Simboli usati nel Symbols used in this Symboles utilisés dans Verwendete Symbole im Símbolos adoptados en
catalogo catalogue le catalogue Katalog el cátalogo

Avvertimento di rischi o pericoli Warnings of risk or hazards Attention aux risques ou dangers Warnung vor Risiko oder Gefahren Advertencia sobre riesgos y
peligros

Pos. 0 Gruppo completo Complete group Groupe complet Gruppe komplett Grupo completo

m Ordinare a metraggio Order per meter Commander à métrage Bestellen meterweise Pedìr por metros

nr Ordinare per unità Order per unit Commander à unité Bestellen por Einheit Pedir por unidad

Var. Quantità variabile Variable quantity Quantité variable Veränderliche Menge Cantidad variable

Da n° Da n° di matricola From the S/no. Du le n° de serie Von der Fabrik Nr. Desde el n° de matrícula

Fino a n° Fino al n° di matricola Up to S/no. Jusqu' au n° de serie Bis der Fabrik Nr. Hasta el n° de matrícula

Gruppo Unit Groupe Gruppe Grupo

Componente del gruppo Group component Composant du groupe Gruppenkomponente Componente del grupo

Particolare del componente gruppo Group component part Détail du composant groupe Gruppekomponenteneinzelheit Pieza del componente grupo

2M Due montanti Duplex Duplex Duplex Duplex

3M Tre montanti Triplex Triplex Triplex Triplex

V.T. Visibilità totale Clear view Grande Visibilité Vollfreisicht Visibilidad Total

A.L.T. Altezza libera totale Full free lift Levée Libre Totale Altezza libera totale Full free lift

CU Cushion Cushion Cushion Ballon-Elastikreifen Cushion

SE Superelastica Superelastic Pleins souples Hochelastischereifen Superelásticas

PN Pneumatica Pneumatic Pneumatiques Luftreifen Neumáticos

SEG SE - Gemellata SE - Twin SE - Roues jumelées SE - Zwilling SE - Gemelas

PNG PN - Gemellata PN - Twin PN - Roues jumelées PN - Zwilling PN - Gemelas

Page 3
Page 4
 INDICE / INDEX / INDEX / VERZEICHNIS / INDICE
1 - ETICHETTE E CATALOGHI / LABELS AND CATALOGUES / N.D. / N.D. / N.D.......................................................................................................................................................................................................................................... Page 10

2 - TELAIO / FREAME / N.D. / N.D. / N.D............................................................................................................................................................................................................................................................................................................ Page 12

3 - SEDILE / SEAT / N.D. / N.D. / N.D.................................................................................................................................................................................................................................................................................................................. Page 16

4 - CRUSCOTTO / DASHBOARD / N.D. / N.D. / N.D.......................................................................................................................................................................................................................................................................................... Page 18

5 - PIANTONE STERZO / STEERING COLUMN / N.D. / N.D. / N.D............................................................................................................................................................................................................................................................... Page 20

6 - AZIONATORE CLACSON / HORN CONTROL / N.D. / N.D. / N.D................................................................................................................................................................................................................................................................ Page 22

8 - ASSALE A BILICO / REAR AXLE / N.D. / N.D. / N.D.................................................................................................................................................................................................................................................................................... Page 24

10 - RUOTE DIRETTRICI / STEER WHEELS / N.D. / N.D. / N.D.......................................................................................................................................................................................................................................................................... Page 28

11 - SCHEMA IMPIANTO GUIDA IDRAULICA (4w) / DIAGRAM OF STEERING ASSISTANCE SYSTEM (4w) / N.D. / N.D. / N.D................................................................................................................................................................ Page 30

12 - SCHEMA IDRAULICO DI SOLLEVAMENTO / HOISTING HYDRAULIC SYSTEM / N.D. / N.D. / N.D......................................................................................................................................................................................................... Page 32

13 - SERBATOIO E FILTRO OLIO / OIL TANK AND FILTER / N.D. / N.D. / N.D................................................................................................................................................................................................................................................. Page 34

14 - MOTORE E POMPA DI SOLLEVAMENTO / HOISTING MOTOR AND PUMP / N.D. / N.D. / N.D................................................................................................................................................................................................................ Page 36

15 - DISTRIBUTORE IDRAULICO / CONTROL VALVE / N.D. / N.D. / N.D........................................................................................................................................................................................................................................................ Page 40

16 - MOTORE DI TRAZIONE / DRIVE MOTOR / N.D. / N.D. / N.D........................................................................................................................................................................................................................................................................ Page 44

17 - RIDUTTORE HFS 502 / REDUCTION GEAR HFS 502 / N.D. / N.D. / N.D..................................................................................................................................................................................................................................................... Page 46

17 - RIDUTTORE GP20 / REDUCTION GEAR GP20 / N.D. / N.D. / N.D............................................................................................................................................................................................................................................................... Page 50

18 - RUOTE MOTRICI / DRIVE WHEELS / N.D. / N.D. / N.D................................................................................................................................................................................................................................................................................ Page 52

19 - COMANDO ELETTRONICO / ELETTRONIC CONTROL / N.D. / N.D. / N.D................................................................................................................................................................................................................................................. Page 54

20 - COMPONENTI ELETTRICI / MISCELLANEOUS ELETTRICAL / N.D. / N.D. / N.D...................................................................................................................................................................................................................................... Page 58

21 - PEDALIERA ACCELERATORE / SPEED PEDAL / N.D. / N.D. / N.D......................................................................................................................................................................................................................................................... Page 62

22 - PEDALIERA E POMPA FRENO / BRAKE PUMP AND PEDAL / N.D. / N.D. / N.D....................................................................................................................................................................................................................................... Page 64

23 - FRENO DI STAZIONAMENTO / PARKING BRAKE / N.D. / N.D. / N.D....................................................................................................................................................................................................................................................... Page 66

24 - MARTINETTO INCLINAZIONE / TILT JACK / N.D. / N.D. / N.D.................................................................................................................................................................................................................................................................. Page 70

25 - DISPOSITIVI E ACCESSORI / DEVICES AND ACCESSORIESES / N.D. / N.D. / N.D............................................................................................................................................................................................................................... Page 73

ACCESSORI / ACCESSORIES / N.D. / N.D. / N.D......................................................................................................................................................................................................................................................................................... Page 74

Page 5
 DISPOSITIVI DI SEGNALAZIONE VISIVA E DI ILLUMINAZIONE / LIGHTING EQUIPMENT AND ATTACHMENTS / N.D. / N.D. / N.D..................................................................................................................................................... Page 78

IMPIANTO LUCI PER CIRCOLAZIONE SU STRADA TRATTE BREVI (SALTUARIA) / STREET LIGHTING SYSTEM ONLY ITALY / N.D. / N.D. / N.D............................................................................................................................ Page 82

IMPIANTO LUCI COMPLETO / COMPLETE LIGHTING EQUIPMENT / N.D. / N.D. / N.D............................................................................................................................................................................................................................. Page 86

CABINA +150mm (VERSIONE SCANDINAVIA ) / CABIN +150mm (SCANDINAVIAN VERSION) / N.D. / N.D. / N.D.................................................................................................................................................................................. Page 88

CABINA fino a N° 209642 / CABIN up to the N° 209642 / N.D. / N.D. / N.D................................................................................................................................................................................................................................................... Page 94

CABINA da N° 209643 / CABIN from N° 209643 / N.D. / N.D. / N.D............................................................................................................................................................................................................................................................... Page 98

IMPIANTO RISCALDATORE / HEATER EQUIPMENT / N.D. / N.D. / N.D..................................................................................................................................................................................................................................................... Page 104

PEDALIERA BASCULANTE / SWAYING PEDAL SYSTEM / N.D. / N.D. / N.D.............................................................................................................................................................................................................................................. Page 106

DISTRIBUTORE CON LEVA MULTIFUNZIONE / DISTRIBUTOR WITH MULTIFUNCTION LEVER / N.D. / N.D. / N.D............................................................................................................................................................................... Page 110

26 - INVERSORE AL VOLANTE / DIRECTION INVERSOR LEVER / N.D. / N.D. / N.D....................................................................................................................................................................................................................................... Page 115

INVERSORE AL VOLANTE / DIRECTION INVERSOR LEVER / N.D. / N.D. / N.D........................................................................................................................................................................................................................................ Page 116

PEDALIERA ACCELERATORE / SPEED PEDAL / N.D. / N.D. / N.D............................................................................................................................................................................................................................................................. Page 118

27 - GRUPPO MONTANTI (nuovi con profilo laminato) / MASTS GROUP (new masts with rolled steel section) / N.D. / N.D. / N.D.......................................................................................................................................................... Page 121

MONTANTI (2M) VT / MASTS (2M) VT / N.D. / N.D. / N.D.............................................................................................................................................................................................................................................................................. Page 122

MARTINETTO ELEVATORE (2M) VT / LIFT JACK (2M) VT / N.D. / N.D. / N.D............................................................................................................................................................................................................................................. Page 124

CARRELLINO PIASTRA FISSA (2M) FEM A - FEM B / FORK CARRIAGE (2M) FEM A - FEM B / N.D. / N.D. / N.D................................................................................................................................................................................... Page 126

TRASLATORE LATERALE (2M) FEM A - FEM B / SIDESHIFTING CARRIAGE (2M) FEM A - FEM B / N.D. / N.D. / N.D.......................................................................................................................................................................... Page 128

IMPIANTO SOLLEVAM. E DRENAGGIO (2M) VT / LIFTING AND DRAINAGE HYDRAULIC SYSTEM (2M) VT / N.D. / N.D. / N.D............................................................................................................................................................ Page 130

IMPIANTO ALIMENTAZIONE TRASLATORE LAT. (2M) VT / SIDESHIFTING DEVICE HYDRAULIC INSTALL (2M) VT / N.D. / N.D. / N.D............................................................................................................................................... Page 132

MONTANTI (3M) VT / MASTS (3M) VT / N.D. / N.D. / N.D.............................................................................................................................................................................................................................................................................. Page 134

MARTINETTO ELEVATORE (3M) VT / LIFT JACK (3M) VT / N.D. / N.D. / N.D............................................................................................................................................................................................................................................. Page 138

CARRELLINO PIASTRA FISSA (3M) VT - FEM A - FEM B / FORK CARRIAGE (3M) VT - FEM A - FEM B / N.D. / N.D. / N.D................................................................................................................................................................... Page 140

TRASLATORE LATERALE (3M) VT - FEM A - FEM B / SIDESHIFTING CARRIAGE (3M) VT - FEM A - FEM B / N.D. / N.D. / N.D............................................................................................................................................................ Page 142

IMPIANTO SOLLEVAMENTO E DRENAGGIO (3M) VT / LIFTING AND DRAINAGE HYDRAULIC SYSTEM (3M) VT / N.D. / N.D. / N.D................................................................................................................................................... Page 144

IMPIANTO ALIMENTAZIONE TRASLATORE LAT. (3M) VT / SIDESHIFTING DEVICE HYDRAULIC INSTALL (3M) VT / N.D. / N.D. / N.D............................................................................................................................................... Page 146

Page 6
 MONTANTI (2M) A.L.T. / MASTS (2M) A.L.T. / N.D. / N.D. / N.D.................................................................................................................................................................................................................................................................... Page 148

MARTINETTO ELEVATORE CENTRALE (2M) A.L.T. / CENTRAL LIFT JACK (2M) A.L.T. / N.D. / N.D. / N.D............................................................................................................................................................................................ Page 152

MARTINETTO ELEVATORE LATERALE (2M) A.L.T. / SIDE LIFT JACK (2M) A.L.T. / N.D. / N.D. / N.D...................................................................................................................................................................................................... Page 154

CARRELLINO PIASTRA FISSA (2M) A.L.T. FEM A - FEM B / FORK CARRIAGE (2M) A.L.T. FEM A - FEM B / N.D. / N.D. / N.D.............................................................................................................................................................. Page 156

TRASLATORE LATERALE (2M) A.L.T. FEM A - FEM B / SIDESHIFTING CARRIAGE (2M) A.L.T. FEM A - FEM B / N.D. / N.D. / N.D...................................................................................................................................................... Page 158

IMPIANTO SOLLEVAMENTO E DRENAGGIO (2M) A.L.T. / LIFTING AND DRAINAGE HYDRAULIC SYSTEM (2M) A.L.T. / N.D. / N.D. / N.D......................................................................................................................................... Page 162

IMPIANTO ALIMENTAZIONE TRASLATORE LAT. (2M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (2M) A.L.T. / N.D. / N.D. / N.D.......................................................................................................................... Page 164

MONTANTI (3M) A.L.T. / MASTS (3M) A.L.T. / N.D. / N.D. / N.D.................................................................................................................................................................................................................................................................... Page 166

MARTINETTO ELEVATORE LATERALE (3M) A.L.T. / SIDE LIFT JACK (3M) A.L.T. / N.D. / N.D. / N.D...................................................................................................................................................................................................... Page 170

MARTINETTO ELEVATORE CENTRALE (3M) A.L.T. / CENTRAL LIFT JACK (3M) A.L.T. / N.D. / N.D. / N.D............................................................................................................................................................................................. Page 172

CARRELLINO PIASTRA FISSA (3M) A.L.T. FEM A - FEM B / FORK CARRIAGE (3M) A.L.T. FEM A - FEM B / N.D. / N.D. / N.D.............................................................................................................................................................. Page 174

TRASLATORE LATERALE (3M) A.L.T. FEM A - FEM B / SIDESHIFTING CARRIAGE (3M) A.L.T. FEM A - FEM B / N.D. / N.D. / N.D...................................................................................................................................................... Page 176

IMPIANTO SOLLEVAMENTO E DRENAGGIO (3M) A.L.T. / LIFTING AND DRAINAGE SYSTEM (3M) A.L.T. / N.D. / N.D. / N.D............................................................................................................................................................... Page 180

IMPIANTO ALIMENTAZIONE TRASLATORE LAT. (3M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (3M) A.L.T. / N.D. / N.D. / N.D.......................................................................................................................... Page 182

FORCHE FEM 2A / FORKS FEM 2A / N.D. / N.D. / N.D................................................................................................................................................................................................................................................................................ Page 184

FORCHE FEM 2B / FORKS FEM 2B / N.D. / N.D. / N.D................................................................................................................................................................................................................................................................................. Page 186

27 - GRUPPO MONTANTI / MASTS GROUP / N.D. / N.D. / N.D.......................................................................................................................................................................................................................................................................... Page 189

MONTANTI (2M) / MASTS (DUPLEX) / N.D. / N.D. / N.D............................................................................................................................................................................................................................................................................... Page 190

MARTINETTO ELEVATORE (2M) / LIFT JACK (DUPLEX) / N.D. / N.D. / N.D............................................................................................................................................................................................................................................... Page 192

CARRELLINO PIASTRA FISSA (2M) / FORK CARRIAGE (DUPLEX) / N.D. / N.D. / N.D.............................................................................................................................................................................................................................. Page 194

CARRELLINO TRASLATORE LATERALE (2M) / SIDESHIFTING CARRIAGE (DUPLEX) / N.D. / N.D. / N.D............................................................................................................................................................................................. Page 196

IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (2M) / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (DUPLEX) / N.D. / N.D. / N.D........................................................................................................................... Page 198

FORCHE (2M) / FORKS (DUPLEX) / N.D. / N.D. / N.D................................................................................................................................................................................................................................................................................... Page 200

MONTANTI (3M) / MASTS (TRIPLEX) / N.D. / N.D. / N.D............................................................................................................................................................................................................................................................................... Page 202

MARTINETTO ELEVATORE (3M) / LIFT JACK (TRIPLEX) / N.D. / N.D. / N.D.............................................................................................................................................................................................................................................. Page 206

Page 7
CARRELLINO PIASTRA FISSA (3M) / FORK CARRIAGE (TRIPLEX) / N.D. / N.D. / N.D............................................................................................................................................................................................................................. Page 208

CARRELLINO TRASLATORE LATERALE (3M) / SIDESHIFTING CARRIAGE (TRIPLEX) / N.D. / N.D. / N.D.............................................................................................................................................................................................. Page 210

IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (3M) / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (TRIPLEX) / N.D. / N.D. / N.D.......................................................................................................................... Page 212

FORCHE (3M) / FORKS (TRIPLEX) / N.D. / N.D. / N.D.................................................................................................................................................................................................................................................................................. Page 214

MONTANTI (2M) A.L.T. / MASTS (DUPLEX) F.F.L. / N.D. / N.D. / N.D.......................................................................................................................................................................................................................................................... Page 216

MARTINETTO ELEVATORE CENTRALE (2M) A.L.T. / CENTRAL LIFT JACK (DUPLEX) F.F.L. / N.D. / N.D. / N.D................................................................................................................................................................................... Page 220

MARTINETTO ELEVATORE LATERALE (2M) A.L.T. / SIDE LIFT JACK (DUPLEX) F.F.L. / N.D. / N.D. / N.D............................................................................................................................................................................................. Page 222

CARRELLINO PIASTRA FISSA (2M) A.L.T. / FORK CARRIAGE (DUPLEX) F.F.L. / N.D. / N.D. / N.D......................................................................................................................................................................................................... Page 224

CARRELLINO TRASLATORE LATERALE (2M) A.L.T. / SIDESHIFTING CARRIAGE (DUPLEX) F.F.L. / N.D. / N.D. / N.D......................................................................................................................................................................... Page 226

IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (2M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (DUPLEX) F.F.L. / N.D. / N.D. / N.D...................................................................................................... Page 228

FORCHE (2M) A.L.T. / FORKS (DUPLEX) F.F.L. / N.D. / N.D. / N.D.............................................................................................................................................................................................................................................................. Page 232

MONTANTI (3M) A.L.T. / MASTS (TRIPLEX) F.F.L. / N.D. / N.D. / N.D.......................................................................................................................................................................................................................................................... Page 234

MARTINETTO ELEVATORE CENTRALE (3M) A.L.T. / CENTRAL LIFT JACK (TRIPLEX) F.F.L. / N.D. / N.D. / N.D................................................................................................................................................................................... Page 238

MARTINETTO ELEVATORE LATERALE (3M) A.L.T. / SIDE LIFT JACK(TRIPLEX) F.F.L. / N.D. / N.D. / N.D.............................................................................................................................................................................................. Page 240

CARRELLINO PIASTRA FISSA (3M) A.L.T. / FORK CARRIAGE (TRIPLEX) F.F.L. / N.D. / N.D. / N.D........................................................................................................................................................................................................ Page 242

CARRELLINO TRASLATORE LATERALE (3M) A.L.T. / SIDESHIFTING CARRIAGE (TRIPLEX) F.F.L. / N.D. / N.D. / N.D......................................................................................................................................................................... Page 244

IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (3M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (TRIPLEX) F.F.L. / N.D. / N.D. / N.D..................................................................................................... Page 246

FORCHE (3M) A.L.T. / FORKS (TRIPLEX) F.F.L. / N.D. / N.D. / N.D............................................................................................................................................................................................................................................................. Page 250

Page 8
This Page Intentionally Blank
CBE12F_ETICHETTE_E_CATALOGHI_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 1999015R1CE 1 nr KIT ETICHETTE VARIE BT LABELS KIT JEU ETIQUETTES AUFKLEBER-SATZ JUEGO ETIQUETAS
2 0300389R1CE 2 nr ETICHETTA LOGO BT d.120 B LABEL ETIQUETTE AUFKLEBER ETIQUETA
3 0300390R1CE 2 nr ETICHET."CARGO 1.2 " B LABEL ETIQUETTE AUFKLEBER ETIQUETA
4 0300409R1CE 2 nr ETICHETTA LOGO BT d.75 BI LABEL ETIQUETTE AUFKLEBER ETIQUETA

ETICHETTE E CATALOGHI / LABELS AND CATALOGUES Page 10

ETICHETTE E CATALOGHI / LABELS AND CATALOGUES Page 11
CBE12F_TELAIO_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 4774093R1CE 1 nr PROTEZIONE CONDUCENTE ALL DRIVER'S OVERHEAD GUARD TOIT DE PROTECTION FAHRERSCHUTZDACH PROTECCION DEL CONDUCTOR
versione scandinavia scandinavian version
1 4774070R1CE 1 nr [Link] CBE 1.2 DRIVER'S OVERHEAD GUARD TOIT DE PROTECTION FAHRERSCHUTZDACH PROTECCION DEL CONDUCTOR
2 1773095R1CE 1 nr SPORTELLINO [Link] DOOR PORTE KLAPPE PORTILLO
3 0023060CE 1 nr MANOPOLA B.259/25p-M8x20 HAND GRIP HAND GRIP POIGNEE DREHKNOPF
4 1888048CE 4 nr SUPPORTO TUBI IDROGUIDA D SUPPORT SUPPORT HALTERUNG SOPORTE
5 1773247R1CE 1 nr CARTER DISTRIBUTORE D.950 COVER CARTER GEH¬USE CARTER
6 3774144R1CE 1 nr ASSIEME COFANO D.010300 ( BONNET CAPOT HAUBE CAPOT
Da n. 213570 Da n. 213570 Da n. 213570 Da n. 213570 Da n. 213570
6 3774002R1CE 1 nr ASSIEME COFANO BATTERIA C BATTERY COVER UNIT GROUPE COUVERCLE BATTERIE BATTERIEHAUBEGRUPPE GRUPO COFRE BATERIA
7 1773189CE 1 nr CORNICE ASOLA COFANO D.95 PROFILE PROFIL PROFIL PERFIL
7 1773535CE 1 nr CORNICE ASOLA COFANO PROFILE PROFIL PROFIL PERFIL
Da n. 213570 Da n. 213570 Da n. 213570 Da n. 213570 Da n. 213570
8 0070827CE 1 nr MANIGLIA POCHET PULL rif. HANDLE POIGNEE HANDGRIFF MANILLA
Da n. 213570 Da n. 213570 Da n. 213570 Da n. 213570 Da n. 213570
9 2864011CE 1 nr GANCIO COFANO D.93551 HOOK CROCHET HAKEN GANCHO
9 2772105CE 1 nr AGGANCIO COFANO COVER HOOK ACCROCHAGE CAPOT HAUBE ANHAKEN ENGANCHE CAPOT
Da n. 213570 Da n. 213570 Da n. 213570 Da n. 213570 Da n. 213570
10 1863081CE 1 nr MOLLA D.93551/2 SPRING RESSORT FEDER RESORTE
11 1773536CE 1 nr CORNICE SCASSO COFANO SPI PROFILE PROFIL PROFIL PERFIL
Da n. 213570 Da n. 213570 Da n. 213570 Da n. 213570 Da n. 213570
12 1863078CE 1 nr CERNIERA DESTRA D.93821 HINGE CHARNIERE GELENK BISAGRA
13 1863079CE 1 nr CERNIERA SINISTRA D.93822 HINGE CHARNIERE GELENK BISAGRA
14 1777099CE 1 nr CABLAGGIO UOMO PRESENTE P WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
15 2894020CE 1 nr SERRATURA "SOUTHCO" MODIF LOCK SERRURE SCHLOSS CERRADURA
16 2772057CE 1 nr RISCONTRO SCONTRINO COFAN HOOK ACCROCHAGE KUPPLUNG ENGANCHE
17 0070715CE 2 nr MOLLA GAS RIFERIMENTO 261 GAS SPRING RESSORT A GAZ GASFEDER RESORTE A GAS
18 1773325CE 1 nr FERMO BATTERIA D.960839 RETAINER ARRET SPERRE RETEN
19 1773026CE 2 nr PARAFANGO ANTERIORE D.940 RIGHT FENDER GARDE-BOUE DROITE RECHTER KOTFLSGEL GUARDABARRO DERECHO
19 1773566CE 1 nr PARAFANGO DESTRO (BLITZ 3 RIGHT FENDER GARDE-BOUE DROITE RECHTS KOTFLUGEL GUARDABARRO DERECHO
Da n. 213570 Da n. 213570 Da n. 213570 Da n. 213570 Da n. 213570
19 1773567CE 1 nr PARAFANGO SINISTRO (BLITZ LEFT FENDER GARDE-BOUE GAUCHE LINKER KOTFLSGEL GUARDABARRO IZQUIERDO
Da n. 213570 Da n. 213570 Da n. 213570 Da n. 213570 Da n. 213570

TELAIO / FREAME Page 12

TELAIO / FREAME Page 13
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
20 1773077CE 2 nr COPERCHIO D.940543 COVER COUVERCLE DECKEL TAPA
21 1773195CE 2 nr AGGANCIO COFANO POSTERIOR COVER HOOK ACCROCHAGE CAPOT HAUBE ANHAKEN ENGANCHE CAPOT
22 1773018CE 4 nr STAFFA SUPPORTO FANALI D. BRACKET ETRIER BSGEL ESTRIBO
24 1773169CE 1 nr SPESSORE CONTRAPPESO D.94 SHIM EPAISSEUR DICKE ESPESOR
Var. Var.
25 0120011CE 4 nr [Link] D.20 UNI6592 Z WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
26 0100085CE 4 nr VITE TE M20X60 UNI5739 ZI SCREW VIS SCHRAUBE TORNILLO
27 1774004R1CE 1 nr COPERCHIO COMANDO D.95018 COVER COUVERCLE DECKEL TAPA
28 1773211CE 1 nr PERNO TRAINO D.950711 PIN PIVOT STIFT PERNO
29 2772061R1CE 1 nr CONTRAPPESO MOD.3939 D.96 COUNTERWEIGHT CONTREPOIDS GEGENGEWICHT CONTRAPESO
30 2773003CE 2 nr FANALE [Link] BLITZ(L STOP LIGHT FEU DE STOP BREMSLEUCHTE LUZ FRENO
31 0057670CE 2 nr LAMPADINA 24V-21W [Link] BULB LAMPE GLÜHBIRNE BOMBILLA
32 0993196CE 2 nr TRASPARENTE PER FANALE ST LIGHT GLASS VITRE DU FEU LICHTGLASS CRISTAL PARA LUZ
33 2773004CE 2 nr FANALE [Link] B BACKING LAMP FEU DE MARCHE ARRIEURE R?CKFAHRLEUCHTE FAROL DE MARCHA ATRAS
34 0057977CE 2 nr LAMPADINA 24V-10W [Link] BULB LAMPE GLÜHBIRNE BOMBILLA
35 0993197CE 2 nr TRASPARENTE PER FANALE RE LIGHT GLASS VITRE DU FEU LICHTGLASS CRISTAL PARA LUZ
36 1777128R1CE 2 nr FANALE POSTERIORE 4 LUCI REARLIGHT FEU ARRIERE RSCKLEUCHTE FAROL TRASERO
37 0057977CE 1 nr LAMPADINA 24V-10W [Link] BULB LAMPE GLÜHBIRNE BOMBILLA
38 0018332CE 1 nr LAMPADA 24V-5/21W [Link] LAMP AMPOULE LAMPE LAMPARA
39 0993197CE 1 nr TRASPARENTE PER FANALE RE LIGHT GLASS VITRE DU FEU LICHTGLASS CRISTAL PARA LUZ
40 2772074R1CE 1 nr CARENATURA FANALI CBE 1.2 COVER CARTER GEHÄUSE CARTER

TELAIO / FREAME Page 14

TELAIO / FREAME Page 15
CBE12F_SEDILE_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 0070817R1CE 1 nr SEDILE MSG30 C/MICRO+CINT SEAT AND SAFETY BELT WITH SIEGE ET CEINTURES DES SE SITZ + SICHERHEITSGURT ASIENTO Y CINTURONES DE S
1 0070821CE 1 nr SEDILE MSG30 STOFFA C/MIC SEAT SIEGE SITZ ASIENTO
versione scandinavia scandinavian version
2 S990115CE 1 nr CUSCINO SEDUTA SEAT CUSHION COUSSIN DE SIEGE ZIEHKISSEN (SITZ) ALMOHADILLA (ASIENTO)
versione scandinavia scandinavian version
2 0993339R1CE 1 nr CUSCINO SEDILE RIF.101924 SEAT CUSHION COUSSIN DE SIEGE ZIEHKISSEN (SITZ) ALMOHADILLA (ASIENTO)
3 S990116CE 1 nr CUSCINO SCHIENALE SEAT CUSHION COUSSIN DE SIEGE ZIEHKISSEN (SITZ) ALMOHADILLA (ASIENTO)
versione scandinavia scandinavian version
3 0993340R1CE 1 nr CUSCINO SCHIENALE RIF.101 SEAT CUSHION COUSSIN DE SIEGE ZIEHKISSEN (SITZ) ALMOHADILLA (ASIENTO)
4 0070802CE 1 nr CINTURA C/ARROT. x MSG30 SAFETY BELT CEINTURE DE SECURITE SICHERHEITSGURT CINTURON DE SEGURIDAD
5 0993508CE 1 nr MICROINTERUTTORE RIF.1018 MICROSWITCH MICRO-INTERRUPTEUR MIKROSCHALTER MICROINTERRUPTOR
6 0070807CE 1 nr COPPIA BRACCIOLI X SEDILE SET OF ARM RESTS COUPLE DE ACCOUDOIRS ARMLEHNENPAAR PAR BRAZOS

SEDILE / SEAT Page 16

SEDILE / SEAT Page 17
CBE12F_CRUSCOTTO_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 0057871CE 1 nr PANNELLO A 6 VIE "COBO" R PANEL PANNEAU PLATTE PANEL
2 0057870CE 6 nr TAPPO "COBO" rif.30.33.04 PLUG BOUCHON VERSCHLUSS TAPON
3 0054777R1CE 1 nr CRUSCOTTO TIPO "ALFA" VER INSTRUMENTAL PANEL PANNEAU DES INSTRUMENTS ARMATURENBRETT SALPICADERO
4 1773139CE 1 nr STAFFA SUPPORTO CRUSCOTTO BRACKET ETRIER BSGEL ESTRIBO
5 2772033R1CE 1 nr PLANCIA IN SMC D.950634 ( DASHBOARD TABLEAU DE BORD ARMATURENBTRETT TABLERO DE INSTRUMENTOS
5 2772118R1CE 1 nr PLANCIA IN SMC (CBE 1.2-2 DASHBOARD TABLEAU DE BORD ARMATURENBTRETT TABLERO DE INSTRUMENTOS
versione scandinavia scandinavian version
6 1777207CE 1 nr CABLAGGIO AUSILIARIO (CBE WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
versione scandinavia scandinavian version
6 1777112CE 1 nr CABLAGGIO AUSILIARIO (CRU WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
7 1777040CE 1 nr CHIAVE AVVIAMENTO C/COPER START KEY CLE DE CONTACT ZSNDSCHLSSSEL LLAVE PARA ENCENDIDO
8 0100114CE 1 nr VITE TE M6X20 UNI5739 ZIN SCREW VIS SCHRAUBE TORNILLO
9 1773276CE 1 nr STAFFA IRRIGIDIMENTO PLAN BRACKET ETRIER B?GEL ESTRIBO
10 0070389CE 7 nr PIASTR 4.2RNUO920A (EX NU PLATE PLAQUE PLATTE PLANCHA
11 0105124CE 6 nr VITE ATBC 4,2x16 Pz-AB 69 SCREW VIS SCHRAUBE TORNILLO
12 1776019CE 1 nr CARENATURA PIANTONE D.931 STEERING COLUMN COVER CARTER COLONNE DE DIRECTI LENKS¬ULEGEH¬USE CARTER COLUMNA DE DIRECCI
13 0105126CE 1 nr VITE ATBC 4,2x9,5Pz-AB 69 SCREW VIS SCHRAUBE TORNILLO
14 1773519CE 1 nr TAPPETINO D.001440 (BLITZ FLOOR MAT TAPIS FUSSMATTE ALFOMBRA
15 0108007CE 3 nr VITE TBEI M6X16 C/FLANG,1 SCREW VIS SCHRAUBE TORNILLO
16 0120132CE 7 nr [Link] MAGG.D6,6x2 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
17 1773288CE 1 nr PEDANA D.960074 FOOTBOARD PLATEFORME TRITTBRETT TARIMA
18 1776018CE 1 nr CARENATURA [Link] COVER CARTER GEH¬USE CARTER
19 0102050CE 4 nr VITE TSPEI M6X18 UNI 5933 SCREW VIS SCHRAUBE TORNILLO
20 0108002CE 4 nr VITE TBEI M6X12 C/FLANG.1 SCREW VIS SCHRAUBE TORNILLO
21 0054815CE 1 nr CONTAORE CURTIS 701 TNOO1 HOUR METER HORAMETRE BETRIEBSSTUNDENZÄHLER CUENTAHORAS
versione scandinavia scandinavian version
22 1777160CE 1 nr CABLAGGIO IMPIANTO CONTAO WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
versione scandinavia scandinavian version
23 1917086CE 1 nr PULSANTE DI EMERGENZA CAB PUSH BUTTON BOUTON DRUCKKNOPF PULSADOR
versione scandinavia scandinavian version

CRUSCOTTO / DASHBOARD Page 18

CRUSCOTTO / DASHBOARD Page 19
CBE12F_PIANTONE_STERZO_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 2772073R1CE 1 nr VOLANTE CON POMELLO D.990 STEERING WHEEL VOLANT LENKRAD VOLANTE DE DIRECCION
2 0023241CE 1 nr POMELLO VOLANTE COMPLETO KNOB BOUTON KNOPF PERILLA
3 0134032CE 1 nr ANEL EL A42 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
4 1773388R1CE 1 nr TAPPO DI CHIUSURA MOZZO P PLUG BOUCHON VERSCHLUSS TAPON
5 2776009CE 1 nr PIANTONE STERZO D.931060 STEERING COLUMN COLONNE DE DIRECTION LENKS?ULE COLUMNA DE DIRECCION
6 1776038CE 1 nr DISTANZIALE MORSETTO D.94 SPACER ECARTEUR ABSTANDSTSCK DISTANCIADOR
7 0023232CE 1 nr MANIGLIA A RIPRESA MR.80A HANDLE POIGNEE HANDGRIFF MANILLA
8 0094841CE 1 nr IDROGUIDA DINAMICA OSPF 8 HYDRAULIC STEERING DIRECTION ASSISTEE HYDROLENKUNG SERVODIRECCION
Da n. 192483 Da n. 192483 Da n. 192483 Da n. 192483 Da n. 192483
8 0094830CE 1 nr IDROGUIDA EATON 263-4383- HYDRAULIC STEERING DIRECTION ASSISTEE HYDROLENKUNG SERVODIRECCION
9 1776088CE 1 nr PERNO MORSETTO PER CABINA PIN PIVOT STIFT PERNO
10 1776023CE 2 nr PERNO FULCRO D.940019 PIN PIVOT STIFT PERNO
11 0100121CE 4 nr VITE TE M8X20 UNI5739 ZIN SCREW VIS SCHRAUBE TORNILLO
12 0120211CE 4 nr [Link].D8-5/16" DIN12 SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
13 1777198CE 1 nr CABLAGGIO PIANTONE STERZO WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
versione scandinavia scandinavian version
13 1777100CE 1 nr CABLAGGIO PIANTONE STERZO WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO

PIANTONE STERZO / STEERING COLUMN Page 20

PIANTONE STERZO / STEERING COLUMN Page 21
CBE12F_AZIONATORE_CLACSON_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 2773026CE 1 nr AZIONATORE CLAXON D.00115 SIGNAL HORN AVERTISSEUR ACOUSTIQUE SIGNALHORN AVISADOR CLAXON
versione scandinavia scandinavian version
1 2773009CE 1 nr AZIONATORE CLAXON D.95065 SIGNAL HORN AVERTISSEUR ACOUSTIQUE SIGNALHORN AVISADOR CLAXON
2 1773392CE 1 nr MOLLA SPRING RESSORT FEDER RESORTE
3 1777171CE 1 nr MICRO CABLATO MICROSWITCH MICRO-INTERRUPTEUR MIKROSCHALTER MICROINTERRUPTOR
versione scandinavia scandinavian version
3 0053056CE 1 nr MICROINTERRUTTORE XG2 S20 MICROSWITCH MICRO-INTERRUPTEUR MIKROSCHALTER MICROINTERRUPTOR
4 1607353CE 1 nr PROTEZIONE SU PULSANTE CL GUARD PROTECTION SCHUTZ PROTECCION
5 0058061CE 1 nr AVVISATORE A DISCO 48V 90 WARNING HORN KLAXON HORN CLAXON
6 1607352CE 1 nr DIODO CABLATO 1N4007 D.89 DIODE DIODE DIODE DIODE

AZIONATORE CLACSON / HORN CONTROL Page 22

AZIONATORE CLACSON / HORN CONTROL Page 23
CBE12F_ASSALE_A_BILICO_1

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4776004CE 1 nr ASSALE BILICO D.960032 (B STEERING AXLE ESSIEU DIRECTEUR LENKACHSE EJE DIRECTOR
1 3776014CE 1 nr CILINDRO IDROGUIDA D.9407 STEERING CYLINDER CYLINDRE DE DIRECTION LENKZYLINDER CILINDRO DE DIRECCION
2 2998150CE 1 nr KIT GUARNIZIONI MART. SER GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
3 2996041CE 2 nr KIT BIELLETTE BLITZ E DRA CONNECTING ROD JEU SATZ JUEGO
9 0120210CE 4 nr RONDELLA 12 UNI 1751 WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
10 0100057CE 4 nr VITE TE M12X35 UNI5739 ZI SCREW VIS SCHRAUBE TORNILLO
11 0100108CE 9 nr VITE TE M5X16 UNI5739 ZIN SCREW VIS SCHRAUBE TORNILLO
12 0120209CE 12 nr RONDELLA EL.5 DIN137-B ZI SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
13 1766209CE 3 nr COPERCHIO D.93126 COVER COUVERCLE DECKEL TAPA
14 1766210CE 4 nr GUARNIZIONE PER COPERCHIO GASKET GARNITURE DICHTUNG VAINA
15 0013898CE 4 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
18 0135050CE 2 nr SPINA CIL. 10X20 UNI1707 PLUG GOUPILLE STECKER CLAVIJA
19 0016276CE 4 nr ASTUCCIO DL 30 25 SHEATH GAINE GEHÄUSE VAINA
20 0016654CE 4 nr ANELLO TENUTA ET 30-38 GAS RING BAGUE D'ETANCHEITE DICHTUNGSRING ANILLO DE JUNTA ESTANCA
21 1021494CE 2 nr PARAPOLVERE D.56642/1 DUST GUARD PROTECTION SCHUTZ PROTECCION
22 0014317CE 2 nr CUSCINETTO ASSIALE 30x52x BALL BEARING ROULEMENTS A BILLES KUGELLAGER COJINETE
23 1776059CE 1 nr PERNO PER FUSO DX D.94072 PIN PIVOT STIFT PERNO
23 1766211CE 1 nr PERNO PER FUSO D.93128 PIN PIVOT STIFT PERNO
25 0133131CE 2 nr VITE S.T.E.I. M10X20 UNI SCREW VIS SCHRAUBE TORNILLO
26 1776106CE 1 nr FUSO SINISTRO D.981364 LEFT AXLE SPINDLE FUSEE GAUCHE LINKE ACHSENSPINDEL HUSO IZQUIERDO
27 1776107CE 1 nr FUSO DESTRO D.981365 RIGHT AXLE SPINDLE FUSEE DROITE RECHTE ACHSENSPINDEL HUSO DERECHO
28 0120036CE 10 nr RONDELLA EL. D14 UNI1751 SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
29 0100541CE 10 nr VITE TE M14X1,5X35 5740 1 SCREW VIS SCHRAUBE TORNILLO
30 0064136CE 2 nr GUARNIZIONE DPSM 70858 GASKET GARNITURE DICHTUNG VAINA
31 0080019CE 2 nr CUSCINETTO 32009 45x75x2 BALL BEARING ROULEMENTS A BILLES KUGELLAGER COJINETE
32 1776089CE 2 nr MOZZO ASSALE STERZANTE BL HUB MOYEU NABE CUBO
33 0014171CE 2 nr CUSCINETTO 32206 30x62x2 BALL BEARING ROULEMENTS A BILLES KUGELLAGER COJINETE
34 1606155CE 2 nr RONDELLA SPESSORE D.56641 WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
35 0131015CE 2 nr COPIGLIA 5X50 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
36 0110166CE 2 nr DADO ES. INTAGLIO M24X2 U NUT ECROU MUTTER TUERCA
37 1024731CE 2 nr COPERCHIETTO D.70434 COVER COUVERCLE DECKEL TAPA
38 0070506CE 2 nr BOCCOLA ELAST."SUTUCO" RI BUSHING BAGUE BUCHSE BUCHSE
39 1773549CE 2 nr SUPPORTO BILICO STAMPATO AXLE BEARING SUPPORT A ESSIEU ACHSENLAGER SOPORTE EJE
40 1866050CE 2 nr RONDELLA D.55 SP.6 D.9507 WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
41 0120157CE 2 nr [Link].D10 DIN 6 SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
42 0100376CE 2 nr VITE TE M10X25 UNI5739 ZI SCREW VIS SCHRAUBE TORNILLO
43 0120036CE 4 nr RONDELLA EL. D14 UNI1751 SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA

