twin-disc with fl oating
possible to change the lever ratio to 18 or 20 mm calipers. On-road use of the brake master
to set the ideal “feeling” between rider and bike. cylinder is enabled by a specifi c microswitch for
By changing the ratio, the brakes can be made illuminating the Stop Light (brake).
more responsive and faster (20 mm) or more
I UK D F E DK
RCS Corsa Corta conditions. SPORT setting – indicated with the
RCS CORSA CORTA is the latest evolution in letter S, the beginning of the bite point is shorter
the radial master cylinder concept which than in the N setting. This setting produces
combines innovative technology with the a more dynamic response suitable for
technical solutions adopted directly from the sportier riding.
master cylinders used in MotoGP. The most RACE setting – indicated with the
significant achievement is that the RCS CORSA letter R, the position of the cam
CORTA allows the rider to tailor the “bite point” mechanism shortens the initial
exactly where they want it, with an easily stage of the bite point further to
accessible selector on the top of the master produce the same immediate
cylinder itself. The selector operates a cam response of the master
mechanism to let the user choose between three cylinders used in MotoGP. This
different responsiveness settings: setting is ideal for use on the
NORMAL setting – indicated with the letter N, the race track, where every hundredth
bite point starts more gradually, making it of a second shaved off a lap time
suitable for city riding or braking in poor grip counts.
85
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 85 19/09/18 14:37
POMPA FRIZIONE • CLUTCH MASTER CYLINDERS
110.C036.50
P
3-LIGHTS
Forged Clutch Master Cylinder
Caratteristiche Tecniche
Technical Features
Materiale
C.AL
Material
Tipo
RADIAL
Type
Ø Pistone mm
15
Ø Piston mm
Interasse leva
18
Lever ratio Il logo Brembo svolge la
funzione di indicatore di livello
fluido serbatoio.
Cablaggio elettrico incluso e The reservoir indicator for fluid
adattabile alla maggior parte level is fully integrated in the
delle motociclette. Brembo logo.
Electric cable included and plug&play
with the most popular bikes.
86 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 86 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
110.C036.10
P
3-LIGHTS
Forged Brake Master Cylinder
Caratteristiche Tecniche
Technical Features
Materiale
C.AL
Material
Singolo/doppio disco
DOUBLE
Single/double disc
Ø Pistone mm
18
Ø Piston mm
Interasse leva Regolazione distanza leva
19 frontale.
Lever ratio
Frontal lever gap adjustment.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
87
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 87 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
Caratteristiche Tecniche
Technical Features
88 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 88 19/09/18 14:37
2
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
89
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 89 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
*
110.A263.10-19RCS RCS
R P 110.A263.20-15RCS Forged Radial
110.A263.30-15RCS Brake Master
110.A263.40-17RCS
Cylinder
110.A263.45-14RCS
Caratteristiche Tecniche
Technical Features
90 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 90 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
Caratteristiche Tecniche
Technical Features
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
91
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 91 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
XA7.G7.GO
R
GP Billet Radial
Brake Master Cylinder
Caratteristiche Tecniche
Technical Features
Materiale
B.AL
Material
Singolo/doppio disco
DOUBLE
Single/double disc
Ø Pistone mm
19
Ø Piston mm
Interasse leva
18
Lever ratio Corpo pompa lavorato Regolazione distanza
dal pieno. leva laterale.
Billet-machined master Lateral lever gap adjustment.
cylinder body.
92 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 92 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
Billet Radial XR0.11.30
XR0.11.70 R
Brake Master Cylinder
XR0.11.71
XR0.11.72
XR0.11.B0
Caratteristiche Tecniche
Technical Features
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
93
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 93 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
110.4760.60 Forged Radial
R 110.4760.70 Brake Master Cylinder
110.4760.75
110.4760.80
110.4760.82
110.4760.85
110.4760.87
Caratteristiche Tecniche
Technical Features
94 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 94 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
XA2.B3.80
R
Enduro Cast
Brake Master Cylinder
Caratteristiche Tecniche
Technical Features
Materiale
C.AL
Material
Singolo/doppio disco
SINGLE
Single/double disc
Ø Pistone mm
10
Ø Piston mm
Interasse leva
19
Lever ratio Regolazione distanza leva,
specifica per pompa Off-Road.
Lever gap adjustment, specific
for Off-Road master cylinder
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
95
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 95 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
XA2.B3.A0
R
MX Cast Brake Master Cylinder
Caratteristiche Tecniche
Technical Features
Materiale
C.AL
Material
Singolo/doppio disco
SINGLE
Single/double disc
Ø Pistone mm
10
Ø Piston mm
Interasse leva
19
Lever ratio Regolazione distanza leva, Logo Brembo Racing lavorato
specifica per pompa al laser.
Off-Road. Laser etched Brembo Racing
Lever gap adjustment, specific logo.
for Off-Road master cylinder.
96 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 96 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
110.D087.15
R
MX Cast Brake Master Cylinder
Caratteristiche Tecniche
Technical Features
Materiale
C.AL
Material
Singolo/doppio disco
SINGLE
Single/double disc
Ø Pistone mm
9
Ø Piston mm
Interasse leva
19
Lever ratio Logo Brembo lavorato in
bassorilievo. Dipinto a mano.
Low-relief machined Brembo
logo. Hand painted finishing.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
97
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 97 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
110.D087.10
R
MX Cast Brake Master Cylinder
Caratteristiche Tecniche
Technical Features
Materiale
C.AL
Material
Singolo/doppio disco
SINGLE
Single/double disc
Ø Pistone mm
10
Ø Piston mm
Interasse leva
16
Lever ratio Regolazione distanza leva,
specifica per pompa Off-Road.
