Service Parts List
Axle
113/051
APL-2397
July 2012
SPICER OFF-HIGHWAY AXLE DIVISION *113/ 51* 1082460163
Data rilascio
03/05/2004
N° foglio
1
Denominazione Gruppo tipo Modello Cliente: TEREX DEUTSCHLAND C.I. e data
Ponte differenziale fisso con riduzioni finali epicicloidali 113 51 ultima
[Link]: 020438 N° disegno [Link] modifica
Quantità olio Macchina: FEL 884 - 40 KM/H R 0683
Note 03/05/2004
ATTENZIONE: 01 2638
- I gruppi vanno spediti riempiti di olio
- Verniciare i gruppi con smalto GRIGIO 105.01.5087 23/09/2004
- Proteggere le colonnette dalla verniciatura
02 2706
13/09/2005
Flangia a flangia [mm] 1920. lt. 16.00 03 1082
Rapporto coppia conica 9:29 Corona diam. 305 - Pallinata 07/04/2006
Rapporto riduzioni finali 1:6 - 4 sat. Int. Col. 425 lt. 2.60
04 3475
15/11/2006
05 0229
25/01/2010
06 0017
Denominazione Sottogruppo Caratteristiche N°Complessivo 18/01/2012
Scatola e 113-01/24 [Link] 07 0568
coperchi 15/03/2012
Differenziale 113-04/22 Autobloccante 30% - Dischi in KEVLAR [Link]
Mozzo ruota 113-06/04 Colonnette e dadi zincati M22 L=76 [Link]
Flangia DIN 150 - 8f Ø12
Freno 113-07/11 A disco in bagno d'olio 6 dischi Wellman - Gioco 1 mm [Link]
Particolari sciolti
113-01-0001
113/ 51 1
CENTRAL HOUSING 3/07/12
113 113-01/24
1 [Link] 1 TAPPO SFIATO
RENIFLARD
VENT
TAPÓN DE RESPIRADERO
ENTLUEFTER
2 016.04.0428 4 VITE A TESTA CILINDRICA
VIS A TETE CYLINDRIQUE
CYLINDER BOLT
TORNILLO DE CABEZA CILÍNDRICA
ZYLINDERSCHRAUBE
3 001.05.2945 4 ANELLO OR
JOINT OR
O - RING
ANILLO TOROIDAL
O - RING
4 [Link] 2 COPERCHIO INTERMEDIO
COUVERCLE INTERMEDIAIRE
INTERMEDIATE COVER
TAPA DE INTERMEDIO
ZWISCHENDECKEL
5 [Link] 1 SCATOLA
CARTER
HOUSING
CAJA
GEHAEUSE
6 002.02.1429 1 ANELLO D'ARRESTO
BAGUE D'ARRET
SNAP RING
ARO DE RETENCIÓN
SPRENGRING
7 [Link] 1 TAPPO
BOUCHON
PLUG
TAPÓN
STOPFEN
8 [Link] 1 TAPPO
BOUCHON
PLUG
TAPÓN
STOPFEN
113-01-0001
113/ 51 2
CENTRAL HOUSING 3/07/12
113 113-01/24
9 [Link] 1 TAPPO MAGNETICO
BOUCHON MAGNETIQUE
MAGNET PLUG
TAPÓN MAGNÉTICO
MAGNETSTOPFEN
10 016.14.1138 1 VITE DI CHIUSURA
VIS DE FERMETURE
PLUG
TAPÓN
VERSCHLUSS-SCHRAUBE
11
12
13
14
15
16
17 [Link] 1 TAPPO