ASSALE A BILICO / REAR AXLE Page 24

ASSALE A BILICO / REAR AXLE Page 25
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
44 0100533CE 4 nr VITE TE M14x110 UNI5737 Z SCREW VIS SCHRAUBE TORNILLO
45 0070506CE 2 nr BOCCOLA ELAST."SUTUCO" RI BUSHING BAGUE BUCHSE BUCHSE
46 1866010CE 2 nr SUPPORTO PER ANTIVIBRANTE SUPPORT SUPPORT HALTERUNG SOPORTE
47 1866050CE 2 nr RONDELLA D.55 SP.6 D.9507 WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
48 0120157CE 2 nr [Link].D10 DIN 6 SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
49 0100376CE 2 nr VITE TE M10X25 UNI5739 ZI SCREW VIS SCHRAUBE TORNILLO
50 0120036CE 4 nr RONDELLA EL. D14 UNI1751 SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
51 0100466CE 4 nr VITE TE M14X140 UNI5737 Z SCREW VIS SCHRAUBE TORNILLO
52 1777065CE 1 nr CABLAGGIO [Link] WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
53 1776086CE 1 nr COPERCHIO POTENZIOMETRO D COVER COUVERCLE DECKEL TAPA
54 0018238CE 1 nr PASSACAVO EUROM FAIRLEAD GALOCHE KABELDURCHGANG AISLADOR PASAPANEL
55 0054723CE 1 nr POTENZIOMETRO rif.CP10/00 POTENTIOMETER POTENTIOMETRE POTENTIOMETER POTENCIOMETRO
56 1776085CE 1 nr SUPPORTO POTENZIOMETRO D. SUPPORT SUPPORT HALTERUNG SOPORTE
57 1776087CE 1 nr ALBERINO POTENZIOMETRO D. SHAFT ARBRE WELLE EJE
58 0110040CE 1 nr DADO ES. M6 UNI5588 ZINC. NUT ECROU MUTTER TUERCA
59 0101190CE 3 nr VITE TCEI M5X18 UNI5931 8 SCREW VIS SCHRAUBE TORNILLO
60 1773405CE 1 nr FLANGIA INTERMEDIA D.0001 FLANGE BRIDE FLANSCH BRIDA
Da n. 190848 Da n. 190848 Da n. 190848 Da n. 190848 Da n. 190848
61 0135262CE 1 nr SPINA UNI-ISO 8734 4X16 8 PLUG GOUPILLE STECKER CLAVIJA
Da n. 190848 Da n. 190848 Da n. 190848 Da n. 190848 Da n. 190848
62 0101202CE 3 nr VITE TCEI M5X16 UNI5931 1 SCREW VIS SCHRAUBE TORNILLO
Da n. 190848 Da n. 190848 Da n. 190848 Da n. 190848 Da n. 190848

ASSALE A BILICO / REAR AXLE Page 26

ASSALE A BILICO / REAR AXLE Page 27
CBE12F_RUOTE_DIRETTRICI_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 2776003CE 1 nr RUOTA DIRETTRICE CUSH (BL
2 0091037CE 1 nr CUSHION 381X127X285,8 CUSHION CUSHION CUSHION CUSHION
3 1776010CE 1 nr CERCHIO CUSHION D.286X127 RIM JANTE FELGE LLANTA
4 2776042CE 1 nr RUOTA [Link] D.96036 STEERING WHEEL ROUE DIRECTRICE LENKRAD RUEDA DIRECTRIZ
5 0090548CE 1 nr SUPERELASTICO 16X6-8 C SUPERELASTIC PNEUS PLEIN SOUPLES SUPERALASTIK SUPERELASTICAS
6 1776098CE 1 nr CERCHIO 4.33R-8 D.960361 RIM JANTE FELGE LLANTA

RUOTE DIRETTRICI / STEER WHEELS Page 28

RUOTE DIRETTRICI / STEER WHEELS Page 29
CBE12F_SCHEMA_IMP_GUIDA_IDRAULICA_4W_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 0060323CE 1 nr RACCORDO A GOMITO A107039 CONNECTION RACCORD ANSCHLUSS UNION
2 1775071CE 1 nr TUBO SCARICO DA IDROGUIDA EXHAUST PIPE TUYAU D' ECHAPPEMENT ABLASSROHR TUBO DE ESCAPE
3 1775025CE 1 nr TUBO DA PRIORIT.A IDROG.L PIPE TUYAU SCHLAUCH TUBO
4 1773270CE 1 nr TUBO DA PRIORITARIA A IDR PIPE TUYAU SCHLAUCH TUBO
5 0060314CE 6 nr RACCORDO ORIENT.90GR 9/16 CONNECTION RACCORD ANSCHLUSS UNION
6 0064437CE 1 nr VALVOLA EATON 606-1419-00 VALVE SOUPAPE VENTIL VALVULA
6 0064544CE 1 nr VALVOLA PRIORITARIA DINAM VALVE SOUPAPE VENTIL VALVULA
Da n. 192483 Da n. 192483 Da n. 192483 Da n. 192483 Da n. 192483
7 0060314CE 1 nr RACCORDO ORIENT.90GR 9/16 CONNECTION RACCORD ANSCHLUSS UNION
8 0061879CE 1 nr TUBO FLEX SAE100R1 T DA 1 FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
9 0060382CE 2 nr RACCORDO DIR.A102001/10 J CONNECTION RACCORD ANSCHLUSS UNION
10 1773272CE 1 nr TUBO DA IDROGUIDA A FINCA PIPE TUYAU SCHLAUCH TUBO
11 0061875CE 1 nr TUBO FLEX SAE100R1 T DA 1 FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
12 1773273CE 1 nr TUBO DA IDROGUIDA D.96000 PIPE TUYAU SCHLAUCH TUBO
13 0060278CE 4 nr RIDUZIONE MASCHIO 1/2"G-F REDUCTION REDUCTION VERMINDERUNG REDUCCION
14 0060316CE 2 nr RACCORDO DIR.9/16JIC-1/4G CONNECTION RACCORD ANSCHLUSS UNION

SCHEMA IMPIANTO GUIDA IDRAULICA (4w) / DIAGRAM OF STEERING ASSISTANCE SYSTEM (4w) Page 30
SCHEMA IMPIANTO GUIDA IDRAULICA (4w) / DIAGRAM OF STEERING ASSISTANCE SYSTEM (4w) Page 31
CBE12F_SCHEMA_IDRAULICO_DI_SOLLEVAMENTO_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 0060320CE 3 nr NIPPLO M-M A102023-1017 ( NIPPLE NIPPLE NIPPEL NIPLE
2 0061885CE 1 nr TUBO SAE100R7 D.8 L=890 R FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
3 0061886CE 1 nr TUBO SAE100R7 D.8 L=920 R FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
4 0060321CE 1 nr NIPPLO M-M A102023-1617 ( NIPPLE NIPPLE NIPPEL NIPLE
5 2778019CE 1 nr RACCORDO C/VALVOLA PARACA CONNECTION RACCORD ANSCHLUSS UNION
6 0061873CE 1 nr TUBO FLEX SAE100R2 AT DA FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
7 0120239CE 1 nr RONDELLA RAME 3/8"G.(d.23 COPPER WASHER RONDELLE DE CUIVRE KUPFERSCHEIBE ARANDELA COBRE
8 0060189CE 1 nr PORTAGOMMA GPGM 3/8 DM.16 CONNECTION RACCORD ANSCHLUSS UNION
9 0014717CE 2 nr FASCETTA C1 (20-30/12) CLAMP COLLIER DE SERRAGE SCHELLE ABRAZADERA
10 0061193CE 0 mt TUBO FL TX300 dn16 FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
11 0060339CE 1 nr RACCORDO OR.90GR.A107039/ CONNECTION RACCORD ANSCHLUSS UNION
12 0061872CE 1 nr TUBO FLEX SAE100R2 AT DA FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
13 0060338CE 3 nr NIPPLO A102023/1621 JIC 7 NIPPLE NIPPLE NIPPEL NIPLE
14 0060247CE 1 nr PORTAGOMMA GPGM 1/2 DM.16 CONNECTION RACCORD ANSCHLUSS UNION
16 1773269CE 1 nr PROLUNGA SU PRIORITARIA EXTENSION ARM RALLONGE VERL¬NGERUNG ELEMENTO DE PROLONGACION
17 0063096CE 1 nr VALVOLA UNIDIREZIONALE DA VALVE SOUPAPE VENTIL VALVULA
18 0120198CE 2 nr RONDELLA GOMMATA 1/2" GAS WASHER RONDELLE DE CAOUTCHOUC GUMMISCHEIBE ARANDELA DE GOMA
19 0060415CE 1 nr RIDUZIONE RM 3/4-1/2 MAT REDUCTION REDUCTION VERMINDERUNG REDUCCION
20 0120199CE 1 nr RONDELLA GOMMATA 3/4" GAS WASHER RONDELLE DE CAOUTCHOUC GUMMISCHEIBE ARANDELA DE GOMA
21 0018436CE 1 nr GUARNIZIONE OR 3093 GASKET GARNITURE DICHTUNG VAINA
22 1775072CE 1 nr FLANGIA SU POMPA ASPIRAZI FLANGE BRIDE FLANSCH BRIDA
23 0061866CE 1 nr TUBO FLEX SAE100R4 1"-1/4 FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
24 1775055CE 1 nr TUBI ALIMENTAZIONE MART.B PIPE TUYAU SCHLAUCH TUBO
25 0061869CE 1 nr TUBO FLEX SAE100R2 AT DA FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
26 0060293CE 1 nr MINIPRESA DI PRESSIONE 1/ SOCKET DOUILLE STECKDOSE TOMA
27 1773267CE 1 nr FLANGIA JIC7/8-14 CON PRE FLANGE BRIDE FLANSCH BRIDA
28 0018522CE 1 nr GUARNIZIONE OR 3075 GASKET GARNITURE DICHTUNG VAINA
29 0120233CE 1 nr RONDELLA RAME D.1/8x16x1, COPPER WASHER RONDELLE DE CUIVRE KUPFERSCHEIBE ARANDELA COBRE

SCHEMA IDRAULICO DI SOLLEVAMENTO / HOISTING HYDRAULIC SYSTEM Page 32

SCHEMA IDRAULICO DI SOLLEVAMENTO / HOISTING HYDRAULIC SYSTEM Page 33
CBE12F_SERBATOIO_E_FILTRO_OLIO_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 2778013CE 1 nr SERBATOIO OLIO D.950802 OIL TANK RESERVOIR D'HUILE ÍLTANK TANQUE DEL ACEITE
2 0023258CE 2 mt TUBO POLIETILENE 8X6 NERO FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
3 0020648CE 1 nr FASCETTA A1 CLAMP COLLIER DE SERRAGE SCHELLE ABRAZADERA
4 0064526CE 1 nr FILTRO OLIO ARGO E 072-52 OIL FILTER FILTRE DE LÆHUILE ÍLFILTER FILTRO DE ACEITE
5 0992971CE 1 nr TAPPO FILTRO RIF.E0721200 COVER COUVERCLE DECKEL TAPA
6 0992972CE 1 nr MOLLA FILTRO RIF.N0151606 SPRING RESSORT FEDER RESORTE
7 0992973CE 1 nr ANELLO TENUTA RIF.N031056 WASHER BAGUE D'ETANCHEITE DICHTUNGSRING ANILLO DE JUNTA ESTANCA
8 0992256CE 1 nr ASTA LIVELLO RIF.C4 0421- OIL DIPSTICK JAUGE A HUILE ÍLMESSSTAB VARILLA MEDID. NIVEL ACEI
9 0992253CE 1 nr [Link] RIF.P3.052 OIL FILTER CARTRIDGE CART. FILTRE A HUILE ÍLFILTEREINSATZ CARTUCHO FILTRO DEL ACEIT
10 0992974CE 1 nr O.R. 47x2 RIF.N0070472 O-RING JOINT TORIQUE O-RING EMPAQUETADURA DE ANILLO
11 0992975CE 1 nr FILTRO SFIATO ARIA RIF.L1 AIR FILTER WITH BREATHER FILTRE A AIR AVEC EVENT LUFTFILTER MIT ENTLUEFTER FILTRE AIRE CON RESPIRADE
12 0992976CE 1 nr CLIP RIF.N0260253 CLIP CLIP CLIP CLIP
13 0992977CE 1 nr GUARNIZIONE RIF.D0230708 GASKET GARNITURE DICHTUNG VAINA

SERBATOIO E FILTRO OLIO / OIL TANK AND FILTER Page 34

SERBATOIO E FILTRO OLIO / OIL TANK AND FILTER Page 35
CBE12F_MOTORE_E_POMPA_DI_SOLLEVAMENTO_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 0058026CE 1 nr MOTORE SOLLEVAMENTO TSL21 LIFTING MOTOR MOTEUR DÆELEVATION HUBMOTOR MOTOR ELEVACION
1 0993182CE 1 nr ANELLO DI TENUTA RIF.5001 GAS RING BAGUE D'ETANCHEITE DICHTUNGSRING ANILLO DE JUNTA ESTANCA
2 0992091CE 1 nr CUSCINETTO 6206 2ZC3 HL BALL BEARING ROULEMENTS A BILLES KUGELLAGER COJINETE
3 0993594CE 1 nr SPAZZOLA 10X32X32 C/USURA BRUSH BALAI BÜRSTE ESCOBILLA
Dal n° di matricola SHABMULLER From the s/n SHABMULLER 133616
3 0993184CE 1 nr SPAZZOLA C/SENSORE USURA BRUSH WITH SENSOR BALAIS AVEC SENSEUR BSRSTE MIT SENSOR ESCOBILLA CON CAPTADOR
Fino al n° di matricola SHABMU Up to the s/n SHABMULLER 13337
4 0993595CE 3 nr SPAZZOLA NORMALE 10X32X32 BRUSH BALAI BÜRSTE ESCOBILLA
Dal n° di matricola SHABMULLER From the s/n SHABMULLER 133616
4 0993183CE 3 nr SPAZZOLA 10X32X40 RIF. 50 BRUSH BALAI BSRSTE ESCOBILLA
Fino al n° di matricola SHABMU Up to the s/n SHABMULLER 13337
5 0993593CE 1 nr COLLARE PORTASPAZZ. D210 COLLAR COLLIER ANSCHLAGBUND COLLAR
Dal n° di matricola SHABMULLER From the s/n SHABMULLER 133616
5 0992239CE 1 nr ANELLO PORTASPAZZOLE RIF. RING ANNEAU RING ANILLO
Fino al n° di matricola SHABMU Up to the s/n SHABMULLER 13337
6 0993734CE 4 nr MOLLA [Link].5001 SPRING RESSORT FEDER RESORTE
Dal n° di matricola SHABMULLER From the s/n SHABMULLER 133616
6 0992240CE 4 nr MOLLA PORTASPAZZOLA RIF. SPRING RESSORT FEDER RESORTE
Fino al n° di matricola SHABMU Up to the s/n SHABMULLER 13337
7 0992235CE 2 nr MORSETTO TERMINALE RIF.50 TERMINAL BORNE KLEMME TERMINAL
Fino al n° di matricola SHABMU Up to the s/n SHABMULLER 13337
7 0993733CE 2 nr MORSETTO TERMINALE RIF500 TERMINAL BORNE KLEMME TERMINAL
Dal n° di matricola SHABMULLER From the s/n SHABMULLER 133616
8 0992756CE 1 nr SENSORE TEMPERATURA RIF. TEMPERATURE SENSOR CAPTEUR-TEMPERATURE TEMPERATURGEBER CAPTADOR TEMPERATURA
9 0992757CE 1 nr MOLLA A TAZZA RIF. 500095 SPRING RESSORT FEDER RESORTE
10 0993186CE 1 nr VENTOLA RIF.50013736 FAN VENTILATEUR LSFTER VENTILADOR
11 0992092CE 1 nr CUSCINETTO SKF 6205 ZZ C3 BALL BEARING ROULEMENTS A BILLES KUGELLAGER COJINETE
12 0993185CE 1 nr INDOTTO RIF.50006803 ROTOR ROTOR ROTOR ROTOR
13 0993181CE 1 nr BOBINA 210-6.306/308 RIF. COIL BOBINE SPULE BOBINA
14 0070638CE 1 nr GIUNTO NON PASSANTE "SALA JOINT JOINT KUPPLUNG JUNTA
15 0064383CE 1 nr GUARNIZIONE OR 133 GASKET GARNITURE DICHTUNG VAINA
16 0094085CE 1 nr POMPA 2PZ-16S-BO3B2 16L R PUMP POMPE PUMPE BOMBA
17 0100409CE 4 nr VITE TE M10X120 UNI5737 Z SCREW VIS SCHRAUBE TORNILLO
18 0120121CE 4 nr [Link]. D10 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
19 0120006CE 4 nr [Link] D.10 UNI6592 Z WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
20 1773265CE 1 nr LAMIERA SUPPORTO MOTORE D PLATE (sheet of metal) TOLE BLECH CHAPA
21 0062340CE 1 nr COLLARE A BULLONE PC 214- COLLAR COLLIER ANSCHLAGBUND COLLAR

MOTORE E POMPA DI SOLLEVAMENTO / HOISTING MOTOR AND PUMP Page 36

MOTORE E POMPA DI SOLLEVAMENTO / HOISTING MOTOR AND PUMP Page 37
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
22 1773324CE 4 nr ANTIVIBRANTE DIS.960826 6 VIBRATION DAMPING ANTIVIBRATOIRE SCHWINGUNGSD¬MPFEND ANTIVIBRATORIO
23 0120211CE 8 nr [Link].D8-5/16" DIN12 SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
24 0110041CE 8 nr DADO ES. M8 UNI5588 ZINC. NUT ECROU MUTTER TUERCA

MOTORE E POMPA DI SOLLEVAMENTO / HOISTING MOTOR AND PUMP Page 38

MOTORE E POMPA DI SOLLEVAMENTO / HOISTING MOTOR AND PUMP Page 39
CBE12F_DISTRIBUTORE_IDRAULICO_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 0094518CE 1 nr DISTRIBUTORE 3vie HC-FL50 3 VALVES DISTRIBUTOR DISTRIBUTEUR 3 LEVIERS 3-FACH STEUERBLOCK DISTRIBUIDOR 3 LEVAS
"Hydrocontrol" "Hydrocontrol"
1 0094519CE 1 nr DISTRIBUTORE 4vie HC-FL50 4 VALVES DISTRIBUTOR DISTRIBUTEUR 4 LEVIERS 4-FACH STEUERBLOCK DISTRIBUIDOR 4 LEVAS
"Hydrocontrol" "Hydrocontrol"
1 4778032CE 1 nr DISTRIBUTORE VDM07/ALD/U4 3 VALVES DISTRIBUTOR DISTRIBUTEUR 3 LEVIERS 3-FACH STEUERBLOCK DISTRIBUIDOR 3 LEVAS
"Salami" "Salami"
1 4778033CE 1 nr DISTRIBUTORE VDM07/ALDD/U DISTRIBUTOR/VALVE DISTRIB
"Salami" "Salami"
2 0991908CE 3 nr VALVOLA VS RIF.420270340 VALVE SOUPAPE VENTIL VALVULA
"Salami" "Salami"
2 S990101CE 1 nr VALVOLA DI MAX.180BAR MAX. PRESSURE VALVE SOUPAPE DE MAXIMUM [Link] VALVULA DE MAXIMA PRESION
"Hydrocontrol" "Hydrocontrol"
3 S990100CE 1 nr KIT RICHIAMO STELO CORSA KIT JEU SATZ JUEGO
"Hydrocontrol" "Hydrocontrol"
4 S990097CE 3 nr KIT VALVOLA PARACADUTE RI KIT JEU SATZ JUEGO
"Hydrocontrol" "Hydrocontrol"
5 S990098CE 3 nr VALVOLA ANTIURTO RIF.2535 SHOCKPROOF VALVE SOUPAPE ANTI-CHOC STOSSFESTVENTIL VALVULA ANTI-IMPACTO
"Hydrocontrol" "Hydrocontrol"
6 S990097CE 1 nr KIT VALVOLA PARACADUTE RI KIT JEU SATZ JUEGO
"Hydrocontrol" "Hydrocontrol"
7 S990102CE 1 nr KIT VALVOLA RITEGNO KIT JEU SATZ JUEGO
"Hydrocontrol" "Hydrocontrol"
8 S990096CE 1 nr KIT GUARNIZ. RIF.JPS16100 GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
"Hydrocontrol" 4 vie "Hydrocontrol" 4 valves
8 S990103CE 1 nr KIT GUARNIZ. RIF.JPS16100 GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
"Hydrocontrol" 3 vie "Hydrocontrol" 3 valves
9 2772124CE 1 nr LEVA COMANDO [Link] CONTROL LEVER LEVIER DE COMMANDE STEUERHEBEL PALANCA DE MANDO
versione allungata scandinavia scandinavian lengthened versio
9 2776049CE 1 nr LEVA COMANDO 4a VIA COMPL CONTROL LEVER LEVIER DE COMMANDE STEUERHEBEL PALANCA DE MANDO
4 vie 4 valves
9 2774109CE 1 nr LEVA COMANDO ATTREZZATURA CONTROL LEVER LEVIER DE COMMANDE STEUERHEBEL PALANCA DE MANDO
versione scandinavia (4 vie) scandinavian version (4 valves
10 1775013CE 1 nr TAPPO PER LEVA 4 VIA NERO PLUG BOUCHON VERSCHLUSS TAPON
Solo per distributore a 4 vie Only for 4 valves distributor
11 2776048CE 1 nr LEVA COMANDO TRASLATORE C SIDESHIFTING LEVER LEVIER DU DEPLACEMENT SEITENSCHIEBERHEBEL PALANCA DESPLAZADOR
11 2772123CE 1 nr LEVA COMANDO TRASLATORE A SIDESHIFTING LEVER LEVIER DU DEPLACEMENT SEITENSCHIEBERHEBEL PALANCA DESPLAZADOR
versione allungata scandinavia scandinavian lengthened versio

DISTRIBUTORE IDRAULICO / CONTROL VALVE Page 40

DISTRIBUTORE IDRAULICO / CONTROL VALVE Page 41
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
11 2774108CE 1 nr LEVA COMANDO TRASLATORE ( SIDESHIFTING LEVER LEVIER DU DEPLACEMENT SEITENSCHIEBERHEBEL PALANCA DESPLAZADOR
versione scandinavia scandinavian version
12 1775012CE 1 nr TAPPO PER LEVA [Link] PLUG BOUCHON VERSCHLUSS TAPON
13 2772122CE 1 nr LEVA COMANDO BRANDEGGIO A TILTING LEVER LEVIER DE INCLINAISON NEIGUNGHEBEL PALANCA DE INCLINACION
versione allungata scandinavia scandinavian lengthened versio
13 2774107CE 1 nr LEVA COMANDO BRANDEGGIO ( TILTING LEVER LEVIER DE INCLINAISON NEIGUNGHEBEL PALANCA DE INCLINACION
versione scandinavia scandinavian version
13 2776047CE 1 nr LEVA COMANDO BRANDEGGIO C TILTING LEVER LEVIER DE INCLINAISON NEIGUNGHEBEL PALANCA DE INCLINACION
14 1775011CE 1 nr TAPPO PER LEVA [Link] PLUG BOUCHON VERSCHLUSS TAPON
15 2772121CE 1 nr LEVA COMANDO [Link] LIFTING LEVER LEVIER DE ELEVATION HUBHEBEL PALANCA DE ELEVACION
versione allungata scandinavia scandinavian lengthened versio
15 2774106CE 1 nr LEVA COMANDO SOLLEVAMENTO LIFTING LEVER LEVIER DE ELEVATION HUBHEBEL PALANCA DE ELEVACION
versione scandinavia scandinavian version
15 2776046CE 1 nr LEVA COMANDO SOLLEVAMENTO LIFTING LEVER LEVIER DE ELEVATION HUBHEBEL PALANCA DE ELEVACION
16 1775010CE 1 nr TAPPO PER LEVA [Link] PLUG BOUCHON VERSCHLUSS TAPON
17 1773245CE 4 nr FORCELLA RINVIO COMANDI A COTTER PIN FOURCHETTE GESPALTER STIFT HORQUILLA
18 1773278CE 4 nr ASTINA COMANDO SPOLE DIST ROD TIGE STANGE VARILLA
19 2772048CE 1 nr ARTICOLAZIONE POTENZIOMET ARTICULATED JOINT ARTICULATION GELENK JUNTA
20 1773274CE 1 nr DISTANZIALE PER PACCO LEV SPACER ECARTEUR ABSTANDSTSCK DISTANCIADOR
Solo per distributore a 3 vie Only for 3 valves distributor
21 1727095CE 1 nr POTENZIOMETRO D.83218 POTENTIOMETER POTENTIOMETRE POTENTIOMETER POTENCIOMETRO
22 1773246CE 1 nr PERNO FULCRO LEVE D.95090 LEVER PIN PIVOT LEVIER HEBELBOLZEN PERNO DE PALANCA
23 1607375CE 4 nr MICRO STAGNO PER DISTRIBU MICROSWITCH MICRO-INTERRUPTEUR MIKROSCHALTER MICROINTERRUPTOR
versione scandinavia scandinavian version
23 0053056CE 4 nr MICROINTERRUTTORE XG2 S20 MICROSWITCH MICRO-INTERRUPTEUR MIKROSCHALTER MICROINTERRUPTOR
24 1773241CE 2 nr PIASTRINO A "C" PORTA INT PLATE PLAQUE PL¬TTCHEN PLACA
25 1773248CE 1 nr COPERCHIO COMANDO LEVISMI COVER COUVERCLE DECKEL TAPA
Solo per distributore a 3 vie Only for 3 valves distributor
25 1773264CE 1 nr COPERCHIO COMANDO LEVISMI COVER COUVERCLE DECKEL TAPA
Solo per distributore a 4 vie Only for 4 valves distributor
26 1933157CE 4 nr SOFFIETTO D.991317 BELLOWS SOUFFLET BLASEBALG FUELLE
27 1777078CE 1 nr CABLAGGIO PER DEVIATORE D WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO

DISTRIBUTORE IDRAULICO / CONTROL VALVE Page 42

DISTRIBUTORE IDRAULICO / CONTROL VALVE Page 43
CBE12F_MOTORE_DI_TRAZIONE_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 0058007CE 1 nr MOTORE TRAZIONE TSL210A-2 DRIVE MOTOR MOTEUR DE TRACTION FAHRMOTOR MOTOR DE TRACCION
1 0992235CE 4 nr MORSETTO TERMINALE RIF.50 TERMINAL BORNE KLEMME TERMINAL
Fino al n° di matricola SHABMU Up to the s/n SHABMULLER 13320
1 0993733CE 4 nr MORSETTO TERMINALE RIF500 TERMINAL BORNE KLEMME TERMINAL
Dal n° di matricola SHABMULLER From the s/n SHABMULLER 133539
2 0992236CE 1 nr INDOTTO RIF. 50023693 ROTOR ROTOR ROTOR ROTOR
3 0993593CE 1 nr COLLARE PORTASPAZZ. D210 COLLAR COLLIER ANSCHLAGBUND COLLAR
Dal n° di matricola SHABMULLER From the s/n SHABMULLER 133539
3 0992239CE 1 nr ANELLO PORTASPAZZOLE RIF. RING ANNEAU RING ANILLO
Fino al n° di matricola SHABMU Up to the s/n SHABMULLER 13320
4 1777114CE 1 nr VENTOLA CABLATA 48V D.971 FAN VENTILATEUR LSFTER VENTILADOR
5 0992242CE 1 nr SPAZZOLA CON INDICATORE U BRUSH BALAI BÜRSTE ESCOBILLA
Fino al n° di matricola SHABMU Up to the s/n SHABMULLER 13320
5 0993731CE 1 nr SPAZZOLA 10X32X32 C/USURA BRUSH BALAI BSRSTE ESCOBILLA
Dal n° di matricola SHABMULLER From the s/n SHABMULLER 133539
6 0992238CE 1 nr GUARNIZIONE OR RIF. 50013 GASKET
7 0992091CE 1 nr CUSCINETTO 6206 2ZC3 HL BALL BEARING ROULEMENTS A BILLES KUGELLAGER COJINETE
8 0992237CE 1 nr PARAOLIO MOT. RIF. 500139 OIL SEAL JOINT ETANCHE A L'HUILE ÍLABDICHTUNG SELLO DE ACEITE
9 0992243CE 1 nr BOBINE RIF. 50029017 COIL BOBINE SPULE BOBINA
10 0016361CE 1 nr CUSCINETTO 6205 2RS C3 HL BALL BEARING ROULEMENTS A BILLES KUGELLAGER COJINETE
11 0992240CE 4 nr MOLLA PORTASPAZZOLA RIF. SPRING RESSORT FEDER RESORTE
Fino al n° di matricola SHABMU Up to the s/n SHABMULLER 13320
11 0993734CE 4 nr MOLLA [Link].5001 SPRING RESSORT FEDER RESORTE
Dal n° di matricola SHABMULLER From the s/n SHABMULLER 133539
12 0992241CE 3 nr SPAZZOLA RIF. 50010365 BRUSH BALAI BÜRSTE ESCOBILLA
Fino al n° di matricola SHABMU Up to the s/n SHABMULLER 13320
12 0993730CE 3 nr SPAZZOLA NORMALE 10X32X32 BRUSH BALAI BSRSTE ESCOBILLA
Dal n° di matricola SHABMULLER From the s/n SHABMULLER 133539
13 0992842CE 1 nr BANDELLA PORTA VENTOLA RI SUPPORT SUPPORT HALTERUNG SOPORTE
14 0992297CE 1 nr CHIAVETTA RIF. 50014908 SPLINE CLAVETTE WELLENKEIL CHAVETA
15 0993573CE 1 nr COPERCHIO MOT. TRAZ BLITZ COVER COUVERCLE DECKEL TAPA
16 0013885CE 1 nr GHIERA GUK M20 RING NUT BAGUE NUTMUTTER CASQUILLO

MOTORE DI TRAZIONE / DRIVE MOTOR Page 44

MOTORE DI TRAZIONE / DRIVE MOTOR Page 45
CBE12F_RIDUTTORE_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 0093325CE 1 nr RIDUTTORE RUOTA DX HFS502 WHEEL REDUCTION GEAR REDUCTEUR ROUE RADGETRIEBE REDUCTOR RUEDA
0 0093326CE 1 nr RIDUTTORE RUOTA SX HFS502 WHEEL REDUCTION GEAR REDUCTEUR ROUE RADGETRIEBE REDUCTOR RUEDA
1 0992864CE 1 nr SFIATO RIDUTTORE HURTH D. BREATHER PIPE EVENT ENTLSFTER RESPIRADERO
2 0992158CE 5 nr VITE RUOTA RIF.305657 SCREW VIS SCHRAUBE TORNILLO
3 0992949CE 1 nr PARAOLIO GAMMA RING RIF.4 OIL SEAL JOINT ETANCHE A L'HUILE ÍLABDICHTUNG SELLO DE ACEITE
4 0992948CE 1 nr NILOS RING RIF. 302357 RING ANNEAU RING ANILLO
5 0992157CE 2 nr GUARNIZIONE RIF.063480103 GASKET GARNITURE DICHTUNG JUNTA
6 0992162CE 2 nr TAPPO MAGNETICO RIF.05013 PLUG BOUCHON VERSCHLUSS TAPON
7 0992950CE 1 nr PASTIGLIA RIF. 480531 DIAPHRAGM DIAPHRAGME MEMBRANE DIAFRAGMA
8 0992159CE 1 nr 0992159CE
9 0992156CE 2 nr ANELLO ELASTICO RIF.06305 SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
10 0992808CE 1 nr ANELLO TENUTA 8x15x3 SD-P GAS RING BAGUE D'ETANCHEITE DICHTUNGSRING ANILLO DE JUNTA ESTANCA
11 0992812CE 1 nr CUSCINETTO 6006 NR BALL BEARING ROULEMENTS A BILLES KUGELLAGER COJINETE
12 0992512CE 1 nr PIGNONE RIDUTT.Z=29 RIF.6 PINION PIGNON RITZEL PINON
13 0993525CE 3 nr LAMELLA EST. RIF.475824 FRICTION DISK DISQUE D' EMBRAYAGE KUPPLUNGSSCHEIBE DISCO DE EMBRAGUE
14 0993526CE 2 nr LAMELLA INT. RIF.475825 FRICTION DISK
15 0993527CE 1 nr RASAMENTO SP.4,8 RIF.490 SPACER ECARTEUR ABSTANDSSTÜCK DISTANCIADOR
15 0993528CE 1 nr RASAMENTO SP.5,3 RIF.6509 SPACER ECARTEUR ABSTANDSSTÜCK DISTANCIADOR
15 0993529CE 1 nr RASAMENTO SP.5,8 RIF.6509 SPACER ECARTEUR ABSTANDSSTÜCK DISTANCIADOR
16 0993530CE 1 nr SPINA RIF.0631.313.003 PLUG GOUPILLE STECKER CLAVIJA
17 0993531CE 1 nr PIATTO RIF. 490141 PLATE PLAQUE PLÄTTCHEN PLACA
18 0993532CE 1 nr INGRANAGGIO RIF.660247 GEAR ENGRENAGE GETRIEBE ENGRANAJE
19 0993533CE 3 nr MOLLA RIF.270480 SPRING RESSORT FEDER RESORTE
20 0993534CE 3 nr INGRANAGGIO RIF.650131 GEAR ENGRENAGE GETRIEBE ENGRANAJE
21 0993535CE 3 nr CUSCINETTO RIF.650003 BALL BEARING ROULEMENTS A BILLES KUGELLAGER COJINETE
22 0993536CE 1 nr ALBERO RIF.490105 SHAFT ARBRE WELLE EJE
23 0993537CE 1 nr GABBIA A RULLI RIF.106582 ROLLER HOUSE CAGE A ROULEAUX ROLLENGEHAEUSE PORTARRODILLOS
24 0993538CE 1 nr SPESSORE RIF.0630.000.076 SHIM EPAISSEUR DICKE ESPESOR
24 0993539CE 1 nr SPESSORE RIF.448304 SHIM EPAISSEUR DICKE ESPESOR
24 0993540CE 1 nr SPESSORE RIF.0630.000.078 SHIM EPAISSEUR DICKE ESPESOR
24 0993541CE 1 nr SPESSORE RIF.0630.004.032 SHIM EPAISSEUR DICKE ESPESOR
24 0993542CE 1 nr SPESSORE RIF.104971 SHIM EPAISSEUR DICKE ESPESOR
25 0993543CE 10 nr VITE RIF.650004 SCREW VIS SCHRAUBE TORNILLO
26 0993544CE 1 nr DADO RIF.439608 NUT ECROU MUTTER TUERCA
27 0993304CE 1 nr PERNO PUNTALE FRENO RIF.4 PIN PIVOT STIFT PERNO
28 0993562CE 1 nr COPERCHIO RIDUTTORE RIF 4 COVER COUVERCLE DECKEL TAPA
29 0110227CE 5 nr DADO AUTOBL. N/70/114X1,5 SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA

RIDUTTORE HFS 502 / REDUCTION GEAR HFS 502 Page 46

RIDUTTORE HFS 502 / REDUCTION GEAR HFS 502 Page 47
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
30 0992375CE 1 nr LEVA FRENO COMPLETA RIF.6 BRAKE LEVER LEVIER DU FREIN BREMSHEBEL PALANCA DEL FRENO

RIDUTTORE HFS 502 / REDUCTION GEAR HFS 502 Page 48

RIDUTTORE HFS 502 / REDUCTION GEAR HFS 502 Page 49
CBE12F_RIDUTTORE_GP20_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 0093376CE 1 nr RIDUTTORE DS GP20-18,2 ri REDUCTION GEAR REDUCTEUR UNTERSETZUNGSGETRIEBE REDUCTOR
0 0093377CE 1 nr RIDUTTORE SN GP20-18,2 ri REDUCTION GEAR REDUCTEUR UNTERSETZUNGSGETRIEBE REDUCTOR
1 1773157CE 5 nr DADO CIECO D.78081/21 NUT ECROU MUTTER TUERCA
versione scandinavia scandinavian version
1 0110227CE 5 nr DADO AUTOBL. N/70/114X1,5 SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
2 0992158CE 5 nr VITE RUOTA RIF.305657 SCREW VIS SCHRAUBE TORNILLO
3 S990035CE 1 nr ALBERO RIF.4699300077 SHAFT ARBRE WELLE EJE
4 S990030CE 1 nr GABBIA A RULLI RIF.063530 ROLLER HOUSE CAGE A ROULEAUX ROLLENGEHAEUSE PORTARRODILLOS
5 S990033CE 1 nr SFIATO RIF.0637885613 BREATHER PIPE EVENT ENTLÜFTER RESPIRADERO
6 0992949CE 1 nr PARAOLIO GAMMA RING RIF.4 OIL SEAL JOINT ETANCHE A L'HUILE ÍLABDICHTUNG SELLO DE ACEITE
7 0992948CE 1 nr NILOS RING RIF. 302357 RING ANNEAU RING ANILLO
8 S990031CE 1 nr ANELLO TENUTA RIF.0634309 GAS RING BAGUE D'ETANCHEITE DICHTUNGSRING ANILLO DE JUNTA ESTANCA
9 0992157CE 2 nr GUARNIZIONE RIF.063480103 GASKET GARNITURE DICHTUNG JUNTA
10 0992162CE 2 nr TAPPO MAGNETICO RIF.05013 PLUG BOUCHON VERSCHLUSS TAPON
11 0993543CE 10 nr VITE RIF.650004 SCREW VIS SCHRAUBE TORNILLO
12 S990034CE 1 nr GHIERA RIF.662219 RING NUT BAGUE NUTMUTTER CASQUILLO
13 0993534CE 3 nr INGRANAGGIO RIF.650131 GEAR ENGRENAGE GETRIEBE ENGRANAJE
14 0993535CE 3 nr CUSCINETTO RIF.650003 BALL BEARING ROULEMENTS A BILLES KUGELLAGER COJINETE
15 S990039CE 1 nr RASAMENTO RIF.4699209005 SPACER ECARTEUR ABSTANDSSTÜCK DISTANCIADOR
16 S990037CE 3 nr DISCO INTERNO RIF.660244 DISK DISQUE SCHEIBE DISCO
17 S990036CE 4 nr DISCO ESTERNO RIF.660243 DISK DISQUE SCHEIBE DISCO
18 S990032CE 3 nr MOLLA RIF.0632040021 SPRING RESSORT FEDER RESORTE
19 0993532CE 1 nr INGRANAGGIO RIF.660247 GEAR ENGRENAGE GETRIEBE ENGRANAJE
20 S990040CE 1 nr DISCO PRESSANTE RIF.66025 DISK DISQUE SCHEIBE DISCO
21 0992812CE 1 nr CUSCINETTO 6006 NR BALL BEARING ROULEMENTS A BILLES KUGELLAGER COJINETE
22 S990048CE 1 nr CORONA RIF.650547 CROWN COURONNE KRANZ CORONA
23 0992950CE 1 nr PASTIGLIA RIF. 480531 DIAPHRAGM DIAPHRAGME MEMBRANE DIAFRAGMA
24 0993530CE 1 nr SPINA RIF.0631.313.003 PLUG GOUPILLE STECKER CLAVIJA
25 S990038CE 1 nr COPERCHIO RIDUTTORE RIF.6 COVER COUVERCLE DECKEL TAPA
26 0992808CE 1 nr ANELLO TENUTA 8x15x3 SD-P GAS RING BAGUE D'ETANCHEITE DICHTUNGSRING ANILLO DE JUNTA ESTANCA
27 0992512CE 1 nr PIGNONE RIDUTT.Z=29 RIF.6 PINION PIGNON RITZEL PINON
28 0993376CE 1 nr LEVA FRENO COMPLETA RIF.6 BRAKE LEVER LEVIER DU FREIN BREMSHEBEL PALANCA DEL FRENO