Lever gap adjustment, specific
for Off-Road master cylinder.
98 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 98 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
110.D087.50
R
Enduro Cast
Brake Master Cylinder
Caratteristiche Tecniche
Technical Features
Materiale
C.AL
Material
Singolo/doppio disco
SINGLE
Single/double disc
Ø Pistone mm
10
Ø Piston mm
Interasse leva
16
Lever ratio Dettaglio del microswitch.
Microswitch detail.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
99
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 99 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
X98.57.60 Thumb Rear Billet
R X98.57.70 Brake Master Cylinder
X98.57.80
Caratteristiche Tecniche
Technical Features
100 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 100 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
Caratteristiche Tecniche
Technical Features
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
101
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 101 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
XA5.21.30
R
Rear Billet
Brake Master Cylinder with Reservoir
Caratteristiche Tecniche
Technical Features
Materiale
B.AL
Material
Singolo/doppio disco
SINGLE
Single/double disc
Ø Pistone mm
13
Ø Piston mm
Interasse leva
N.A.
Lever ratio Logo Brembo lavorato al laser. Corpo pompa lavorato
Laser etched Brembo logo. dal pieno.
Billet-machined master
cylinder body.
102 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 102 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
XA5.21.40
R
Rear Billet
Brake Master Cylinder with Reservoir
Caratteristiche Tecniche
Technical Features
Materiale
B.AL
Material
Singolo/doppio disco
SINGLE
Single/double disc
Ø Pistone mm
13
Ø Piston mm
Interasse leva
N.A.
Lever ratio Logo Brembo lavorato al laser. Corpo pompa lavorato
Laser etched Brembo logo. dal pieno.
Billet-machined master
cylinder body.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
103
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 103 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
XA0.J0.10
R
Rear Billet
Brake Master Cylinder with Reservoir
Caratteristiche Tecniche
Technical Features
Materiale
B.AL
Material
Singolo/doppio disco
SINGLE
Single/double disc
Ø Pistone mm
13
Ø Piston mm
Interasse leva
N.A.
Lever ratio Oblò per controllo livello fluido. Logo Brembo lavorato in
Spyglass for fluid level check. bassorilievo. Dipinto a mano.
Low-relief machined Brembo
logo. Hand painted finishing.
104 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 104 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
XA2.C6.10
R
Rear Billet
Brake Master Cylinder with Reservoir
Caratteristiche Tecniche
Technical Features
Materiale
B.AL
Material
Singolo/doppio disco
SINGLE
Single/double disc
Ø Pistone mm
13
Ø Piston mm
Interasse leva
N.A.
Lever ratio Logo Brembo lavorato al laser. Corpo pompa lavorato
Laser etched Brembo logo. dal pieno.
Billet-machined master
cylinder body.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
105
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 105 19/09/18 14:37
POMPE FRIZIONE - CLUTCH MASTER CYLINDERS
Caratteristiche Tecniche
Technical Features
Materiale
F.AL
Material
Singolo/doppio disco
RADIAL
Single/double disc
Ø Pistone mm
15
Ø Piston mm
Interasse leva
16 - 18
Lever ratio Finto
106 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 106 19/09/18 14:37
POMPE FRIZIONE • CLUTCH MASTER CYLINDERS
RCS 110.A263.50 - 16RCS *
110.A263.55 - 17RCS R P
Forged Clutch
Master Cylinder 110.A263.65 - 14RCS
110.A263.70 - 19RCS
Caratteristiche Tecniche
Technical Features
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 107 19/09/18 14:37
POMPE FRIZIONE - CLUTCH MASTER CYLINDERS
110.A897.70
P
1” Handlebar RCS
Forged Clutch Master Cylinder
Caratteristiche Tecniche
Technical Features Ø 1”
Materiale
F.AL
Material
Tipo
RADIAL
Type
Ø Pistone mm
19
Ø Piston mm
Interasse leva
18 - 20
Lever ratio Fissaggio al manubrio da 1 Regolazione interasse leva
pollice, specifico per Custom. con sistema brevettato RCS.
1” handlebar fixing, Lever ratio adjustment
Custom specific. with patented RCS system.
108 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 108 19/09/18 14:37
POMPE FRIZIONE - CLUTCH MASTER CYLINDERS
Billet Radial XR0.11.50
XR0.11.51 R P
Clutch Master Cylinder
XR0.11.55
Caratteristiche Tecniche
Technical Features
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
109
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 109 19/09/18 14:37
POMPE FRIZIONE - CLUTCH MASTER CYLINDERS
XR0.16.10
R
MX Cast
Clutch Master Cylinder
Caratteristiche Tecniche
Technical Features
Materiale
C.AL
Material
Tipo
AXIAL
Type
Ø Pistone mm
10
Ø Piston mm
Interasse leva
17,7
Lever ratio Regolazione distanza leva, Logo Brembo Racing lavorato
specifica per pompa al laser.
Off-Road. Laser etched Brembo Racing
Lever gap adjustment, specific logo.
for Off-Road master cylinder.
110 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 110 19/09/18 14:37
POMPE FRIZIONE - CLUTCH MASTER CYLINDERS
110.9203.50
R
MX Cast Clutch Master Cylinder
Caratteristiche Tecniche
Technical Features
Materiale
C.AL
Material
Tipo
AXIAL
Type
Ø Pistone mm
10
Ø Piston mm
Interasse leva
17,7
Lever ratio Regolazione distanza leva,
specifica per pompa Off-Road.