BOUCHON
PLUG
TAPÓN
STOPFEN
113-01-0001
113/ 51 3
CENTRAL HOUSING 3/07/12
113 113-01/24
18 011.07.1478 1 ROSETTA DI TENUTA
BAGUE D'ETANCHEITE
SEAL WASHER
ARANDELA DE ESTANQUIDAD
DICHTRING
113-04-0005
113/ 51 1
DIFFERENTIAL 3/07/12
113 113-04/22
1 016.30.4162 2 VITE
VIS
BOLT
TORNILLO
SCHRAUBE
2 [Link] 2 GHIERA
ECROU
RING NUT
ABRAZADERA
WELLENMUTTER
3 005.09.0762 2 CUSCINETTO A RULLI CONICI
ROULEMENT A R. CONIQUES
TAPER ROLLER BEARING
COJINETE DE BOLAS
KEGELROLLENLAGER
4 016.28.3390 20 VITE
VIS
BOLT
TORNILLO
SCHRAUBE
5 [Link] 1 SCATOLA DIFFERENZIALE
CARTER DIFFERENTIEL
DIFFERENTIAL CARRIER
CAJA DE DIFERENCIAL
DIFFERENTIALGEHAEUSE
6 [Link] 1 COPPIA CONICA
COUPLE CONIQUE
BEVEL GEAR SET
PAR CONICO
KEGEL- UND TELLERRADPAAR
7
8 [Link] 2 PLANETARIO
PLANETAIRE
DIFFERENTIAL SIDE GEAR
PLANETARIO
AUSGLEICHSWELLENRAD
9 [Link] 4 RONDELLA DI RASAMENTO
RONDELLE
FRICTION WASHER
ARANDELA DE FRICCIÓN
113-04-0005
113/ 51 2
DIFFERENTIAL 3/07/12
113 113-04/22
ANLAUFSCHEIBE
10 [Link] 4 SATELLITE
SATELLITE
DIFFERENTIAL PINION
ENGRANAJE SATÉLITE
AUSGLEICHSKEGELRAD
11 [Link] 2 PERNO DIFFERENZIALE
AXE
DIFFERENTIAL SHAFT
PERNO DE DIFERENCIAL
AUSGLEICHSBOLZEN
12 016.38.4239 15 VITE
VIS
BOLT
TORNILLO
SCHRAUBE
13 005.10.1457 1 CUSCINETTO A RULLI CONICI
ROULEMENT A R. CONIQUES
TAPER ROLLER BEARING
COJINETE DE BOLAS
KEGELROLLENLAGER
14 [Link] 1 KIT ANELLI
KIT ARRETOIR
RING KIT
KIT DE ANILLO
RINGE KIT
15 [Link] 1 DISTANZIALE
ENTRETOISE
SPACER
DISTANCIADOR
DISTANZRING
16 001.13.1234 1 ANELLO DI TENUTA
JOINT D'ETANCHEITE
SEAL
ANILLO DE ESTANQUEIDAD
DICHTRING
17 001.05.0818 1 ANELLO OR
JOINT OR
O - RING
ANILLO TOROIDAL
O - RING
113-04-0005
113/ 51 3
DIFFERENTIAL 3/07/12
113 113-04/22
18 [Link] 1 DADO
ECROU
NUT
TUERCA
MUTTER
19 [Link] 1 LAMIERA DI PROTEZIONE
PROTECTION EN TOLE
COVER PLATE
CHAPA DE PROTECCIÓN
SCHUTZBLECH
20 005.09.0831 1 CUSCINETTO A RULLI CONICI
ROULEMENT A R. CONIQUES
TAPER ROLLER BEARING
COJINETE DE BOLAS
KEGELROLLENLAGER
21 [Link] 1 KIT SPESSORI
KIT CALES
SHIM KIT
KIT DE ESPESOR
PASS-SCHEIBEN KIT
22
23 [Link] 1 FLANGIA
BRIDE
FLANGE
BRIDA
FLANSCH
24
25
26
27
113-04-0005
113/ 51 4