RIDUTTORE GP20 / REDUCTION GEAR GP20 Page 50

RIDUTTORE GP20 / REDUCTION GEAR GP20 Page 51
CBE12F_RUOTE_MOTRICI_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 2776002CE 1 nr RUOTA MOTRICE CUSH (BLITZ
2 0019595CE 1 nr CUSHION 432X152X308 CUSHION CUSHION CUSHION CUSHION
3 1776009CE 1 nr CERCHIO CUSHION 308X152 D RIM JANTE FELGE LLANTA
4 2776005CE 1 nr RUOTA [Link] ECO KC12-1 DRIVE WHEEL ROUE MOTRICE ANTRIEBSRAD RUEDA MOTRIZ
5 0090547CE 1 nr SUPERELASTICO 18X7-8 CON SUPERELASTIC PNEUS PLEIN SOUPLES SUPERALASTIK SUPERELASTICAS
6 1776012CE 1 nr CERCHIO 4.33R-8 D.93969 RIM JANTE FELGE LLANTA
7 2776027CE 1 nr RUOTA [Link] D.941006 B DRIVE WHEEL ROUE MOTRICE ANTRIEBSRAD RUEDA MOTRIZ
8 0018894CE 1 nr CAMERA X PN 18X7-8 AIR TUBE CHAMBRE A AIR LUFTSCHLAUCH CAMARA DE AIRE
9 0090002CE 1 nr COPERTURA 18X7-8 16PR CON COVER COUVERCLE DECKEL TAPA
10 1776067CE 1 nr CERCHIO 4.33R-8 D.941005 RIM JANTE FELGE LLANTA

RUOTE MOTRICI / DRIVE WHEELS Page 52

RUOTE MOTRICI / DRIVE WHEELS Page 53
CBE12F_COMANDO_ELETTRONICO_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 1774045CE 1 nr COPERCHIO IN LAMIERA D.00 COVER COUVERCLE DECKEL TAPA
Da n. 216570 Da n. 216570 Da n. 216570 Da n. 216570 Da n. 216570
1 1773262CE 1 nr COPERCHIO IN ABS D.950940 COVER COUVERCLE DECKEL TAPA
2 1577024CE 1 nr CABLAGGIO VENTOLA AREAZIO WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
3 1773263CE 1 nr CONVOGLIATORE D.950941 CONVEYOR CONVOYEUR KSHLERHAUBE CONDUCTOR
4 0120180CE 4 nr [Link].D4 UNI1751 ZIN SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
5 0120105CE 4 nr [Link] D.4 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
6 0110039CE 4 nr DADO ES. M4 UNI5588 ZINC. NUT ECROU MUTTER TUERCA
7 0064492CE 1 mt GUARNIZIONE ASSORICAMBI R GASKET GARNITURE DICHTUNG VAINA
8 0054730CE 1 nr MODULO [Link].B1S ELECTRONIC CONTROL UNIT COMMANDE ELECTRONIQUE ELEKTRONISCHE STEUERUNG MANDO ELECTRONICO
8 0054968CE 1 nr MODULO TRAZIONE B1/48V "Z DRIVE CONTROL UNIT COMMANDE DE TRACTION FAHRSTEUERUNG MANDO DE TRACCION
Da n. 216570 Da n. 216570 Da n. 216570 Da n. 216570 Da n. 216570
8 0054969CE 1 nr MODULO TRAZIONE B1/48V "Z DRIVE CONTROL UNIT COMMANDE DE TRACTION FAHRSTEUERUNG MANDO DE TRACCION
versione scandinavia scandinavian version
9 1777076CE 1 nr CABLAGGIO TELERUTTORI D.9 WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
10 0051050CE 2 nr TELEINVERTITORE DC182B/53 REMOTE CONTROL REVERSER TELEINVERSEUR FERNUMRICHTER TELECONMUTADOR INVERSOR
11 0992884CE 2 nr KIT-CONTATTI DC 182B ST T CONTACTS KIT JEU DE CONTACTS KONTAKTENSATZ JUEGO DE CONTACTOS
12 1777103CE 1 nr BARRA DI COLLEGAMENTO TEL CONNECTING BAR BARRE DE CONNEXION VERBINDUNGSSTANGE BARRA DE ACOPLAMIENTO
13 1777105CE 1 nr BARRA DI COLLEGAMENTO TEL CONNECTING BAR BARRE DE CONNEXION VERBINDUNGSSTANGE BARRA DE ACOPLAMIENTO
14 1777027CE 1 nr PONTE DI COLLEGAMENTO PER CONNECTING JUMPER BARRETTE DE CONNEXION VERBINDUNGSBRSCKE CONECTOR PUENTE
15 0120156CE 4 nr ROS EL DENT EST CON D8 ZI SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
16 0100121CE 4 nr VITE TE M8X20 UNI5739 ZIN SCREW VIS SCHRAUBE TORNILLO
17 0133008CE 1 nr VITE STEI M8X40 UNI5923 1 SCREW VIS SCHRAUBE TORNILLO
18 0120209CE 6 nr RONDELLA EL.5 DIN137-B ZI SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
19 0100422CE 6 nr VITE TE M5X8 UNI5739 ZINC SCREW VIS SCHRAUBE TORNILLO
20 0101010CE 10 nr VITE TCEI M5X14 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
21 0120003CE 10 nr ROND. PIANA D.5 UNI6592 Z WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
22 0105125CE 1 nr VITE ATBC 4,2x13 Pz-AB 69 SCREW
23 0120106CE 1 nr [Link] D.5 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
24 0100501CE 4 nr VITE TE M4X55 6.S UNI5739 SCREW VIS SCHRAUBE TORNILLO
25 0054956CE 1 nr MODULO SOLLEVAMENTO HP350 LIFTING CONTROL UNIT COMMANDE D'ELEVATION HUBSTEUERUNG MANDO LEVANTAMIENTO
Da n. 216570 Da n. 216570 Da n. 216570 Da n. 216570 Da n. 216570
25 0054734CE 1 nr MODULO SOLLEV. ZAPIMOS HP LIFTING CONTROL UNIT COMMANDE D'ELEVATION HUBSTEUERUNG MANDO LEVANTAMIENTO
26 0070599CE 1 nr 0070599CE

COMANDO ELETTRONICO / ELETTRONIC CONTROL Page 54

COMANDO ELETTRONICO / ELETTRONIC CONTROL Page 55
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
27 1773306CE 1 nr 1773306CE
28 0110062CE 2 nr DADO M8 UNI5589 ZINC.G NUT ECROU MUTTER TUERCA
29 0051042CE 1 nr [Link] SW 181 REMOTE CONTROL REVERSER TELEINVERSEUR FERNUMRICHTER TELECONMUTADOR INVERSOR
30 0992885CE 1 nr KIT-CONTATTI 181/2180-43T CONTACTS KIT JEU DE CONTACTS KONTAKTENSATZ JUEGO DE CONTACTOS
31 1777079CE 1 nr CABLAGGIO COMANDO SOLLEVA WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
32 1777116CE 1 nr DIODO CABLATO D.971401 DIODE DIODE DIODE DIODE
33 1777214CE 1 nr RESISTENZA CABLATA RESISTANCE RESISTANCE WIDERSTAND RESISTENCIA
Da n. 216570 Da n. 216570 Da n. 216570 Da n. 216570 Da n. 216570
34 0054971CE 1 nr DIODO IR-IRKE 236/04 0054971
Da n. 216570 Da n. 216570
35 0051072CE 1 nr TELERUTTORE SW200-20 48V CONTACTOR TELERUPTEUR SCH?TZ TELERRUPTOR
versione scandinavia scandinavian version
36 1607352CE 1 nr DIODO CABLATO 1N4007 D.89 DIODE DIODE DIODE DIODE
versione scandinavia scandinavian version

COMANDO ELETTRONICO / ELETTRONIC CONTROL Page 56

COMANDO ELETTRONICO / ELETTRONIC CONTROL Page 57
CBE12F_COMPONENTI_ELETTRICI_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 1773194CE 1 nr STAFFA FERMA CAVI BATTERI BRACKET ETRIER BSGEL ESTRIBO
2 1777013CE 1 nr CAVI SPINA PRESA A BATTER ELECTRIC CABLE CABLE ELECTRIQUE KABELLEITUNG CABLE CONDUCTOR
3 0057781CE 1 nr MANIGLIA ROSSA RIF ANDERS HANDLE POIGNEE HANDGRIFF MANILLA
4 0057816CE 1 nr [Link] SBE160 E CONNECTOR CONNECTEUR STECKER CONECTOR
5 1777080CE 1 nr CAVI SPINA PRESA A BARRA ELECTRIC CABLE CABLE ELECTRIQUE KABELLEITUNG CABLE CONDUCTOR
5 1777179CE 1 nr CAVI DA SPINA PRESA A IMP ELECTRIC CABLE CABLE ELECTRIQUE KABELLEITUNG CABLE CONDUCTOR
versione scandinavia scandinavian version
6 0057816CE 1 nr [Link] SBE160 E CONNECTOR CONNECTEUR STECKER CONECTOR
7 1777033CE 1 nr SCHEDA SERVIZI AUSILIARI ELETRONIC CARD CARTE ELECTRONIQUE STEUERKARTE TARJETA ELECTRONICA
versione scandinavia scandinavian version
7 1777071CE 1 nr SCHEDA SERVIZI AUSILIARI ELETRONIC CARD CARTE ELECTRONIQUE STEUERKARTE TARJETA ELECTRONICA
8 0850083CE 1 nr FUSIBILE TIPO WEBER 5X20 FUSE FUSIBLE SICHERUNG FUSIBLE
9 0018749CE 5 nr FUSIBILE 5 A. [Link] 5X FUSE FUSIBLE SICHERUNG FUSIBLE
10 0023301CE 1 nr MANOPOLA ZIGRINATA RIF.B. HAND GRIP HAND GRIP POIGNEE DREHKNOPF
11 1773277CE 1 nr BARRETTA PORTA FUSIBILI D FUSE SUPPORT SUPPORT HALTERUNG SOPORTE
12 0057957CE 1 nr FUSIBILE TRAZIONE 60x11 3 DRIVE FUSE FUSIBLE TRACTION ZUGSICHERUNG FUSIBLE TRACCION
13 0057958CE 1 nr FUSIBILE TRAZIONE 60x11 1 DRIVE FUSE FUSIBLE TRACTION ZUGSICHERUNG FUSIBLE TRACCION
14 0020019CE 1 nr COLONNINA [Link].35 STUD BOLT ENTRETOISE SCHRAUBBOLZEN BARRITA
15 2773036CE 1 nr GRUPPO FUSIBILI (BLITZ 31 UNIT GROUPE GRUPPE GRUPO
16 0057957CE 1 nr FUSIBILE TRAZIONE 60x11 3 DRIVE FUSE FUSIBLE TRACTION ZUGSICHERUNG FUSIBLE TRACCION
17 0054967CE 1 nr FUSIBILE 32A "OMEGA GL151 FUSE FUSIBLE SICHERUNG FUSIBLE
18 0057958CE 1 nr FUSIBILE TRAZIONE 60x11 1 DRIVE FUSE FUSIBLE TRACTION ZUGSICHERUNG FUSIBLE TRACCION
19 0054498CE 1 nr RESISTENZA [Link] 25/ RESISTANCE RESISTANCE WIDERSTAND RESISTENCIA
versione scandinavia scandinavian version
20 1777202CE 1 nr RESISTENZA CABLATA 330ohm RESISTANCE RESISTANCE WIDERSTAND RESISTENCIA
versione scandinavia scandinavian version
21 0053150CE 2 nr RELE 24V CON DIODO COBO RELAY RELAIS RELAIS RELE
versione scandinavia scandinavian version
22 0053154CE 1 nr INTERRUTTORE BASCULANTE C SWITCH INTERRUPTEUR INTERRUPTOR INTERRUPTOR
versione scandinavia scandinavian version
23 0053156CE 3 nr VETRINO VERDE rif.13.350. GLASS VITRE GLASSCHEIBE CRISTAL
versione scandinavia scandinavian version
24 0050132CE 3 nr LAMPADINA 24V 1.2W RIF.00 BULB LAMPE GLÜHBIRNE BOMBILLA
versione scandinavia scandinavian version
25 0053152CE 1 nr CORPO PORTA 2 SPIE rif.09 DOOR CASING CORPS PORTE KLAPPENGEHÄUSE CUERPO PUERTA
versione scandinavia scandinavian version
26 0300438CE 1 nr ETICHETTA SPIE DIREZIONE LABEL ETIQUETTE AUFKLEBER ETIQUETA
versione scandinavia scandinavian version

COMPONENTI ELETTRICI / MISCELLANEOUS ELETTRICAL Page 58

COMPONENTI ELETTRICI / MISCELLANEOUS ELETTRICAL Page 59
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
27 1773560CE 1 nr PIATTO 35x8x55 (CBE vers. PLATE PLAQUE PL¬TTCHEN PLACA
versione scandinavia scandinavian version
28 1773559CE 1 nr PIATTO 55x12x52 (CBE vers PLATE PLAQUE PL¬TTCHEN PLACA
versione scandinavia scandinavian version
29 1773561CE 1 nr SUPPORTO IN LAMIERA (CBE SUPPORT SUPPORT HALTERUNG SOPORTE
versione scandinavia scandinavian version
30 0053221CE 2 nr CONTATTO 2NA rif.P9B20VN CONTACT CONTACT KONTAKT CONTACTO
versione scandinavia scandinavian version
31 0053220CE 1 nr MANIPOLATORE rif.P9XMN2F MANIPULATOR MANIPULATEUR MANIPULATOR MANIPULADOR
versione scandinavia scandinavian version
32 1777200CE 1 nr CABLAGGIO MANIPOLATORE (C WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
versione scandinavia scandinavian version

COMPONENTI ELETTRICI / MISCELLANEOUS ELETTRICAL Page 60

COMPONENTI ELETTRICI / MISCELLANEOUS ELETTRICAL Page 61
CBE12F_PEDALIERA_ACCELERATORE_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 3776024CE 1 nr PEDALIERA ACCELERATORE ( [Link] SYSTEM, DOUBL PEDALIER D'ACCELER., DOUB GASPEDALE, DOPPEL PEDALES ACELERADOR, DOBLE
0 3776049CE 1 nr PEDALIERA ACCELERATORE PE ACCELERATOR PEDAL SYSTEM PEDALIER D'ACCELERATEUR GASPEDALE PEDALES ACELERADOR
versione scandinavia scandinavian version
1 1776017CE 1 nr COPRIPEDALE DESTRO D.9312 PEDAL COVER COUVRE-PEDALE PEDALABDECKUNG PROTECCION DEL PEDAL
2 1776016CE 1 nr COPRIPEDALE SINISTRO D.93 PEDAL COVER COUVRE-PEDALE PEDALABDECKUNG PROTECCION DEL PEDAL
3 1776104CE 2 nr STAFFA DI FERMO BRACKET ETRIER BSGEL ESTRIBO
4 0100117CE 2 nr VITE TE M6X12 UNI5739 TRO SCREW VIS SCHRAUBE TORNILLO
5 0120044CE 3 nr [Link]. D.6 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
6 1022018CE 2 nr ROSETTA GREMBIALINA 6,6X2 WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
7 1773406CE 2 nr MOLLA A TRAZIONE SPRING RESSORT FEDER RESORTE
8 1777104CE 1 nr CABLAGGIO PEDALIERA ACC. WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
9 1777187CE 1 nr MICRO CABLATO D.10098 MICROSWITCH MICRO-INTERRUPTEUR MIKROSCHALTER MICROINTERRUPTOR
versione scandinavia scandinavian version
9 0053056CE 2 nr MICROINTERRUTTORE XG2 S20 MICROSWITCH MICRO-INTERRUPTEUR MIKROSCHALTER MICROINTERRUPTOR
9 1777157CE 1 nr MICRO CABLATO MICROSWITCH MICRO-INTERRUPTEUR MIKROSCHALTER MICROINTERRUPTOR
versione scandinavia scandinavian version
10 0110247CE 6 nr DADO AUTOBLOC N/10/103 3X SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
11 0103045CE 4 nr VITE TC M3X18 UNI6107 TRO SCREW VIS SCHRAUBE TORNILLO
12 0070661CE 4 nr BOCCOLA FLANGIATA [Link] BUSHING BAGUE BUCHSE BUCHSE
13 1776118CE 1 nr SUPPORTO PERNO FILETTATO JOURNAL BEARING SUPPORT GOUJON STIFTLAGER SOPORTE PERNO
14 0110040CE 2 nr DADO ES. M6 UNI5588 ZINC. NUT ECROU MUTTER TUERCA
15 1777124CE 1 nr MOLLA A TORSIONE CILINDRI SPRING RESSORT FEDER RESORTE
16 1777120CE 1 nr PERNO FILETTATO PIN PIVOT STIFT PERNO
17 0023233CE 1 nr GOMMINO PASSACAVO [Link] RUBBER SEAL GARNITURE EN CAOUTCHOUC DICHTGUMMI JUNTA DE CAUCHO
18 0100114CE 1 nr VITE TE M6X20 UNI5739 ZIN SCREW VIS SCHRAUBE TORNILLO
19 0100462CE 1 nr VITE TE M5X12 UNI5739 TRO SCREW VIS SCHRAUBE TORNILLO
20 0120043CE 3 nr [Link]. D.5 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
21 0120105CE 1 nr [Link] D.4 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
22 1993041CE 1 nr KIT POTENZIOMETRO PEDAL.A KIT JEU SATZ JUEGO
22 1993042CE 1 nr KIT POTENZIOMETRO PEDAL.A KIT JEU SATZ JUEGO
versione scandinavia scandinavian version
23 1776093CE 1 nr COPERCHIO SCAT. ACC. DIS. COVER COUVERCLE DECKEL TAPA
24 0103023CE 2 nr VITE TC M5X12 UNI6107 BRU SCREW VIS SCHRAUBE TORNILLO

PEDALIERA ACCELERATORE / SPEED PEDAL Page 62

PEDALIERA ACCELERATORE / SPEED PEDAL Page 63
CBE12F_PEDALIERA_E_POMPA_FRENO_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 0070210CE 1 nr SERBATOIO OLIO FRENI CON OIL TANK RESERVOIR D'HUILE ÍLTANK TANQUE DEL ACEITE
1 S990137CE 1 nr TAPPO ELETTRICO PER SERBA PLUG BOUCHON VERSCHLUSS TAPON
2 1773076CE 1 nr SUPPORTO VASCHETTA FRENI SUPPORT SUPPORT HALTERUNG SOPORTE
3 0019535CE 1 nr MOLLA A FORCELLA ART 1221 SPRING RESSORT FEDER RESORTE
4 0061814CE 1 nr TUBO FLEX.1/8 HL SAEJ 140 FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
5 0061813CE 2 nr TUBO FLEX.1/8 HL SAEJ 140 FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
6 0070530CE 1 nr BLOCCHETTO 3 VIE RBN32F STOP ARRET ANSCHLAG PARADA
7 0002420CE 0 mt TUBO CAVIS 5X9 PIPE TUYAU SCHLAUCH TUBO
8 0020648CE 2 nr FASCETTA A1 CLAMP COLLIER DE SERRAGE SCHELLE ABRAZADERA
9 1925020CE 1 nr VITE CAVA DOPPIA BFDM M12 HOLLOW SCREW VIS CREUX HOHLSCHRAUBE TORNILLO HUECO
Solo con impianto luci complet Only with complet lighting equ
9 0016161CE 1 nr BULLONE FORATO BFM 12X1,5 BOLT BOULON MUTTERSCHRAUBE PERNO
10 1609003CE 3 nr RONDELLA RAME 12.1X18X1,5 COPPER WASHER RONDELLE DE CUIVRE KUPFERSCHEIBE ARANDELA COBRE
11 0060322CE 2 nr VITE DI SPURGO M10x1 RIF. DRAIN SCREW VIS DE PURGE SPÜLENSCHRAUBE TORNILLO DE PURGA
12 1856335CE 1 nr BLOCCHETTO RIPARTITORE D. STOP ARRET ANSCHLAG PARADA
Solo con impianto luci complet Only with complet lighting equ
13 0058063CE 1 nr PRESSOSTATO M10X1 rif.117 PRESSURE SWITCH PRESSOSTAT DRUCKSCHALTER PRESOSTATO
Solo con impianto luci complet Only with complet lighting equ
14 3776023CE 1 nr PEDALIERA FRENO D.9506082 BRAKE PEDAL SYSTEM PEDALIER DU FREIN BREMSSTEUERPEDAL JUEGO DE PEDALES DEL FREN
15 0100462CE 1 nr VITE TE M5X12 UNI5739 TRO SCREW VIS SCHRAUBE TORNILLO
16 0120105CE 1 nr [Link] D.4 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
17 1776015CE 1 nr COPRIPEDALE FRENO D.93127 PEDAL COVER COUVRE-PEDALE PEDALABDECKUNG PROTECCION DEL PEDAL
18 0131022CE 2 nr COPIGLIA 2X15 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
19 1021069CE 1 nr SPINOTTO PEDAL. DIS.56355 PISTON PIN AXE DE PISTON KONTAKTSTIFT PASADOR
20 0100121CE 2 nr VITE TE M8X20 UNI5739 ZIN SCREW VIS SCHRAUBE TORNILLO
21 0120108CE 2 nr [Link] D.8 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
22 0064423CE 1 nr POMPA FRENO 2 STADI D.27/ MASTER BRAKE CYLINDER MAITRE CYLINDRE HAUPTBREMSZYLINDER CILINDRO MAESTRO
23 0992906CE 1 nr KIT GUARNIZIONI RIF.SG116 GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
24 1776097CE 1 nr PUNTALINO CAP EMBOUT AUFLAGESTIFT CASQUILLO
25 0070661CE 2 nr BOCCOLA FLANGIATA [Link] BUSHING BAGUE BUCHSE BUCHSE
26 0100114CE 1 nr VITE TE M6X20 UNI5739 ZIN SCREW VIS SCHRAUBE TORNILLO
27 0110040CE 1 nr DADO ES. M6 UNI5588 ZINC. NUT ECROU MUTTER TUERCA
28 1602511CE 1 nr MOLLA D.55113/56 SPRING RESSORT FEDER RESORTE
29 1777074CE 1 nr MICRO STAGNO [Link] D. MICROSWITCH FOR PEDAL ASS MICRO PEDALIER PEDALMIKROSCHALTER MICRO JUEGO DE PEDALES
30 1776096CE 1 nr SPESSORE DIS.950602 SHIM EPAISSEUR DICKE ESPESOR

PEDALIERA E POMPA FRENO / BRAKE PUMP AND PEDAL Page 64

PEDALIERA E POMPA FRENO / BRAKE PUMP AND PEDAL Page 65
CBE12F_FRENO_DI_STAZIONAMENTO_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 1631619CE 1 nr MOLLA A COMPRESSIONE Dm.8 SPRING RESSORT FEDER RESORTE
Da n. 199446 Da n. 199446 Da n. 199446 Da n. 199446 Da n. 199446
1 1869011CE 1 nr MOLLA COMPRES.FILO1-Dm8-L SPRING RESSORT FEDER RESORTE
2 0101023CE 2 nr VITE TCEI M6X18 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
3 0110040CE 3 nr DADO ES. M6 UNI5588 ZINC. NUT ECROU MUTTER TUERCA
4 0100023CE 1 nr VITE TE M6X25 UNI5739 ZIN SCREW VIS SCHRAUBE TORNILLO
5 0101047CE 1 nr VITE TCEI M6X50 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
6 1866026CE 1 nr SUPPORTO STAZ. D.940330 SUPPORT SUPPORT HALTERUNG SOPORTE
6 1779007CE 1 nr SUPPORTO D.001131 SUPPORT SUPPORT HALTERUNG SOPORTE
Da n. 199446 Da n. 199446 Da n. 199446 Da n. 199446 Da n. 199446
7 0120107CE 4 nr [Link] D.6 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
8 2776014CE 2 nr CAVO FRENO STAZIONAMENTO PARKING BRAKE CABLE CABLE FREIN DE PARKING FESTSTELLBREMSKABEL CABLE FRENO DE APARCAMIEN
9 1776063CE 2 nr TERMINALE CAVO FRENO STAZ TERMINAL TERMINAL TERMINAL TERMINAL
10 1776114CE 1 nr LEVA SGANCIO FRENO DI STA RELEASE LEVER LEVIER DE DEBLOCAGE AUSLÍSEHEBEL PALANCA DE DESENGANCHE
Da n. 199446 Da n. 199446 Da n. 199446 Da n. 199446 Da n. 199446
10 1866023CE 1 nr LEVA SGANCIO D.940327 RELEASE LEVER LEVIER DE DEBLOCAGE AUSLÍSEHEBEL PALANCA DE DESENGANCHE
11 0110128CE 1 nr DADO AUTOBLOC. N10/106 ZI SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
12 1773070CE 1 nr PERNO PER CAVO D.940471 PIN PIVOT STIFT PERNO
13 0100120CE 2 nr VITE TE M8X16 UNI5739 ZIN SCREW VIS SCHRAUBE TORNILLO
14 0120108CE 2 nr [Link] D.8 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
15 3776050CE 1 nr PEDALIERA FRENO DI STAZIO PARKING BRAKE PEDAL PEDALE DU FREIN DE PARKIN STANDBREMSPEDAL PEDAL FRENO DE APARCAM.
versione scandinavia scandinavian version
15 3774084CE 1 nr PEDALIERA FRENO DI STAZIO PARKING BRAKE PEDAL PEDALE DU FREIN DE PARKIN STANDBREMSPEDAL PEDAL FRENO DE APARCAM.
Da n. 199446 Da n. 199446 Da n. 199446 Da n. 199446 Da n. 199446
15 3776040CE 1 nr PEDALE FRENO DI STAZIONAM PARKING BRAKE PEDAL PEDALE DU FREIN DE PARKIN STANDBREMSPEDAL PEDAL FRENO DE APARCAM.
16 0023277CE 1 nr COPRIPEDALE AKRON S1417 A PEDAL COVER COUVRE-PEDALE PEDALABDECKUNG PROTECCION DEL PEDAL
17 2774039CE 1 nr PEDALE FRENO DI STAZIONAM PARKING BRAKE PEDAL
17 2772084CE 1 nr PEDALE FRENO BRAKE PEDAL PEDALE DU FREIN BREMSPEDAL PEDAL DEL FRENO
Da n. 199446 Da n. 199446 Da n. 199446 Da n. 199446 Da n. 199446
18 1773296CE 1 nr MOLLA RICHIAMO PEDALE FRE SPRING RESSORT FEDER RESORTE
19 0070661CE 2 nr BOCCOLA FLANGIATA [Link] BUSHING BAGUE BUCHSE BUCHSE
20 1773318CE 1 nr MOLLA A TORSIONE DIS.9605 SPRING RESSORT FEDER RESORTE

FRENO DI STAZIONAMENTO / PARKING BRAKE Page 66

FRENO DI STAZIONAMENTO / PARKING BRAKE Page 67
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
21 1773438CE 1 nr CAVETTO DI SGANCIO CABLE CABLE KABEL CABLE
Da n. 199446 Da n. 199446 Da n. 199446 Da n. 199446 Da n. 199446
21 2774040CE 1 nr CAVETTO SGANCIO PED. FREN CABLE CABLE KABEL CABLE
22 0135238CE 1 nr MORSETTO A VITE D.9 M4X6 TERMINAL BORNE KLEMME TERMINAL
23 1933160CE 1 nr RISCONTRO SETTORE DENTATO HOOK ACCROCHAGE KUPPLUNG ENGANCHE
Da n. 199446 Da n. 199446 Da n. 199446 Da n. 199446 Da n. 199446
23 2774041CE 1 nr SALTARELLO DIS.960292 GEAR ENGRANAGE GETRIEBE ENGRANAJE
24 1777155CE 1 nr MICRO CABLATO D.010093 MICROSWITCH MICRO-INTERRUPTEUR MIKROSCHALTER MICROINTERRUPTOR
versione scandinavia scandinavian version
24 1777069CE 1 nr CABLAGGIO MICRO STAGNO FR WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO

FRENO DI STAZIONAMENTO / PARKING BRAKE Page 68

FRENO DI STAZIONAMENTO / PARKING BRAKE Page 69
CBE12F_MARTINETTO_INCLINAZIONE_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4778014CE 1 nr [Link].2,[Link]-6 TILTING CYLINDER VERIN DE INCLINAISION NEIGUNGZYLINDER CILINDRO DE INCLINACION
1 2778021CE 1 nr TESTA ASTA E=110 ROD HEAD TETE TIGE STANGENKOPF CABEZA VARILLA
2 0013898CE 1 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
3 0070085CE 1 nr SNODO SFERICO GE30ES2RS BALL AND SOCKET JOINT ARTICULATION A ROTULE KUGELGELENK ARTICULACION DE BOLA
4 0110272CE 1 nr DADO ESAGONALE BASSO 24X2 NUT ECROU MUTTER TUERCA
4 1775063CE 1 nr DADO PER SOFFIETTO D.9611 NUT ECROU MUTTER TUERCA
versione scandinavia scandinavian version
5 1775057CE 1 nr CALOTTA CYLINDER HEAD CALOTTE KAPPE TAPA
6 1775064CE 1 nr ASTA ROD TIGE STANGE VARILLA
7 1775059CE 1 nr DISTANZIALE SPACER ECARTEUR ABSTANDSTÜCK DISTANCIADOR
8 1775062CE 1 nr PISTONE PISTON PISTON KOLBEN EMBOLO
9 0110295CE 1 nr DADO AUTOBLOC BASSO 24X2 SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
10 2998158CE 1 nr KIT [Link] GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
11 1774002CE 2 nr PIASTRINO DI FERMO D.9403 STOP PLATE PLAQUE D'ARRET SICHERUNGSBLECH PLACA DE PARADA
12 0120120CE 2 nr [Link]. D.8 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
13 0101036CE 2 nr VITE TCEI M8X20 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
14 0013898CE 1 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
15 0070085CE 1 nr SNODO SFERICO GE30ES2RS BALL AND SOCKET JOINT ARTICULATION A ROTULE KUGELGELENK ARTICULACION DE BOLA
16 1774001CE 2 nr PERNO CON FRESATURA E FOR PIN PIVOT STIFT PERNO
17 0023251CE 1 nr SOFFIETTO ART.186750 (CER BELLOWS SOUFFLET BLASEBALG FUELLE
versione scandinavia scandinavian version

MARTINETTO INCLINAZIONE / TILT JACK Page 70

MARTINETTO INCLINAZIONE / TILT JACK Page 71
This Page Intentionally Blank
CBE12F_ACC_
CBE12F_ACC_ACCESSORI_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 1814072CE 1 nr PROLUNGA GRIGLIA REGGIC.L EXTENDED LOAD BACK-REST 8 DOSSERET DE CHARGE RALLON LASTENSCHUTZGITTER VERLAE PROTECCION DE CARGA ALARG
1 1604266CE 1 nr PROLUNGA GRIGLIA P.L=900 LOAD BACK-REST EXTENSION RALLONGE DE GRILLE DE CHA LASTSCHUTZGITTER VERL¬NG. ALARGADERA PROTECCION DE
1 1604268CE 1 nr [Link] P.L=950 K16/ EXTENSION ARM RALLONGE VERLÄNGERUNG ALARGADERA
1 1604249CE 1 nr PROLUNGA GRIGLIA REGGIC.L LOAD BACK-REST EXTENSION RALLONGE DE GRILLE DE CHA LASTSCHUTZGITTER VERL¬NG. ALARGADERA PROTECCION DE
1 1624363CE 1 nr [Link] REGGIC.L.120 EXTENSION LOAD BACK REST RALLONGE DE GRILLE DE CHA LASTSCHUTZGITTER VERLÄNG. ALARGAD. PROTEC. DE CARGA
1 1854021CE 1 nr PROLUNGA [Link] L=13 LOAD BACK-REST EXTENSION RALLONGE DE GRILLE DE CHA LASTSCHUTZGITTER VERLÄNG. ALARGAD. PROTEC. DE CARGA
1 1624451CE 1 nr [Link] REGGIC.L.150 LOAD BACK-REST EXTENSION RALLONGE DE GRILLE DE CHA LASTSCHUTZGITTER VERL¬NG. ALARGADERA PROTECCION DE
1 1624359CE 1 nr PROLUNGA GRIGIA REGGIC.L= LOAD BACK-REST EXTENSION RALLONGE DE GRILLE DE CHA LASTSCHUTZGITTER VERL¬NG. ALARGADERA PROTECCION DE
2 1604391CE 1 nr GRIGLIA REGGICARICO L=110 LOAD BACK-REST GRILLE DE CHARGE LASTSCHUTZGITTER PROTECCION DE CARGA
2 1604267CE 1 nr GRIGLIA REGGIC.L=950 D.89 LOAD BACK-REST GRILLE DE CHARGE LASTSCHUTZGITTER PROTECCION DE CARGA
2 1604248CE 1 nr GRIGLIA REGGIC.L=1000 D.8 LOAD BACK-REST GRILLE DE CHARGE LASTSCHUTZGITTER PROTECCION DE CARGA
2 1854019CE 1 nr GRIGLIA REGGICARICO L=130 LOAD BACKREST L=1300 GRILLE DE CHARGE LASTSCHUTZGITTER PROTECCION DE CARGA
2 1624362CE 1 nr GRIGLIA [Link].L.120 LOAD BACK-REST GRILLE DE CHARGE LASTSCHUTZGITTER PROTECCION DE CARGA
2 1604265CE 1 nr GRIGLIA REGGIC.P.L=900 K1 LOAD BACK-REST GRILLE DE CHARGE LASTSCHUTZGITTER PROTECCION DE CARGA
2 1764288CE 1 nr GRIGLIA REGGIC.L.1500 DIS LOAD BACK-REST GRILLE DE CHARGE LASTSCHUTZGITTER PROTECCION DE CARGA
2 1814071CE 1 nr GRIGLIA REGGIC.L=850 ECO/ LOAD BACK-REST GRILLE DE CHARGE LASTSCHUTZGITTER PROTECCION DE CARGA
3 3604112CE 1 nr 3604112CE PROLUNGA FORCHE FEM2B D.9
Specificare lunghezza richiest Please specify requested lengh
4 1773172CE 1 nr RETE PER SPORTELLINO PROT SAFETY GUARD GRILLE DE PROTECTION SCHUTZGITTER RED DE PROTECCION
5 1773185CE 1 nr RETE DI PROTEZIONE BLITZ SAFETY GUARD GRILLE DE PROTECTION SCHUTZGITTER RED DE PROTECCION
6 0120107CE 4 nr [Link] D.6 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
7 0135161CE 2 nr VITE TBEI M6X16 UNBRACO T SCREW VIS SCHRAUBE TORNILLO
8 0110040CE 8 nr DADO ES. M6 UNI5588 ZINC. NUT ECROU MUTTER TUERCA
9 1773182CE 6 nr CAVALLOTTO LARGO PER RETE U BOLT (BRACKET) ETRIER BSGEL ESTRIBO
10 1724136CE 8 nr PIASTRINA [Link] PLATE PLAQUE PLATTE PLANCHA
11 0120119CE 18 nr [Link]. D.6 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
12 0135191CE 10 nr VITE T B E I M 6X25 ZINC SCREW VIS SCHRAUBE TORNILLO
13 1773183CE 2 nr CAVALLOTTO STRETTO PER RE U BOLT (BRACKET) ETRIER BSGEL ESTRIBO
14 0135196CE 2 nr VITE TBEI 6X20 UNI 7380 SCREW VIS SCHRAUBE TORNILLO
15 1868009CE 1 nr SUPPORTO SPECCHIO RETROVI SUPPORT SUPPORT HALTERUNG SOPORTE
16 0050102CE 1 nr [Link]. RIF LEFT REARVIEW MIRROR RETROVISEUR GAUCHE LINKER RÜCKSPIEGEL RETROVISOR IZQUIERDO
17 1773366CE 1 nr LAMIERA DI CONTENIMENTO A PLATE (sheet of metal) TOLE BLECH CHAPA
18 1773367CE 1 nr LAMIERA DI CONTENIMENTO P PLATE (sheet of metal) TOLE BLECH CHAPA

LA RICHIESTA DELLA PROLUNGA FORCHE COMPORTA UNA NUOVA TARGHETTATURA DEL CARRELLO / THE REQUEST FOR FORK EXTENSION NEEDS A NEW PLATE ON THE TRUCK / N.D. /
N.D. / N.D.

ACCESSORI / ACCESSORIES Page 74

ACCESSORI / ACCESSORIES Page 75
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
19 1773365CE 1 nr PANNELLO [Link] COMPLETE UPPER PANEL PANNEAU SUPERIEUR COMPLET [Link] PLATTE PANEL SUPERIOR COMPLETO
20 1773366CE 1 nr LAMIERA DI CONTENIMENTO A PLATE (sheet of metal) TOLE BLECH CHAPA
21 1773367CE 1 nr LAMIERA DI CONTENIMENTO P PLATE (sheet of metal) TOLE BLECH CHAPA

LA RICHIESTA DELLA PROLUNGA FORCHE COMPORTA UNA NUOVA TARGHETTATURA DEL CARRELLO / THE REQUEST FOR FORK EXTENSION NEEDS A NEW PLATE ON THE TRUCK / N.D. /
N.D. / N.D.