Lever gap adjustment, specific
for Off-Road master cylinder.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
111
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 111 19/09/18 14:37
POMPE FRIZIONE - CLUTCH MASTER CYLINDERS
110.B012.xx*
R P
Mechanical Clutch Lever
Caratteristiche Tecniche
Technical Features
Materiale
B.AL
Material
Tipo
MECHANICAL
Type
Ø Pistone mm
N.A.
Ø Piston mm
Interasse leva
N.A.
Lever ratio Dettaglio della lavorazione
dal pieno.
Billet machining detail.
112 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 112 19/09/18 14:37
POMPE FRIZIONE - CLUTCH MASTER CYLINDER
KBA-ABE NO YES NO NO NO NO
CARATTERISTICHE TECNICHE • TECHNICAL FEATURES
Ø PISTONE (mm) • PISTON Ø (mm) 15 15 17 14 19 19
INTERASSE LEVA • LEVER RATIO 18 16 - 18 16 - 18 16 - 18 16 - 18 18 - 20
TIPO DI LEVA • LEVER TYPE LL LL LL LL LL LL
TIPO • TYPE RADIAL RADIAL RADIAL RADIAL RADIAL RADIAL
MATERIALE C.AL F.AL F.AL F.AL F.AL F.AL
MATERIAL
PROTEZIONE SUPERFICIALE HA HA HA HA HA HA
SURFACE PROTECTION
PESO (g) • WEIGHT (g) 500 350 350 350 350 350
MICROINTERRUTTORE LUCE FRENO YES NO NO NO NO NO
BRAKE LIGHT MICRO-SWITCH
Ø FISSAGGIO MANUBRIO (mm) 22,2 22,2 22,2 22,2 22,2 25,4
HANDLEBAR FIXING Ø (mm)
FLUIDO FRENI • BRAKE FLUID DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4
NOTE
KBA-ABE NO NO NO NO NO NO
CARATTERISTICHE TECNICHE • TECHNICAL FEATURES
Ø PISTONE (mm) • PISTON Ø (mm) 16 16 19 10 10 N.A.
INTERASSE LEVA • LEVER RATIO 16 18 18 17,7 17,7 N.A.
TIPO DI LEVA • LEVER TYPE FL FL FL STD STD FL
TIPO • TYPE RADIAL RADIAL RADIAL AXIAL AXIAL MECHANICAL
MATERIALE B.AL B.AL B.AL C.AL C.AL B.AL
MATERIAL
PROTEZIONE SUPERFICIALE HA HA HA HA HA HA
SURFACE PROTECTION
PESO (gr) • WEIGHT (gr) 286 286 286 320 300 130
MICROINTERRUTTORE LUCE FRENO NO NO NO NO NO NO
BRAKE LIGHT MICRO-SWITCH
Ø FISSAGGIO MANUBRIO (mm) 22,2 22,2 22,2 22 22 OE
HANDLEBAR FIXING Ø (mm)
FLUIDO FRENI • BRAKE FLUID DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 NO
NOTE Use with original
bracket
113
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 113 04/10/18 10:21
POMPE FRIZIONE • CLUTCH MASTER CYLINDERS
114
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 114 04/10/18 10:21
110.A263.70 110.A897.70 XR0.11.50 XR0.11.51 XR0.11.55 XR0.16.10 110.9203.50 110.B012.xx
10353060 10353060
105150210 105150210
105338763 105338763
110477110 110477110
110312720 110312720
110A26379 110A26379
110A26386 110A26386
110A26389 110A26389
110A26387
110A26388 110A89787
110A26381
110A26391
115
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 115 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
KBA-ABE NO NO NO NO NO NO NO NO
CARATTERISTICHE TECNICHE • TECHNICAL FEATURES
Ø pistone (mm) • Piston ø (mm) 19 16 16 16 16 10 10 9
Interasse leva • Lever ratio 18 18 18 18 18 19 19 19
Tipo di leva •Lever type FL LL SL FLL FSL STD STD STD
Anteriore/posteriore
FRONT FRONT FRONT FRONT FRONT FRONT FRONT FRONT
Front/rear
Tipo • Type RADIAL RADIAL RADIAL RADIAL RADIAL AXIAL AXIAL AXIAL
Singolo/doppio disco
DOUBLE SINGLE SINGLE SINGLE SINGLE SINGLE SINGLE SINGLE
Single/double disc
Materiale • Material F.AL F.AL F.AL F.AL F.AL C.AL C.AL C.AL
Protezione superficiale
HA HA HA HA HA HA HA HA
Surface protection
Peso (g) • Weight (g) 286 286 286 286 286 280 275 310
Microinterruttore luce freno
NO NO NO NO NO YES NO NO
Brake light microswitch
Diametro fissaggio manubrio (mm)
22,2 22,2 22,2 22,2 22,2 22,5 22,5 22
Handlebar fixing diam. (mm)
Fluido freno • Brake fluid DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4
Note Enduro MX MX
116
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 116 19/09/18 14:37
110.A263.45 110.A897.10 110.A897.30 XA7.G7.G0 XR0.11.30 XR0.11.70 XR0.11.71 XR0.11.72 XR0.11.B0 110.4760.60 110.4760.70
14RCS 19RCS 1" 15RCS 1" 16x16 FL 19x16 FL 19x18 FL 19x20 FL 16x16 FSL 19x20 LL 19x18 LL
NO NO NO NO NO NO NO NO NO NO NO
14 19 15 19 16 19 19 19 16 19 19
18 - 20 18 - 20 18 - 20 18 16 16 18 20 16 20 18
LL LL LL FLL FL FL FL FL FSL LL LL
FRONT FRONT FRONT FRONT FRONT FRONT FRONT FRONT FRONT FRONT FRONT
RADIAL RADIAL RADIAL RADIAL RADIAL RADIAL RADIAL RADIAL RADIAL RADIAL RADIAL
SINGLE DOUBLE SINGLE DOUBLE SINGLE DOUBLE DOUBLE DOUBLE SINGLE DOUBLE DOUBLE
F.AL F.AL F.AL B.AL B.AL B.AL B.AL B.AL B.AL F.AL F.AL
HA HA HA HA HA HA HA HA HA HA HA
350 350 350 280 286 286 286 286 286 286 286
22,2 25,4 25,4 22 22,2 22,2 22,2 22,2 22,2 22,2 22,2
DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4
110.D087.10 110.D087.50 X98.57.60 X98.57.70 X98.57.80 X96.37.10 X96.37.20 XA5.21.30 XA5.21.40 XA0.J0.10 XA2.C6.10
PS 13 PS 11 PS 14 PS 11 PS 13 WITH RESERVOIR WITH RESERVOIR WITH RESERVOIR WITH RESERVOIR
NO NO NO NO NO NO NO NO NO NO NO
10 10 13 11 14 11 13 13 13 13 13
16 16 16 16 16 N.A. N.A. N.A. N.A. N.A. N.A.