DIFFERENTIAL 3/07/12
113 113-04/22
28
29
30
31
32
33
34
35
36
37
38
113-04-0005
113/ 51 5
DIFFERENTIAL 3/07/12
113 113-04/22
39
40
41
42 [Link] 1 DIFFERENZIALE
DIFFERENTIEL
DIFFERENTIAL
DIFERENCIAL
DIFFERENTIAL
43 [Link] 2 DISCO FRIZIONE
DISQUE D'EMBRAJAGE
CLUTCH DISC
DISCO DE EMBRAGUE
KUPPLUNGSSCHEIBE
113-06-0001
113/ 51 1
HUB REDUCTION 3/07/12
113 113-06/04
1 [Link] 2 BRACCIO
CORPS D'ESSIEU
AXLE CASE
BRAZO
ACHSKOERPER
2
3 [Link] 40 VITE
VIS
BOLT
TORNILLO
SCHRAUBE
4 [Link] 2 SEMIASSE
DEMI-ARBRE
HALF SHAFT
SEMIEJE
ACHSWELLE
5 001.43.3687 2 ANELLO DI TENUTA
JOINT D'ETANCHEITE
SEAL
ANILLO DE ESTANQUEIDAD
DICHTRING
6 [Link] 2 ANELLO
BAGUE
RING
ANILLO
RING
7 [Link] 2 ANELLO DI TENUTA
JOINT D'ETANCHEITE
SEAL
ANILLO DE ESTANQUEIDAD
DICHTRING
8 005.10.1427 4 CUSCINETTO A RULLI CONICI
ROULEMENT A R. CONIQUES
TAPER ROLLER BEARING
COJINETE DE BOLAS
KEGELROLLENLAGER
9 [Link] 24 COLONNETTA
GOUJON DE ROUE
WHEEL STUD
PRISIONERO
113-06-0001
113/ 51 2
HUB REDUCTION 3/07/12
113 113-06/04
RADBOLZEN
10 [Link] 2 MOZZO RUOTA
MOYEU DE ROUE
WHEEL HUB
CUBO DE MAZA
RADNABE
11 006.08.2865 24 DADO A SEDE SFERICA
ECROU DEMI-SPHERIQUE
WHEEL NUT
TURCA ASIENTA ESFÉRICA
KUGELBUNDMUTTER
12 001.05.1424 2 ANELLO OR
JOINT OR
O - RING
ANILLO TOROIDAL
O - RING
13 002.14.3202 8 ANELLO D'ARRESTO
BAGUE D'ARRET
SNAP RING
ARO DE RETENCIÓN
SPRENGRING
14 [Link] 8 SATELLITE (PLAN.)
SATELLITE
PLANET GEAR
ENGRANAJE PLANETARIO
PLANETENRAD
15 [Link] 8 CUSCINETTO
ROULEMENT
BEARING
COJINETE
LAGER
16 [Link] 2 SUPPORTO SATELLITI
SUPPORT SATELLITES
PLANET GEAR CARRIER
TAPA PORTASATÉLITES
PLANETENGEHAEUSE
17 [Link] 2 SUPPORTO SATELLITI
SUPPORT SATELLITES
PLANET GEAR CARRIER
TAPA PORTASATÉLITES
PLANETENGEHAEUSE
113-06-0001
113/ 51 3
HUB REDUCTION 3/07/12
113 113-06/04
18 [Link] 2 TAPPO
BOUCHON
PLUG
TAPÓN
STOPFEN
19 016.06.0442 4 VITE A TESTA CONICA
VIS A TETE CONIQUE
COUNTERSUNK BOLT
TORNILLO DE CABEZA CONICA
SENKSCHRAUBE
20 [Link] 2 RONDELLA DI RASAMENTO
RONDELLE
FRICTION WASHER
ARANDELA DE FRICCIÓN
ANLAUFSCHEIBE
21 006.22.4177 16 DADO
ECROU
NUT
TUERCA
MUTTER
22 [Link] 16 PRIGIONIERO
GOUJON
STUD
PRISIONERO
STIFTSCHRAUBE