ACCESSORI / ACCESSORIES Page 76

ACCESSORI / ACCESSORIES Page 77
CBE12F_ACC_DISPOSITIVI_DI_SEGNALAZIONE_VISIVA_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 0053154CE 1 nr INTERRUTTORE BASCULANTE C SWITCH INTERRUPTEUR INTERRUPTOR INTERRUPTOR
2 0057877CE 1 nr VETRINO "COBO" RIF.13.350 GLASS VITRE GLASSCHEIBE CRISTAL
3 0057924CE 1 nr VETRINO [Link] 13.350.0 GLASS VITRE GLASSCHEIBE CRISTAL
4 0057871CE 1 nr PANNELLO A 6 VIE "COBO" R PANEL PANNEAU PLATTE PANEL
5 0057870CE 4 nr TAPPO "COBO" rif.30.33.04 PLUG BOUCHON VERSCHLUSS TAPON
6 0054738CE 2 nr PORTAFUSIBILE INNESTI LAM FUSE CARRIER DOUILLE DES FUSIBLES SICHERUNGSTR?GER PORTAFUSIBLE
7 0054713CE 1 nr FUSIBILE A LAMA 5A DIN 72 FUSE FUSIBLE SICHERUNG FUSIBLE
8 0054739CE 2 nr COPERCHIO PORTAFUSIBILI M COVER COUVERCLE DECKEL TAPA
9 0057883CE 1 nr FUSIBILE A LAMA 7,5A-32V FUSE FUSIBLE SICHERUNG FUSIBLE
10 0050153CE 1 nr LAMPADA ROTANTE 24V 70W r REVOLVING WARNING LIGHT CLIGNOTANT D'URGENCE WARNBLINKANLAGE REMPLAGUEADOR DE EMERGENC
11 0992584CE 1 nr LAMPADINA BA 15S 45W 48V. BULB LAMPE GLÜHBIRNE BOMBILLA
12 0050134CE 1 nr LAMPADA FLASH ELEV 1 FLASHING BEACON GIROPHARE RUNDUMLEUCHTEN FARO ROTATIVO DESTELLANTE
13 1777217CE 1 nr CABLAGGIO FARI DI LAVORO WIRING HARNESS
14 1777159CE 1 nr CABLAGGIO LAMPADA ROTANTE
15 0050139CE 2 nr FARO LAVORO C/[Link].2 OPERATION LIGHTHOUSE PHARE DE TRAVAIL ORIENTIERBARER FARO DE TRABAJO
16 0050128CE 2 nr LAMPADA ALOGENA H3 24V 70 LAMP AMPOULE LAMPE LAMPARA
17 1868018CE 1 nr SUPPORTO FARO ANTERIORE D SUPPORT SUPPORT HALTERUNG SOPORTE
18 1868017CE 1 nr SUPPORTO FARO ANTERIORE S SUPPORT SUPPORT HALTERUNG SOPORTE
19 0101021CE 3 nr VITE TCEI M6X12 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
20 1773190CE 1 nr SUPPORTO LAMPADA ROTANTE SUPPORT SUPPORT HALTERUNG SOPORTE
21 0120107CE 4 nr [Link] D.6 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
22 0135196CE 4 nr VITE TBEI 6X20 UNI 7380 SCREW VIS SCHRAUBE TORNILLO
23 1777109CE 1 nr CABLAGGIO PER NR.2 FARI A WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
24 0120119CE 1 nr [Link]. D.6 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
25 0120107CE 1 nr [Link] D.6 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
26 0110040CE 1 nr DADO ES. M6 UNI5588 ZINC. NUT ECROU MUTTER TUERCA
27 0054880CE 1 nr ALIMENTATORE DC-DC 24v 36 POWER SUPPLY ALIMENTATEUR SPEISER ALIMENTADOR
27 0054861CE 1 nr ALIMENTATORE DC-DC 24v 24 POWER SUPPLY ALIMENTATEUR SPEISER ALIMENTADOR
28 0057959CE 1 nr AVVISATORE ACUSTICO INTER WARNING HORN KLAXON HORN CLAXON
29 0135153CE 2 nr VITE TBEI M8X15 UNBRAKO T SCREW VIS SCHRAUBE TORNILLO
30 0100113CE 1 nr VITE TE M6X16 UNI5739 ZIN SCREW VIS SCHRAUBE TORNILLO
31 1777062CE 1 nr CABLAGGIO SEGNALATORE ACU WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
32 1777102CE 1 nr CABLAGGIO AVVISATORE ACUS WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
33 1777117CE 1 nr DIODO CABLATO PER AVVISAT DIODE DIODE DIODE DIODE
34 1777115CE 1 nr CABLAGGIO IMPIANTI OPZION WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
35 0053114CE 1 nr INTERRUTTORE "COBO" RIF.1 SWITCH INTERRUPTEUR INTERRUPTOR INTERRUPTOR
36 0135196CE 2 nr VITE TBEI 6X20 UNI 7380 SCREW VIS SCHRAUBE TORNILLO

DISPOSITIVI DI SEGNALAZIONE VISIVA E DI ILLUMINAZIONE / LIGHTING EQUIPMENT AND ATTACHMENTS Page 78

DISPOSITIVI DI SEGNALAZIONE VISIVA E DI ILLUMINAZIONE / LIGHTING EQUIPMENT AND ATTACHMENTS Page 79
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
37 0120107CE 2 nr [Link] D.6 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
38 0120044CE 2 nr [Link]. D.6 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA

DISPOSITIVI DI SEGNALAZIONE VISIVA E DI ILLUMINAZIONE / LIGHTING EQUIPMENT AND ATTACHMENTS Page 80

DISPOSITIVI DI SEGNALAZIONE VISIVA E DI ILLUMINAZIONE / LIGHTING EQUIPMENT AND ATTACHMENTS Page 81
CBE12F_ACC_IMP_LUCI_PER_CIRCOLAZIONE_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 0053114CE 1 nr INTERRUTTORE "COBO" RIF.1 SWITCH INTERRUPTEUR INTERRUPTOR INTERRUPTOR
2 0057874CE 1 nr VETRINO "COBO" RIF.13.350 GLASS VITRE GLASSCHEIBE CRISTAL
3 0057924CE 1 nr VETRINO [Link] 13.350.0 GLASS VITRE GLASSCHEIBE CRISTAL
4 0057871CE 1 nr PANNELLO A 6 VIE "COBO" R PANEL PANNEAU PLATTE PANEL
5 0057870CE 4 nr TAPPO "COBO" rif.30.33.04 PLUG BOUCHON VERSCHLUSS TAPON
6 0057881CE 1 nr PORTAFUSIBILE A 8 VIE RIF FUSE CARRIER DOUILLE DES FUSIBLES SICHERUNGSTR?GER PORTAFUSIBLE
7 0057883CE 2 nr FUSIBILE A LAMA 7,5A-32V FUSE FUSIBLE SICHERUNG FUSIBLE
8 1773275CE 1 nr PIASTRA PORTA COMPONENTI PLATE PLAQUE PLATTE PLANCHA
9 0054713CE 1 nr FUSIBILE A LAMA 5A DIN 72 FUSE FUSIBLE SICHERUNG FUSIBLE
10 0023048CE 2 nr POMELLO VC 254/60 B M10 KNOB BOUTON KNOPF PERILLA
11 1653116CE 1 nr BANDINELLA PROTEZ. FORCHE SUPPORT SUPPORT HALTERUNG SOPORTE
12 0050096CE 1 mt ROTOLO MT45 BANDA AUTOA LABEL ETIQUETTE AUFKLEBER ETIQUETA
13 1653117CE 1 nr PROTEZIONE FORCHE INFER. GUARD PROTECTION SCHUTZ PROTECCION
14 0135161CE 2 nr VITE TBEI M6X16 UNBRACO T SCREW VIS SCHRAUBE TORNILLO
15 0120107CE 6 nr [Link] D.6 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
16 0050102CE 1 nr [Link]. RIF LEFT REARVIEW MIRROR RETROVISEUR GAUCHE LINKER RÜCKSPIEGEL RETROVISOR IZQUIERDO
17 0135196CE 2 nr VITE TBEI 6X20 UNI 7380 SCREW VIS SCHRAUBE TORNILLO
18 1868009CE 1 nr SUPPORTO SPECCHIO RETROVI SUPPORT SUPPORT HALTERUNG SOPORTE
19 0050153CE 2 nr LAMPADA ROTANTE 24V 70W r REVOLVING WARNING LIGHT CLIGNOTANT D'URGENCE WARNBLINKANLAGE REMPLAGUEADOR DE EMERGENC
20 0101102CE 4 nr VITE TCEI M6X20 UNI5931 1 SCREW VIS SCHRAUBE TORNILLO
21 0120107CE 4 nr [Link] D.6 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
22 0120044CE 4 nr [Link]. D.6 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
23 0101143CE 6 nr VITE TCEI M6X12 UNI5931 T SCREW VIS SCHRAUBE TORNILLO
24 1773190CE 2 nr SUPPORTO LAMPADA ROTANTE SUPPORT SUPPORT HALTERUNG SOPORTE
25 0050125CE 2 nr FANALE ANTERIORE LUCE DI HEADLIGHT FEU ANTERIEUR VORDERLEUCHTE LUZ ANTERIOR
26 0050099CE 2 nr LAMPADA 24V-50/45W BILUX LAMP AMPOULE LAMPE LAMPARA
27 0110117CE 2 nr DADO AUTOBLOC. N/70/110 Z SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
28 1863170CE 2 nr STAFFA FANALE ANTERIORE D BRACKET ETRIER BSGEL ESTRIBO
29 1868011CE 2 nr SUPPORTO FARO [Link] SUPPORT SUPPORT HALTERUNG SOPORTE
30 1777113CE 1 nr CABLAGGIO [Link] CIRCOL WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
31 0054675CE 1 nr CONVERTITORE DC/DC 16A-24 CONVERTER CONVERTISSEUR WANDLER CONVERTIDOR
32 1607352CE 1 nr DIODO CABLATO 1N4007 D.89 DIODE DIODE DIODE DIODE
33 0053100CE 1 nr CLACSON "BELLI" 24V MOD.9 ELECTRIC HORN AVERTISSEUR SONORE SIGNALHORN CLAXON

LA RICHIESTA DELL' IMPIANTO LUCI COMPORTA UNA NUOVA TARGHETTATURA DEL CARRELLO / THE REQUEST FOR STREET LIGHTING SYSTEM NEEDS A NEW PLATE ON THE TRUCK / N.D. /
N.D. / N.D.

IMPIANTO LUCI PER CIRCOLAZIONE SU STRADA TRATTE BREVI (SALTUARIA) / STREET LIGHTING SYSTEM ONLY ITALY Page 82
IMPIANTO LUCI PER CIRCOLAZIONE SU STRADA TRATTE BREVI (SALTUARIA) / STREET LIGHTING SYSTEM ONLY ITALY Page 83
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
34 0053154CE 1 nr INTERRUTTORE BASCULANTE C SWITCH INTERRUPTEUR INTERRUPTOR INTERRUPTOR
35 0135248CE 2 nr VITE TBEI M6X12 UNI7380 8 SCREW VIS SCHRAUBE TORNILLO

LA RICHIESTA DELL' IMPIANTO LUCI COMPORTA UNA NUOVA TARGHETTATURA DEL CARRELLO / THE REQUEST FOR STREET LIGHTING SYSTEM NEEDS A NEW PLATE ON THE TRUCK / N.D. /
N.D. / N.D.

IMPIANTO LUCI PER CIRCOLAZIONE SU STRADA TRATTE BREVI (SALTUARIA) / STREET LIGHTING SYSTEM ONLY ITALY Page 84
IMPIANTO LUCI PER CIRCOLAZIONE SU STRADA TRATTE BREVI (SALTUARIA) / STREET LIGHTING SYSTEM ONLY ITALY Page 85
CBE12F_ACC_IMP_LUCI_COMPLETO_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 0020412CE 1 nr DEVIATORE FRECCE RIF.15.1 DIRECTION INDICATOR SWITC RUPTEUR POUR MICRO DE DIR RICHTUNGSSCHALTER CAMBIADOR DE DIRECCION
2 1776082CE 1 nr CARENATURA PIANTONE PER I STEERING COLUMN COVER CARTER COLONNE DE DIRECTI LENKS¬ULEGEH¬USE CARTER COLUMNA DE DIRECCI
3 0050132CE 2 nr LAMPADINA 24V 1.2W RIF.00 BULB LAMPE GLÜHBIRNE BOMBILLA
4 0053152CE 1 nr CORPO PORTA 2 SPIE rif.09 DOOR CASING CORPS PORTE KLAPPENGEHÄUSE CUERPO PUERTA
5 0057880CE 1 nr VETRINO ARANCIO "COBO" R GLASS VITRE GLASSCHEIBE CRISTAL
6 0053151CE 1 nr VETRINO "COBO" RIF.13.350 GLASS VITRE GLASSCHEIBE CRISTAL
7 0053145CE 1 nr INTERRUTTORE BASCUL.RIF16 SWITCH INTERRUPTEUR INTERRUPTOR INTERRUPTOR
8 0057874CE 1 nr VETRINO "COBO" RIF.13.350 GLASS VITRE GLASSCHEIBE CRISTAL
9 0057871CE 1 nr PANNELLO A 6 VIE "COBO" R PANEL PANNEAU PLATTE PANEL
10 0057870CE 4 nr TAPPO "COBO" rif.30.33.04 PLUG BOUCHON VERSCHLUSS TAPON
11 0057883CE 1 nr FUSIBILE A LAMA 7,5A-32V FUSE FUSIBLE SICHERUNG FUSIBLE
12 0054713CE 2 nr FUSIBILE A LAMA 5A DIN 72 FUSE FUSIBLE SICHERUNG FUSIBLE
13 0057881CE 1 nr PORTAFUSIBILE A 8 VIE RIF FUSE CARRIER DOUILLE DES FUSIBLES SICHERUNGSTR?GER PORTAFUSIBLE
14 1773275CE 1 nr PIASTRA PORTA COMPONENTI PLATE PLAQUE PLATTE PLANCHA
15 0050125CE 2 nr FANALE ANTERIORE LUCE DI HEADLIGHT FEU ANTERIEUR VORDERLEUCHTE LUZ ANTERIOR
16 0050099CE 2 nr LAMPADA 24V-50/45W BILUX LAMP AMPOULE LAMPE LAMPARA
17 0019063CE 2 nr LAMPADA 24V-3W MICRO BAIO LAMP AMPOULE LAMPE LAMPARA
18 1863170CE 2 nr STAFFA FANALE ANTERIORE D BRACKET ETRIER BSGEL ESTRIBO
19 1868011CE 2 nr SUPPORTO FARO [Link] SUPPORT SUPPORT HALTERUNG SOPORTE
20 0057860CE 1 nr INTERMITTENZA 24v-47w "CO INTERMITTENCE INTERMITTENCE BLINKGEBER INTERMITENCIA
21 0057973CE 1 nr CONVERTITORE DC/DC 30-95/ CONVERTER CONVERTISSEUR WANDLER CONVERTIDOR
240 W 240 W
21 0054675CE 1 nr CONVERTITORE DC/DC 16A-24 CONVERTER CONVERTISSEUR WANDLER CONVERTIDOR
340 W 340 W
22 0018331CE 2 nr LAMPADINA 24V-5W SFERA AT BULB LAMPE GLÜHBIRNE BOMBILLA
23 0057670CE 4 nr LAMPADINA 24V-21W [Link] BULB LAMPE GLÜHBIRNE BOMBILLA
24 1868013CE 2 nr SUPPORTO INDICATORE DI DI SUPPORT SUPPORT HALTERUNG SOPORTE
25 0050052CE 1 nr INDICATORE DI DIREZIONE D INDICATOR INDICATEUR ANZEIGER INDICADOR
26 0050053CE 1 nr LAMPEGGIATORE [Link] 0001 FLASHLIGHT CLIGNOTANT BLINKLEUCHTE LUZ INTERMITENTE
27 1777110CE 1 nr CABLAGGIO IMPIANTO LUCI C WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO

IMPIANTO LUCI COMPLETO / COMPLETE LIGHTING EQUIPMENT Page 86

IMPIANTO LUCI COMPLETO / COMPLETE LIGHTING EQUIPMENT Page 87
CBE12F_ACC_CABINA_B_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4774233CE 1 nr CABINA RIALZATA H=2100 C/ CAB CABINE KABINE CABINA
1 3774119CE 1 nr KIT PANNELLO ANTERIORE RI PANEL KIT JEU PANNEAU PLATTESATZ JUEGO PANEL
2 0993944CE 1 nr VETRO [Link] H=+150 FRONT GLASS VITRE AVANT VORDERE GLASSCHEIBE CRISTAL DELANTERO
3 0992387CE 1 mt GUARNIZIONE X [Link]. R GASKET GARNITURE DICHTUNG VAINA
Var. Var.
4 0992058CE 1 nr SPAZZOLA TERGICRISTALLO R BRUSH BALAI BÜRSTE ESCOBILLA
5 0993692CE 1 nr SPRUZZINO LAVA VETRI FORG SPRAY SPRAY SPRITZER PULVERIZADOR
6 0992987CE 1 nr BRACCIO TERGICRISTALLO RI ARM BRAS ARM BRAZO
7 0993679CE 3 nr RONDELLA RIF. 2000114 WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
8 0993680CE 2 nr BORCHIA SVASATA RIF.20001 THREADED BUSHING BAGUE FILETEE GEWINDEBUCHSE CASQUILLO ROSCADO
9 0992133CE 2 nr DISTANZIALE GOMMA PER VET SPACER ECARTEUR ABSTANDSTÜCK DISTANCIADOR
10 0993558CE 1 nr SERIGRAFIA ADESIVA FORGH LABEL ETIQUETTE AUFKLEBER ETIQUETA
11 0992986CE 1 nr MOTORINO TERGICRISTALLO V WIPER MOTOR MOTEUR ESSUIE GLACE WISCHERMOTOR MOTOR LIMPIAPARABRISAS
12 0993489CE 4 nr BORCHIA SVASATA RIF. 2007 THREADED BUSHING BAGUE FILETEE GEWINDEBUCHSE CASQUILLO ROSCADO
13 0993488CE 8 nr GUARNIZIONE PER VETRO R GASKET GARNITURE DICHTUNG VAINA
14 0993581CE 1 nr STAFFA DI FISSAGGIO PANNE BRACKET ETRIER BÜGEL ESTRIBO
15 0993490CE 4 nr COPRIDADO M8 RIF. 2004 NUT ECROU MUTTER TUERCA
16 3774126CE 1 nr KIT TETTO COMPLETO RIALZ. KIT JEU SATZ JUEGO
17 3774076CE 1 nr KIT CAPPELLINO rif.400109 KIT JEU SATZ JUEGO
18 0993778CE 2 nr STAFFA TETTO RIF.3103617 BRACKET ETRIER BSGEL ESTRIBO
19 0992379CE 1 nr GUARNIZIONE PORTA DX-SX R GASKET GARNITURE DICHTUNG VAINA
Var. Var.
20 0993392CE 1 nr POMELLO M8X30 RIF.2040230 KNOB BOUTON KNOPF PERILLA
21 0993746CE 1 mt PROFILO OPEL PICCOLO RIF. PROFILE PROFIL PROFIL PERFIL
Var. Var.
22 3774121CE 1 nr KIT TETTO BLITZ 12/18 FOR KIT JEU SATZ JUEGO
23 0992059CE 1 nr SPECCHIO RETROVISORE INTE REARVIEW MIRROR RETROVISEUR R?CKSPIEGEL ESPEJO RETROVISOR
24 0993984CE 1 nr INSONORIZZANTE TETTO POST SOUND PROOFING MATERIAL ISOLANT ACOUSTIQUE SCHALLD?MMEND INSONORIZANTE
25 0993987CE 1 nr VETRO IN LEXAN PER TETTO ROOF GLASS VITRE TOIT DACHGLASSCHEIBE CRISTAL TECHO
26 3774120CE 1 nr KIT PANNELLO POSTERIORE C PANEL KIT JEU PANNEAU PLATTESATZ JUEGO PANEL
27 0993988CE 1 nr VETRO POSTER.C/RESISTENZA REAR GLASS VITRE ARRIERE HINTERE GLASSCHEIBE CRISTAL TRASERO
28 0993598CE 2 nr ATTACCO MOLLA GAS RIF.200 CONNECTION EMBOUT ANSCHLUSS CONEXION
29 0992952CE 2 nr MOLLA A GAS X CABINA 4774 GAS SPRING RESSORT A GAZ GASFEDER RESORTE A GAS
31 0993412CE 1 nr BRACCIO TERGICRISTALLO R ARM BRAS ARM BRAZO
32 0991683CE 1 nr SPAZZOLA TERGI ANTER. RIF BRUSH BALAI BÜRSTE ESCOBILLA
33 0993442CE 1 nr MOTORINO TERGICRISTALLO R WIPER MOTOR MOTEUR ESSUIE GLACE WISCHERMOTOR MOTOR LIMPIAPARABRISAS
34 0993964CE 1 mt GUARNIZIONE GUISNAP C/ALE GASKET GARNITURE DICHTUNG VAINA
Var. Var.

CABINA +150mm (VERSIONE SCANDINAVIA ) / CABIN +150mm (SCANDINAVIAN VERSION) Page 88

CABINA +150mm (VERSIONE SCANDINAVIA ) / CABIN +150mm (SCANDINAVIAN VERSION) Page 89
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
35 0993631CE 1 nr MANIGLIA DX RIF.2007553 HANDLE POIGNEE HANDGRIFF MANILLA
35 0993632CE 1 nr MANIGLIA SX RIF.2007552 HANDLE POIGNEE HANDGRIFF MANILLA
36 0993599CE 2 nr GUARNIZIONE X MANIGLIA PO GASKET GARNITURE DICHTUNG VAINA
37 0993468CE 2 nr RISCONTRO MANIGLIA POST.R HOOK ACCROCHAGE KUPPLUNG ENGANCHE
38 0992055CE 1 mt GUARNIZIONE X VETRO LAT.R GASKET GARNITURE DICHTUNG VAINA
Var. Var.
39 0992056CE 1 mt PROFILO X [Link] LAT PROFILE PROFIL PROFIL PERFIL
Var. Var.
40 0993786CE 1 nr CERNIERA X PANNELLO POST. HINGE CHARNIERE GELENK BISAGRA
41 3774123CE 1 nr KIT PORTA DX BLITZ 12/15 KIT JEU SATZ JUEGO
41 3774124CE 1 nr KIT PORTA SX BLITZ 12/15 KIT JEU SATZ JUEGO
42 0993959CE 1 nr SERRATURA SCONTRO RIF.200 LOCK SERRURE SCHLOSS CERRADURA
43 0993474CE 1 mt GUARNIZIONE PORTIERA RIF. GASKET GARNITURE DICHTUNG VAINA
Var. Var.
44 0993934CE 1 nr RULLINO REGGIPORTA ASSEMB ROLLER ROULEAU ROLLE RODILLO
45 0993958CE 1 nr SERRATURA ESTERNA SX RIF. LEFT LOCK SERRURE GAUCHE LINKES SCHLOSS CERRADURA IZQUIERDA
45 0993957CE 1 nr SERRATURA ESTERNA DX RIF. RIGHT LOCK SERRURE DROITE RECHTES SCHLOSS CERRADURA DERECHA
46 0993472CE 1 nr SERRATURA COMPLETA SX RIF LEFT LOCK SERRURE GAUCHE LINKES SCHLOSS CERRADURA IZQUIERDA
46 0993473CE 1 nr SERRATURA COMPLETA DX RIF RIGHT LOCK SERRURE DROITE RECHTES SCHLOSS CERRADURA DERECHA
47 0993681CE 2 nr CERNIERA RIF.3400003 HINGE CHARNIERE GELENK BISAGRA
48 0993660CE 2 nr PERNO CERNIERA PORTA CONNECTION EMBOUT ANSCHLUSS CONEXION
49 0993784CE 1 nr MOLLA A GAS L=355 C/OCC. GAS SPRING RESSORT A GAZ GASFEDER RESORTE A GAS
50 0993990CE 1 nr VETRO SCORREVOLE SX C/FIN SIDE SLIDING GLASS VITRE LATERALE COULISSANT GLEITENDE SEITENGLASSCHEI CRISTAL LATERAL DESLIZAB
50 0993980CE 1 nr VETRO SCORREVOLE C/FINEST SIDE SLIDING GLASS VITRE LATERALE COULISSANT GLEITENDE SEITENGLASSCHEI CRISTAL LATERAL DESLIZAB
51 0993981CE 1 nr VETRO FISSO [Link]-SX R FRONT GLASS VITRE AVANT VORDERE GLASSCHEIBE CRISTAL DELANTERO
53 0993414CE 1 mt GUARNIZIONE BAULE R GASKET GARNITURE DICHTUNG VAINA
54 1773393CE 1 nr PIASTRINO FISSAGGIO MANIG PLATE PLAQUE PL¬TTCHEN PLACA
55 0070735CE 1 nr MANIGLIA RHRS-20.300.62 " HANDLE POIGNEE HANDGRIFF MANILLA
56 0054738CE 1 nr PORTAFUSIBILE INNESTI LAM FUSE CARRIER DOUILLE DES FUSIBLES SICHERUNGSTR?GER PORTAFUSIBLE
57 0057883CE 1 nr FUSIBILE A LAMA 7,5A-32V FUSE FUSIBLE SICHERUNG FUSIBLE
58 0054739CE 1 nr COPERCHIO PORTAFUSIBILI M COVER COUVERCLE DECKEL TAPA
59 4778027CE 1 nr MARTINETTO INCLIN.2gr.30' TILTING CYLINDER VERIN DE INCLINAISION NEIGUNGZYLINDER CILINDRO DE INCLINACION
Solo per 3 montanti V.T. e A.L Only for C.V and F.F.L. triple
60 1775070CE 1 nr ASTA ROD TIGE STANGE VARILLA
Solo per 3 montanti V.T. e A.L Only for C.V and F.F.L. triple
61 2998158CE 1 nr KIT [Link] GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
Solo per 3 montanti V.T. e A.L Only for C.V and F.F.L. triple

CABINA +150mm (VERSIONE SCANDINAVIA ) / CABIN +150mm (SCANDINAVIAN VERSION) Page 90

CABINA +150mm (VERSIONE SCANDINAVIA ) / CABIN +150mm (SCANDINAVIAN VERSION) Page 91
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
62 0054860CE 1 nr ALIMENTATORE DC-DC 24v 14 POWER SUPPLY ALIMENTATEUR SPEISER ALIMENTADOR
140 W 140 W
63 0135153CE 2 nr VITE TBEI M8X15 UNBRAKO T SCREW VIS SCHRAUBE TORNILLO
64 1777108CE 1 nr CABLAGGIO TERGICRISTALLO WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
65 1776088CE 1 nr PERNO MORSETTO PER CABINA PIN PIVOT STIFT PERNO
66 1866047CE 1 nr PIASTRINO PER LIMITAZIONE PLATE PLAQUE PL¬TTCHEN PLACA

CABINA +150mm (VERSIONE SCANDINAVIA ) / CABIN +150mm (SCANDINAVIAN VERSION) Page 92

CABINA +150mm (VERSIONE SCANDINAVIA ) / CABIN +150mm (SCANDINAVIAN VERSION) Page 93
CBE12F_ACC_CABINA_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4774191CE 1 nr CABINA COMPLETA STD "FORG CAB
2 4774172CE 1 nr CABINA C/LUNOTTO TERMICO CAB CABINE KABINE CABINA
4 3774073CE 1 nr KIT PANNELLO ANTERIORE ri PANEL KIT JEU PANNEAU PLATTESATZ JUEGO PANEL
5 0993587CE 2 nr VETRO [Link].3004560 F FRONT GLASS VITRE AVANT VORDERE GLASSCHEIBE CRISTAL DELANTERO
6 0992387CE 1 mt GUARNIZIONE X [Link]. R GASKET GARNITURE DICHTUNG VAINA
7 0992058CE 1 nr SPAZZOLA TERGICRISTALLO R BRUSH BALAI BÜRSTE ESCOBILLA
8 0993692CE 1 nr SPRUZZINO LAVA VETRI FORG SPRAY SPRAY SPRITZER PULVERIZADOR
9 0992987CE 1 nr BRACCIO TERGICRISTALLO RI ARM BRAS ARM BRAZO
10 0993679CE 3 nr RONDELLA RIF. 2000114 WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
11 0993680CE 2 nr BORCHIA SVASATA RIF.20001 THREADED BUSHING BAGUE FILETEE GEWINDEBUCHSE CASQUILLO ROSCADO
12 0992133CE 2 nr DISTANZIALE GOMMA PER VET SPACER ECARTEUR ABSTANDSTÜCK DISTANCIADOR
13 0993558CE 1 nr SERIGRAFIA ADESIVA FORGH LABEL ETIQUETTE AUFKLEBER ETIQUETA
14 0992986CE 1 nr MOTORINO TERGICRISTALLO V WIPER MOTOR MOTEUR ESSUIE GLACE WISCHERMOTOR MOTOR LIMPIAPARABRISAS
15 0993489CE 4 nr BORCHIA SVASATA RIF. 2007 THREADED BUSHING BAGUE FILETEE GEWINDEBUCHSE CASQUILLO ROSCADO
16 0993488CE 8 nr GUARNIZIONE PER VETRO R GASKET GARNITURE DICHTUNG VAINA
17 0993507CE 4 nr STAFFA [Link] [Link] BRACKET ETRIER BSGEL ESTRIBO
18 0993490CE 4 nr COPRIDADO M8 RIF. 2004 NUT ECROU MUTTER TUERCA
19 3774077CE 1 nr KIT PORTA DS RIF.4001116 KIT JEU SATZ JUEGO
21 0993781CE 4 nr SUPPORTO CERNIERA X CABIN SUPPORT SUPPORT HALTERUNG SOPORTE
22 0993660CE 4 nr PERNO CERNIERA PORTA CONNECTION EMBOUT ANSCHLUSS CONEXION
23 0993473CE 1 nr SERRATURA COMPLETA DX RIF RIGHT LOCK SERRURE DROITE RECHTES SCHLOSS CERRADURA DERECHA
24 0992913CE 1 nr SCONTRO INT. SERRATURA RETAINER ARRET FESTSTELLER RETEN
25 0993470CE 2 nr COPPIA MANIGLIE RIF.200 HANDLES KIT JEU POIGNEES HANDGRIFFSATZ JUEGO MANILLAS
26 0993474CE 1 mt GUARNIZIONE PORTIERA RIF. GASKET GARNITURE DICHTUNG VAINA
27 0992055CE 1 mt GUARNIZIONE X VETRO LAT.R GASKET GARNITURE DICHTUNG VAINA
28 0992056CE 1 mt PROFILO X [Link] LAT PROFILE PROFIL PROFIL PERFIL
29 0993785CE 1 nr VETRO LAT. FISSO PORTA DX SIDE GLASS VITRE LATERALE SEITENGLASSCHEIBE CRISTAL LATERAL
30 0993414CE 1 mt GUARNIZIONE BAULE R GASKET GARNITURE DICHTUNG VAINA
31 3774097CE 1 nr KIT TETTO COMPLETO rif.45 KIT JEU SATZ JUEGO
32 3774075CE 1 nr KIT TETTO rif.4001090 "FO KIT JEU SATZ JUEGO
33 0993394CE 1 nr GUARNIZIONE PER TETTO R GASKET GARNITURE DICHTUNG VAINA
34 0993805CE 1 nr FONOASSORBENTE TETTO POST ACOUSTIC INSULATION INSONORISANT SCHALLSCHLUCKER FONOABSORBENTE
35 0992059CE 1 nr SPECCHIO RETROVISORE INTE REARVIEW MIRROR RETROVISEUR R?CKSPIEGEL ESPEJO RETROVISOR
36 0993777CE 1 nr TETTO LEXAN RIF.3103645 OVERHEAD GUARD ROOF TOIT PROTECTION-CONDUCTEU FAHRERSCHUTZDACH TECHO PROTECC. CONDUCTOR
37 3774076CE 1 nr KIT CAPPELLINO rif.400109 KIT JEU SATZ JUEGO
38 0992379CE 1 nr GUARNIZIONE PORTA DX-SX R GASKET GARNITURE DICHTUNG VAINA
39 0993392CE 2 nr POMELLO M8X30 RIF.2040230 KNOB BOUTON KNOPF PERILLA

CABINA fino a N° 209642 / CABIN up to the N° 209642 Page 94

CABINA fino a N° 209642 / CABIN up to the N° 209642 Page 95
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
40 0993778CE 2 nr STAFFA TETTO RIF.3103617 BRACKET ETRIER BSGEL ESTRIBO
41 0993746CE 1 mt PROFILO OPEL PICCOLO RIF. PROFILE PROFIL PROFIL PERFIL
42 3774074CE 1 nr KIT PANNELLO POSTERIORE C PANEL KIT JEU PANNEAU PLATTESATZ JUEGO PANEL
43 0993718CE 1 nr VETRO POST.C/RESISTENZA R REAR GLASS VITRE ARRIERE HINTERE GLASSCHEIBE CRISTAL TRASERO
44 0993598CE 2 nr ATTACCO MOLLA GAS RIF.200 CONNECTION EMBOUT ANSCHLUSS CONEXION
45 0992952CE 2 nr MOLLA A GAS X CABINA 4774 GAS SPRING RESSORT A GAZ GASFEDER RESORTE A GAS
46 0991683CE 1 nr SPAZZOLA TERGI ANTER. RIF BRUSH BALAI BÜRSTE ESCOBILLA
47 0993412CE 1 nr BRACCIO TERGICRISTALLO R ARM BRAS ARM BRAZO
48 0993442CE 1 nr MOTORINO TERGICRISTALLO R WIPER MOTOR MOTEUR ESSUIE GLACE WISCHERMOTOR MOTOR LIMPIAPARABRISAS
49 0993414CE 1 mt GUARNIZIONE BAULE R GASKET GARNITURE DICHTUNG VAINA
50 0993631CE 1 nr MANIGLIA DX RIF.2007553 HANDLE POIGNEE HANDGRIFF MANILLA
51 0993599CE 1 nr GUARNIZIONE X MANIGLIA PO GASKET GARNITURE DICHTUNG VAINA
52 0993468CE 1 nr RISCONTRO MANIGLIA POST.R HOOK ACCROCHAGE KUPPLUNG ENGANCHE
53 0993786CE 1 nr CERNIERA X PANNELLO POST. HINGE CHARNIERE GELENK BISAGRA
54 3774081CE 1 nr 3774081CE
55 0993780CE 1 nr VETRO POST. STD RIF.30048 REAR GLASS VITRE ARRIERE HINTERE GLASSCHEIBE CRISTAL TRASERO
56 3774078CE 1 nr KIT PORTA SN RIF.4001115 KIT JEU SATZ JUEGO
58 0993784CE 1 nr MOLLA A GAS L=355 C/OCC. GAS SPRING RESSORT A GAZ GASFEDER RESORTE A GAS
59 0993472CE 1 nr SERRATURA COMPLETA SX RIF LEFT LOCK SERRURE GAUCHE LINKES SCHLOSS CERRADURA IZQUIERDA
60 0993782CE 1 nr VETRO FISSO INF. PORTA SX FRONT LOWER GLASS VITRE AVANT INFERIEURE UNTERE VORDERGLASSCHEIBE CRISTAL DELANTERO INFERI
61 0993783CE 1 nr KIT VETRI SCORR C/TELAIO SLIDING GLASS KIT JEU GLACE COULISSANTE SCHIEBESEITENGLAS-SATZ JUEGO CRISTAL DESLIZABLE
62 1773393CE 1 nr PIASTRINO FISSAGGIO MANIG PLATE PLAQUE PL¬TTCHEN PLACA
63 0070735CE 2 nr MANIGLIA RHRS-20.300.62 " HANDLE POIGNEE HANDGRIFF MANILLA
64 0054738CE 1 nr PORTAFUSIBILE INNESTI LAM FUSE CARRIER DOUILLE DES FUSIBLES SICHERUNGSTR?GER PORTAFUSIBLE
65 0057883CE 1 nr FUSIBILE A LAMA 7,5A-32V FUSE FUSIBLE SICHERUNG FUSIBLE
66 0054739CE 1 nr COPERCHIO PORTAFUSIBILI M COVER COUVERCLE DECKEL TAPA
67 4778027CE 1 nr MARTINETTO INCLIN.2gr.30' TILTING CYLINDER VERIN DE INCLINAISION NEIGUNGZYLINDER CILINDRO DE INCLINACION
Solo per 3 MONTANTI V.T. e 3 M Only for C.V. TRIPLEX MASTS GR
68 1775070CE 1 nr ASTA ROD TIGE STANGE VARILLA
Solo per 3 MONTANTI V.T. e 3 M Only for C.V. TRIPLEX MASTS GR
69 2998158CE 1 nr KIT [Link] GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
Solo per 3 MONTANTI V.T. e 3 M Only for C.V. TRIPLEX MASTS GR
70 0054860CE 1 nr ALIMENTATORE DC-DC 24v 14 POWER SUPPLY ALIMENTATEUR SPEISER ALIMENTADOR
71 0135153CE 2 nr VITE TBEI M8X15 UNBRAKO T SCREW VIS SCHRAUBE TORNILLO
72 1777108CE 1 nr CABLAGGIO TERGICRISTALLO WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO

CABINA fino a N° 209642 / CABIN up to the N° 209642 Page 96

CABINA fino a N° 209642 / CABIN up to the N° 209642 Page 97
CBE12F_ACC_CABINA_A_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4774238CE 1 nr CABINA COMPLETA STD rif.5 CABIN WITH WINDSCREEN WIP CABINE AVEC ESSUIE GLACE KABINE MIT SCHEIBENWISCHE CABINA CON ENJUGADOR
1 3774073CE 1 nr KIT PANNELLO ANTERIORE ri PANEL KIT JEU PANNEAU PLATTESATZ JUEGO PANEL
2 0993587CE 1 nr VETRO [Link].3004560 F FRONT GLASS VITRE AVANT VORDERE GLASSCHEIBE CRISTAL DELANTERO
3 0992387CE 1 mt GUARNIZIONE X [Link]. R GASKET GARNITURE DICHTUNG VAINA
Var. Var.
4 0992058CE 1 nr SPAZZOLA TERGICRISTALLO R BRUSH BALAI BÜRSTE ESCOBILLA
5 0993692CE 1 nr SPRUZZINO LAVA VETRI FORG SPRAY SPRAY SPRITZER PULVERIZADOR
6 0992987CE 1 nr BRACCIO TERGICRISTALLO RI ARM BRAS ARM BRAZO
7 0993679CE 3 nr RONDELLA RIF. 2000114 WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
8 0993680CE 2 nr BORCHIA SVASATA RIF.20001 THREADED BUSHING BAGUE FILETEE GEWINDEBUCHSE CASQUILLO ROSCADO
9 0992133CE 2 nr DISTANZIALE GOMMA PER VET SPACER ECARTEUR ABSTANDSTÜCK DISTANCIADOR
10 0993558CE 1 nr SERIGRAFIA ADESIVA FORGH LABEL ETIQUETTE AUFKLEBER ETIQUETA
11 0992986CE 1 nr MOTORINO TERGICRISTALLO V WIPER MOTOR MOTEUR ESSUIE GLACE WISCHERMOTOR MOTOR LIMPIAPARABRISAS
12 0993489CE 4 nr BORCHIA SVASATA RIF. 2007 THREADED BUSHING BAGUE FILETEE GEWINDEBUCHSE CASQUILLO ROSCADO
13 0993488CE 8 nr GUARNIZIONE PER VETRO R GASKET GARNITURE DICHTUNG VAINA
14 0993507CE 4 nr STAFFA [Link] [Link] BRACKET ETRIER BSGEL ESTRIBO
15 0993490CE 4 nr COPRIDADO M8 RIF. 2004 NUT ECROU MUTTER TUERCA
16 3774139CE 1 nr KIT TETTO COMPLETO rif.45 KIT JEU SATZ JUEGO
17 3774076CE 1 nr KIT CAPPELLINO rif.400109 KIT JEU SATZ JUEGO
18 0993778CE 2 nr STAFFA TETTO RIF.3103617 BRACKET ETRIER BSGEL ESTRIBO
19 0992379CE 1 nr GUARNIZIONE PORTA DX-SX R GASKET GARNITURE DICHTUNG VAINA
Var. Var.
20 0993392CE 1 nr POMELLO M8X30 RIF.2040230 KNOB BOUTON KNOPF PERILLA
21 0993746CE 1 mt PROFILO OPEL PICCOLO RIF. PROFILE PROFIL PROFIL PERFIL
Var. Var.
22 2774087CE 1 nr KIT TETTO RIF.4001266 FOR KIT JEU SATZ JUEGO
23 0992059CE 1 nr SPECCHIO RETROVISORE INTE REARVIEW MIRROR RETROVISEUR R?CKSPIEGEL ESPEJO RETROVISOR
24 0993777CE 1 nr TETTO LEXAN RIF.3103645 OVERHEAD GUARD ROOF TOIT PROTECTION-CONDUCTEU FAHRERSCHUTZDACH TECHO PROTECC. CONDUCTOR
25 0993805CE 1 nr FONOASSORBENTE TETTO POST ACOUSTIC INSULATION INSONORISANT SCHALLSCHLUCKER FONOABSORBENTE
26 2774085CE 1 nr KIT PANNELLO POSTERIORE C PANEL KIT JEU PANNEAU PLATTESATZ JUEGO PANEL
27 0993718CE 1 nr VETRO POST.C/RESISTENZA R REAR GLASS VITRE ARRIERE HINTERE GLASSCHEIBE CRISTAL TRASERO
28 0993598CE 2 nr ATTACCO MOLLA GAS RIF.200 CONNECTION EMBOUT ANSCHLUSS CONEXION
29 0992952CE 2 nr MOLLA A GAS X CABINA 4774 GAS SPRING RESSORT A GAZ GASFEDER RESORTE A GAS
31 0993412CE 1 nr BRACCIO TERGICRISTALLO R ARM BRAS ARM BRAZO
32 0991683CE 1 nr SPAZZOLA TERGI ANTER. RIF BRUSH BALAI BÜRSTE ESCOBILLA
33 0993442CE 1 nr MOTORINO TERGICRISTALLO R WIPER MOTOR MOTEUR ESSUIE GLACE WISCHERMOTOR MOTOR LIMPIAPARABRISAS
34 0993964CE 1 mt GUARNIZIONE GUISNAP C/ALE GASKET GARNITURE DICHTUNG VAINA
Var. Var.