STD STD STD STD STD N.A. N.A. N.A. N.A. N.A. N.A.
FRONT FRONT REAR REAR REAR REAR REAR REAR REAR REAR REAR
AXIAL AXIAL AXIAL AXIAL
AXIAL AXIAL AXIAL AXIAL AXIAL N.A. N.A.
with reservoir with reservoir with reservoir with reservoir
SINGLE SINGLE SINGLE SINGLE SINGLE SINGLE SINGLE SINGLE SINGLE SINGLE SINGLE
C.AL C.AL B.AL B.AL B.AL C.AL C.AL B.AL B.AL B.AL B.AL
HA HA HA HA HA HA HA HA HA HA HA
NO YES NO NO NO NO NO NO NO NO NO
DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4 DOT 4
Use only with Use only with
MX Enduro Left side only Left side only Left side only
Thumb M/C Thumb M/C
117
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 117 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
118
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 118 04/10/18 10:22
110.A263.45 110.A897.10 110.A897.30 XA7.G7.G0 XR0.11.30 XR0.11.70 XR0.11.71 XR0.11.72 XR0.11.B0 110.4760.60 110.4760.70
110A26377 110A26377 110A26377 10510710 10510710 10510710 10510710 10510710 10510710 10510710 10510710
110312720 110312720 110312720 110312710 110312710 110312710 110312710 110312710 110312710 110312710 110312710
110A26387
110A26380
110A26390
119
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 119 19/09/18 14:37
POMPE FRENO • BRAKE MASTER CYLINDERS
120
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 120 04/10/18 10:22
110.D087.10 110.D087.50 X98.57.60 X98.57.70 X98.57.80 X96.37.10 X96.37.20 XA5.21.30 XA5.21.40 XA0.J0.10 XA2.C6.10
10B40518
121
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 121 19/09/18 14:37
ACCESSORI RCS • RCS ACCESSORIES
122 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 122 19/09/18 14:37
ACCESSORI RCS • RCS ACCESSORIES
R P
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
123
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 123 19/09/18 14:37
FLUIDO FRENI • BRAKE FLUID
04.8164.11
R
Fluido freni LCF 600 Plus
LCF 600 Plus Brake Fluid
Caratteristiche Tecniche
2
• r ange colore: aspetto dal trasparente all'ambra. Nel caso di fluido
nuovo, appena tolto dalla bottiglia sigillata, il colore può risultare
diverso dal range, la performance resta invariata.
•S olo per utilizzo racing, non adatto ad uso stradale.
Technical Features
124 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 124 19/09/18 14:37
FLUIDO FRENI • BRAKE FLUID
04.8164.50
R P
Fluido freni Sport EVO 500++
Sport EVO 500++ Brake Fluid
Caratteristiche Tecniche
2
• Non deve essere utilizzato in impianti predisposti per fluidi minerali.
•R ange colore: aspetto dal trasparente all'ambra. Nel caso di fluido
nuovo, appena tolto dalla bottiglia sigillata, il colore può risultare
diverso dal range, la performance resta invariata.
•S olo per utilizzo racing, non adatto ad uso stradale.
Technical Features
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
125
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 2 POMPE ES.indd 125 19/09/18 14:37
DISCHI FRENO
BRAKE DISCS
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 3 DISCHI FRENO ES.indd 126 08/10/18 14:07
kW
F - Part Number R - Part Number
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 3 DISCHI FRENO ES.indd 127 08/10/18 14:07
DISCHI FRENO
BRAKE DISCS
I UKconcentrato
Un D F di tecnologia
E DK Brembo I UK D F E DK
Concentrated Brembo technology
I dischi Brembo Racing e High Performance, concepiti e Brembo Racing and High Performance discs are designed
testati per lavorare al meglio con le pastiglie, uniscono un and tested to work best with brake pads, combining constant
rendimento effi cace e costante nell’utilizzo estremo a un peso and effi cient performance in extreme applications with signifi
decisamente contenuto. I materiali impiegati e le particolari cantly reduced weight. The materials used and the special
lavorazioni utilizzate garantiscono un notevole incremento della processing employed ensure a significant increase in braking
potenza frenante, un’estrema resistenza a stress termomeccanici power, impressive resistance to prolonged thermomechanical
prolungati e un’assoluta uniformità nelle prestazioni. I dischi stress and absolute performance consistency. Brembo discs are
Brembo, caratterizzati da un inconfondibile look racing, offrono le characterised by an unmistakable racing look and ensure the
più alte performance in ogni situazione. highest performance in every situation.