23 [Link] 2 LAMIERA DI SICUREZZA
TOLE DE SECURITE
LOCKING PLATE
BLOQUEO DE LA CUBIERTA
SICHERUNGSBLECH
24 [Link] 2 SUPPORTO PORTACORONA
SUPPORT PORTE COURONNE
RING GEAR SUPPORT
SOPORTE DE CORONA
HOHLRADTRAEGER
25 [Link] 2 CORONA DENTATA
COURONNE DENTEE
RING GEAR
CORONA DENTADA
ZAHNKRANZ
113-06-0001
113/ 51 4
HUB REDUCTION 3/07/12
113 113-06/04
26 [Link] 2 ANELLO DI SICUREZZA
ARRETOIR
CIRCLIP
ANILLO DE SEGURIDAD
SICHERUNGSRING
27 [Link] 6 TAPPO MAGNETICO
BOUCHON MAGNETIQUE
MAGNET PLUG
TAPÓN MAGNÉTICO
MAGNETSTOPFEN
28
29
30
31
32 [Link] 2 PIGNONE
PIGNON
PINION
PIÑÓN
RITZEL
33
34
35 [Link] 2 SUPPORTO PORTACORONA
SUPPORT PORTE COURONNE
RING GEAR SUPPORT
113-06-0001
113/ 51 5
HUB REDUCTION 3/07/12
113 113-06/04
SOPORTE DE CORONA
HOHLRADTRAEGER
113-07-0002
113/ 51 1
BRAKES 3/07/12
113 113-07/11
1
2 [Link] 6 DISCO FRENO
DISQUE DE FREIN
BRAKE DISC
DISCO DE FRENO
BREMSSCHEIBE
3 [Link] 6 DISCO FRENO INTERMEDIO
DISQUE INTERMEDIAIRE
INTERMEDIATE BRAKE DISC
DISCO DE FRENO INTERMEDIO
GEGENLAMELLE
4 [Link] 2 BUSSOLA
MANCHON DE REDUCTION
REDUCTION BUSHING
CASQUILLO
ZWISCHENBUCHSE
5 [Link] 6 VITE REGISTRO
VIS DE REGLAGE
ADJUSTING BOLT
TORNILLO EN REGISTRO
NACHSTELLSCHRAUBE
6 [Link] 6 MOLLA
RESSORT
SPRING
MUELLE
FEDER
7 [Link] 6 VITE REGISTRO
VIS DE REGLAGE
ADJUSTING BOLT
TORNILLO EN REGISTRO
NACHSTELLSCHRAUBE
8 [Link] 6 MOLLA
RESSORT
SPRING
MUELLE
FEDER
9 [Link] 2 PISTONE
PISTON
PISTON
PISTÓN
113-07-0002
113/ 51 2
BRAKES 3/07/12
113 113-07/11
KOLBEN
10 [Link] 2 ANELLO ANTIESTRUSIONE
BAGUE ANTIEXTRUSION
BACK - UP RING
ANILLO ANTIEXTRUSIÓN
ANTIEXTRUSIONSRING
11 001.05.1251 2 ANELLO OR
JOINT OR
O - RING
ANILLO TOROIDAL
O - RING
12 [Link] 2 TAPPO
BOUCHON
PLUG
TAPÓN
STOPFEN
13
14 [Link] 2 VITE SPURGO
VIS DE PURGE
BLEEDING BOLT
PURGADOR
ABBLASESCHRAUBE
15 [Link] 2 TAPPO
BOUCHON
PLUG
TAPÓN
STOPFEN
16 001.05.3736 2 ANELLO OR
JOINT OR
O - RING
ANILLO TOROIDAL
O - RING
17 [Link] 2 ANELLO ANTIESTRUSIONE
BAGUE ANTIEXTRUSION
BACK - UP RING
ANILLO ANTIEXTRUSIÓN
ANTIEXTRUSIONSRING
113-07-0002
113/ 51 3
BRAKES 3/07/12
113 113-07/11
18 [Link] 2 VITE SPINA
VIS A BROCHE
PILOT BOLT
TORNILLO DE ENCHUFE
FUEHRUNGSSCHRAUBE