CABINA da N° 209643 / CABIN from N° 209643 Page 98

CABINA da N° 209643 / CABIN from N° 209643 Page 99
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
35 0993631CE 1 nr MANIGLIA DX RIF.2007553 HANDLE POIGNEE HANDGRIFF MANILLA
35 0993632CE 1 nr MANIGLIA SX RIF.2007552 HANDLE POIGNEE HANDGRIFF MANILLA
36 0993599CE 2 nr GUARNIZIONE X MANIGLIA PO GASKET GARNITURE DICHTUNG VAINA
37 0993468CE 2 nr RISCONTRO MANIGLIA POST.R HOOK ACCROCHAGE KUPPLUNG ENGANCHE
38 0992055CE 1 mt GUARNIZIONE X VETRO LAT.R GASKET GARNITURE DICHTUNG VAINA
Var. Var.
39 0992056CE 1 mt PROFILO X [Link] LAT PROFILE PROFIL PROFIL PERFIL
Var. Var.
40 0993786CE 1 nr CERNIERA X PANNELLO POST. HINGE CHARNIERE GELENK BISAGRA
41 2774088CE 1 nr KIT PORTA SX RIF.4001272 KIT JEU SATZ JUEGO
41 2774089CE 1 nr KIT PORTA DX RIF.4001273 KIT JEU SATZ JUEGO
42 0993959CE 1 nr SERRATURA SCONTRO RIF.200 LOCK SERRURE SCHLOSS CERRADURA
43 0993474CE 1 mt GUARNIZIONE PORTIERA RIF. GASKET GARNITURE DICHTUNG VAINA
Var. Var.
44 0993934CE 1 nr RULLINO REGGIPORTA ASSEMB ROLLER ROULEAU ROLLE RODILLO
45 0993958CE 1 nr SERRATURA ESTERNA SX RIF. LEFT LOCK SERRURE GAUCHE LINKES SCHLOSS CERRADURA IZQUIERDA
45 0993957CE 1 nr SERRATURA ESTERNA DX RIF. RIGHT LOCK SERRURE DROITE RECHTES SCHLOSS CERRADURA DERECHA
46 0993472CE 1 nr SERRATURA COMPLETA SX RIF LEFT LOCK SERRURE GAUCHE LINKES SCHLOSS CERRADURA IZQUIERDA
46 0993473CE 1 nr SERRATURA COMPLETA DX RIF RIGHT LOCK SERRURE DROITE RECHTES SCHLOSS CERRADURA DERECHA
47 0993681CE 2 nr CERNIERA RIF.3400003 HINGE CHARNIERE GELENK BISAGRA
48 0993660CE 2 nr PERNO CERNIERA PORTA CONNECTION EMBOUT ANSCHLUSS CONEXION
49 0993784CE 1 nr MOLLA A GAS L=355 C/OCC. GAS SPRING RESSORT A GAZ GASFEDER RESORTE A GAS
50 0993783CE 1 nr KIT VETRI SCORR C/TELAIO SLIDING GLASS KIT JEU GLACE COULISSANTE SCHIEBESEITENGLAS-SATZ JUEGO CRISTAL DESLIZABLE
51 0993782CE 1 nr VETRO FISSO INF. PORTA SX FRONT LOWER GLASS VITRE AVANT INFERIEURE UNTERE VORDERGLASSCHEIBE CRISTAL DELANTERO INFERI
52 0993785CE 1 nr VETRO LAT. FISSO PORTA DX SIDE GLASS VITRE LATERALE SEITENGLASSCHEIBE CRISTAL LATERAL
53 0993414CE 1 mt GUARNIZIONE BAULE R GASKET GARNITURE DICHTUNG VAINA
54 1773393CE 1 nr PIASTRINO FISSAGGIO MANIG PLATE PLAQUE PL¬TTCHEN PLACA
55 0070735CE 1 nr MANIGLIA RHRS-20.300.62 " HANDLE POIGNEE HANDGRIFF MANILLA
56 0054738CE 1 nr PORTAFUSIBILE INNESTI LAM FUSE CARRIER DOUILLE DES FUSIBLES SICHERUNGSTR?GER PORTAFUSIBLE
57 0057883CE 1 nr FUSIBILE A LAMA 7,5A-32V FUSE FUSIBLE SICHERUNG FUSIBLE
58 0054739CE 1 nr COPERCHIO PORTAFUSIBILI M COVER COUVERCLE DECKEL TAPA
59 4778027CE 1 nr MARTINETTO INCLIN.2gr.30' TILTING CYLINDER VERIN DE INCLINAISION NEIGUNGZYLINDER CILINDRO DE INCLINACION
Solo per 3 montanti V.T. e A.L Only for C.V and F.F.L. triple
60 1775070CE 1 nr ASTA ROD TIGE STANGE VARILLA
Solo per 3 montanti V.T. e A.L Only for C.V and F.F.L. triple
61 2998158CE 1 nr KIT [Link] GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
Solo per 3 montanti V.T. e A.L Only for C.V and F.F.L. triple

CABINA da N° 209643 / CABIN from N° 209643 Page 100

CABINA da N° 209643 / CABIN from N° 209643 Page 101
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
62 0054860CE 1 nr ALIMENTATORE DC-DC 24v 14 POWER SUPPLY ALIMENTATEUR SPEISER ALIMENTADOR
140 W 140 W
63 0135153CE 2 nr VITE TBEI M8X15 UNBRAKO T SCREW VIS SCHRAUBE TORNILLO
64 1777108CE 1 nr CABLAGGIO TERGICRISTALLO WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
65 1776088CE 1 nr PERNO MORSETTO PER CABINA PIN PIVOT STIFT PERNO
66 1866047CE 1 nr PIASTRINO PER LIMITAZIONE PLATE PLAQUE PL¬TTCHEN PLACA

CABINA da N° 209643 / CABIN from N° 209643 Page 102

CABINA da N° 209643 / CABIN from N° 209643 Page 103
CBE12F_ACC_IMP_RISCALDATORE_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 0057614CE 1 nr ELETTROVENT.002-B37-42D C ELECTRIC FAN VENTILATEUR ELECTRIQUE ELEKTROLÜFTER VENTILADOR ELECTRICO
2 0058031CE 1 nr GRIGLIA DI PROTEZIONE EBM GRIP GRILLE GITTER REJILLA
3 1773320CE 1 nr MANICOTTO SBRINAMENTO CRI SLEEVE MANCHON MANSCHETTE MANGUITO
4 1773321CE 1 nr DISTANZIALE PER SPECCHIO SPACER ECARTEUR ABSTANDSTSCK DISTANCIADOR
5 1773322CE 1 nr RISCALDATORE "ZIVAN" 48v- HEATER? RECHAUFFEUR HEIZGERÄT GRUPO CALENTADOR
6 0102011CE 2 nr VITE TSPEI M6X10 UNI5933 SCREW VIS SCHRAUBE TORNILLO
7 1778005CE 1 nr CONVOGLIATORE ARIA D.9606 CONVEYOR CONVOYEUR KSHLERHAUBE CONDUCTOR
8 0023269CE 2 nr ANTIVIBRANTE rif.781054 D VIBRATION DAMPING ANTIVIBRATOIRE SCHWINGUNGSDÄMPFEND ANTIVIBRATORIO
9 0100019CE 2 nr VITE TE M6X12 UNI5739 BRU SCREW VIS SCHRAUBE TORNILLO
10 0023265CE 1 nr PASSACAVO [Link] 200/280/ FAIRLEAD GALOCHE KABELDURCHGANG AISLADOR PASAPANEL

IMPIANTO RISCALDATORE / HEATER EQUIPMENT Page 104

IMPIANTO RISCALDATORE / HEATER EQUIPMENT Page 105
CBE12F_ACC_PEDALIERA_BASCULANTE_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 3776046CE 1 nr PEDALIERA BASCULANTE D.00 SWAYING ACCEL. PEDAL SYST PEDALIER D'ACCEL. BASCULA SCHWINGENDE GASPEDALE PEDALES ACELER. BASCULANT
1 1893216CE 1 nr LEVETTA DS. DIS.990254 LEVER? LEVIER HEBEL PALANCA
2 0019517CE 2 nr ARTICOLAZ.A ROTULA TIPO A ARTICULATED JOINT ARTICULATION GELENK JUNTA
3 1899004CE 2 nr TIRANTE D.911953/12 TENSION ROD TIRANT ZUGSTANGE TIRANTE
4 0060508CE 2 nr ARTICOLAZIONE A ROTULA M8 ARTICULATED JOINT ARTICULATION GELENK JUNTA
5 0135148CE 4 nr SPINA ELAST.D.5 X 26 UNI ELASTIC PIN GOUPILLE ELASTIQUE SPANNSTIFT PASADOR ELASTICO
6 1893206CE 1 nr COPERCHIO [Link] D. COVER COUVERCLE DECKEL TAPA
7 1933145CE 1 nr CAMMA AZIONAMENTO POTENZD CAM CAME NOCKEN LEVA
8 1933144CE 1 nr CAMMA AZIONAMENTO MICRO D CAM CAME NOCKEN LEVA
9 1893207CE 1 nr COPERCHIO [Link] D. COVER COUVERCLE DECKEL TAPA
10 2932002CE 1 nr BLOCCHETTO PRESSORE D BLOCK? ARRET ANSCHLAG PARADA
11 0013898CE 2 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
12 1893215CE 1 nr LEVETTA SN. DIS.990253 LEVER LEVIER HEBEL PALANCA
13 1607026CE 2 nr MOLLA DIS. 80966 (EX 1602 SPRING RESSORT FEDER RESORTE
14 1933143CE 1 nr DISTANZIALE D.58556/423 SPACER ECARTEUR ABSTANDSTSCK DISTANCIADOR
15 0070759CE 6 nr BOCCOLA FMB1617 DU BUSHING BAGUE BUCHSE BUCHSE
16 1774021CE 1 nr ALBERO COMANDO CAMME SHAFT ARBRE WELLE EJE
17 1866077CE 2 nr PIASTRINO MICRO PLATE PLAQUE PL¬TTCHEN PLACA
18 1897009CE 1 nr CABLAGGIO MICRO CONNETT.R WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
19 1897008CE 1 nr CABLAGGIO MICRO CONNETT. WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
20 1896024CE 2 nr COPRIPEDALE D.971776 PEDAL COVER COUVRE-PEDALE PEDALABDECKUNG PROTECCION DEL PEDAL
21 0134010CE 2 nr ANEL EL A16 UNI7435 EST ( SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
22 1933140CE 1 nr SUPPORTO POTENZIOMETRO D BEARING SUPPORT HALTERUNG SOPORTE
23 1887002CE 1 nr POTENZIOMETRO CABLATO D.9 POTENTIOMETER POTENTIOMETRE POTENTIOMETER POTENCIOMETRO
24 1602511CE 1 nr MOLLA D.55113/56 SPRING RESSORT FEDER RESORTE
25 0023103CE 1 nr COPRIPEDALE ART.4566 PEDAL COVER COUVRE-PEDALE PEDALABDECKUNG PROTECCION DEL PEDAL
26 0070661CE 2 nr BOCCOLA FLANGIATA [Link] BUSHING BAGUE BUCHSE BUCHSE
27 0064423CE 1 nr POMPA FRENO 2 STADI D.27/ MASTER BRAKE CYLINDER MAITRE CYLINDRE HAUPTBREMSZYLINDER CILINDRO MAESTRO
28 0992906CE 1 nr KIT GUARNIZIONI RIF.SG116 GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
29 0131022CE 1 nr COPIGLIA 2X15 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
30 1021069CE 2 nr SPINOTTO PEDAL. DIS.56355 PISTON PIN AXE DE PISTON KONTAKTSTIFT PASADOR
31 1776097CE 1 nr PUNTALINO CAP EMBOUT AUFLAGESTIFT CASQUILLO
32 1917012CE 1 nr CABLAGGIO MICRO STAGNO FR WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
33 1776096CE 1 nr SPESSORE DIS.950602 SHIM EPAISSEUR DICKE ESPESOR
34 1776094CE 1 nr PERNO PEDALE ACCELERATORE PIN PIVOT STIFT PERNO
35 1937032CE 1 nr CABLAGGIO INTERFACCIA PED WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
36 1773411CE 1 nr TAPPETINO PER [Link] FLOOR MAT TAPIS FUSSMATTE ALFOMBRA

PEDALIERA BASCULANTE / SWAYING PEDAL SYSTEM Page 106

PEDALIERA BASCULANTE / SWAYING PEDAL SYSTEM Page 107
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
37 1773412CE 1 nr CARTER D.000841 COVER CARTER GEH¬USE CARTER

PEDALIERA BASCULANTE / SWAYING PEDAL SYSTEM Page 108

PEDALIERA BASCULANTE / SWAYING PEDAL SYSTEM Page 109
CBE12F_ACC_DISTRIBUTORE_CON_LEVA_MULTIFUNZIONE_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 4778038CE 1 nr DISTRIBUTORE VDM07/ALD/U4 DISTRIBUTOR 3 VALVES? DISTRIBUTEUR STEUERBLOCK DISTRIBUIDOR
1 4778039CE 1 nr DISTRIBUTORE VDM07/ALDD/U DISTRIBUTOR 4 VALVES? DISTRIBUTEUR STEUERBLOCK DISTRIBUIDOR
2 0991908CE 3 nr VALVOLA VS RIF.420270340 VALVE SOUPAPE VENTIL VALVULA
3 0135245CE 4 nr SPINA ELAST. 4X22 UNI 687 ELASTIC PIN GOUPILLE ELASTIQUE SPANNSTIFT PASADOR ELASTICO
4 1773278CE 4 nr ASTINA COMANDO SPOLE DIST ROD TIGE STANGE VARILLA
5 2772047CE 1 nr LEVA COMANDO 4a VIA COMPL CONTROL LEVER LEVIER DE COMMANDE STEUERHEBEL PALANCA DE MANDO
Solo per distributore a 4 vie Only for 4 valves distributor
6 1775013CE 1 nr TAPPO PER LEVA 4 VIA NERO PLUG BOUCHON VERSCHLUSS TAPON
Solo per distributore a 4 vie Only for 4 valves distributor
7 2772046CE 1 nr LEVA COMANDO TRASLATORE C SIDESHIFTING LEVER LEVIER DU DEPLACEMENT SEITENSCHIEBERHEBEL PALANCA DESPLAZADOR
8 1775012CE 1 nr TAPPO PER LEVA [Link] PLUG BOUCHON VERSCHLUSS TAPON
9 1773415CE 1 nr LEVA COMANDO SOLLEVAM.-BR LIFTING LEVER LEVIER DE ELEVATION HUBHEBEL PALANCA DE ELEVACION
10 1775010CE 1 nr TAPPO PER LEVA [Link] PLUG BOUCHON VERSCHLUSS TAPON
11 2772048CE 1 nr ARTICOLAZIONE POTENZIOMET ARTICULATED JOINT ARTICULATION GELENK JUNTA
12 1727095CE 1 nr POTENZIOMETRO D.83218 POTENTIOMETER POTENTIOMETRE POTENTIOMETER POTENCIOMETRO
13 1773246CE 1 nr PERNO FULCRO LEVE D.95090 LEVER PIN PIVOT LEVIER HEBELBOLZEN PERNO DE PALANCA
14 0134006CE 2 nr ANEL EL A12 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
15 1773423CE 1 nr STAFFA SINISTRA D.000888 BRACKET ETRIER BSGEL ESTRIBO
16 1773422CE 1 nr STAFFA DESTRA D.000887 BRACKET ETRIER BSGEL ESTRIBO
17 0053056CE 4 nr MICROINTERRUTTORE XG2 S20 MICROSWITCH MICRO-INTERRUPTEUR MIKROSCHALTER MICROINTERRUPTOR
18 1773241CE 2 nr PIASTRINO A "C" PORTA INT PLATE PLAQUE PL¬TTCHEN PLACA
19 1773416CE 1 nr BLOCCHETTO D.000882 STOP ARRET ANSCHLAG PARADA
20 0070841CE 3 nr TESTA DI BIELLA [Link] 6 BIG END TETE DE BIELLE GROSSES PLEUELAUGE CABEZA DE VAST. DEL PISTO
21 1933125CE 2 nr BOCCOLA D.990758 BUSHING BAGUE BUCHSE BUCHSE
22 1773245CE 2 nr FORCELLA RINVIO COMANDI A COTTER PIN FOURCHETTE GESPALTER STIFT HORQUILLA
23 0135246CE 4 nr SPINA CILINDRICA 4X30 UNI PLUG GOUPILLE STECKER CLAVIJA
24 1773418CE 1 nr RINVIO BRANDEGGIO D.00088 DRIVING GEAR RENVOI VORGELEGE TRANSMISION
25 0133067CE 4 nr VSTEI M3X6 UNI 5927-67 12 SCREW VIS SCHRAUBE TORNILLO
26 0135261CE 2 nr SPINA CILINDRICA 4X35 UNI PLUG GOUPILLE STECKER CLAVIJA
27 0070846CE 4 nr BOCCOLA CON COLLARE PAF 1 BUSHING BAGUE BUCHSE BUCHSE
28 1773417CE 1 nr RINVIO SOLLEVAMENTO D.000 DRIVING GEAR RENVOI VORGELEGE TRANSMISION
29 1933128CE 1 nr PERNO SOLLEVAMENTO D.9907 PIN PIVOT STIFT PERNO
30 1773424CE 1 nr TRAVERSA D.000889 CROSSBEAM TRAVERSE QUERBALKEN TRAVERSANO
31 1773274CE 1 nr DISTANZIALE PER PACCO LEV SPACER ECARTEUR ABSTANDSTSCK DISTANCIADOR
Solo per distributore a 3 vie Only for 3 valves distributor
32 1773419CE 1 nr COPERCHIO COMANDO LEVISMI COVER COUVERCLE DECKEL TAPA
Solo per distributore a 3 vie Only for 3 valves distributor

DISTRIBUTORE CON LEVA MULTIFUNZIONE / DISTRIBUTOR WITH MULTIFUNCTION LEVER Page 110
DISTRIBUTORE CON LEVA MULTIFUNZIONE / DISTRIBUTOR WITH MULTIFUNCTION LEVER Page 111
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
32 1773420CE 1 nr COPERCHIO COMANDO LEVISMI INSPECTION COVER? CALOTTE KAPPE TAPA
Solo per distributore a 4 vie Only for 4 valves distributor
33 1773421CE 1 nr SUPPORTO SINGOLO SOFFIETT SUPPORT SUPPORT HALTERUNG SOPORTE
34 0023046CE 1 nr SOFFIETTO rif.3816 "MALO" BELLOWS SOUFFLET BLASEBALG FUELLE
35 1933157CE 2 nr SOFFIETTO D.991317 BELLOWS SOUFFLET BLASEBALG FUELLE
36 1777078CE 1 nr CABLAGGIO PER DEVIATORE D WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO

DISTRIBUTORE CON LEVA MULTIFUNZIONE / DISTRIBUTOR WITH MULTIFUNCTION LEVER Page 112
DISTRIBUTORE CON LEVA MULTIFUNZIONE / DISTRIBUTOR WITH MULTIFUNCTION LEVER Page 113
This Page Intentionally Blank
CBE12F_INV_AL_VOLANTE_
CBE12F_INV_AL_VOLANTE_INV_AL_VOLANTE_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 2773027CE 1 nr INVERSORE-CORPO CON MICRO HAND DIRECTION LEVER INVERSEUR DE DIRECTION HANDUMSCHALTUNG PALANCA DE INVERSION
versione scandinavia scandinavian version
1 2776015CE 1 nr INVERSORE CON MICRO D.940 HAND DIRECTION LEVER INVERSEUR DE DIRECTION HANDUMSCHALTUNG PALANCA DE INVERSION
2 1777172CE 1 nr MICRO CABLATO MICROSWITCH MICRO-INTERRUPTEUR MIKROSCHALTER MICROINTERRUPTOR
versione scandinavia scandinavian version
2 0018109CE 3 nr [Link] XFK4S8 MICROSWITCH MICRO-INTERRUPTEUR MIKROSCHALTER MICROINTERRUPTOR
3 0070097CE 1 nr SNODO SFERICO GE10 E BALL AND SOCKET JOINT ARTICULATION A ROTULE KUGELGELENK ARTICULACION DE BOLA
4 2992031CE 1 nr KIT RICHIAMO LEVA INVERSO KIT JEU SATZ JUEGO
5 1776053CE 1 nr CARENATURA PIANTONE INV.V STEERING COLUMN COVER CARTER COLONNE DE DIRECTI LENKS¬ULEGEH¬USE CARTER COLUMNA DE DIRECCI
6 1607353CE 1 nr PROTEZIONE SU PULSANTE CL GUARD PROTECTION SCHUTZ PROTECCION

INVERSORE AL VOLANTE / DIRECTION INVERSOR LEVER Page 116

INVERSORE AL VOLANTE / DIRECTION INVERSOR LEVER Page 117
CBE12F_INV_AL_VOLANTE_PEDALIERA_ACCELERATORE_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 3776041CE 1 nr PEDALIERA ACCELERATORE ( ACCEL. PEDAL SYSTEM SIMPL PEDALIER D'ACCELER., SIMP GASPEDALE, EINFACH PEDALES ACELERADOR, SIMPL
0 3776048CE 1 nr PEDALIERA ACCELERATORE IN ACCELERATOR PEDAL SYSTEM PEDALIER D'ACCELERATEUR GASPEDALE PEDALES ACELERADOR
versione scandinavia scandinavian version
1 1773406CE 2 nr MOLLA A TRAZIONE SPRING RESSORT FEDER RESORTE
2 0053056CE 1 nr MICROINTERRUTTORE XG2 S20 MICROSWITCH MICRO-INTERRUPTEUR MIKROSCHALTER MICROINTERRUPTOR
2 1777157CE 1 nr MICRO CABLATO MICROSWITCH MICRO-INTERRUPTEUR MIKROSCHALTER MICROINTERRUPTOR
versione scandinavia scandinavian version
3 0110247CE 4 nr DADO AUTOBLOC N/10/103 3X SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
4 0103045CE 2 nr VITE TC M3X18 UNI6107 TRO SCREW VIS SCHRAUBE TORNILLO
5 0070661CE 4 nr BOCCOLA FLANGIATA [Link] BUSHING BAGUE BUCHSE BUCHSE
6 1777075CE 1 nr CABLAGGIO PEDALE ACCEL. P WIRING HARNESS CABLAGE VERDRAHTUNG CABLEO
7 0110040CE 2 nr DADO ES. M6 UNI5588 ZINC. NUT ECROU MUTTER TUERCA
8 0100114CE 1 nr VITE TE M6X20 UNI5739 ZIN SCREW VIS SCHRAUBE TORNILLO
9 0103055CE 2 nr VITE TC M6X20 UNI 6107 TR SCREW VIS SCHRAUBE TORNILLO
10 1776118CE 1 nr SUPPORTO PERNO FILETTATO JOURNAL BEARING SUPPORT GOUJON STIFTLAGER SOPORTE PERNO
11 0023233CE 1 nr GOMMINO PASSACAVO [Link] RUBBER SEAL GARNITURE EN CAOUTCHOUC DICHTGUMMI JUNTA DE CAUCHO
12 0120105CE 3 nr [Link] D.4 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
13 0120043CE 3 nr [Link]. D.5 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
14 0100462CE 1 nr VITE TE M5X12 UNI5739 TRO SCREW VIS SCHRAUBE TORNILLO
15 1776050CE 1 nr COPRIPEDALE [Link] PEDAL COVER COUVRE-PEDALE PEDALABDECKUNG PROTECCION DEL PEDAL
16 1777120CE 1 nr PERNO FILETTATO PIN PIVOT STIFT PERNO
17 1777124CE 1 nr MOLLA A TORSIONE CILINDRI SPRING RESSORT FEDER RESORTE
18 0120044CE 2 nr [Link]. D.6 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
19 1776104CE 1 nr STAFFA DI FERMO BRACKET ETRIER BSGEL ESTRIBO
20 1022018CE 1 nr ROSETTA GREMBIALINA 6,6X2 WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
21 0100117CE 1 nr VITE TE M6X12 UNI5739 TRO SCREW VIS SCHRAUBE TORNILLO
22 1993041CE 1 nr KIT POTENZIOMETRO PEDAL.A KIT JEU SATZ JUEGO
23 1776093CE 1 nr COPERCHIO SCAT. ACC. DIS. COVER COUVERCLE DECKEL TAPA

PEDALIERA ACCELERATORE / SPEED PEDAL Page 118

PEDALIERA ACCELERATORE / SPEED PEDAL Page 119
This Page Intentionally Blank
CBE12F_MONT_A_
CBE12F_MONT_A_MONTANTI_2M_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 1774038CE 2 nr PERNO PER RULLO D.60.5 ROLLER PIN PIVOT ROULEAU ROLLENBOLZEN PERNO DE RODILLO
2 1774027CE 2 nr PERNO PER RULLO D.90.8 ROLLER PIN PIVOT ROULEAU ROLLENBOLZEN PERNO DE RODILLO
3 0135181CE 2 nr INGRASSATORE A 90 M 6X1 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
4 0013898CE 6 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
5 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
6 2774045CE 2 nr RULLO GUIDA DIAM.60,5 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
7 0134029CE 4 nr ANEL EL A35 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
8 2934004CE 4 nr PATTINO GUIDA TRASV. D.97 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
9 2914028CE 2 nr RULLO GUIDA D.90,8 D.9708 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
10 0134036CE 2 nr ANEL EL A50 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
11 1774089CE 2 nr TIRANTE CATENA CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
12 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
13 1774010CE 2 nr DADO AUTOCENTRANTE NUT ECROU MUTTER TUERCA
14 0131002CE 2 nr COPIGLIA 1.5X15 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
15 0023376CE 2 nr TAPPO [Link] 320 286 "OTM PLUG BOUCHON VERSCHLUSS TAPON
16 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
VAR. VAR.
17 2774075CE 2 nr PULEGGIA CATENA PULLEY POULIE RIEMENSCHEIBE POLEA
18 1774024CE 2 nr COLLARE CILINDRO SECONDAR COLLAR COLLIER ANSCHLAGBUND COLLAR
19 0101127CE 4 nr VITE TCEI M8X70 UNI5931 1 SCREW VIS SCHRAUBE TORNILLO
20 0110288CE 4 nr DADO AUTOBL.M8x1,25 N/70/ SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
21 0100244CE 2 nr VITE TE M12X45 UNI5737 BR SCREW VIS SCHRAUBE TORNILLO
22 1021757CE 2 nr RONDELLA D.56641/52 WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
23 1774023CE 2 nr GHIERA REGOLAZIONE CILIND RING NUT BAGUE NUTMUTTER CASQUILLO
24 0134016CE 2 nr ANEL EL A22 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
25 0134031CE 2 nr ANEL EL A40 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
26 1774020CE 2 nr ANCORARAGGIO MONTANTE HOOK ACCROCHAGE KUPPLUNG ENGANCHE
27 0070188CE 2 nr SNODO SFERICO GE 40ES.2RS BALL AND SOCKET JOINT ARTICULATION A ROTULE KUGELGELENK ARTICULACION DE BOLA
28 0101053CE 4 nr VITE TCEI M10X35 UNI5931 SCREW VIS SCHRAUBE TORNILLO
29 0120121CE 4 nr [Link]. D10 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA

MONTANTI (2M) VT / MASTS (2M) VT Page 122

MONTANTI (2M) VT / MASTS (2M) VT Page 123
CBE12F_MONT_A_MARTINETTO_ELEVATORE_2M_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr CORPO BODY CORPS GEAUSE CUERPO
codice secondo altezza di soll code according to lift height
1 1775219CE 1 nr FONDELLO PER CILINDRO SOL BOTTOM CULOT ENDSCHEIBE FONDILLO
2 0063009CE 1 nr VALVOLA [Link]-N-H OD.41 VALVE SOUPAPE VENTIL VALVULA
3 2998185CE 1 nr KIT [Link].C/F GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS

MARTINETTO ELEVATORE (2M) VT / LIFT JACK (2M) VT Page 124

MARTINETTO ELEVATORE (2M) VT / LIFT JACK (2M) VT Page 125
CBE12F_MONT_A_CARRELLINO_PIASTRA_FISSA_2M_FEM_A_FEM_B_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4774293CE 1 nr CARRELLINO C/P.F.L=900 F FORK CARRIAGE TABLIER PORTE-FOURCHE GABELTR?GER TABLERO HORQUILLAS
FEM 2B FEM 2B
0 4774294CE 1 nr CARRELLINO C/P.F.L=900 F FORK CARRIAGE TABLIER PORTE-FOURCHE GABELTR?GER TABLERO HORQUILLAS
FEM 2A FEM 2A
1 0134036CE 4 nr ANEL EL A50 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
2 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
3 2914028CE 4 nr RULLO GUIDA D.90,8 D.9708 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
4 2934004CE 4 nr PATTINO GUIDA TRASV. D.97 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
5 0013898CE 4 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
6 1774027CE 4 nr PERNO PER RULLO D.90.8 ROLLER PIN PIVOT ROULEAU ROLLENBOLZEN PERNO DE RODILLO
7 1604235CE 2 nr ARRESTO FORCA K16/30 D.88 STOP ARRET ANSCHLAG PARADA
8 0102054CE 2 nr VITE TSPEI M12X20 UNI5933 SCREW VIS SCHRAUBE TORNILLO
9 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
VAR. VAR.
10 0131002CE 2 nr COPIGLIA 1.5X15 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
11 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
12 0131031CE 2 nr COPIGLIA 3X20 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
13 1824044CE 2 nr TIRANTE CATENA DIS.80542 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
14 1774010CE 2 nr DADO AUTOCENTRANTE NUT ECROU MUTTER TUERCA

CARRELLINO PIASTRA FISSA (2M) FEM A - FEM B / FORK CARRIAGE (2M) FEM A - FEM B Page 126
CARRELLINO PIASTRA FISSA (2M) FEM A - FEM B / FORK CARRIAGE (2M) FEM A - FEM B Page 127
CBE12F_MONT_A_CARRELLINO_E_TRASLATORE_LAT_2M_FEM_A_FEM_B_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4774295CE 1 nr CARRELLINO TRASL.L=900 F SIDESHIFT FORK CARRIAGE TABLIER DEPLACEMENT LAT. SEITENSCHIEBER GABELTR?GE TABLERO DESPLADOR LAT.
FEM 2A FEM 2A
0 4774296CE 1 nr CARRELLINO TRASL.L=900 F SIDESHIFT FORK CARRIAGE TABLIER DEPLACEMENT LAT. SEITENSCHIEBER GABELTR?GE TABLERO DESPLADOR LAT.
FEM 2B FEM 2B
15 1603448CE 2 nr TAMPONE D.92303 STOP ARRET ANSCHLAG PARADA
16 1623289CE 2 nr PATTINO D.92193 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
17 1603449CE 2 nr SPESSORE DI REGISTRO D.92 SHIM EPAISSEUR DICKE ESPESOR
18 1603450CE 2 nr PATTINO INFERIORE D.92301 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
19 0062043CE 1 nr COLLARE X TUBI GEMELLATI COLLAR COLLIER ANSCHLAGBUND COLLAR
20 1934050CE 1 nr MORSETTO [Link] TERMINAL BORNE KLEMME TERMINAL
21 0101028CE 2 nr VITE TCEI M6X35 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
22 0013898CE 2 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
23 0060297CE 4 nr RACCORDO CAST 101905 CONNECTION RACCORD ANSCHLUSS UNION
24 0060299CE 2 nr RACCORDO CAST 104205 CONNECTION RACCORD ANSCHLUSS UNION
25 1603504CE 2 nr TUBO [Link] CILIND PIPE TUYAU SCHLAUCH TUBO
26 0060298CE 2 nr RACCORDO CAST 104605 CONNECTION RACCORD ANSCHLUSS UNION
27 1603506CE 4 nr BUSSOLA PER TRASLATORE D. BUSHING DOUILLE BUCHSE CASQUILLO
28 1603446CE 4 nr VITE DI REGISTRAZIONE D.9 ADJUSTING SCREW VIS DE REGLAGE EINSTELLSCHRAUBE TORNILLO DE REGULACION
29 1603447CE 1 nr SPESSORE DI REGISTRAZIONE SHIM EPAISSEUR DICKE ESPESOR
VAR. VAR.
30 1774091CE 1 nr LAMIERA CHIUSURA [Link] PLATE (sheet of metal) TOLE BLECH CHAPA
31 1603505CE 4 nr ASTA PER TRASLATORE D.922 ROD TIGE STANGE VARILLA
33 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
34 0013898CE 4 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
35 2914028CE 4 nr RULLO GUIDA D.90,8 D.9708 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
36 0134036CE 4 nr ANEL EL A50 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
37 1774027CE 4 nr PERNO PER RULLO D.90.8 ROLLER PIN PIVOT ROULEAU ROLLENBOLZEN PERNO DE RODILLO
38 2934004CE 4 nr PATTINO GUIDA TRASV. D.97 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
39 2998141CE 1 nr [Link].D. GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
40 0131002CE 2 nr COPIGLIA 1.5X15 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
41 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
VAR. VAR.
42 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
43 0131031CE 2 nr COPIGLIA 3X20 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
44 1824044CE 2 nr TIRANTE CATENA DIS.80542 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
45 1774010CE 2 nr DADO AUTOCENTRANTE NUT ECROU MUTTER TUERCA
46 1774092CE 1 nr LAMIERA CHIUSURA [Link] PLATE (sheet of metal) TOLE BLECH CHAPA

TRASLATORE LATERALE (2M) FEM A - FEM B / SIDESHIFTING CARRIAGE (2M) FEM A - FEM B Page 128
TRASLATORE LATERALE (2M) FEM A - FEM B / SIDESHIFTING CARRIAGE (2M) FEM A - FEM B Page 129
CBE12F_MONT_A_IMP_SOLLEVAMENTO_E_DRENAGGIO_2M_VT_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 0020460CE 1 nr VALVOLA HAWE SB 25C VALVE SOUPAPE VENTIL VALVULA
2 1994031CE 1 nr CORPO VALVOLA DISCESA RIF VALVE SOUPAPE VENTIL VALVULA
3 0100197CE 1 nr VITE TE M8X50 UNI5737 SCREW VIS SCHRAUBE TORNILLO
4 0060258CE 2 nr DADO CAST 100207 (EX B 12 NUT ECROU MUTTER TUERCA
5 0060615CE 2 nr RACCORDO OGIVA 100107.4 C CONNECTION RACCORD ANSCHLUSS UNION
7 0060375CE 1 nr RACCORDO A "T" PLAST.x TU CONNECTION RACCORD ANSCHLUSS UNION
8 0060356CE 2 nr [Link] [Link].1/8" CONNECTION RACCORD ANSCHLUSS UNION
9 1775221CE 1 nr TUBO RIGIDO PIPE CONDUITE RIGIDE ROHR TUBO RIGIDO
10 1775220CE 1 nr TUBO RIGIDO DS [Link] PIPE CONDUITE RIGIDE ROHR TUBO RIGIDO
11 0023258CE 1 mt TUBO POLIETILENE 8X6 NERO FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
VAR. VAR.