T-Drive I Il disco
UK T-Drive,
D nato
F dall’esperienza
E DK maturataI in
MotoGP e Superbike, presenta un innovativo
UK The D T-Drive
F disc,EbasedDK on experience gained in
MotoGP and Superbike events, has an
accoppiamento tra fascia e campana, costituito da innovative coupling between the rotor and the
otto perni a “T” ricavati sul disco e da otto sagome bell consisting of eight T-shaped pins machined into
sulla campana, che permette l’eliminazione dei the disc and eight outlines on the bell, thereby
nottolini di trascinamento. Attraverso uno specifi co allowing the elimination of drive pawls. A specifi c
studio delle tolleranze, questa conformazione study of tolerances shows that this confi guration
permette, oltre a una signifi cativa riduzione di peso, achieves not only a signifi cant weight reduction but
una fl ottanza, sia radiale sia assiale, capace di also both axial and radial fl oating capable of
trasmettere una maggiore coppia frenante. Questo transmitting more braking torque. This disc also
disco offre anche un’eccellente resistenza agli stress provides excellent resistance to thermomechanical
termomeccanici, evidente soprattutto in condizioni di stress, especially in extreme conditions such as
utilizzo estreme, come nelle competizioni. I dischi races. T-Drive discs are available for the most
T-Drive sono disponibili per le più diffuse common Maxi-Sport models without requiring any
Maxisportive, senza alcuna modifica. modifi cations.
I UK SuperSport
D F discsEwere DK
developed to deliver the
SuperSport I UK SuperSport
I dischi D F sonoE statiDK
sviluppati per
fornire le più alte prestazioni, sia su strada sia highest performance levels, both on road and on
su pista, a tutti i possessori delle più diffuse track, to all owners of the most popular European
Maxisportive europee e giapponesi. In and Japanese Maxi-Sport models. In conjunction
combinazione con le pastiglie Brembo Z04, questi with Brembo Z04 brake pads, these discs have won
dischi hanno vinto numerosi Mondiali SuperSport. I numerous SuperSport World Championships.
dischi SuperSport sono disponibili con fascia SuperSport discs are available with a braking surface
frenante di altezza 34 mm e spessore maggiorato a width of 34 mm and thickness increased to 5,5 mm;
5,5 mm, intercambiabili con gli originali senza they are interchangeable with the original discs
nessuna modifi ca. Completamente fl ottanti, sono without requiring any modifi cations. These fully fl
composti dalla fascia in acciaio trattato oating discs are made from heat-treated steel
termicamente, in grado di resistere a sollecitazioni capable of withstanding extreme thermo-mechanical
termomeccaniche estreme, e dalla campana in stress, with an aluminium alloy bell machined from
lega d’alluminio ricavata dal pieno. the billet.
128
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 3 DISCHI FRENO ES.indd 128 19/09/18 14:51
I
Il UK
nuovo D
disco Ffl ottante
E “MXDKOff- Road I UK The D newF“MX Off-Road”
E DK fl oating disc is
MX Off-Road
Disc”, maggiorato rispetto all’originale oversized compared to original (267 mm)
(267 mm), offre la migliore tecnologia and offers the best Brembo technology in
Brembo in termini di prestazioni e sicurezza. terms of performance and safety. The bell is in
La campana è in alluminio e ricavata dal billet-machined aluminium, while the assembly
pieno, mentre l’assemblaggio è fatto a mano. is performed by hand. This disc is perfectly
Questo disco è perfettamente intercambiabile interchangeable with the original thanks to a
con l’originale grazie all’apposita staffa (anche specifi c bracket (also in billet-machined
questa in alluminio lavorato dal pieno) che aluminium) that repositions the caliper radially.
riposiziona radialmente la pinza. Per offrire un To ensure a complete package geared to high
pacchetto completo orientato alle più alte performance requirements, the kit also includes
performance, il kit comprende anche la specifi specifi c SX sintered brake pads.
che pastiglie SX sinterizzate.
I Il UK D F
disco PistaBassa E
nasce DK I
dall’esperienza UK D PistaBassa
The F Edisc DK
was developed based PistaBassa
acquisita in MotoGP e SBK, con fissaggio on the experience gained in MotoGP and
T-Drive, per avere risparmio di peso e Superbike, with a T-Drive fixing system,
migliorare la trasmissione della coppia allowing for a significant weight reduction and
frenante. A questo si aggiunge la flottanza improved braking torque. Moreover the
della fascia sulla campana per evitare PistaBassa has a full floating disc, which allows
deformazioni alle alte temperature. La fascia for resistance to high temperature distortion.
frenante da 30mm di altezza e 6,75mm di The 30mm high and 6,75mm thick braking
spessore li rende compatibili a tutte le pinze surface width makes them compatible with all
Brembo Racing. Avendo fissaggi e offset Brembo Racing calipers. Their fixings and offset
come i dischi originali non richiedono alcuna are the same as per the original discs, therefore
modifica del cerchio e delle forcelle in no modification of the original wheel and forks
dotazione. L’acciaio della fascia è trattato is required. The braking surface is made from
termicamente per affrontare le più intense heat-treated steel capable of withstanding
sollecitazioni termomeccaniche. extreme thermo-mechanical stress.