IMPIANTO SOLLEVAM. E DRENAGGIO (2M) VT / LIFTING AND DRAINAGE HYDRAULIC SYSTEM (2M) VT Page 130
IMPIANTO SOLLEVAM. E DRENAGGIO (2M) VT / LIFTING AND DRAINAGE HYDRAULIC SYSTEM (2M) VT Page 131
CBE12F_MONT_A_IMP_ALIMENTAZIONE_TRASLATORE_2M_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr IMPIANTO ALIMENTAZIONE CO HYDRAULIC SYSTEM INSTALL. HYDRAUL. HYDRAULISCHE ANLAGE INSTALACION HIDR.
codice secondo altezza di soll code according to lift height
1 (1) 1 nr TUBO PIPE TUYAU SCHLAUCH TUBO
codice secondo altezza di soll code according to lift height
2 (1) 1 nr TUBO PIPE TUYAU SCHLAUCH TUBO
codice secondo altezza di soll code according to lift height
3 0060362CE 2 nr RACCORDO DIR. A103002/10 CONNECTION RACCORD ANSCHLUSS UNION
4 0101028CE 3 nr VITE TCEI M6X35 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
5 0070585CE 1 nr PIASTRA SUPERIORE CF1 "PI PLATE PLAQUE PLATTE PLANCHA
6 0070584CE 1 nr COLLARE DOPPIO CF1 12/12" COLLAR COLLIER ANSCHLAGBUND COLLAR
7 0120119CE 2 nr [Link]. D.6 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
8 0120026CE 2 nr [Link] 6,4 UNI1739 Z WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
9 0062043CE 1 nr COLLARE X TUBI GEMELLATI COLLAR COLLIER ANSCHLAGBUND COLLAR
10 1934050CE 1 nr MORSETTO [Link] TERMINAL BORNE KLEMME TERMINAL
11 0100401CE 1 nr VITE TE M12X55 UNI5737 BR SCREW VIS SCHRAUBE TORNILLO
12 0120122CE 1 nr [Link]. D12 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
13 1775113CE 1 nr PERNO PULEGGIA M.M.E. PULLEY PIN PIVOT DE POULIE RIEMENSCHEIBEBOLZEN PERNO DE POLEA
14 1775111CE 1 nr PULEGGIA TUBI ALIMENT. AT PULLEY POULIE RIEMENSCHEIBE POLEA
15 0134031CE 1 nr ANEL EL A40 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO

IMPIANTO ALIMENTAZIONE TRASLATORE LAT. (2M) VT / SIDESHIFTING DEVICE HYDRAULIC INSTALL (2M) VT Page 132
IMPIANTO ALIMENTAZIONE TRASLATORE LAT. (2M) VT / SIDESHIFTING DEVICE HYDRAULIC INSTALL (2M) VT Page 133
CBE12F_MONT_A_MONTANTI_3M_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 1774038CE 4 nr PERNO PER RULLO D.60.5 ROLLER PIN PIVOT ROULEAU ROLLENBOLZEN PERNO DE RODILLO
2 1774027CE 4 nr PERNO PER RULLO D.90.8 ROLLER PIN PIVOT ROULEAU ROLLENBOLZEN PERNO DE RODILLO
3 0135181CE 2 nr INGRASSATORE A 90 M 6X1 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
4 0013898CE 12 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
5 1994037CE 8 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
6 2774045CE 4 nr RULLO GUIDA DIAM.60,5 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
7 0134029CE 6 nr ANEL EL A35 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
8 2934004CE 8 nr PATTINO GUIDA TRASV. D.97 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
9 2914028CE 4 nr RULLO GUIDA D.90,8 D.9708 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
10 0134036CE 4 nr ANEL EL A50 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
11 1864310CE 4 nr TIRANTE CATENA RIF.15574 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
12 1994015CE 4 nr PERNO TIRANTE CATENA RIF. PIN PIVOT STIFT PERNO
13 1869012CE 4 nr DADO AUTOBLOCCANTE RIF.03 SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
14 0131002CE 6 nr COPIGLIA 1.5X15 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
15 0134007CE 4 nr ANEL EL A13 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
16 1824044CE 2 nr TIRANTE CATENA DIS.80542 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
17 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
18 1774010CE 2 nr DADO AUTOCENTRANTE NUT ECROU MUTTER TUERCA
19 0131031CE 2 nr COPIGLIA 3X20 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
20 0070723CE 1 mt CATENA FLEYER BL.644 RIF. CHAIN CHAINE KETTE CADENA
VAR. VAR.
21 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
22 2934069CE 2 nr PULEGGIA PER CATENA SOLLE PULLEY POULIE RIEMENSCHEIBE POLEA
23 2774075CE 2 nr PULEGGIA CATENA PULLEY POULIE RIEMENSCHEIBE POLEA
24 0134031CE 4 nr ANEL EL A40 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
25 1774059CE 2 nr COLLARE COLLAR COLLIER ANSCHLAGBUND COLLAR
26 0101127CE 4 nr VITE TCEI M8X70 UNI5931 1 SCREW VIS SCHRAUBE TORNILLO
27 0110288CE 4 nr DADO AUTOBL.M8x1,25 N/70/ SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
28 0100075CE 2 nr VITE TE M16X50 UNI5739 ZI SCREW VIS SCHRAUBE TORNILLO
29 0120011CE 2 nr [Link] D.20 UNI6592 Z WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
30 1934010CE 2 nr GHIERA [Link]. RING NUT BAGUE BUCHSE CASQUILLO
31 0134016CE 2 nr ANEL EL A22 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
32 1774020CE 2 nr ANCORARAGGIO MONTANTE HOOK ACCROCHAGE KUPPLUNG ENGANCHE
33 0070188CE 2 nr SNODO SFERICO GE 40ES.2RS BALL AND SOCKET JOINT ARTICULATION A ROTULE KUGELGELENK ARTICULACION DE BOLA
34 0101053CE 4 nr VITE TCEI M10X35 UNI5931 SCREW VIS SCHRAUBE TORNILLO
35 0120121CE 4 nr [Link]. D10 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
36 (1) 1 nr RETE NET FILET NETZ RED
codice secondo altezza di soll code according to lift height

MONTANTI (3M) VT / MASTS (3M) VT Page 134

MONTANTI (3M) VT / MASTS (3M) VT Page 135
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
37 1774034CE 1 nr RETE PROTEZIONE SUPERIORE SAFETY GUARD GRILLE DE PROTECTION SCHUTZGITTER RED DE PROTECCION
VAR. VAR.
38 1774060CE 1 nr RETE PROTEZIONE SAFETY GUARD GRILLE DE PROTECTION SCHUTZGITTER RED DE PROTECCION
VAR. VAR.
39 1724136CE 1 nr PIASTRINA [Link] PLATE PLAQUE PLATTE PLANCHA
VAR. VAR.
40 0101138CE 1 nr VITE TCEI M6X14 UNI5931 1 SCREW VIS SCHRAUBE TORNILLO
VAR. VAR.
41 0120119CE 1 nr [Link]. D.6 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
VAR. VAR.

MONTANTI (3M) VT / MASTS (3M) VT Page 136

MONTANTI (3M) VT / MASTS (3M) VT Page 137
CBE12F_MONT_A_MARTINETTO_ELEVATORE_3M_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr MARTINETTO ELEVATORE CENT CYLINDER VERIN ZYLINDER CILINDRO
codice secondo altezza di soll code according to lift height
1 1775217CE 1 nr FONDELLO CILINDRO [Link] BOTTOM CULOT ENDSCHEIBE FONDILLO
2 0063009CE 1 nr VALVOLA [Link]-N-H OD.41 VALVE SOUPAPE VENTIL VALVULA
3 2998167CE 1 nr [Link].D.970 GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS

MARTINETTO ELEVATORE (3M) VT / LIFT JACK (3M) VT Page 138

MARTINETTO ELEVATORE (3M) VT / LIFT JACK (3M) VT Page 139
CBE12F_MONT_A_CARRELLINO_PIASTRA_FISSA_3M_VT_FEM_A_FEM_B

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4774213CE 1 nr CARRELLINO C/[Link] L=90 FORK CARRIAGE TABLIER PORTE-FOURCHE GABELTR?GER TABLERO HORQUILLAS
FEM 2B FEM B
0 4774214CE 1 nr CARRELLINO C/[Link] L=90 FORK CARRIAGE TABLIER PORTE-FOURCHE GABELTR?GER TABLERO HORQUILLAS
FEM A FEM A
1 0134036CE 4 nr ANEL EL A50 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
2 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
3 2914028CE 4 nr RULLO GUIDA D.90,8 D.9708 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
4 2934004CE 4 nr PATTINO GUIDA TRASV. D.97 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
5 0013898CE 4 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
6 1774027CE 4 nr PERNO PER RULLO D.90.8 ROLLER PIN PIVOT ROULEAU ROLLENBOLZEN PERNO DE RODILLO
7 1604235CE 2 nr ARRESTO FORCA K16/30 D.88 STOP ARRET ANSCHLAG PARADA
8 0102054CE 2 nr VITE TSPEI M12X20 UNI5933 SCREW VIS SCHRAUBE TORNILLO
9 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
VAR. VAR.
10 0131002CE 2 nr COPIGLIA 1.5X15 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
11 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
12 0131031CE 2 nr COPIGLIA 3X20 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
13 1824044CE 2 nr TIRANTE CATENA DIS.80542 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
14 1774010CE 2 nr DADO AUTOCENTRANTE NUT ECROU MUTTER TUERCA

CARRELLINO PIASTRA FISSA (3M) VT - FEM A - FEM B / FORK CARRIAGE (3M) VT - FEM A - FEM B Page 140
CARRELLINO PIASTRA FISSA (3M) VT - FEM A - FEM B / FORK CARRIAGE (3M) VT - FEM A - FEM B Page 141
CBE12F_MONT_A_TRASLATORE_LATERALE_3M_FEM_A_FEM_B_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4774226CE 1 nr CARRELLINO TRASL.L=900 FE SIDESHIFT FORK CARRIAGE TABLIER DEPLACEMENT LAT. SEITENSCHIEBER GABELTR?GE TABLERO DESPLADOR LAT.
FEM 2B FEM 2B
0 4774227CE 1 nr CARRELLINO TRASL.L=900 FE SIDESHIFT FORK CARRIAGE TABLIER DEPLACEMENT LAT. SEITENSCHIEBER GABELTR?GE TABLERO DESPLADOR LAT.
FEM 2A FEM 2A
15 1603448CE 2 nr TAMPONE D.92303 STOP ARRET ANSCHLAG PARADA
16 1623289CE 2 nr PATTINO D.92193 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
17 1603449CE 2 nr SPESSORE DI REGISTRO D.92 SHIM EPAISSEUR DICKE ESPESOR
18 1603450CE 2 nr PATTINO INFERIORE D.92301 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
19 0062043CE 1 nr COLLARE X TUBI GEMELLATI COLLAR COLLIER ANSCHLAGBUND COLLAR
20 1934050CE 1 nr MORSETTO [Link] TERMINAL BORNE KLEMME TERMINAL
21 0101028CE 2 nr VITE TCEI M6X35 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
22 0013898CE 2 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
23 0060297CE 4 nr RACCORDO CAST 101905 CONNECTION RACCORD ANSCHLUSS UNION
24 0060299CE 2 nr RACCORDO CAST 104205 CONNECTION RACCORD ANSCHLUSS UNION
25 1603504CE 2 nr TUBO [Link] CILIND PIPE TUYAU SCHLAUCH TUBO
26 0060298CE 2 nr RACCORDO CAST 104605 CONNECTION RACCORD ANSCHLUSS UNION
27 1603506CE 4 nr BUSSOLA PER TRASLATORE D. BUSHING DOUILLE BUCHSE CASQUILLO
28 1603446CE 4 nr VITE DI REGISTRAZIONE D.9 ADJUSTING SCREW VIS DE REGLAGE EINSTELLSCHRAUBE TORNILLO DE REGULACION
29 1603447CE 1 nr SPESSORE DI REGISTRAZIONE SHIM EPAISSEUR DICKE ESPESOR
VAR. VAR.
30 1774091CE 1 nr LAMIERA CHIUSURA [Link] PLATE (sheet of metal) TOLE BLECH CHAPA
31 1603505CE 4 nr ASTA PER TRASLATORE D.922 ROD TIGE STANGE VARILLA
33 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
34 0013898CE 4 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
35 2914028CE 4 nr RULLO GUIDA D.90,8 D.9708 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
36 0134036CE 4 nr ANEL EL A50 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
37 1774027CE 4 nr PERNO PER RULLO D.90.8 ROLLER PIN PIVOT ROULEAU ROLLENBOLZEN PERNO DE RODILLO
38 2934004CE 4 nr PATTINO GUIDA TRASV. D.97 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
39 2998141CE 1 nr [Link].D. GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
40 0131002CE 2 nr COPIGLIA 1.5X15 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
41 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
m m
42 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
43 0131031CE 2 nr COPIGLIA 3X20 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
44 1824044CE 2 nr TIRANTE CATENA DIS.80542 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
45 1774010CE 1 nr DADO AUTOCENTRANTE NUT ECROU MUTTER TUERCA
46 1774092CE 1 nr LAMIERA CHIUSURA [Link] PLATE (sheet of metal) TOLE BLECH CHAPA

TRASLATORE LATERALE (3M) VT - FEM A - FEM B / SIDESHIFTING CARRIAGE (3M) VT - FEM A - FEM B Page 142
TRASLATORE LATERALE (3M) VT - FEM A - FEM B / SIDESHIFTING CARRIAGE (3M) VT - FEM A - FEM B Page 143
CBE12F_MONT_A_IMPIANTO_SOLLEVAMENTO_E_DRENAGGIO_3M_VT_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 0020460CE 1 nr VALVOLA HAWE SB 25C VALVE SOUPAPE VENTIL VALVULA
2 1994031CE 1 nr CORPO VALVOLA DISCESA RIF VALVE SOUPAPE VENTIL VALVULA
3 0100197CE 1 nr VITE TE M8X50 UNI5737 SCREW VIS SCHRAUBE TORNILLO
4 0060258CE 2 nr DADO CAST 100207 (EX B 12 NUT ECROU MUTTER TUERCA
5 0060255CE 2 nr ANELLO CAST 100107 (EX A1 RING ANNEAU RING ANILLO
6 0060645CE 2 nr RACCORDO "A 707037-1217"- CONNECTION RACCORD ANSCHLUSS UNION
7 0060375CE 1 nr RACCORDO A "T" PLAST.x TU CONNECTION RACCORD ANSCHLUSS UNION
8 0060356CE 2 nr [Link] [Link].1/8" CONNECTION RACCORD ANSCHLUSS UNION
9 1775102CE 1 nr TUBO RIGIDO PIPE CONDUITE RIGIDE ROHR TUBO RIGIDO
10 1775101CE 1 nr TUBO RIGIDO PIPE CONDUITE RIGIDE ROHR TUBO RIGIDO
11 0023258CE 1 mt TUBO POLIETILENE 8X6 NERO FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
m m

IMPIANTO SOLLEVAMENTO E DRENAGGIO (3M) VT / LIFTING AND DRAINAGE HYDRAULIC SYSTEM (3M) VT Page 144
IMPIANTO SOLLEVAMENTO E DRENAGGIO (3M) VT / LIFTING AND DRAINAGE HYDRAULIC SYSTEM (3M) VT Page 145
CBE12F_MONT_A_IMP_ALIMENTAZIONE_TRASLATORE_3M_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr IMPIANTO ALIMENTAZIONE CO HYDRAULIC SYSTEM INSTALL. HYDRAUL. HYDRAULISCHE ANLAGE INSTALACION HIDR.
codice secondo altezza di soll code according to lift height
1 (1) 1 nr TUBO PIPE TUYAU SCHLAUCH TUBO
2 0060362CE 2 nr RACCORDO DIR. A103002/10 CONNECTION RACCORD ANSCHLUSS UNION
3 0100031CE 4 nr VITE TE M8X16 UNI5739 BRU SCREW VIS SCHRAUBE TORNILLO
4 0120005CE 4 nr [Link] D.8 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
5 0120005CE 4 nr [Link] D.8 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
6 0101024CE 4 nr VITE TCEI M6X20 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
7 0101029CE 2 nr VITE TCEI M6X40 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
8 0120119CE 2 nr [Link]. D.6 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
9 0120026CE 2 nr [Link] 6,4 UNI1739 Z WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
10 0062043CE 2 nr COLLARE X TUBI GEMELLATI COLLAR COLLIER ANSCHLAGBUND COLLAR
11 1934050CE 1 nr MORSETTO [Link] TERMINAL BORNE KLEMME TERMINAL
12 0100231CE 1 nr VITE TE M12X60 UNI5737 BR SCREW VIS SCHRAUBE TORNILLO
13 0120122CE 1 nr [Link]. D12 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
14 1775113CE 1 nr PERNO PULEGGIA M.M.E. PULLEY PIN PIVOT DE POULIE RIEMENSCHEIBEBOLZEN PERNO DE POLEA
15 1775111CE 1 nr PULEGGIA TUBI ALIMENT. AT PULLEY POULIE RIEMENSCHEIBE POLEA
16 0134031CE 1 nr ANEL EL A40 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
17 (1) 1 nr ASTA ROD TIGE STANGE VARILLA
codice secondo altezza di soll code according to lift height
18 (1) 1 nr ASTA ROD TIGE STANGE VARILLA
codice secondo altezza di soll code according to lift height

IMPIANTO ALIMENTAZIONE TRASLATORE LAT. (3M) VT / SIDESHIFTING DEVICE HYDRAULIC INSTALL (3M) VT Page 146
IMPIANTO ALIMENTAZIONE TRASLATORE LAT. (3M) VT / SIDESHIFTING DEVICE HYDRAULIC INSTALL (3M) VT Page 147
CBE12F_MONT_A_MONTANTI_2M_ALT_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
2 2774045CE 2 nr RULLO GUIDA DIAM.60,5 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
3 0134029CE 2 nr ANEL EL A35 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
4 2934004CE 4 nr PATTINO GUIDA TRASV. D.97 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
5 2914028CE 2 nr RULLO GUIDA D.90,8 D.9708 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
6 0134036CE 2 nr ANEL EL A50 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
7 0135181CE 2 nr INGRASSATORE A 90 M 6X1 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
8 0013898CE 5 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
9 0101127CE 4 nr VITE TCEI M8X70 UNI5931 1 SCREW VIS SCHRAUBE TORNILLO
10 0110288CE 4 nr DADO AUTOBL.M8x1,25 N/70/ SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
11 1774024CE 2 nr COLLARE CILINDRO SECONDAR COLLAR COLLIER ANSCHLAGBUND COLLAR
12 0134016CE 2 nr ANEL EL A22 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
13 1824044CE 2 nr TIRANTE CATENA DIS.80542 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
14 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
15 0131002CE 2 nr COPIGLIA 1.5X15 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
16 0131031CE 2 nr COPIGLIA 3X20 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
17 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
m m
18 1774010CE 2 nr DADO AUTOCENTRANTE NUT ECROU MUTTER TUERCA
19 2774075CE 2 nr PULEGGIA CATENA PULLEY POULIE RIEMENSCHEIBE POLEA
20 1774085CE 1 nr SUPPORTO PULEGGIA CATENA PULLEY SUPPORT SUPPORT POULIE RIEMENSCHEIBESTSTZE SOPORTE POLEA
21 1774085CE 1 nr SUPPORTO PULEGGIA CATENA PULLEY SUPPORT SUPPORT POULIE RIEMENSCHEIBESTSTZE SOPORTE POLEA
22 1774086CE 2 nr PROTEZIONE ANTISCARRUCOLA GUARD PROTECTION SCHUTZ PROTECCION
23 0110246CE 2 nr DADO AUTOBLOC.M12 N70/112 SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
24 0100401CE 2 nr VITE TE M12X55 UNI5737 BR SCREW VIS SCHRAUBE TORNILLO
25 0101040CE 2 nr VITE TCEI M8X35 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
26 0100208CE 4 nr VITE TE M8X25 UNI 5737 SCREW VIS SCHRAUBE TORNILLO
27 0120120CE 4 nr [Link]. D.8 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
28 1774076CE 2 nr COLLARE RITEGNO CILINDRO COLLAR COLLIER ANSCHLAGBUND COLLAR
29 0100086CE 2 nr VITE TE M12X16 UNI5739 BR SCREW VIS SCHRAUBE TORNILLO
30 1021757CE 4 nr RONDELLA D.56641/52 WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
31 0120122CE 2 nr [Link]. D12 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
32 1934135CE 2 nr RONDELLA SVASATA WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
33 1774023CE 2 nr GHIERA REGOLAZIONE CILIND RING NUT BAGUE NUTMUTTER CASQUILLO
34 0100244CE 2 nr VITE TE M12X45 UNI5737 BR SCREW VIS SCHRAUBE TORNILLO
35 1774020CE 2 nr ANCORARAGGIO MONTANTE HOOK ACCROCHAGE KUPPLUNG ENGANCHE
36 0070188CE 2 nr SNODO SFERICO GE 40ES.2RS BALL AND SOCKET JOINT ARTICULATION A ROTULE KUGELGELENK ARTICULACION DE BOLA

MONTANTI (2M) A.L.T. / MASTS (2M) A.L.T. Page 148

MONTANTI (2M) A.L.T. / MASTS (2M) A.L.T. Page 149
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
37 0120121CE 4 nr [Link]. D10 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
38 0101053CE 4 nr VITE TCEI M10X35 UNI5931 SCREW VIS SCHRAUBE TORNILLO
39 0134031CE 2 nr ANEL EL A40 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
40 1774034CE 1 nr RETE PROTEZIONE SUPERIORE SAFETY GUARD GRILLE DE PROTECTION SCHUTZGITTER RED DE PROTECCION
VAR. VAR.
41 (1) 1 nr RETE NET FILET NETZ RED
VAR. VAR.
42 1724136CE 1 nr PIASTRINA [Link] PLATE PLAQUE PLATTE PLANCHA
VAR. VAR.
43 0101138CE 1 nr VITE TCEI M6X14 UNI5931 1 SCREW VIS SCHRAUBE TORNILLO
VAR. VAR.
44 0120119CE 1 nr [Link]. D.6 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
VAR. VAR.

MONTANTI (2M) A.L.T. / MASTS (2M) A.L.T. Page 150

MONTANTI (2M) A.L.T. / MASTS (2M) A.L.T. Page 151
CBE12F_MONT_A_MARTINETTO_ELEVATORE_CENT_LAT_2M_ALT_a_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr MARTINETTO ELEVATORE CENT CYLINDER VERIN ZYLINDER CILINDRO
codice secondo altezza di soll code according to lift height
1 1775104CE 1 nr BUSSOLA BUSHING DOUILLE BUCHSE CASQUILLO
2 1775103CE 1 nr FONDELLO BOTTOM CULOT ENDSCHEIBE FONDILLO
3 0063009CE 1 nr VALVOLA [Link]-N-H OD.41 VALVE SOUPAPE VENTIL VALVULA
4 2998186CE 1 nr KIT [Link] GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
6 0120032CE 1 nr RONDELLA M5 (5,5) BONDED WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA

MARTINETTO ELEVATORE CENTRALE (2M) A.L.T. / CENTRAL LIFT JACK (2M) A.L.T. Page 152
MARTINETTO ELEVATORE CENTRALE (2M) A.L.T. / CENTRAL LIFT JACK (2M) A.L.T. Page 153
CBE12F_MONT_A_MARTINETTO_ELEVATORE_CENT_LAT_2M_ALT_b_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr MARTINETTO ELEVATORE LATE CYLINDER VERIN ZYLINDER CILINDRO
codice secondo altezza di soll code according to lift height
7 1775241CE 1 nr TESTA CILINDRO CYLINDER HEAD CULASSE DE CYLINDRE ZYLINDERKOPF CULATA DEL CILINDRO
8 0120032CE 1 nr RONDELLA M5 (5,5) BONDED WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
9 0101031CE 1 nr VITE TCEI M6X10 UNI5931 1 SCREW VIS SCHRAUBE TORNILLO
10 1775240CE 1 nr BUSSOLA BUSHING DOUILLE BUCHSE CASQUILLO
11 1775239CE 1 nr CANOTTO FRENO CYLINDER CYLINDRE ZYLINDER CILINDRO
12 0063009CE 1 nr VALVOLA [Link]-N-H OD.41 VALVE SOUPAPE VENTIL VALVULA
13 1775238CE 1 nr FONDELLO BOTTOM CULOT ENDSCHEIBE FONDILLO
14 2998192CE 1 nr KIT [Link] GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS

MARTINETTO ELEVATORE LATERALE (2M) A.L.T. / SIDE LIFT JACK (2M) A.L.T. Page 154
MARTINETTO ELEVATORE LATERALE (2M) A.L.T. / SIDE LIFT JACK (2M) A.L.T. Page 155
CBE12F_MONT_A_CARRELLINO_PIASTRA_FISSA_2M_ALT_FEM_A_FEM_B_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4774223CE 1 nr CARRELLINO [Link] L=900 FORK CARRIAGE TABLIER PORTE-FOURCHE GABELTR?GER TABLERO HORQUILLAS
FEM 2A FEM 2A
0 4774222CE 1 nr CARRELLINO [Link] L=900 FORK CARRIAGE TABLIER PORTE-FOURCHE GABELTR?GER TABLERO HORQUILLAS
FEM 2B FEM 2B
1 0134036CE 4 nr ANEL EL A50 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
2 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
3 2914028CE 4 nr RULLO GUIDA D.90,8 D.9708 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
4 2934004CE 4 nr PATTINO GUIDA TRASV. D.97 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
5 0135181CE 2 nr INGRASSATORE A 90 M 6X1 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
6 1774027CE 4 nr PERNO PER RULLO D.90.8 ROLLER PIN PIVOT ROULEAU ROLLENBOLZEN PERNO DE RODILLO
7 0013898CE 2 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
8 1605235CE 2 nr PISTONE TUFFANTE D.85733/ WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
9 0102054CE 2 nr VITE TSPEI M12X20 UNI5933 SCREW VIS SCHRAUBE TORNILLO
10 0101064CE 4 nr VITE TCEI M12X20 UNI5931 SCREW VIS SCHRAUBE TORNILLO
11 0120122CE 4 nr [Link]. D12 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
12 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
m m
13 0131002CE 2 nr COPIGLIA 1.5X15 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
14 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
15 0131031CE 2 nr COPIGLIA 3X20 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
16 1824044CE 2 nr TIRANTE CATENA DIS.80542 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
17 1774010CE 2 nr DADO AUTOCENTRANTE NUT ECROU MUTTER TUERCA

CARRELLINO PIASTRA FISSA (2M) A.L.T. FEM A - FEM B / FORK CARRIAGE (2M) A.L.T. FEM A - FEM B Page 156
CARRELLINO PIASTRA FISSA (2M) A.L.T. FEM A - FEM B / FORK CARRIAGE (2M) A.L.T. FEM A - FEM B Page 157
CBE12F_MONT_A_TRASLATORE_LATERALE_2M_ALT_FEM_A_FEM_B

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4774240CE 1 nr TRASLATORE [Link] 2A SIDESHIFT DEPLACEMENT LATERAL SEITENSCHIEBER DESPLAZADOR LATERAL
FEM 2A FEM 2A
0 4774241CE 1 nr TRASLATORE [Link] 2B SIDESHIFT DEPLACEMENT LATERAL SEITENSCHIEBER DESPLAZADOR LATERAL
FEM 2B FEM 2B
18 1603448CE 2 nr TAMPONE D.92303 STOP ARRET ANSCHLAG PARADA
19 1623289CE 2 nr PATTINO D.92193 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
20 1603450CE 2 nr PATTINO INFERIORE D.92301 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
21 1603449CE 2 nr SPESSORE DI REGISTRO D.92 SHIM EPAISSEUR DICKE ESPESOR
22 0062043CE 1 nr COLLARE X TUBI GEMELLATI COLLAR COLLIER ANSCHLAGBUND COLLAR
23 0101026CE 2 nr VITE TCEI M6X25 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
24 0013898CE 2 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
25 0060297CE 4 nr RACCORDO CAST 101905 CONNECTION RACCORD ANSCHLUSS UNION
26 0060299CE 2 nr RACCORDO CAST 104205 CONNECTION RACCORD ANSCHLUSS UNION
27 1603504CE 2 nr TUBO [Link] CILIND PIPE TUYAU SCHLAUCH TUBO
28 0060298CE 2 nr RACCORDO CAST 104605 CONNECTION RACCORD ANSCHLUSS UNION
29 1603506CE 4 nr BUSSOLA PER TRASLATORE D. BUSHING DOUILLE BUCHSE CASQUILLO
30 1603446CE 4 nr VITE DI REGISTRAZIONE D.9 ADJUSTING SCREW VIS DE REGLAGE EINSTELLSCHRAUBE TORNILLO DE REGULACION
31 1603447CE 1 nr SPESSORE DI REGISTRAZIONE SHIM EPAISSEUR DICKE ESPESOR
VAR. VAR.
32 1774091CE 1 nr LAMIERA CHIUSURA [Link] PLATE (sheet of metal) TOLE BLECH CHAPA
33 1603505CE 4 nr ASTA PER TRASLATORE D.922 ROD TIGE STANGE VARILLA
35 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
36 0135181CE 4 nr INGRASSATORE A 90 M 6X1 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
37 2914028CE 4 nr RULLO GUIDA D.90,8 D.9708 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
38 0134036CE 4 nr ANEL EL A50 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
39 1774027CE 4 nr PERNO PER RULLO D.90.8 ROLLER PIN PIVOT ROULEAU ROLLENBOLZEN PERNO DE RODILLO
40 2934004CE 4 nr PATTINO GUIDA TRASV. D.97 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
41 2998141CE 1 nr [Link].D. GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
42 0131002CE 2 nr COPIGLIA 1.5X15 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
43 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
m m
44 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
45 0131031CE 2 nr COPIGLIA 3X20 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
46 1824044CE 2 nr TIRANTE CATENA DIS.80542 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
47 1774010CE 2 nr DADO AUTOCENTRANTE NUT ECROU MUTTER TUERCA
48 0101064CE 4 nr VITE TCEI M12X20 UNI5931 SCREW VIS SCHRAUBE TORNILLO
49 0120122CE 4 nr [Link]. D12 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA

TRASLATORE LATERALE (2M) A.L.T. FEM A - FEM B / SIDESHIFTING CARRIAGE (2M) A.L.T. FEM A - FEM B Page 158
TRASLATORE LATERALE (2M) A.L.T. FEM A - FEM B / SIDESHIFTING CARRIAGE (2M) A.L.T. FEM A - FEM B Page 159
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
51 1774092CE 1 nr LAMIERA CHIUSURA [Link] PLATE (sheet of metal) TOLE BLECH CHAPA

TRASLATORE LATERALE (2M) A.L.T. FEM A - FEM B / SIDESHIFTING CARRIAGE (2M) A.L.T. FEM A - FEM B Page 160
TRASLATORE LATERALE (2M) A.L.T. FEM A - FEM B / SIDESHIFTING CARRIAGE (2M) A.L.T. FEM A - FEM B Page 161
CBE12F_MONT_A_IMPIANTO_SOLLEVAMENTO_E_DRENAGGIO_2M_ALT_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr IMPIANTO ALIMENTAZIONE CO HYDRAULIC SYSTEM INSTALL. HYDRAUL. HYDRAULISCHE ANLAGE INSTALACION HIDR.
codice secondo altezza di soll code according to lift height
1 1994031CE 1 nr CORPO VALVOLA DISCESA RIF VALVE SOUPAPE VENTIL VALVULA
2 0020460CE 1 nr VALVOLA HAWE SB 25C VALVE SOUPAPE VENTIL VALVULA
3 0060258CE 6 nr DADO CAST 100207 (EX B 12 NUT ECROU MUTTER TUERCA
4 0060615CE 6 nr RACCORDO OGIVA 100107.4 C CONNECTION RACCORD ANSCHLUSS UNION
5 0100201CE 1 nr VITE TE M8X70 UNI5737 ZIN SCREW VIS SCHRAUBE TORNILLO
6 0060662CE 2 nr RACCORDO "A 707037-1217" CONNECTION RACCORD ANSCHLUSS UNION
7 0060671CE 2 nr RACCORDO DIRITTO rif.1005 CONNECTION RACCORD ANSCHLUSS UNION
8 0101144CE 2 nr VITE TCEI M5X8 UNI5931 12 SCREW VIS SCHRAUBE TORNILLO
9 0120118CE 2 nr [Link]. D.5 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
10 0070906CE 2 nr COLLARE "RS 1,12/12-1" COLLAR COLLIER ANSCHLAGBUND COLLAR
11 1775242CE 1 nr TUBO RIGIDO PIPE CONDUITE RIGIDE ROHR TUBO RIGIDO
12 1775243CE 1 nr TUBO RIGIDO PIPE CONDUITE RIGIDE ROHR TUBO RIGIDO
13 (1) 1 nr TUBO DESTRO PIPE TUYAU SCHLAUCH TUBO
codice secondo altezza di soll code according to lift height
14 (1) 1 nr TUBO SINISTRO PIPE TUYAU SCHLAUCH TUBO
codice secondo altezza di soll code according to lift height

IMPIANTO SOLLEVAMENTO E DRENAGGIO (2M) A.L.T. / LIFTING AND DRAINAGE HYDRAULIC SYSTEM (2M) A.L.T. Page 162
IMPIANTO SOLLEVAMENTO E DRENAGGIO (2M) A.L.T. / LIFTING AND DRAINAGE HYDRAULIC SYSTEM (2M) A.L.T. Page 163
CBE12F_MONT_A_IMP_ALIMENTAZIONE_TRASLATORE_2M_ALT_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr IMPIANTO ALIMENTAZIONE CO HYDRAULIC SYSTEM INSTALL. HYDRAUL. HYDRAULISCHE ANLAGE INSTALACION HIDR.
codice secondo altezza di soll code according to lift height
1 0100031CE 4 nr VITE TE M8X16 UNI5739 BRU SCREW VIS SCHRAUBE TORNILLO
2 0120120CE 4 nr [Link]. D.8 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
3 0120005CE 3 nr [Link] D.8 UNI6592 ZI WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
4 0101030CE 4 nr VITE TCEI M6X45 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
5 0062043CE 2 nr COLLARE X TUBI GEMELLATI COLLAR COLLIER ANSCHLAGBUND COLLAR
6 0110128CE 4 nr DADO AUTOBLOC. N10/106 ZI SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
7 0100086CE 1 nr VITE TE M12X16 UNI5739 BR SCREW VIS SCHRAUBE TORNILLO
8 0120122CE 2 nr [Link]. D12 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
9 1915108CE 1 nr LAMIERA ANTISCARRUC. TUBO PLATE (sheet of metal) TOLE BLECH CHAPA
10 1775112CE 1 nr PERNO PIN PIVOT STIFT PERNO
11 1775111CE 1 nr PULEGGIA TUBI ALIMENT. AT PULLEY POULIE RIEMENSCHEIBE POLEA
12 0135270CE 1 nr SPINA EL.5x16 UNI 6874-71 ELASTIC PIN GOUPILLE ELASTIQUE SPANNSTIFT PASADOR ELASTICO
13 (1) 1 nr TUBO PIPE TUYAU SCHLAUCH TUBO
codice secondo altezza di soll code according to lift height
14 0060362CE 2 nr RACCORDO DIR. A103002/10 CONNECTION RACCORD ANSCHLUSS UNION
15 (1) 1 nr ASTA ROD TIGE STANGE VARILLA
codice secondo altezza di soll code according to lift height
16 (1) 1 nr ASTA ROD TIGE STANGE VARILLA
codice secondo altezza di soll code according to lift height

IMPIANTO ALIMENTAZIONE TRASLATORE LAT. (2M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (2M) A.L.T. Page 164
IMPIANTO ALIMENTAZIONE TRASLATORE LAT. (2M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (2M) A.L.T. Page 165
CBE12F_MONT_A_MONTANTI_3M_ALT_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 1774038CE 4 nr PERNO PER RULLO D.60.5 ROLLER PIN PIVOT ROULEAU ROLLENBOLZEN PERNO DE RODILLO
2 0135181CE 2 nr INGRASSATORE A 90 M 6X1 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
3 1994037CE 8 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
4 1774034CE 1 nr RETE PROTEZIONE SUPERIORE SAFETY GUARD GRILLE DE PROTECTION SCHUTZGITTER RED DE PROTECCION
5 1724136CE 1 nr PIASTRINA [Link] PLATE PLAQUE PLATTE PLANCHA
VAR. VAR.
6 1774010CE 6 nr DADO AUTOCENTRANTE NUT ECROU MUTTER TUERCA
7 0023376CE 2 nr TAPPO [Link] 320 286 "OTM PLUG BOUCHON VERSCHLUSS TAPON
8 0101138CE 1 nr VITE TCEI M6X14 UNI5931 1 SCREW VIS SCHRAUBE TORNILLO
VAR. VAR.
9 1934142CE 1 nr PROTEZIONE IN RETE INFERI LOWER PROTECTION PROTECTION INFERIEURE UNTERSCHUTZ PROTECCION INFERIOR
10 (1) 1 nr RETE NET FILET NETZ RED
codice secondo altezza di soll CODE ACCORDING TO LIFT HEIGHT
11 0120119CE 1 nr [Link]. D.6 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
VAR. VAR.
12 0101053CE 4 nr VITE TCEI M10X35 UNI5931 SCREW VIS SCHRAUBE TORNILLO
13 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
m m
14 0131002CE 6 nr COPIGLIA 1.5X15 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
15 1994033CE 6 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
16 1774089CE 2 nr TIRANTE CATENA CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
17 1774020CE 2 nr ANCORARAGGIO MONTANTE HOOK ACCROCHAGE KUPPLUNG ENGANCHE
18 0120121CE 4 nr [Link]. D10 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
19 2774045CE 4 nr RULLO GUIDA DIAM.60,5 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
20 0134029CE 6 nr ANEL EL A35 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
21 2934004CE 8 nr PATTINO GUIDA TRASV. D.97 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
22 2774075CE 3 nr PULEGGIA CATENA PULLEY POULIE RIEMENSCHEIBE POLEA
23 0101127CE 4 nr VITE TCEI M8X70 UNI5931 1 SCREW VIS SCHRAUBE TORNILLO
24 0110288CE 4 nr DADO AUTOBL.M8x1,25 N/70/ SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
25 1774024CE 2 nr COLLARE CILINDRO SECONDAR COLLAR COLLIER ANSCHLAGBUND COLLAR
26 0134016CE 2 nr ANEL EL A22 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
27 1774086CE 2 nr PROTEZIONE ANTISCARRUCOLA GUARD PROTECTION SCHUTZ PROTECCION
28 0100244CE 4 nr VITE TE M12X45 UNI5737 BR SCREW VIS SCHRAUBE TORNILLO
29 1021757CE 4 nr RONDELLA D.56641/52 WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
30 1774023CE 4 nr GHIERA REGOLAZIONE CILIND RING NUT BAGUE NUTMUTTER CASQUILLO
31 1774027CE 4 nr PERNO PER RULLO D.90.8 ROLLER PIN PIVOT ROULEAU ROLLENBOLZEN PERNO DE RODILLO
32 2914028CE 4 nr RULLO GUIDA D.90,8 D.9708 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA

MONTANTI (3M) A.L.T. / MASTS (3M) A.L.T. Page 166

MONTANTI (3M) A.L.T. / MASTS (3M) A.L.T. Page 167
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
33 0134036CE 4 nr ANEL EL A50 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
34 0100401CE 2 nr VITE TE M12X55 UNI5737 BR SCREW VIS SCHRAUBE TORNILLO
35 0101040CE 2 nr VITE TCEI M8X35 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
36 1774085CE 2 nr SUPPORTO PULEGGIA CATENA PULLEY SUPPORT SUPPORT POULIE RIEMENSCHEIBESTSTZE SOPORTE POLEA
37 0110246CE 2 nr DADO AUTOBLOC.M12 N70/112 SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
38 0100208CE 4 nr VITE TE M8X25 UNI 5737 SCREW VIS SCHRAUBE TORNILLO
39 0120120CE 6 nr [Link]. D.8 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
40 1774076CE 2 nr COLLARE RITEGNO CILINDRO COLLAR COLLIER ANSCHLAGBUND COLLAR
41 1824044CE 4 nr TIRANTE CATENA DIS.80542 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
42 0131031CE 6 nr COPIGLIA 3X20 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
43 0013898CE 11 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
44 0070188CE 2 nr SNODO SFERICO GE 40ES.2RS BALL AND SOCKET JOINT ARTICULATION A ROTULE KUGELGELENK ARTICULACION DE BOLA
45 0134031CE 2 nr ANEL EL A40 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO

MONTANTI (3M) A.L.T. / MASTS (3M) A.L.T. Page 168

MONTANTI (3M) A.L.T. / MASTS (3M) A.L.T. Page 169
CBE12F_MONT_A_MARTINETTO_ELEVATORE_CENT_LAT_3M_ALT_b_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr MARTINETTO ELEVATORE LATE CYLINDER VERIN ZYLINDER CILINDRO
codice secondo altezza di soll code according to lift height
1 0063009CE 1 nr VALVOLA [Link]-N-H OD.41 VALVE SOUPAPE VENTIL VALVULA
2 1775219CE 1 nr FONDELLO PER CILINDRO SOL BOTTOM CULOT ENDSCHEIBE FONDILLO
3 1775218CE 1 nr CORPO FRENO BRAKE CASING CORPS DU FREIN BREMSKÍRPER CUERPO FRENO
4 2998185CE 1 nr KIT [Link].C/F GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
5 0134133CE 1 nr ANELLO ELASTICO x FORI JV SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
6 0135264CE 1 nr SFERA RB-15,875 BALL BILLE KUGEL BOLA

MARTINETTO ELEVATORE LATERALE (3M) A.L.T. / SIDE LIFT JACK (3M) A.L.T. Page 170
MARTINETTO ELEVATORE LATERALE (3M) A.L.T. / SIDE LIFT JACK (3M) A.L.T. Page 171
CBE12F_MONT_A_MARTINETTO_ELEVATORE_CENT_LAT_3M_ALT_a_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr MARTINETTO ELEVATORE CENT CYLINDER VERIN ZYLINDER CILINDRO
codice secondo altezza di soll code according to lift height
7 1775104CE 1 nr BUSSOLA BUSHING DOUILLE BUCHSE CASQUILLO
8 1775103CE 1 nr FONDELLO BOTTOM CULOT ENDSCHEIBE FONDILLO
9 0063009CE 1 nr VALVOLA [Link]-N-H OD.41 VALVE SOUPAPE VENTIL VALVULA
10 2998186CE 1 nr KIT [Link] GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS

MARTINETTO ELEVATORE CENTRALE (3M) A.L.T. / CENTRAL LIFT JACK (3M) A.L.T. Page 172
MARTINETTO ELEVATORE CENTRALE (3M) A.L.T. / CENTRAL LIFT JACK (3M) A.L.T. Page 173
CBE12F_MONT_A_CARRELLINO_PIASTRA_FISSA_3M_ALT_FEM_A_FEM_B_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4774223CE 1 nr CARRELLINO [Link] L=900 FORK CARRIAGE TABLIER PORTE-FOURCHE GABELTR?GER TABLERO HORQUILLAS
FEM 2A FEM 2A
0 4774222CE 1 nr CARRELLINO [Link] L=900 FORK CARRIAGE TABLIER PORTE-FOURCHE GABELTR?GER TABLERO HORQUILLAS
FEM 2B FEM 2B
1 0134036CE 4 nr ANEL EL A50 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
2 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
3 2914028CE 4 nr RULLO GUIDA D.90,8 D.9708 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
4 2934004CE 4 nr PATTINO GUIDA TRASV. D.97 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
5 1774027CE 4 nr PERNO PER RULLO D.90.8 ROLLER PIN PIVOT ROULEAU ROLLENBOLZEN PERNO DE RODILLO
5 0135181CE 2 nr INGRASSATORE A 90 M 6X1 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
7 0013898CE 2 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
8 1605235CE 2 nr PISTONE TUFFANTE D.85733/ WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
9 0102054CE 2 nr VITE TSPEI M12X20 UNI5933 SCREW VIS SCHRAUBE TORNILLO
10 0101064CE 4 nr VITE TCEI M12X20 UNI5931 SCREW VIS SCHRAUBE TORNILLO
11 0120122CE 4 nr [Link]. D12 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
12 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
m m
13 0131002CE 2 nr COPIGLIA 1.5X15 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
14 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
15 0131031CE 2 nr COPIGLIA 3X20 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
16 1824044CE 2 nr TIRANTE CATENA DIS.80542 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
17 1774010CE 2 nr DADO AUTOCENTRANTE NUT ECROU MUTTER TUERCA

CARRELLINO PIASTRA FISSA (3M) A.L.T. FEM A - FEM B / FORK CARRIAGE (3M) A.L.T. FEM A - FEM B Page 174
CARRELLINO PIASTRA FISSA (3M) A.L.T. FEM A - FEM B / FORK CARRIAGE (3M) A.L.T. FEM A - FEM B Page 175
CBE12F_MONT_A_TRASLATORE_LATERALE_3M_ALT_FEM_A_FEM_B_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4774240CE 1 nr TRASLATORE [Link] 2A SIDESHIFT DEPLACEMENT LATERAL SEITENSCHIEBER DESPLAZADOR LATERAL
FEM 2A FEM 2A
0 4774241CE 1 nr TRASLATORE [Link] 2B SIDESHIFT DEPLACEMENT LATERAL SEITENSCHIEBER DESPLAZADOR LATERAL
FEM 2B FEM 2B
18 1603448CE 2 nr TAMPONE D.92303 STOP ARRET ANSCHLAG PARADA
19 1623289CE 2 nr PATTINO D.92193 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
20 1603450CE 2 nr PATTINO INFERIORE D.92301 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
21 1603449CE 2 nr SPESSORE DI REGISTRO D.92 SHIM EPAISSEUR DICKE ESPESOR
22 0062043CE 1 nr COLLARE X TUBI GEMELLATI COLLAR COLLIER ANSCHLAGBUND COLLAR
23 0101026CE 2 nr VITE TCEI M6X25 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
24 0013898CE 2 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
25 0060297CE 4 nr RACCORDO CAST 101905 CONNECTION RACCORD ANSCHLUSS UNION
26 0060299CE 2 nr RACCORDO CAST 104205 CONNECTION RACCORD ANSCHLUSS UNION
27 1603504CE 2 nr TUBO [Link] CILIND PIPE TUYAU SCHLAUCH TUBO
28 0060298CE 2 nr RACCORDO CAST 104605 CONNECTION RACCORD ANSCHLUSS UNION
29 1603506CE 4 nr BUSSOLA PER TRASLATORE D. BUSHING DOUILLE BUCHSE CASQUILLO
30 1603446CE 4 nr VITE DI REGISTRAZIONE D.9 ADJUSTING SCREW VIS DE REGLAGE EINSTELLSCHRAUBE TORNILLO DE REGULACION
31 1603447CE 1 nr SPESSORE DI REGISTRAZIONE SHIM EPAISSEUR DICKE ESPESOR
VAR. VAR.
32 1774091CE 1 nr LAMIERA CHIUSURA [Link] PLATE (sheet of metal) TOLE BLECH CHAPA
33 1603505CE 4 nr ASTA PER TRASLATORE D.922 ROD TIGE STANGE VARILLA
35 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
36 0135181CE 4 nr INGRASSATORE A 90 M 6X1 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
37 2914028CE 4 nr RULLO GUIDA D.90,8 D.9708 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
38 0134036CE 4 nr ANEL EL A50 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
39 1774027CE 4 nr PERNO PER RULLO D.90.8 ROLLER PIN PIVOT ROULEAU ROLLENBOLZEN PERNO DE RODILLO
40 2934004CE 4 nr PATTINO GUIDA TRASV. D.97 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
41 2998141CE 1 nr [Link].D. GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS
42 0131002CE 2 nr COPIGLIA 1.5X15 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
43 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
m m
44 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
45 0131031CE 2 nr COPIGLIA 3X20 UNI1336 SPLIT PIN GOUPILLE SPLINT PASADOR HENDIDO
46 1824044CE 2 nr TIRANTE CATENA DIS.80542 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
47 1774010CE 2 nr DADO AUTOCENTRANTE NUT ECROU MUTTER TUERCA
48 0101064CE 4 nr VITE TCEI M12X20 UNI5931 SCREW VIS SCHRAUBE TORNILLO
49 0120122CE 4 nr [Link]. D12 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA

TRASLATORE LATERALE (3M) A.L.T. FEM A - FEM B / SIDESHIFTING CARRIAGE (3M) A.L.T. FEM A - FEM B Page 176
TRASLATORE LATERALE (3M) A.L.T. FEM A - FEM B / SIDESHIFTING CARRIAGE (3M) A.L.T. FEM A - FEM B Page 177
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
51 1774092CE 1 nr LAMIERA CHIUSURA [Link] PLATE (sheet of metal) TOLE BLECH CHAPA

TRASLATORE LATERALE (3M) A.L.T. FEM A - FEM B / SIDESHIFTING CARRIAGE (3M) A.L.T. FEM A - FEM B Page 178
TRASLATORE LATERALE (3M) A.L.T. FEM A - FEM B / SIDESHIFTING CARRIAGE (3M) A.L.T. FEM A - FEM B Page 179
CBE12F_MONT_A_IMPIANTO_SOLLEVAMENTO_ E_DRENAGGIO_3M_ALT_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr IMPIANTO ALIMENTAZIONE CO HYDRAULIC SYSTEM INSTALL. HYDRAUL. HYDRAULISCHE ANLAGE INSTALACION HIDR.
codice secondo altezza di soll code according to lift height
1 0060356CE 2 nr [Link] [Link].1/8" CONNECTION RACCORD ANSCHLUSS UNION
2 0023258CE 1 mt TUBO POLIETILENE 8X6 NERO FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
m m
3 0060615CE 6 nr RACCORDO OGIVA 100107.4 C CONNECTION RACCORD ANSCHLUSS UNION
4 (1) 2 nr TUBO PIPE TUYAU SCHLAUCH TUBO
codice secondo altezza di soll code according to lift height
5 0070906CE 4 nr COLLARE "RS 1,12/12-1" COLLAR COLLIER ANSCHLAGBUND COLLAR
6 0101144CE 4 nr VITE TCEI M5X8 UNI5931 12 SCREW VIS SCHRAUBE TORNILLO
7 0120118CE 4 nr [Link]. D.5 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
8 0060615CE 6 nr RACCORDO OGIVA 100107.4 C CONNECTION RACCORD ANSCHLUSS UNION
9 0060662CE 2 nr RACCORDO "A 707037-1217" CONNECTION RACCORD ANSCHLUSS UNION
10 0060663CE 2 nr RACCORDO rif.103907.4 "CA CONNECTION RACCORD ANSCHLUSS UNION
11 1775108CE 1 nr TUBO RIGIDO SN PIPE CONDUITE RIGIDE ROHR TUBO RIGIDO
12 1775089CE 2 nr TUBO RIGIDO PIPE CONDUITE RIGIDE ROHR TUBO RIGIDO
13 1994031CE 2 nr CORPO VALVOLA DISCESA RIF VALVE SOUPAPE VENTIL VALVULA
14 1775107CE 1 nr TUBO RIGIDO DS PIPE CONDUITE RIGIDE ROHR TUBO RIGIDO
15 (1) 1 nr TUBO PIPE TUYAU SCHLAUCH TUBO
codice secondo altezza di soll code according to lift height
16 1775109CE 2 nr PULEGGIA TUBO ALIMENTAZIO PULLEY POULIE RIEMENSCHEIBE POLEA
17 0134024CE 2 nr ANEL EL A30 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
18 1024701CE 2 nr RONDELLA [Link].D.56 WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
19 0101027CE 4 nr VITE TCEI M6X30 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
20 0070624CE 2 nr COLLARE C3 D. 14 "[Link] COLLAR COLLIER ANSCHLAGBUND COLLAR
21 0060323CE 2 nr RACCORDO A GOMITO A107039 CONNECTION RACCORD ANSCHLUSS UNION
22 0060375CE 1 nr RACCORDO A "T" PLAST.x TU CONNECTION RACCORD ANSCHLUSS UNION
23 0020460CE 1 nr VALVOLA HAWE SB 25C VALVE SOUPAPE VENTIL VALVULA
24 0070907CE 2 nr COLLARE "RSGU 0-14/15-1" COLLAR COLLIER ANSCHLAGBUND COLLAR
25 0120119CE 2 nr [Link]. D.6 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
26 0101031CE 2 nr VITE TCEI M6X10 UNI5931 1 SCREW VIS SCHRAUBE TORNILLO

IMPIANTO SOLLEVAMENTO E DRENAGGIO (3M) A.L.T. / LIFTING AND DRAINAGE SYSTEM (3M) A.L.T. Page 180
IMPIANTO SOLLEVAMENTO E DRENAGGIO (3M) A.L.T. / LIFTING AND DRAINAGE SYSTEM (3M) A.L.T. Page 181
CBE12F_MONT_A_IMP_ALIMENTAZIONE_TRASLATORE_3M_ALT

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr IMPIANTO ALIMENTAZIONE CO HYDRAULIC SYSTEM INSTALL. HYDRAUL. HYDRAULISCHE ANLAGE INSTALACION HIDR.
codice secondo altezza di soll code according to lift height
1 0100086CE 1 nr VITE TE M12X16 UNI5739 BR SCREW VIS SCHRAUBE TORNILLO
2 0120122CE 3 nr [Link]. D12 DIN7980 Z SPRING WASHER RONDELLE A RESSORT FEDERSCHEIBE ARANDELA ELASTICA
3 1915108CE 2 nr LAMIERA ANTISCARRUC. TUBO PLATE (sheet of metal) TOLE BLECH CHAPA
4 1775111CE 2 nr PULEGGIA TUBI ALIMENT. AT PULLEY POULIE RIEMENSCHEIBE POLEA
5 0100232CE 1 nr VITE TE M12X65 UNI5737 SCREW VIS SCHRAUBE TORNILLO
6 0134031CE 1 nr ANEL EL A40 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
8 0135270CE 1 nr SPINA EL.5x16 UNI 6874-71 ELASTIC PIN GOUPILLE ELASTIQUE SPANNSTIFT PASADOR ELASTICO
9 0110128CE 2 nr DADO AUTOBLOC. N10/106 ZI SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
10 (1) 1 nr TUBO PIPE TUYAU SCHLAUCH TUBO
codice secondo altezza di soll code according to lift height
11 1775200CE 2 nr MORSETTO FISSAGGIO TUBI D TERMINAL BORNE KLEMME TERMINAL
12 0102020CE 1 nr VITE TSPEI M10X20 UNI5933 SCREW VIS SCHRAUBE TORNILLO
13 0102054CE 1 nr VITE TSPEI M12X20 UNI5933 SCREW VIS SCHRAUBE TORNILLO
14 0070584CE 1 nr COLLARE DOPPIO CF1 12/12" COLLAR COLLIER ANSCHLAGBUND COLLAR
15 0070585CE 1 nr PIASTRA SUPERIORE CF1 "PI PLATE PLAQUE PLATTE PLANCHA
16 0101028CE 3 nr VITE TCEI M6X35 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
17 0101028CE 5 nr VITE TCEI M6X35 UNI5931 Z SCREW VIS SCHRAUBE TORNILLO
18 1935068CE 1 nr STAFFA RINVIO TUBI FLESS. BRACKET ETRIER BSGEL ESTRIBO
19 1935069CE 1 nr DISCO [Link] FLESS. DISK DISQUE SCHEIBE DISCO
20 0060362CE 2 nr RACCORDO DIR. A103002/10 CONNECTION RACCORD ANSCHLUSS UNION
21 1775112CE 1 nr PERNO PIN PIVOT STIFT PERNO
22 1775113CE 1 nr PERNO PULEGGIA M.M.E. PULLEY PIN PIVOT DE POULIE RIEMENSCHEIBEBOLZEN PERNO DE POLEA

IMPIANTO ALIMENTAZIONE TRASLATORE LAT. (3M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (3M) A.L.T. Page 182
IMPIANTO ALIMENTAZIONE TRASLATORE LAT. (3M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (3M) A.L.T. Page 183
CBE12F_MONT_A_FORCHE_2_3M_ALT_FEM_A_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 4774342CE 1 nr FORCA FEM 2A 100X35 L=130 FORK FOURCHE GABEL HORQUILLA
1 4774343CE 1 nr FORCA FEM 2A 100X35 L=140 FORK FOURCHE GABEL HORQUILLA
1 4774299CE 1 nr FORCA FEM 2A 100X35 L=900 FORKS 900 MM FOURCHES 900 MM GABEL HORQUILLA
1 4774300CE 1 nr FORCA FEM 2A 100X35 L=100 FORKS L=1000 FEM 2A FOURCHES 1000 MM GABELN 1000MM FEM 2A HORQUILLAS 1000 MM
1 4774301CE 1 nr FORCA FEM 2A 100X35 L=110 FORKS 1100 MM. FEM 2A FOURCHES 1100 MM GABELN 1100 MM. HORQUILLAS 1100 MM
1 4774302CE 1 nr FORCA FEM 2A 100X35 L=120 FORKS 1200MM FOURCHES 1200 MM GABELN 1200 MM. HORQUILLAS 1200 MM
2 2994133CE 1 nr KIT PERNO ARRESTO FORCA F KIT JEU SATZ JUEGO

Le forche si forniscono solo a coppie / The forks are delivered two by two only / N.D. / N.D. / N.D.

FORCHE FEM 2A / FORKS FEM 2A Page 184

FORCHE FEM 2A / FORKS FEM 2A Page 185
CBE12F_MONT_A_FORCHE_2_3M_ALT_FEM_B_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 4604371CE 1 nr FORCA L.1300 SEZ.100X35 F FORKS 1300 MM. FOURCHES 1300 MM. GABELN 1300 MM. HORQUILLAS 1300 MM.
1 4604372CE 1 nr FORCA L.1400 SEZ.100X35 F FORKS MM 1400 FOURCHES MM 1400 GABELN MM 1400 HORQUILLAS MM 1400
1 4604360CE 1 nr FORCA L.1000 SEZ.100X35 F FORKS MM 1000 FOURCHES MM 1000 GABELN MM 1000 HORQUILLAS MM 1000
1 4604361CE 1 nr FORCA L.1200 SEZ.100X35 F FORKS MM 1200 FOURCHES MM 1200 GABELN MM 1200 HORQUILLAS MM 1200
1 4604364CE 1 nr FORCA L.1100 SEZ.100X35 F FORKS MM 1100 FOURCHES MM 1100 GABELN MM 1100 HORQUILLAS MM 1100
1 4604359CE 1 nr FORCA L.900 SEZ.100X35 FE FORKS 900 MM FOURCHES 900 MM GABELN 900 MM HORQUILLAS 900 MM
2 2994133CE 1 nr KIT PERNO ARRESTO FORCA F KIT JEU SATZ JUEGO

Le forche si forniscono solo a coppie / The forks are delivered two by two only / N.D. / N.D. / N.D.

FORCHE FEM 2B / FORKS FEM 2B Page 186

FORCHE FEM 2B / FORKS FEM 2B Page 187
This Page Intentionally Blank
CBE12F_MONT_
CBE12F_MONT_MONTANTI_2M_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 2862010CE 2 nr RULLO GUIDA D.61,8 RIF.13 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
Per altezze > 5000 For height > 5000
1 1994016CE 2 nr RULLO GUIDA D.60,5 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
2 1994018CE 2 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
3 1994020CE 2 nr PULEGGIA CATENA RIF. 0331 PULLEY POULIE RIEMENSCHEIBE POLEA
4 1994021CE 2 nr TIRANTE CATENA RIF.13580 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
5 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
6 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
7 1994017CE 2 nr RULLO GUIDA D.80,5 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
7 1994038CE 2 nr RULLO GUIDA D.81,8 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
Per altezze > 5000 For height > 5000
8 1994019CE 2 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
9 0070188CE 2 nr SNODO SFERICO GE 40ES.2RS BALL AND SOCKET JOINT ARTICULATION A ROTULE KUGELGELENK ARTICULACION DE BOLA
10 0134031CE 2 nr ANEL EL A40 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
11 0013898CE 6 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
12 1994044CE 2 nr SUPPORTO [Link] MONT ROLLER BEARING PALIER A ROULEAUX ROLLENTR¬GER SOPORTE RODILLO
13 1994045CE 2 nr SUPPORTO [Link] MONT MAST SUPPORT SUPPORT DE MAT MASTBEFESTIGUNG SOPORTE MASTIL
14 1994022CE 2 nr TIRANTE CATENA RIF.10901 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
15 1869012CE 4 nr DADO AUTOBLOCCANTE RIF.03 SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
16 1994033CE 4 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
17 0134033CE 4 nr ANEL. EL. A45 UNI 7435 E( SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
18 0134029CE 2 nr ANEL EL A35 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
19 1864064CE 2 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
20 1864063CE 2 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
21 1864058CE 2 nr COLLARE RITEGNO CILINDRO COLLAR COLLIER ANSCHLAGBUND COLLAR
22 1869013CE 2 nr 1869013CE 1869013
23 0133007CE 2 nr GRANO M12X12 UNI 5923 DOWEL GOUJON STIFT CLAVIJA
24 1864241CE 1 nr RETE ANTICES. DI ESTREM. SAFETY GUARD GRILLE DE PROTECTION SCHUTZGITTER RED DE PROTECCION
25 0101064CE 2 nr VITE TCEI M12X20 UNI5931 SCREW VIS SCHRAUBE TORNILLO
26 1724136CE 2 nr PIASTRINA [Link] PLATE PLAQUE PLATTE PLANCHA
27 2864079CE 2 nr STAFFA COLLEGAMENTO RETE BRACKET ETRIER B?GEL ESTRIBO
28 1994037CE 2 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
29 0110048CE 2 nr DADO ES. M12 UNI5589 NUT ECROU MUTTER TUERCA

MONTANTI (2M) / MASTS (DUPLEX) Page 190

MONTANTI (2M) / MASTS (DUPLEX) Page 191
CBE12F_MONT_MARTINETTO_ELEVATORE_2M_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 (1) 1 nr CORPO BODY CORPS GEAUSE CUERPO
codice secondo altezza di soll code according to lift height
2 (1) 1 nr ASTA ROD TIGE STANGE VARILLA
codice secondo altezza di soll code according to lift height
3 1864017CE 1 nr FONDELLO RIF.13684 BOTTOM CULOT ENDSCHEIBE FONDILLO
4 0063009CE 1 nr VALVOLA [Link]-N-H OD.41 VALVE SOUPAPE VENTIL VALVULA
5 1864018CE 1 nr DADO RITEGNO CILINDRO RIF NUT ECROU MUTTER TUERCA
6 1864061CE 1 nr CALOTTA [Link] COVER COVER KAPPE TAPA
7 2998151CE 1 nr KIT GUARNIZIONI GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS

MARTINETTO ELEVATORE (2M) / LIFT JACK (DUPLEX) Page 192

MARTINETTO ELEVATORE (2M) / LIFT JACK (DUPLEX) Page 193
CBE12F_MONT_CARRELLINO_E_TRASLATORE_LAT_2M_b_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4864003CE 1 nr CARRELLINO SOLL. [Link] FORK CARRIAGE TABLIER PORTE-FOURCHE GABELTR?GER TABLERO HORQUILLAS
0 4864113CE 1 nr 4864113 4864113
Per altezze > 5000 For height > 5000
1 1864064CE 4 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
2 0134033CE 4 nr ANEL. EL. A45 UNI 7435 E( SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
3 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
4 1994038CE 4 nr RULLO GUIDA D.81,8 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
Per altezze > 5000 For height > 5000
4 1994017CE 4 nr RULLO GUIDA D.80,5 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
5 1994019CE 4 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
6 0013898CE 4 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
7 1994045CE 4 nr SUPPORTO [Link] MONT MAST SUPPORT SUPPORT DE MAT MASTBEFESTIGUNG SOPORTE MASTIL
8 1604235CE 2 nr ARRESTO FORCA K16/30 D.88 STOP ARRET ANSCHLAG PARADA
9 0102034CE 2 nr VITE TSPEI 12X30 UNI5933- SCREW VIS SCHRAUBE TORNILLO
10 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
11 1994022CE 2 nr TIRANTE CATENA RIF.10901 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA

CARRELLINO PIASTRA FISSA (2M) / FORK CARRIAGE (DUPLEX) Page 194

CARRELLINO PIASTRA FISSA (2M) / FORK CARRIAGE (DUPLEX) Page 195
CBE12F_MONT_CARRELLINO_E_TRASLATORE_LAT_2M_a_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4864005CE 1 nr CARRELLINO [Link] SIDESHIFT FORK CARRIAGE TABLIER DEPLACEMENT LAT. SEITENSCHIEBER GABELTR?GE TABLERO DESPLADOR LAT.
0 4864115CE 1 nr 4864115 4864115
Per altezze > 5000 For height > 5000
12 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
13 1994019CE 4 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
14 1994038CE 4 nr RULLO GUIDA D.81,8 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
Per altezze > 5000 For height > 5000
14 1994017CE 4 nr RULLO GUIDA D.80,5 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
15 1603506CE 1 nr BUSSOLA PER TRASLATORE D. BUSHING DOUILLE BUCHSE CASQUILLO
16 1994025CE 2 nr TUBO ALIMENTAZ. CILINDRI PIPE TUYAU SCHLAUCH TUBO
17 0060361CE 2 nr RACCORDO CAST 102705 CONNECTION RACCORD ANSCHLUSS UNION
18 1623289CE 2 nr PATTINO D.92193 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
19 0060236CE 2 nr RACCORDO CAST 101905 (EX CONNECTION RACCORD ANSCHLUSS UNION
20 1603449CE 1 nr SPESSORE DI REGISTRO D.92 SHIM EPAISSEUR DICKE ESPESOR
21 1603450CE 2 nr PATTINO INFERIORE D.92301 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
22 1603507CE 2 nr CHIUSURA ESTERNA D.92297 PANEL PANNEAU PLATTE CHAPA
23 1603446CE 4 nr VITE DI REGISTRAZIONE D.9 ADJUSTING SCREW VIS DE REGLAGE EINSTELLSCHRAUBE TORNILLO DE REGULACION
24 1603447CE 1 nr SPESSORE DI REGISTRAZIONE SHIM EPAISSEUR DICKE ESPESOR
25 1603505CE 4 nr ASTA PER TRASLATORE D.922 ROD TIGE STANGE VARILLA
26 0102052CE 12 nr VITE TSPEI M12X35 UNI5933 SCREW VIS SCHRAUBE TORNILLO
27 1603448CE 1 nr TAMPONE D.92303 STOP ARRET ANSCHLAG PARADA
28 1864064CE 4 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
29 0134033CE 4 nr ANEL. EL. A45 UNI 7435 E( SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
30 0013898CE 6 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
31 1994045CE 4 nr SUPPORTO [Link] MONT MAST SUPPORT SUPPORT DE MAT MASTBEFESTIGUNG SOPORTE MASTIL
32 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
33 1994022CE 2 nr TIRANTE CATENA RIF.10901 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
34 2998141CE 1 nr [Link].D. GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS

CARRELLINO TRASLATORE LATERALE (2M) / SIDESHIFTING CARRIAGE (DUPLEX) Page 196

CARRELLINO TRASLATORE LATERALE (2M) / SIDESHIFTING CARRIAGE (DUPLEX) Page 197
CBE12F_MONT_IMP_ALIMENTAZIONE_TRASLATORE_2M_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr IMPIANTO ALIMENTAZIONE CO HYDRAULIC SYSTEM INSTALL. HYDRAUL. HYDRAULISCHE ANLAGE INSTALACION HIDR.
codice secondo altezza di soll CODE ACCORDING TO LIFT HEIGHT
1 1865053CE 1 nr PERNO SOSTEGNO PULEGGIA R PULLEY PIN PIVOT DE POULIE RIEMENSCHEIBEBOLZEN PERNO DE POLEA
2 1865052CE 1 nr PULEGGIA [Link]. RIF. PULLEY POULIE RIEMENSCHEIBE POLEA
3 0060374CE 2 nr [Link] MASCHIO 6500- CONNECTION RACCORD ANSCHLUSS UNION
4 0070585CE 4 nr PIASTRA SUPERIORE CF1 "PI PLATE PLAQUE PLATTE PLANCHA
5 0070584CE 4 nr COLLARE DOPPIO CF1 12/12" COLLAR COLLIER ANSCHLAGBUND COLLAR
6 1994031CE 1 nr CORPO VALVOLA DISCESA RIF VALVE SOUPAPE VENTIL VALVULA
7 1994042CE 1 nr TUBO RIGIDO MARTINETTO SO PIPE CONDUITE RIGIDE ROHR TUBO RIGIDO
8 0060375CE 1 nr RACCORDO A "T" PLAST.x TU CONNECTION RACCORD ANSCHLUSS UNION
9 1994043CE 1 nr TUBO RIGIDO MARTINETTO SO PIPE CONDUITE RIGIDE ROHR TUBO RIGIDO
10 0020460CE 1 nr VALVOLA HAWE SB 25C VALVE SOUPAPE VENTIL VALVULA
11 0023258CE 1 mt TUBO POLIETILENE 8X6 NERO FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
12 0060362CE 2 nr RACCORDO DIR. A103002/10 CONNECTION RACCORD ANSCHLUSS UNION
13 0100232CE 1 nr VITE TE M12X65 UNI5737 SCREW VIS SCHRAUBE TORNILLO
14 0061851CE 1 mt TUBO [Link].1/4 MAC-FLE FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
15 0060365CE 4 nr BOCCOLA A PRESSARE PER TU BUSHING BAGUE BUCHSE BUCHSE
16 0060363CE 2 nr RACCORDO [Link].D. CONNECTION RACCORD ANSCHLUSS UNION
17 0060364CE 2 nr RACCORDO [Link] CONNECTION RACCORD ANSCHLUSS UNION
18 0060258CE 4 nr DADO CAST 100207 (EX B 12 NUT ECROU MUTTER TUERCA
19 0060615CE 4 nr RACCORDO OGIVA 100107.4 C CONNECTION RACCORD ANSCHLUSS UNION
20 0060395CE 2 nr RACCORDO CAMOZZI RIF.1320 CONNECTION RACCORD ANSCHLUSS UNION

IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (2M) / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (DUPLEX) Page 198
IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (2M) / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (DUPLEX) Page 199
CBE12F_MONT_FORCHE_2M_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 4604428CE 1 nr FORCA L.1050 SEZ.100X35 F FORKS 1050 MM FOURCHES 1050 MM GABELN 1050 MM HORQUILLAS 1050 MM
1 4604360CE 1 nr FORCA L.1000 SEZ.100X35 F FORKS MM 1000 FOURCHES MM 1000 GABELN MM 1000 HORQUILLAS MM 1000
1 4604361CE 1 nr FORCA L.1200 SEZ.100X35 F FORKS MM 1200 FOURCHES MM 1200 GABELN MM 1200 HORQUILLAS MM 1200
1 4604364CE 1 nr FORCA L.1100 SEZ.100X35 F FORKS MM 1100 FOURCHES MM 1100 GABELN MM 1100 HORQUILLAS MM 1100
1 4604365CE 1 nr FORCA L=1150 SEZ100X35 FE FORKS MM 1150 FOURCHES MM 1150 GABELN MM 1150 HORQUILLAS MM 1150
1 4604359CE 1 nr FORCA L.900 SEZ.100X35 FE FORKS 900 MM FOURCHES 900 MM GABELN 900 MM HORQUILLAS 900 MM
2 2994133CE 1 nr KIT PERNO ARRESTO FORCA F KIT JEU SATZ JUEGO

Le forche si foniscono solo a coppie / The forks are delivered two by two only / N.D. / N.D. / N.D.

FORCHE (2M) / FORKS (DUPLEX) Page 200

FORCHE (2M) / FORKS (DUPLEX) Page 201
CBE12F_MONT_MONTANTI_3M_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 1864310CE 2 nr TIRANTE CATENA RIF.15574 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
2 1994015CE 4 nr PERNO TIRANTE CATENA RIF. PIN PIVOT STIFT PERNO
3 2862010CE 4 nr RULLO GUIDA D.61,8 RIF.13 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
4 1994018CE 4 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
5 2864092CE 2 nr PULEGGIA CATENA RIF.15577 PULLEY POULIE RIEMENSCHEIBE POLEA
6 1864311CE 2 nr TIRANTE CATENA RIF.15575 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
7 0070723CE 1 mt CATENA FLEYER BL.644 RIF. CHAIN CHAINE KETTE CADENA
8 1864056CE 2 nr TAMPONE FINE CORSA RIF.13 STOP ARRET ANSCHLAG PARADA
9 1994022CE 2 nr TIRANTE CATENA RIF.10901 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
10 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
11 1994033CE 4 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
12 1994020CE 2 nr PULEGGIA CATENA RIF. 0331 PULLEY POULIE RIEMENSCHEIBE POLEA
13 0134033CE 4 nr ANEL. EL. A45 UNI 7435 E( SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
14 0070188CE 2 nr SNODO SFERICO GE 40ES.2RS BALL AND SOCKET JOINT ARTICULATION A ROTULE KUGELGELENK ARTICULACION DE BOLA
15 1994037CE 8 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
16 1994038CE 4 nr RULLO GUIDA D.81,8 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
17 1994019CE 4 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
18 0134031CE 2 nr ANEL EL A40 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
19 0013898CE 12 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
20 1994044CE 4 nr SUPPORTO [Link] MONT ROLLER BEARING PALIER A ROULEAUX ROLLENTR¬GER SOPORTE RODILLO
21 1994045CE 4 nr SUPPORTO [Link] MONT MAST SUPPORT SUPPORT DE MAT MASTBEFESTIGUNG SOPORTE MASTIL
22 1864063CE 4 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
23 0134029CE 4 nr ANEL EL A35 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
24 1864064CE 4 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
25 0134033CE 4 nr ANEL. EL. A45 UNI 7435 E( SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
26 1869012CE 1 nr DADO AUTOBLOCCANTE RIF.03 SELF-LOCKING NUT ECROU AUTOBLOQUANT SELBSTSPERRENDMUTTER TUERCA AUTOTRABADORA
27 0101065CE 2 nr VITE TCEI M12X25 UNI5931 SCREW VIS SCHRAUBE TORNILLO
28 1864117CE 2 nr COLLARE RITEGNO CILINDRO COLLAR COLLIER ANSCHLAGBUND COLLAR
29 1859022CE 1 nr RONDELLA SPESSORE D.56641 WASHER RONDELLE UNTERLEGSCHEIBE ARANDELA
VAR. VAR.
30 0133007CE 4 nr GRANO M12X12 UNI 5923 DOWEL GOUJON STIFT CLAVIJA
32 1864241CE 1 nr RETE ANTICES. DI ESTREM. SAFETY GUARD GRILLE DE PROTECTION SCHUTZGITTER RED DE PROTECCION
VAR. VAR.
33 (1) 1 nr RETE NET FILET NETZ RED
codice secondo altezza di soll CODE ACCORDING TO LIFT HEIGHT
34 1724136CE 1 nr PIASTRINA [Link] PLATE PLAQUE PLATTE PLANCHA
VAR. VAR.

MONTANTI (3M) / MASTS (TRIPLEX) Page 202

MONTANTI (3M) / MASTS (TRIPLEX) Page 203
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
35 2864079CE 1 nr STAFFA COLLEGAMENTO RETE BRACKET ETRIER B?GEL ESTRIBO
VAR. VAR.
36 (1) 1 nr RETE NET FILET NETZ RED
codice secondo altezza di soll CODE ACCORDING TO LIFT HEIGHT

MONTANTI (3M) / MASTS (TRIPLEX) Page 204

MONTANTI (3M) / MASTS (TRIPLEX) Page 205
CBE12F_MONT_MARTINETTO_ELEVATORE_3M_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 (1) 1 nr CORPO BODY CORPS GEAUSE CUERPO
codice secondo altezza di soll code according to lift height
2 (1) 1 nr ASTA ROD TIGE STANGE VARILLA
codice secondo altezza di soll code according to lift height
3 1864108CE 1 nr FONDELLO RIF.13735 BOTTOM CULOT ENDSCHEIBE FONDILLO
4 0063009CE 1 nr VALVOLA [Link]-N-H OD.41 VALVE SOUPAPE VENTIL VALVULA
5 1864018CE 1 nr DADO RITEGNO CILINDRO RIF NUT ECROU MUTTER TUERCA
6 1864061CE 1 nr CALOTTA [Link] COVER COVER KAPPE TAPA
7 2998153CE 1 nr KIT GUARNIZIONI RIF.11839 GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS

MARTINETTO ELEVATORE (3M) / LIFT JACK (TRIPLEX) Page 206

MARTINETTO ELEVATORE (3M) / LIFT JACK (TRIPLEX) Page 207
CBE12F_MONT_CARRELLINO_E_TRASLATORE_LAT_3M_b_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4864011CE 1 nr CARRELLINO SOLL. [Link] FORK CARRIAGE TABLIER PORTE-FOURCHE GABELTR?GER TABLERO HORQUILLAS
1 1864064CE 4 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
2 0134033CE 4 nr ANEL. EL. A45 UNI 7435 E( SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
3 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
4 1994038CE 4 nr RULLO GUIDA D.81,8 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
5 1994019CE 4 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
6 0013898CE 4 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
7 1994045CE 4 nr SUPPORTO [Link] MONT MAST SUPPORT SUPPORT DE MAT MASTBEFESTIGUNG SOPORTE MASTIL
8 1604235CE 2 nr ARRESTO FORCA K16/30 D.88 STOP ARRET ANSCHLAG PARADA
9 0102034CE 2 nr VITE TSPEI 12X30 UNI5933- SCREW VIS SCHRAUBE TORNILLO
10 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
11 1994022CE 2 nr TIRANTE CATENA RIF.10901 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA

CARRELLINO PIASTRA FISSA (3M) / FORK CARRIAGE (TRIPLEX) Page 208

CARRELLINO PIASTRA FISSA (3M) / FORK CARRIAGE (TRIPLEX) Page 209
CBE12F_MONT_CARRELLINO_E_TRASLATORE_LAT_3M_a_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4864013CE 1 nr CARRELLINO [Link] SIDESHIFT FORK CARRIAGE TABLIER DEPLACEMENT LAT. SEITENSCHIEBER GABELTR?GE TABLERO DESPLADOR LAT.
12 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
13 1994019CE 4 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
14 1994038CE 4 nr RULLO GUIDA D.81,8 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
Per altezze > 5000 For height > 5000
15 1603506CE 4 nr BUSSOLA PER TRASLATORE D. BUSHING DOUILLE BUCHSE CASQUILLO
16 1994025CE 2 nr TUBO ALIMENTAZ. CILINDRI PIPE TUYAU SCHLAUCH TUBO
17 0060361CE 2 nr RACCORDO CAST 102705 CONNECTION RACCORD ANSCHLUSS UNION
18 1623289CE 2 nr PATTINO D.92193 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
19 0060236CE 2 nr RACCORDO CAST 101905 (EX CONNECTION RACCORD ANSCHLUSS UNION
20 1603449CE 1 nr SPESSORE DI REGISTRO D.92 SHIM EPAISSEUR DICKE ESPESOR
VAR. VAR.
21 1603450CE 2 nr PATTINO INFERIORE D.92301 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
22 1603507CE 2 nr CHIUSURA ESTERNA D.92297 PANEL PANNEAU PLATTE CHAPA
23 1603446CE 4 nr VITE DI REGISTRAZIONE D.9 ADJUSTING SCREW VIS DE REGLAGE EINSTELLSCHRAUBE TORNILLO DE REGULACION
24 1603447CE 1 nr SPESSORE DI REGISTRAZIONE SHIM EPAISSEUR DICKE ESPESOR
VAR. VAR.
25 1603505CE 4 nr ASTA PER TRASLATORE D.922 ROD TIGE STANGE VARILLA
26 0102052CE 12 nr VITE TSPEI M12X35 UNI5933 SCREW VIS SCHRAUBE TORNILLO
27 1603448CE 2 nr TAMPONE D.92303 STOP ARRET ANSCHLAG PARADA
28 1864064CE 4 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
29 0134033CE 4 nr ANEL. EL. A45 UNI 7435 E( SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
30 0013898CE 6 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
31 1994045CE 4 nr SUPPORTO [Link] MONT MAST SUPPORT SUPPORT DE MAT MASTBEFESTIGUNG SOPORTE MASTIL
32 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
33 1994022CE 2 nr TIRANTE CATENA RIF.10901 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
34 2998141CE 1 nr [Link].D. GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS

CARRELLINO TRASLATORE LATERALE (3M) / SIDESHIFTING CARRIAGE (TRIPLEX) Page 210

CARRELLINO TRASLATORE LATERALE (3M) / SIDESHIFTING CARRIAGE (TRIPLEX) Page 211
CBE12F_MONT_IMP_ALIMENTAZIONE_TRASLATORE_3M_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr IMPIANTO ALIMENTAZIONE CO HYDRAULIC SYSTEM INSTALL. HYDRAUL. HYDRAULISCHE ANLAGE INSTALACION HIDR.
codice secondo altezza di soll CODE ACCORDING TO LIFT HEIGHT
1 1865051CE 2 nr PERNO SOSTEGNO PULEGGIA R PULLEY PIN PIVOT DE POULIE RIEMENSCHEIBEBOLZEN PERNO DE POLEA
2 1994027CE 2 nr PULEGGIA RINVIO TUBI RIF. PULLEY POULIE RIEMENSCHEIBE POLEA
3 0062008CE 5 nr COLLARE C2 D.12 "[Link]. COLLAR COLLIER ANSCHLAGBUND COLLAR
4 1994042CE 1 nr TUBO RIGIDO MARTINETTO SO PIPE CONDUITE RIGIDE ROHR TUBO RIGIDO
5 0060375CE 1 nr RACCORDO A "T" PLAST.x TU CONNECTION RACCORD ANSCHLUSS UNION
6 1994031CE 1 nr CORPO VALVOLA DISCESA RIF VALVE SOUPAPE VENTIL VALVULA
7 0064090CE 1 nr VALVOLA HAWE SB 27-C VALVE SOUPAPE VENTIL VALVULA
8 1994043CE 1 nr TUBO RIGIDO MARTINETTO SO PIPE CONDUITE RIGIDE ROHR TUBO RIGIDO
9 0070585CE 1 nr PIASTRA SUPERIORE CF1 "PI PLATE PLAQUE PLATTE PLANCHA
10 0070584CE 1 nr COLLARE DOPPIO CF1 12/12" COLLAR COLLIER ANSCHLAGBUND COLLAR
11 0060374CE 2 nr [Link] MASCHIO 6500- CONNECTION RACCORD ANSCHLUSS UNION
12 0060362CE 2 nr RACCORDO DIR. A103002/10 CONNECTION RACCORD ANSCHLUSS UNION
13 0023258CE 1 mt TUBO POLIETILENE 8X6 NERO FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
14 0061851CE 1 mt TUBO [Link].1/4 MAC-FLE FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
15 0060365CE 4 nr BOCCOLA A PRESSARE PER TU BUSHING BAGUE BUCHSE BUCHSE
16 0060364CE 2 nr RACCORDO [Link] CONNECTION RACCORD ANSCHLUSS UNION
17 0060363CE 2 nr RACCORDO [Link].D. CONNECTION RACCORD ANSCHLUSS UNION
18 0061854CE 1 mt SPIRALE METALLICA De.17 S SPIRAL SPIRALE SPIRALE ESPIRAL
19 0060258CE 4 nr DADO CAST 100207 (EX B 12 NUT ECROU MUTTER TUERCA
20 0060615CE 4 nr RACCORDO OGIVA 100107.4 C CONNECTION RACCORD ANSCHLUSS UNION
21 0060395CE 2 nr RACCORDO CAMOZZI RIF.1320 CONNECTION RACCORD ANSCHLUSS UNION

IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (3M) / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (TRIPLEX) Page 212
IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (3M) / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (TRIPLEX) Page 213
CBE12F_MONT_FORCHE_3M_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 4604428CE 1 nr FORCA L.1050 SEZ.100X35 F FORKS 1050 MM FOURCHES 1050 MM GABELN 1050 MM HORQUILLAS 1050 MM
1 4604360CE 1 nr FORCA L.1000 SEZ.100X35 F FORKS MM 1000 FOURCHES MM 1000 GABELN MM 1000 HORQUILLAS MM 1000
1 4604361CE 1 nr FORCA L.1200 SEZ.100X35 F FORKS MM 1200 FOURCHES MM 1200 GABELN MM 1200 HORQUILLAS MM 1200
1 4604364CE 1 nr FORCA L.1100 SEZ.100X35 F FORKS MM 1100 FOURCHES MM 1100 GABELN MM 1100 HORQUILLAS MM 1100
1 4604365CE 1 nr FORCA L=1150 SEZ100X35 FE FORKS MM 1150 FOURCHES MM 1150 GABELN MM 1150 HORQUILLAS MM 1150
1 4604359CE 1 nr FORCA L.900 SEZ.100X35 FE FORKS 900 MM FOURCHES 900 MM GABELN 900 MM HORQUILLAS 900 MM
2 2994133CE 1 nr KIT PERNO ARRESTO FORCA F KIT JEU SATZ JUEGO

Le forche si foniscono solo a coppie / The forks are delivered two by two only / N.D. / N.D. / N.D.