I UK Created
D F E DKhighest possible
I UK per D
Nati fornireFle piùEaltre DK
prestazioni, su to provide the
performance on the road and off-road for
Motard
strada come in pista e in off-road, ai
possessori di motociclette da motard European and Japanese motard owners,
europee e giapponesi, i dischi Motard hanno Motard discs, combined with Brembo Z04
preso parte a numerose competizioni, in pads, have taken part in numerous
combinazione con le pastiglie Brembo Z04. I competitions. Motard discs are completely fl
dischi Motard sono completamente fl ottanti e oating and interchangeable with original
intercambiabili con gli originali senza bisogno equipment without the need for any modifi
di alcuna modifi ca, grazie alla fascia frenante cations thanks to the 34 mm braking surface
in acciaio trattato termicamente da 34 mm di width realized with heat treated steel, and the
altezza e spessore maggiorato a 5,5 mm. thickness increased to 5,5 mm. They are also
Sono inoltre completati dalla campana, in lega completed by a black anodized billet aluminium
d’alluminio ricavata dal pieno, di colore nero. alloy bell.
I UK AllDCustomF fansEkeenDK
I A UK
tutti gliDappassionati
F E Custom
DK che to combine safety,
performance and design will welcome
Custom Disc
vogliono coniugare sicurezza,
performance e design, Brembo Racing Brembo Racing’s new Custom Disc,
propone il nuovo Custom Disc, interchangeable with the original and
intercambiabile con l’originale, in grado di embodying the best Brembo technology as
offrire la migliore tecnologia Brembo quanto a regards performance and safety, together with
prestazioni e sicurezza, insieme ad uno stile eye-catching style. This fl oating disc has a
accattivante. Questo disco fl ottante ha un diameter of 11,5 inches and is perfectly
diametro di 11,5 pollici, perfettamente interchangeable with 292 mm by 5 mm thick OE
intercambiabile con i dischi OE da 292 mm e discs. The design of the billet-machined bell has
5 mm di spessore. Il design della campana, a distinctive, anthracite black fi - nish achieved
realizzata totalmente dal pieno, ha come through a unique oxidation process.
elemento distintivo una fi nitura nero antracite
ottenuta grazie a un processo di ossidazione.
129
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 3 DISCHI FRENO ES.indd 129 19/09/18 14:52
DISCHI FRENO • BRAKE DISCS
R P T-Drive
130The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 3 DISCHI FRENO ES.indd 130 19/09/18 14:52
3
Caratteristiche Tecniche
Technical Features
Materiale fascia
SST
Disc material
Materiale campana
B.AL
Bell material
Flottanza completa
YES
Full floating
Tipo di trascinamento
T
Fixing type Dettaglio trascinamento Logo Brembo Racing lavorato
T-Drive. al laser.
T-Drive system detail. Laser etched Brembo Racing
logo.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
131
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 3 DISCHI FRENO ES.indd 131 19/09/18 14:52
DISCHI FRENO • BRAKE DISCS
R P SuperSport
2016 2017
SUPERSTOCK SUPERSTOCK
1000 1000
WORLD WORLD
CHAMPION CHAMPION
Caratteristiche Tecniche
Technical Features
Materiale fascia
SST
Disc material
Materiale campana
B.AL
Bell material
Flottanza completa
YES
Full floating
Tipo di trascinamento
ROUND
Fixing type
3
Trascinamento a bussola tonda.
Round bushing drive system.
132 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 3 DISCHI FRENO ES.indd 132 19/09/18 14:52
DISCHI FRENO • BRAKE DISCS
The Groove P
Caratteristiche Tecniche
Technical Features
Materiale fascia
SST
Disc material
Materiale campana
B.AL
Bell material
Flottanza completa
YES
Full floating
Tipo di trascinamento
ROUND
Fixing type
3
Logo Brembo lavorato
in bassorilievo. Dipinto a mano.
Low-relief machining Brembo logo.
Hand painted fi nishing.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
133
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 3 DISCHI FRENO ES.indd 133 19/09/18 14:52
DISCHI FRENO • BRAKE DISCS
R MX Off-Road
Caratteristiche Tecniche
Technical Features
Materiale fascia
SST
Disc material
Materiale campana
B.AL
Bell material
Flottanza completa
YES
Full floating
Tipo di trascinamento SPECIAL
Fixing type ROUND
3
Trascinamento “Special Round”
specifico per disco Off-Road.
“Special Round” bushing specific
for Off-Road disc.
134 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 3 DISCHI FRENO ES.indd 134 19/09/18 14:52
DISCHI FRENO • BRAKE DISCS
PistaBassa R
Caratteristiche Tecniche
Technical Features
Materiale fascia
SST
Disc material
Materiale campana
B.AL
Bell material
Flottanza completa
YES
Full floating
Tipo di trascinamento
T
Fixing type
3
Lavorazione dal pieno del logo Brembo.
Billet-machined Brembo logo on the bell.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
135
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 3 DISCHI FRENO ES.indd 135 19/09/18 14:52
DISCHI FRENO • BRAKE DISCS
R P Motard
Caratteristiche Tecniche
Technical Features
Materiale fascia
SST
Disc material
Materiale campana
B.AL
Bell material
Flottanza completa
YES
Full floating
Tipo di trascinamento
ROUND
Fixing type
3
Trascinamento a bussola tonda.