FORCHE (3M) / FORKS (TRIPLEX) Page 214

FORCHE (3M) / FORKS (TRIPLEX) Page 215
CBE12F_MONT_MONTANTI_2M_ALT_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 0013898CE 8 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
2 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
3 1994044CE 2 nr SUPPORTO [Link] MONT ROLLER BEARING PALIER A ROULEAUX ROLLENTR¬GER SOPORTE RODILLO
4 1994016CE 2 nr RULLO GUIDA D.60,5 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
5 0134029CE 2 nr ANEL EL A35 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
6 1994018CE 2 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
7 1994049CE 2 nr PULEGGIA X [Link].0091 PULLEY POULIE RIEMENSCHEIBE POLEA
8 1864094CE 2 nr VITE SUPERIORE SEMISUPPOR SCREW VIS SCHRAUBE TORNILLO
9 1864050CE 2 nr SEMISUPPORTO ESTERNO PULE SUPPORT SUPPORT HALTERUNG SOPORTE
10 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
11 1864062CE 2 nr SEMISUPPORTO PULEGGIA TRA SUPPORT SUPPORT HALTERUNG SOPORTE
12 2864069CE 2 nr SEMISUPPORTO PULEGGIA INT SUPPORT SUPPORT HALTERUNG SOPORTE
13 1864086CE 2 nr PULEGGIA RIF.13570/1 PULLEY POULIE RIEMENSCHEIBE POLEA
14 1864087CE 2 nr ANELLO ROTOLAMENTO DRENAG RING ANNEAU RING ANILLO
15 1864186CE 2 nr B0CCOLA RIF.13950 BUSHING BAGUE BUCHSE CASQUILLO
16 1864053CE 2 nr ANELLO ADATTATORE RIF.131 RING ANNEAU RING ANILLO
17 1994049CE 2 nr PULEGGIA X [Link].0091 PULLEY POULIE RIEMENSCHEIBE POLEA
18 1864062CE 2 nr SEMISUPPORTO PULEGGIA TRA SUPPORT SUPPORT HALTERUNG SOPORTE
19 1864094CE 2 nr VITE SUPERIORE SEMISUPPOR SCREW VIS SCHRAUBE TORNILLO
20 0101064CE 2 nr VITE TCEI M12X20 UNI5931 SCREW VIS SCHRAUBE TORNILLO
21 1994045CE 2 nr SUPPORTO [Link] MONT MAST SUPPORT SUPPORT DE MAT MASTBEFESTIGUNG SOPORTE MASTIL
22 0134033CE 4 nr ANEL. EL. A45 UNI 7435 E( SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
23 1994019CE 4 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
24 1864064CE 2 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
25 1994017CE 2 nr RULLO GUIDA D.80,5 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
26 0070188CE 2 nr SNODO SFERICO GE 40ES.2RS BALL AND SOCKET JOINT ARTICULATION A ROTULE KUGELGELENK ARTICULACION DE BOLA
27 0134031CE 2 nr ANEL EL A40 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
28 (1) 1 nr RETE NET FILET NETZ RED
VAR. - codice secondo altezza VAR. - CODE ACCORDING TO LIFT
29 1724136CE 1 nr PIASTRINA [Link] PLATE PLAQUE PLATTE PLANCHA
VAR. VAR.
30 1864241CE 1 nr RETE ANTICES. DI ESTREM. SAFETY GUARD GRILLE DE PROTECTION SCHUTZGITTER RED DE PROTECCION
31 1864063CE 2 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
32 1864142CE 2 nr PERNO TIRANTE RIF.12779/3 PIN PIVOT STIFT PERNO
33 1994022CE 2 nr TIRANTE CATENA RIF.10901 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
34 1994037CE 2 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
35 0110048CE 2 nr DADO ES. M12 UNI5589 NUT ECROU MUTTER TUERCA

MONTANTI (2M) A.L.T. / MASTS (DUPLEX) F.F.L. Page 216

MONTANTI (2M) A.L.T. / MASTS (DUPLEX) F.F.L. Page 217
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
36 1995046CE 4 nr PULEGGIA [Link]. RIF.129 PULLEY POULIE RIEMENSCHEIBE POLEA

MONTANTI (2M) A.L.T. / MASTS (DUPLEX) F.F.L. Page 218

MONTANTI (2M) A.L.T. / MASTS (DUPLEX) F.F.L. Page 219
CBE12F_MONT_MARTINETTO_ELEVATORE_CENT_LAT_2M_ALT_a_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr MARTINETTO ELEVATORE CENT CYLINDER VERIN ZYLINDER CILINDRO
codice secondo altezza di soll code according to lift height
7 (1) 1 nr ASTA ROD TIGE STANGE VARILLA
codice secondo altezza di soll code according to lift height
8 (1) 1 nr CORPO BODY CORPS GEAUSE CUERPO
codice secondo altezza di soll code according to lift height
9 0063009CE 1 nr VALVOLA [Link]-N-H OD.41 VALVE SOUPAPE VENTIL VALVULA
10 1864013CE 1 nr GHIERA RITEGNO FONDELLO R RING NUT BAGUE NUTMUTTER CASQUILLO
11 1864012CE 1 nr FONDELLO RIF.13663 BOTTOM CULOT ENDSCHEIBE FONDILLO
12 2998155CE 1 nr KIT GUARNIZIONI RIF.13670 GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS

MARTINETTO ELEVATORE CENTRALE (2M) A.L.T. / CENTRAL LIFT JACK (DUPLEX) F.F.L. Page 220
MARTINETTO ELEVATORE CENTRALE (2M) A.L.T. / CENTRAL LIFT JACK (DUPLEX) F.F.L. Page 221
CBE12F_MONT_MARTINETTO_ELEVATORE_CENT_LAT_2M_ALT_b_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr MARTINETTO ELEVATORE LATE CYLINDER VERIN ZYLINDER CILINDRO
codice secondo altezza di soll code according to lift height
1 (1) 1 nr ASTA ROD TIGE STANGE VARILLA
codice secondo altezza di soll code according to lift height
2 (1) 1 nr CORPO BODY CORPS GEAUSE CUERPO
codice secondo altezza di soll code according to lift height
3 0063009CE 1 nr VALVOLA [Link]-N-H OD.41 VALVE SOUPAPE VENTIL VALVULA
4 1864182CE 1 nr FONDELLO RIF.13210 BOTTOM CULOT ENDSCHEIBE FONDILLO
5 1864183CE 1 nr GHIERA RITEGNO CILINDRO R RING NUT BAGUE NUTMUTTER CASQUILLO
6 2998151CE 1 nr KIT GUARNIZIONI GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS

MARTINETTO ELEVATORE LATERALE (2M) A.L.T. / SIDE LIFT JACK (DUPLEX) F.F.L. Page 222
MARTINETTO ELEVATORE LATERALE (2M) A.L.T. / SIDE LIFT JACK (DUPLEX) F.F.L. Page 223
CBE12F_MONT_CARRELLINO_E_TRASLATORE_LAT_2M_ALT_b_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4864007CE 1 nr CARRELLINO SOLL. [Link] FORK CARRIAGE TABLIER PORTE-FOURCHE GABELTR?GER TABLERO HORQUILLAS
1 1604235CE 2 nr ARRESTO FORCA K16/30 D.88 STOP ARRET ANSCHLAG PARADA
2 0102034CE 2 nr VITE TSPEI 12X30 UNI5933- SCREW VIS SCHRAUBE TORNILLO
3 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
4 1994017CE 4 nr RULLO GUIDA D.80,5 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
5 1994019CE 4 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
6 0013898CE 4 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
7 1994045CE 4 nr SUPPORTO [Link] MONT MAST SUPPORT SUPPORT DE MAT MASTBEFESTIGUNG SOPORTE MASTIL
8 1864064CE 2 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
9 0134033CE 2 nr ANEL. EL. A45 UNI 7435 E( SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
10 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
11 1994022CE 2 nr TIRANTE CATENA RIF.10901 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA

CARRELLINO PIASTRA FISSA (2M) A.L.T. / FORK CARRIAGE (DUPLEX) F.F.L. Page 224
CARRELLINO PIASTRA FISSA (2M) A.L.T. / FORK CARRIAGE (DUPLEX) F.F.L. Page 225
CBE12F_MONT_CARRELLINO_E_TRASLATORE_LAT_2M_ALT_a_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4864009CE 1 nr CARRELLINO [Link] SIDESHIFT FORK CARRIAGE TABLIER DEPLACEMENT LAT. SEITENSCHIEBER GABELTR?GE TABLERO DESPLADOR LAT.
12 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
13 1994019CE 4 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
14 1994017CE 4 nr RULLO GUIDA D.80,5 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
15 1603506CE 4 nr BUSSOLA PER TRASLATORE D. BUSHING DOUILLE BUCHSE CASQUILLO
16 1994025CE 2 nr TUBO ALIMENTAZ. CILINDRI PIPE TUYAU SCHLAUCH TUBO
17 0060361CE 2 nr RACCORDO CAST 102705 CONNECTION RACCORD ANSCHLUSS UNION
18 1623289CE 2 nr PATTINO D.92193 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
19 0060236CE 2 nr RACCORDO CAST 101905 (EX CONNECTION RACCORD ANSCHLUSS UNION
20 1603449CE 1 nr SPESSORE DI REGISTRO D.92 SHIM EPAISSEUR DICKE ESPESOR
VAR. VAR.
21 1603450CE 2 nr PATTINO INFERIORE D.92301 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
22 1603507CE 2 nr CHIUSURA ESTERNA D.92297 PANEL PANNEAU PLATTE CHAPA
23 1603446CE 4 nr VITE DI REGISTRAZIONE D.9 ADJUSTING SCREW VIS DE REGLAGE EINSTELLSCHRAUBE TORNILLO DE REGULACION
24 1603447CE 1 nr SPESSORE DI REGISTRAZIONE SHIM EPAISSEUR DICKE ESPESOR
VAR. VAR.
25 1603505CE 4 nr ASTA PER TRASLATORE D.922 ROD TIGE STANGE VARILLA
26 0102052CE 12 nr VITE TSPEI M12X35 UNI5933 SCREW VIS SCHRAUBE TORNILLO
27 1603448CE 2 nr TAMPONE D.92303 STOP ARRET ANSCHLAG PARADA
28 1864064CE 4 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
29 0013898CE 4 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
30 1994045CE 4 nr SUPPORTO [Link] MONT MAST SUPPORT SUPPORT DE MAT MASTBEFESTIGUNG SOPORTE MASTIL
31 0134033CE 4 nr ANEL. EL. A45 UNI 7435 E( SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
32 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
33 1994022CE 2 nr TIRANTE CATENA RIF.10901 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
34 2998141CE 1 nr [Link].D. GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS

CARRELLINO TRASLATORE LATERALE (2M) A.L.T. / SIDESHIFTING CARRIAGE (DUPLEX) F.F.L. Page 226
CARRELLINO TRASLATORE LATERALE (2M) A.L.T. / SIDESHIFTING CARRIAGE (DUPLEX) F.F.L. Page 227
CBE12F_MONT_IMP_ALIMENTAZIONE_TRASLATORE_2M_ALT_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr IMPIANTO ALIMENTAZIONE CO HYDRAULIC SYSTEM INSTALL. HYDRAUL. HYDRAULISCHE ANLAGE INSTALACION HIDR.
codice secondo altezza di soll CODE ACCORDING TO LIFT HEIGHT
1 0060180CE 2 nr RACCORDO CAST 102003 (EX CONNECTION RACCORD ANSCHLUSS UNION
2 0060356CE 2 nr [Link] [Link].1/8" CONNECTION RACCORD ANSCHLUSS UNION
3 0060395CE 6 nr RACCORDO CAMOZZI RIF.1320 CONNECTION RACCORD ANSCHLUSS UNION
4 0023258CE 1 mt TUBO POLIETILENE 8X6 NERO FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
5 0061852CE 1 mt TUBO [Link].3/16 MAC-FL FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
6 0060144CE 2 nr RACCORDO CAST 103905 (EX CONNECTION RACCORD ANSCHLUSS UNION
7 1864265CE 2 nr TIRANTE [Link] DRENAG.R TENSION ROD TIRANT ZUGSTANGE TIRANTE
8 (1) 1 nr TUBO DESTRO RIGHT PIPE
codice secondo altezza di soll code according to lift height
8 (1) 1 nr TUBO SINISTRO LEFT PIPE
codice secondo altezza di soll code according to lift height
9 (1) 1 nr TUBO PIPE
codice secondo altezza di soll code according to lift height
10 0060375CE 1 nr RACCORDO A "T" PLAST.x TU CONNECTION RACCORD ANSCHLUSS UNION
11 1994031CE 1 nr CORPO VALVOLA DISCESA RIF VALVE SOUPAPE VENTIL VALVULA
12 0020460CE 1 nr VALVOLA HAWE SB 25C VALVE SOUPAPE VENTIL VALVULA
13 (1) 1 nr TUBO PIPE
codice secondo altezza di soll code according to lift height
14 0060574CE 2 nr RACCORDO CAST 102007 CONNECTION RACCORD ANSCHLUSS UNION
15 1864268CE 2 nr RACCORDO RIF.13869 CONNECTION RACCORD ANSCHLUSS UNION
16 0060258CE 4 nr DADO CAST 100207 (EX B 12 NUT ECROU MUTTER TUERCA
17 0060615CE 4 nr RACCORDO OGIVA 100107.4 C CONNECTION RACCORD ANSCHLUSS UNION
18 1864266CE 1 nr SEMICOLLARE RIF.13906/1 HALF COLLAR SEMI-COLLIER HALBBUNDRING SEMIABRAZADERA
18 1864267CE 1 nr SEMICOLLARE RIF.13906/2 HALF COLLAR SEMI-COLLIER HALBBUNDRING SEMIABRAZADERA
19 0061853CE 1 mt TUBO [Link].5/16 MAC-FL FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
20 0060399CE 2 nr RACCORDO A "T" CAST 10250 CONNECTION RACCORD ANSCHLUSS UNION
25 0062008CE 8 nr COLLARE C2 D.12 "[Link]. COLLAR COLLIER ANSCHLAGBUND COLLAR
26 0062009CE 4 nr PIASTRA INFERIORE C2 "PI. PLATE PLAQUE PLATTE PLANCHA
27 1864185CE 2 nr STAFFA SERRAGGIO TUBI RIF BRACKET ETRIER BSGEL ESTRIBO
28 0060362CE 2 nr RACCORDO DIR. A103002/10 CONNECTION RACCORD ANSCHLUSS UNION
29 0070584CE 1 nr COLLARE DOPPIO CF1 12/12" COLLAR COLLIER ANSCHLAGBUND COLLAR
30 0061851CE 1 mt TUBO [Link].1/4 MAC-FLE FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
31 0070585CE 2 nr PIASTRA SUPERIORE CF1 "PI PLATE PLAQUE PLATTE PLANCHA
32 0060365CE 4 nr BOCCOLA A PRESSARE PER TU BUSHING BAGUE BUCHSE BUCHSE
33 0060364CE 2 nr RACCORDO [Link] CONNECTION RACCORD ANSCHLUSS UNION

IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (2M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (DUPLEX) F.F.L. Page 228
IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (2M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (DUPLEX) F.F.L. Page 229
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
34 0060363CE 2 nr RACCORDO [Link].D. CONNECTION RACCORD ANSCHLUSS UNION
35 0060366CE 2 nr BOCCOLA A PRESSARE PER TU BUSHING BAGUE BUCHSE BUCHSE
36 0060309CE 2 nr RACCORDO TN100-22L CONNECTION RACCORD ANSCHLUSS UNION
37 0060380CE 2 nr RACCORDO [Link].J CONNECTION RACCORD ANSCHLUSS UNION
38 0060367CE 4 nr BOCCOLA A PRESSARE PER TU BUSHING BAGUE BUCHSE BUCHSE
39 0060370CE 2 nr RACCORDO [Link].D. CONNECTION RACCORD ANSCHLUSS UNION
40 1995046CE 4 nr PULEGGIA [Link]. RIF.129 PULLEY POULIE RIEMENSCHEIBE POLEA

IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (2M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (DUPLEX) F.F.L. Page 230
IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (2M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (DUPLEX) F.F.L. Page 231
CBE12F_MONT_FORCHE_2M_ALT_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 4604428CE 1 nr FORCA L.1050 SEZ.100X35 F FORKS 1050 MM FOURCHES 1050 MM GABELN 1050 MM HORQUILLAS 1050 MM
1 4604360CE 1 nr FORCA L.1000 SEZ.100X35 F FORKS MM 1000 FOURCHES MM 1000 GABELN MM 1000 HORQUILLAS MM 1000
1 4604361CE 1 nr FORCA L.1200 SEZ.100X35 F FORKS MM 1200 FOURCHES MM 1200 GABELN MM 1200 HORQUILLAS MM 1200
1 4604364CE 1 nr FORCA L.1100 SEZ.100X35 F FORKS MM 1100 FOURCHES MM 1100 GABELN MM 1100 HORQUILLAS MM 1100
1 4604365CE 1 nr FORCA L=1150 SEZ100X35 FE FORKS MM 1150 FOURCHES MM 1150 GABELN MM 1150 HORQUILLAS MM 1150
1 4604359CE 1 nr FORCA L.900 SEZ.100X35 FE FORKS 900 MM FOURCHES 900 MM GABELN 900 MM HORQUILLAS 900 MM
2 2994133CE 1 nr KIT PERNO ARRESTO FORCA F KIT JEU SATZ JUEGO

Le forche si foniscono solo a coppie / The forks are delivered two by two only / N.D. / N.D. / N.D.

FORCHE (2M) A.L.T. / FORKS (DUPLEX) F.F.L. Page 232

FORCHE (2M) A.L.T. / FORKS (DUPLEX) F.F.L. Page 233
CBE12F_MONT_MONTANTI_3M_ALT_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 0013898CE 9 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
2 1994037CE 8 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
3 2862010CE 4 nr RULLO GUIDA D.61,8 RIF.13 GUIDE ROLLER ROULEAU-GUIDE F?HRUNGSROLLE RODILLO GUIA
Per altezze > 5000 For height > 5000
4 1994018CE 4 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
5 1994044CE 4 nr SUPPORTO [Link] MONT ROLLER BEARING PALIER A ROULEAUX ROLLENTR¬GER SOPORTE RODILLO
6 1994021CE 2 nr TIRANTE CATENA RIF.13580 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
7 1864142CE 2 nr PERNO TIRANTE RIF.12779/3 PIN PIVOT STIFT PERNO
8 0070188CE 2 nr SNODO SFERICO GE 40ES.2RS BALL AND SOCKET JOINT ARTICULATION A ROTULE KUGELGELENK ARTICULACION DE BOLA
9 0134031CE 2 nr ANEL EL A40 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
10 1994045CE 4 nr SUPPORTO [Link] MONT MAST SUPPORT SUPPORT DE MAT MASTBEFESTIGUNG SOPORTE MASTIL
11 1994038CE 4 nr RULLO GUIDA D.81,8 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
Per altezze > 5000 For height > 5000
12 1994019CE 4 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
13 1994022CE 2 nr TIRANTE CATENA RIF.10901 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
14 1994033CE 4 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
15 0070017CE 1 mt CATENA BL.534 (EX 16699) CHAIN CHAINE KETTE CADENA
16 1994049CE 2 nr PULEGGIA X [Link].0091 PULLEY POULIE RIEMENSCHEIBE POLEA
17 1864056CE 2 nr TAMPONE FINE CORSA RIF.13 STOP ARRET ANSCHLAG PARADA
18 1864094CE 2 nr VITE SUPERIORE SEMISUPPOR SCREW VIS SCHRAUBE TORNILLO
19 1864050CE 2 nr SEMISUPPORTO ESTERNO PULE SUPPORT SUPPORT HALTERUNG SOPORTE
20 1864062CE 2 nr SEMISUPPORTO PULEGGIA TRA SUPPORT SUPPORT HALTERUNG SOPORTE
21 1864063CE 4 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
22 0134029CE 4 nr ANEL EL A35 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
23 1864064CE 4 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
24 0134033CE 4 nr ANEL. EL. A45 UNI 7435 E( SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
25 0134029CE 4 nr ANEL EL A35 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
26 0101065CE 2 nr VITE TCEI M12X25 UNI5931 SCREW VIS SCHRAUBE TORNILLO
27 1864058CE 2 nr COLLARE RITEGNO CILINDRO COLLAR COLLIER ANSCHLAGBUND COLLAR
28 1724136CE 1 nr PIASTRINA [Link] PLATE PLAQUE PLATTE PLANCHA
VAR. VAR.
29 2864079CE 1 nr STAFFA COLLEGAMENTO RETE BRACKET ETRIER B?GEL ESTRIBO
VAR. VAR.
30 1864241CE 1 nr RETE ANTICES. DI ESTREM. SAFETY GUARD GRILLE DE PROTECTION SCHUTZGITTER RED DE PROTECCION
31 (1) 1 nr RETE NET FILET NETZ RED
VAR. - codice secondo altezza VAR. - CODE ACCORDING TO LIFT
32 (1) 1 nr RETE NET FILET NETZ RED
VAR. - codice secondo altezza VAR. - CODE ACCORDING TO LIFT

MONTANTI (3M) A.L.T. / MASTS (TRIPLEX) F.F.L. Page 234

MONTANTI (3M) A.L.T. / MASTS (TRIPLEX) F.F.L. Page 235
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
33 1864053CE 2 nr ANELLO ADATTATORE RIF.131 RING ANNEAU RING ANILLO
34 1995046CE 2 nr PULEGGIA [Link]. RIF.129 PULLEY POULIE RIEMENSCHEIBE POLEA

MONTANTI (3M) A.L.T. / MASTS (TRIPLEX) F.F.L. Page 236

MONTANTI (3M) A.L.T. / MASTS (TRIPLEX) F.F.L. Page 237
CBE12F_MONT_MARTINETTO_ELEVATORE_CENT_LAT_3M_ALT_a_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr MARTINETTO ELEVATORE CENT CYLINDER VERIN ZYLINDER CILINDRO
codice secondo altezza di soll code according to lift height
7 (1) 1 nr ASTA ROD TIGE STANGE VARILLA
codice secondo altezza di soll code according to lift height
8 (1) 1 nr CORPO BODY CORPS GEAUSE CUERPO
codice secondo altezza di soll code according to lift height
9 0063009CE 1 nr VALVOLA [Link]-N-H OD.41 VALVE SOUPAPE VENTIL VALVULA
10 1864013CE 1 nr GHIERA RITEGNO FONDELLO R RING NUT BAGUE NUTMUTTER CASQUILLO
11 1864012CE 1 nr FONDELLO RIF.13663 BOTTOM CULOT ENDSCHEIBE FONDILLO
12 2998155CE 1 nr KIT GUARNIZIONI RIF.13670 GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS

MARTINETTO ELEVATORE CENTRALE (3M) A.L.T. / CENTRAL LIFT JACK (TRIPLEX) F.F.L. Page 238
MARTINETTO ELEVATORE CENTRALE (3M) A.L.T. / CENTRAL LIFT JACK (TRIPLEX) F.F.L. Page 239
CBE12F_MONT_MARTINETTO_ELEVATORE_CENT_LAT_3M_ALT_b_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr MARTINETTO ELEVATORE LATE CYLINDER VERIN ZYLINDER CILINDRO
codice secondo altezza di soll code according to lift height
1 (1) 1 nr ASTA ROD TIGE STANGE VARILLA
codice secondo altezza di soll code according to lift height
2 (1) 1 nr CORPO BODY CORPS GEAUSE CUERPO
codice secondo altezza di soll code according to lift height
3 0063009CE 1 nr VALVOLA [Link]-N-H OD.41 VALVE SOUPAPE VENTIL VALVULA
4 1864017CE 1 nr FONDELLO RIF.13684 BOTTOM CULOT ENDSCHEIBE FONDILLO
5 1864018CE 1 nr DADO RITEGNO CILINDRO RIF NUT ECROU MUTTER TUERCA
6 2998151CE 1 nr KIT GUARNIZIONI GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS

MARTINETTO ELEVATORE LATERALE (3M) A.L.T. / SIDE LIFT JACK(TRIPLEX) F.F.L. Page 240
MARTINETTO ELEVATORE LATERALE (3M) A.L.T. / SIDE LIFT JACK(TRIPLEX) F.F.L. Page 241
CBE12F_MONT_CARRELLINO_E_TRASLATORE_LAT_3M_ALT_b_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4864015CE 1 nr CARRELLINO SOLL. [Link] FORK CARRIAGE TABLIER PORTE-FOURCHE GABELTR?GER TABLERO HORQUILLAS
1 1864064CE 4 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
2 0134033CE 4 nr ANEL. EL. A45 UNI 7435 E( SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
3 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
4 1994038CE 4 nr RULLO GUIDA D.81,8 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
Per altezze > 5000 For height > 5000
5 1994019CE 4 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
6 0013898CE 4 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
7 1994045CE 4 nr SUPPORTO [Link] MONT MAST SUPPORT SUPPORT DE MAT MASTBEFESTIGUNG SOPORTE MASTIL
8 1604235CE 2 nr ARRESTO FORCA K16/30 D.88 STOP ARRET ANSCHLAG PARADA
9 0102034CE 2 nr VITE TSPEI 12X30 UNI5933- SCREW VIS SCHRAUBE TORNILLO
10 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
11 1994022CE 2 nr TIRANTE CATENA RIF.10901 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA

CARRELLINO PIASTRA FISSA (3M) A.L.T. / FORK CARRIAGE (TRIPLEX) F.F.L. Page 242
CARRELLINO PIASTRA FISSA (3M) A.L.T. / FORK CARRIAGE (TRIPLEX) F.F.L. Page 243
CBE12F_MONT_CARRELLINO_E_TRASLATORE_LAT_3M_ALT_a_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 4864017CE 1 nr CARRELLINO [Link] SIDESHIFT FORK CARRIAGE TABLIER DEPLACEMENT LAT. SEITENSCHIEBER GABELTR?GE TABLERO DESPLADOR LAT.
12 1994037CE 4 nr GRANO DI REGISTRAZIONE RI DOWEL PIN GOUJON STIFT CLAVIJA
13 1994019CE 4 nr PATTINO DI GUIDA TRASVERS GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
14 1994038CE 4 nr RULLO GUIDA D.81,8 RIF.05 GUIDE ROLLER ROULEAU-GUIDE FSHRUNGSROLLE RODILLO GUIA
15 1603506CE 4 nr BUSSOLA PER TRASLATORE D. BUSHING DOUILLE BUCHSE CASQUILLO
16 1994025CE 2 nr TUBO ALIMENTAZ. CILINDRI PIPE TUYAU SCHLAUCH TUBO
17 0060361CE 2 nr RACCORDO CAST 102705 CONNECTION RACCORD ANSCHLUSS UNION
18 1623289CE 2 nr PATTINO D.92193 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
19 0060236CE 2 nr RACCORDO CAST 101905 (EX CONNECTION RACCORD ANSCHLUSS UNION
20 1603449CE 1 nr SPESSORE DI REGISTRO D.92 SHIM EPAISSEUR DICKE ESPESOR
VAR. VAR.
21 1603450CE 2 nr PATTINO INFERIORE D.92301 GUIDE SHOE PATIN GUIDE GLEITSCHUH PATIN DE GUIA
22 1603507CE 2 nr CHIUSURA ESTERNA D.92297 PANEL PANNEAU PLATTE CHAPA
23 1603446CE 4 nr VITE DI REGISTRAZIONE D.9 ADJUSTING SCREW VIS DE REGLAGE EINSTELLSCHRAUBE TORNILLO DE REGULACION
24 1603447CE 1 nr SPESSORE DI REGISTRAZIONE SHIM EPAISSEUR DICKE ESPESOR
VAR. VAR.
25 1603505CE 4 nr ASTA PER TRASLATORE D.922 ROD TIGE STANGE VARILLA
26 0102052CE 12 nr VITE TSPEI M12X35 UNI5933 SCREW VIS SCHRAUBE TORNILLO
27 1603448CE 2 nr TAMPONE D.92303 STOP ARRET ANSCHLAG PARADA
28 1864064CE 4 nr DISCO PER PATTINO TRASVER DISK DISQUE SCHEIBE DISCO
29 0134033CE 4 nr ANEL. EL. A45 UNI 7435 E( SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
30 0013898CE 6 nr INGRASS [Link].M6 UNI-766 GREASE NIPPLE GRAISSEUR SCHMIERNIPPEL ENGRASADOR
31 1994045CE 4 nr SUPPORTO [Link] MONT MAST SUPPORT SUPPORT DE MAT MASTBEFESTIGUNG SOPORTE MASTIL
32 1994033CE 2 nr PERNO ATTACCO CATENA RIF. PIN PIVOT STIFT PERNO
33 1994022CE 2 nr TIRANTE CATENA RIF.10901 CHAIN TENSION ROD TENDEUR DE CHAINE KETTENSPANNSTANGE TIRANTE DE LA CADENA
34 2998141CE 1 nr [Link].D. GASKETS KIT JEU JOINTS DICHTUNGSATZ JUEGO JUNTAS

CARRELLINO TRASLATORE LATERALE (3M) A.L.T. / SIDESHIFTING CARRIAGE (TRIPLEX) F.F.L. Page 244
CARRELLINO TRASLATORE LATERALE (3M) A.L.T. / SIDESHIFTING CARRIAGE (TRIPLEX) F.F.L. Page 245
CBE12F_MONT_IMP_ALIMENTAZIONE_TRASLATORE_3M_ALT

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

0 (1) 1 nr IMPIANTO ALIMENTAZIONE CO HYDRAULIC SYSTEM INSTALL. HYDRAUL. HYDRAULISCHE ANLAGE INSTALACION HIDR.
codice secondo altezza di soll code according to lift height
1 0060180CE 4 nr RACCORDO CAST 102003 (EX CONNECTION RACCORD ANSCHLUSS UNION
2 0060144CE 2 nr RACCORDO CAST 103905 (EX CONNECTION RACCORD ANSCHLUSS UNION
3 1864192CE 1 nr STAFFA RITEGNO TUBO DRENA BRACKET ETRIER BSGEL ESTRIBO
4 0060371CE 2 nr RACCORDO CAST 104607 CONNECTION RACCORD ANSCHLUSS UNION
5 (1) 1 nr TUBO PIPE
codice secondo altezza di soll code according to lift height
6 1994031CE 1 nr CORPO VALVOLA DISCESA RIF VALVE SOUPAPE VENTIL VALVULA
7 0060375CE 1 nr RACCORDO A "T" PLAST.x TU CONNECTION RACCORD ANSCHLUSS UNION
8 0020460CE 1 nr VALVOLA HAWE SB 25C VALVE SOUPAPE VENTIL VALVULA
9 (1) 1 nr TUBO PIPE
codice secondo altezza di soll code according to lift height
10 0060373CE 2 nr RACCORDO 90gr.A107062/101 CONNECTION RACCORD ANSCHLUSS UNION
11 0060372CE 2 nr RACCORDO CAST 103807 CONNECTION RACCORD ANSCHLUSS UNION
12 1865074CE 2 nr PULEGGIA RIF.15635 PULLEY POULIE RIEMENSCHEIBE POLEA
13 0060356CE 2 nr [Link] [Link].1/8" CONNECTION RACCORD ANSCHLUSS UNION
14 0023258CE 1 mt TUBO POLIETILENE 8X6 NERO FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
15 1995053CE 1 nr STAFFA RITEGNO TUBO DRENA BRACKET ETRIER BSGEL ESTRIBO
16 1865073CE 2 nr ANELLO DI ROTOLAMENTO RIF RING ANNEAU RING ANILLO
17 0060395CE 4 nr RACCORDO CAMOZZI RIF.1320 CONNECTION RACCORD ANSCHLUSS UNION
18 (1) 2 nr TUBO PIPE
codice secondo altezza di soll code according to lift height
21 0060362CE 2 nr RACCORDO DIR. A103002/10 CONNECTION RACCORD ANSCHLUSS UNION
22 0062008CE 3 nr COLLARE C2 D.12 "[Link]. COLLAR COLLIER ANSCHLAGBUND COLLAR
23 0070585CE 3 nr PIASTRA SUPERIORE CF1 "PI PLATE PLAQUE PLATTE PLANCHA
24 0070584CE 1 nr COLLARE DOPPIO CF1 12/12" COLLAR COLLIER ANSCHLAGBUND COLLAR
25 0062011CE 2 nr COLLARE C2 D.10 "[Link]. COLLAR COLLIER ANSCHLAGBUND COLLAR
26 1995046CE 4 nr PULEGGIA [Link]. RIF.129 PULLEY POULIE RIEMENSCHEIBE POLEA
27 1995048CE 2 nr DISCO DI CHIUSURA RIF.136 DISK DISQUE SCHEIBE DISCO
28 0035223CE 0 mm TUBO D.8X1 ST 35.4 BONDER PIPE TUYAU SCHLAUCH TUBO
29 0061851CE 1 mt TUBO [Link].1/4 MAC-FLE FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
30 0060365CE 4 nr BOCCOLA A PRESSARE PER TU BUSHING BAGUE BUCHSE BUCHSE
31 0060364CE 2 nr RACCORDO [Link] CONNECTION RACCORD ANSCHLUSS UNION
32 0060363CE 2 nr RACCORDO [Link].D. CONNECTION RACCORD ANSCHLUSS UNION
33 0060258CE 2 nr DADO CAST 100207 (EX B 12 NUT ECROU MUTTER TUERCA
34 0060615CE 2 nr RACCORDO OGIVA 100107.4 C CONNECTION RACCORD ANSCHLUSS UNION

IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (3M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (TRIPLEX) F.F.L. Page 246
IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (3M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (TRIPLEX) F.F.L. Page 247
Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES
35 0060374CE 2 nr [Link] MASCHIO 6500- CONNECTION RACCORD ANSCHLUSS UNION
36 1864055CE 2 nr ANELLO ANTIUSURA PULEGGIA RING ANNEAU RING ANILLO
37 0134022CE 2 nr ANEL EL A28 UNI 7435 EST SNAP RING ANNEAU A RESSORT SPANNRING ANILLO ELASTICO
38 0061911CE 1 mt TUBO FLESS. De5.5 Di2.4 R FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
39 0060423CE 4 nr RACCORDO PERNO LISCIO C/B CONNECTION RACCORD ANSCHLUSS UNION
40 0061853CE 1 mt TUBO [Link].5/16 MAC-FL FLEXIBLE PIPE TUYAU FLEXIBLE SCHLAUCH TUBO FLEXIBLE
41 0060367CE 4 nr BOCCOLA A PRESSARE PER TU BUSHING BAGUE BUCHSE BUCHSE
42 0060368CE 4 nr RACCORDO [Link] CONNECTION RACCORD ANSCHLUSS UNION
43 0060370CE 4 nr RACCORDO [Link].D. CONNECTION RACCORD ANSCHLUSS UNION

IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (3M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (TRIPLEX) F.F.L. Page 248
IMPIANTO ALIMENTAZIONE TRASLATORE LATERALE (3M) A.L.T. / SIDESHIFTING DEVICE HYDRAULIC INSTALLATION (TRIPLEX) F.F.L. Page 249
CBE12F_MONT_FORCHE_3M_ALT_

Pos. Part number [Link] DENOMINAZIONE DESCRIPTION DESIGNATION BENENNUNG DENOMINACIONES

1 4604428CE 1 nr FORCA L.1050 SEZ.100X35 F FORKS 1050 MM FOURCHES 1050 MM GABELN 1050 MM HORQUILLAS 1050 MM
1 4604360CE 1 nr FORCA L.1000 SEZ.100X35 F FORKS MM 1000 FOURCHES MM 1000 GABELN MM 1000 HORQUILLAS MM 1000
1 4604361CE 1 nr FORCA L.1200 SEZ.100X35 F FORKS MM 1200 FOURCHES MM 1200 GABELN MM 1200 HORQUILLAS MM 1200
1 4604364CE 1 nr FORCA L.1100 SEZ.100X35 F FORKS MM 1100 FOURCHES MM 1100 GABELN MM 1100 HORQUILLAS MM 1100
1 4604365CE 1 nr FORCA L=1150 SEZ100X35 FE FORKS MM 1150 FOURCHES MM 1150 GABELN MM 1150 HORQUILLAS MM 1150
1 4604359CE 1 nr FORCA L.900 SEZ.100X35 FE FORKS 900 MM FOURCHES 900 MM GABELN 900 MM HORQUILLAS 900 MM
2 2994133CE 1 nr KIT PERNO ARRESTO FORCA F KIT JEU SATZ JUEGO

Le forche si foniscono solo a coppie / The forks are delivered two by two only / N.D. / N.D. / N.D.

FORCHE (3M) A.L.T. / FORKS (TRIPLEX) F.F.L. Page 250

FORCHE (3M) A.L.T. / FORKS (TRIPLEX) F.F.L. Page 251