Round bushing drive system.
136 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 3 DISCHI FRENO ES.indd 136 19/09/18 14:52
DISCHI FRENO • BRAKE DISCS
Custom P
Caratteristiche Tecniche
Technical Features
Materiale fascia
SST
Disc material
Materiale campana
B.AL
Bell material
Flottanza completa
YES
Full floating
Tipo di trascinamento
ROUND
Fixing type
3
Trascinamento a bussola tonda.
Round bushing drive system.
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
137
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 3 DISCHI FRENO ES.indd 137 19/09/18 14:52
DISCHI FRENO • BRAKE DISCS
ROUND
NUMERO DI TRASCINAMENTI
8 10 10
FIXING NUMBER
ASSEMBLATO A MANO
YES YES YES
HAND ASSEMBLY
NOTE
138
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 3 DISCHI FRENO ES.indd 138 19/09/18 14:52
MX OFF-ROAD PISTABASSA MOTARD CUSTOM
R R R P P
NO NO NO NO
PLUG & PLAY REFER TO YOUR DEALER PLUG & PLAY PLUG & PLAY
3 6,75 5,5 5
27 30 34 46
6 8 10 10
139
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 3 DISCHI FRENO ES.indd 139 19/09/18 14:52
PASTIGLIE FRENO
BRAKE PADS
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 4 PASTIGLIE ES.indd 140 27/09/18 10:39
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 4 PASTIGLIE ES.indd 141 27/09/18 10:39
PASTIGLIE FRENO
BRAKE PADS
I UK D
Performance, F durataE eDKsicurezza I UK D F E DK
Record-setting performance,
da primato durability and safety
Brembo presenta una scelta completa di pastiglie Brembo presents a comprehensive range of
Brembo Racing e High Performance. Queste Brembo Racing and High Performance brake pads.
pastiglie, sviluppate per le competizioni, sono state These brake pads designed for competitions offer
progettate per offrire il massimo delle prestazioni maximum performance even in the most extreme
nelle situazioni più estreme. Maggiore controllo della situations. Better braking control, system stability,
frenata, stabilità dell’impianto, aumento della increased braking power, resistance to high
potenza frenante, resistenza alle alte temperature, temperatures, low wear and easy running-in: these
usura ridotta, facilità di rodaggio: sono tutte are all features offered by Brembo Racing and High
caratteristiche offerte dai materiali d’attrito Brembo Performance friction materials. Each one has its own
Racing e High Performance. Ognuno con proprie particular performance features behaviour, so that
peculiarità di comportamento, i vari materiali d’attrito these friction materials cover a wide range of
coprono un’ampia possibilità di utilizzo, offrendo al applications and offer drivers the chance to choose
pilota l’opportunità di scegliere la pastiglia più adatta the most suitable brake pad. The outcome is an
alla destinazione d’uso. Il risultato fi nale è uno extraordinary feeling in tune with the bike’s braking
straordinario feeling con l’impianto frenante della system. The friction materials on offer especially
motocicletta. Tra i materiali d’attrito proposti, spicca include the excellent Brembo Racing Z04
l’eccellenza della mescola Brembo Racing Z04, compound, as used by most Superbike and
utilizzata dalla maggioranza dei team nei Supersport Championship teams and now available
Campionati Mondiali Superbike e also for Superstock, Motocross and Supermotard.
Supersport e ora disponibile anche The huge success of this product means that these
per applicazioni Superstock, Brembo Racing brake pads are also proposed in a
Motocross e Supermotard. Il wide range for road and racing bikes alongside
grande successo di questo BE
original equipment calipers. From one star to
CS
prodotto ha fatto sì che another. The Brembo Racing Z03 compound is also
ora questa pastiglia now available and is designed for riders seeking
Brembo Racing sia durability in addition to performance, as in
proposta anche in Endurance races. All Brembo Racing products are
una vasta gamma researched, designed 4 and manufactured for use in
3
per moto stradali, races and2on private circuits. BE
CS
da FR
guidare in pista, WR The compounds used
in the 1
friction material are therefore unsuitable for
da abbinare alle everyday driving conditions and on-road use is very
pinze di primo CS
inadvisable.
BE
equipaggiamento.
Da una star all’altra. 4
3
Ora è disponibile FR 2 WR
anche la mescola CS BE 1
CT 3 4
MF Z03,
Brembo Racing
FR
anch’essa sviluppata
1
2 WR
per chi cerca una lunga attacco CS BE
durata, oltre alle BT bite CS BE rodaggio
bedding
prestazioni, come accade 4
3
nelle gare Endurance. attrito medio resistenza usura
FRTutti i MF mean1friction 2 CT resistance
WR wear
prodotti Brembo Racing sono 4
studiati, progettati e realizzati per 3 4
resistenza al fading modulabilità
l’utilizzo in pista e su circuiti privati. LeMF FR fading resistance CT
23
control WR
mescole che costituiscono il materiale FR BT 12
WR
1
d’attrito, quindi, non sono adatte alle condizioni di costanza
guida quotidiane e se ne sconsiglia l’uso su strada. CS consistency BE
BT
MF CT
142
MF 4 CT
BT 3 CT
MF
FR 1
2 WR
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 4 PASTIGLIE ES.indd 142 19/09/18 14:59
FRONT • Racing compounds REAR • Racing compounds
CS BE
CS BE
4
4 3
3 FR 1
2 WR
FR 1
2 WR
MF CT
MF CT
BT
BT
Z04 H38
CS BE CS BE
4 4
3 3
FR 1
2 WR FR 2 WR
1
MF CT MF CT
BT BT
Z03 ID450
4
3
4
3 FR 1
2 WR
FR 2 WR
1
MF CT
MF CT
BT
Genuine BT MD512HH
143
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 4 PASTIGLIE ES.indd 143 19/09/18 14:59
PASTIGLIE FRENO • BRAKE PADS
W LARGHEZZA
WIDTH (mm)
H ALTEZZA
HEIGHT (mm)
T SPESSORE
THICKNESS (mm)
A
COMPOUND • MESCOLA Code W H T
GENUINE 107785510
Z03 (SINTERED ENDURANCE) 107A48667
Z04 (SINTERED) 107A48647
35 40,5 8
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
B
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) 107A48668
Z04 (SINTERED) 107A48648
75 48 8
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
C
COMPOUND • MESCOLA Code W H T
GENUINE 107988210
Z03 (SINTERED ENDURANCE) 107A48669
Z04 (SINTERED) 107A48639
102,2 42 7,9
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
4
D
COMPOUND • MESCOLA Code W H T
GENUINE 107442650
Z03 (SINTERED ENDURANCE) 107A48673
Z04 (SINTERED) 107A48653
69,6 50,9 8,5
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
144 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 4 PASTIGLIE ES.indd 144 19/09/18 14:59
DISEGNI IN SCALA 1:1
DRAWING SCALE 1:1
PASTIGLIE FRENO • BRAKE PADS
E
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) -
Z04 (SINTERED) 107A48650
37,9 49,5 8
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
F
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) 107A48671
Z04 (SINTERED) 107A48651
71,1 55 8,1
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
G
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) 107A48672
Z04 (SINTERED) 107A48652
61,5 44,6 8,5
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
4
W H T
30,6 48 8,5
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
145
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 4 PASTIGLIE ES.indd 145 19/09/18 14:59
PASTIGLIE FRENO • BRAKE PADS
W LARGHEZZA
WIDTH (mm)
H ALTEZZA
HEIGHT (mm)
T SPESSORE
THICKNESS (mm)
H
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) 07B36640
Z04 (SINTERED) -
94,3 34 11,5
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
I
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) -
Z04 (SINTERED) 107A48656
82,2 51,1 8,15
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
L
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) 107A48675
Z04 (SINTERED) 107A48655
78,1 46,2 7,8
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
4
M
COMPOUND • MESCOLA Code W H T
GENUINE 107670821
Z03 (SINTERED ENDURANCE) 107A48674
Z04 (SINTERED) 107670823
74,5 55,5 8,6
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
146 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 4 PASTIGLIE ES.indd 146 19/09/18 15:00
DISEGNI IN SCALA 1:1
DRAWING SCALE 1:1
PASTIGLIE FRENO • BRAKE PADS
N
COMPOUND • MESCOLA Code W H T
GENUINE 107684830
Z03 (SINTERED ENDURANCE) -
Z04 (SINTERED) 107A48603
77,4 40,7 8
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
O
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) -
Z04 (SINTERED) 107A48602
77,4 40,7 9,4
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
P
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) 107A48622
Z04 (SINTERED) -
77,4 42,85 10,7
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
4
Q
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) 07A02310/20
Z04 (SINTERED) 07835424
82,4 28,9 9,5
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
147
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 4 PASTIGLIE ES.indd 147 19/09/18 15:00
PASTIGLIE FRENO • BRAKE PADS
W LARGHEZZA
WIDTH (mm)
H ALTEZZA
HEIGHT (mm)
T SPESSORE
THICKNESS (mm)
R
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) -
Z04 (SINTERED) 107A48604
43,2 48,8 9
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) 07787427
S
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) -
Z04 (SINTERED) -
51 54 7,4
ID 450 (ORGANIC) 107694910
MD 512 HH (SINTERED) -
H38 (SINTERED) -
V
COMPOUND • MESCOLA Code W H T
GENUINE 107861750
Z03 (SINTERED ENDURANCE) -
Z04 (SINTERED) 107A48646
94 36,2 7,5
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
4
Z
COMPOUND • MESCOLA Code W H T
GENUINE 07849312/27
Z03 (SINTERED ENDURANCE) -
Z04 (SINTERED) -
64 41,8 8
ID 450 (ORGANIC) -
MD 512 HH (SINTERED) -
H38 (SINTERED) -
148 The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 4 PASTIGLIE ES.indd 148 19/09/18 15:00
DISEGNI IN SCALA 1:1
DRAWING SCALE 1:1
PASTIGLIE FRENO • BRAKE PADS
X
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) -
Z04 (SINTERED) -
35,75 29 7,6
ID 450 (ORGANIC) 07934090
MD 512 HH (SINTERED) X206022
H38 (SINTERED) 07934080
W
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) -
Z04 (SINTERED) -
49,75 30 7,6
ID 450 (ORGANIC) 07934020
MD 512 HH (SINTERED) -
H38 (SINTERED) 07934070
Y
COMPOUND • MESCOLA Code W H T
GENUINE -
Z03 (SINTERED ENDURANCE) -
Z04 (SINTERED) -
49,75 36 7,6
ID 450 (ORGANIC) 07934010
MD 512 HH (SINTERED) X988802
H38 (SINTERED) 07934040
The data contained in this catalogue are provided for information purposes only and therefore may be subject to change and are not intended to provide all relevant information for use and installation of our products.
149
1447_BR MO CATALOGO MOTO HP E RACING INTERNO 2018 4 PASTIGLIE ES.indd 149 04/10/18 10:23
