Spare Parts Catalogue
GS-25-S4-1150x525
Handling systems | Transpallet manuali
Valid for machine code: GFB41000000
Revision: 0 (5/2007)
Copyright 2010 Pramac Group, All Rights Reserved.
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - [Link] This document was printed on 13 Luglio 2010
Functional Group Functional Group Number Table Number Revision
Gruppo comando 1 - 0 (05-2007)
GS-25-S4-1150x525 - Machine code: GFB41000000 Spare Parts Catalogue GS-25-S4-1150x525 - Revision: 0 (5/2007)
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - [Link] This document was printed on 13 Luglio 2010
Functional Group Functional Group Number Table Number Revision
Gruppo comando 1 - 0 (05-2007)
GS-25-S4-1150x525 - Machine code: GFB41000000 Spare Parts Catalogue GS-25-S4-1150x525 - Revision: 0 (5/2007)
Position Part Number Description Notes
301 S0004013007 Pistone Gs (lavorato) -
302 G09019 - Valido per macchine prodotte fino al 28/02/1999
G09007 Bicchiere Guida Molla Gs/usa '99 [Link] Valido per macchine prodotte dal 01/03/2000
303 G090001 Kit Guarnizioni Gs Valido per macchine con matricola fino a 657540
P0KI00003 Kit Guarnizioni Gs '02 Valido per macchine con matricola da 657541
304 G001103 Molla De42 F.4,5x125 P.15 M-zn -
305 S0004013006 Pistoncino Pompa Gs -
306 S0004010470 Cilindretto Brunito Gs-gs/galv Montato -
307 S0004013008 Perno Passaggio Catena (l.98) Brun. -
308 G096001 Rondella Rame 18x23,5x1,5 -
309 S0004011012 Ponticello Ghisa Gs Lavorato -
310 S0004013001 Rullino Pompaggio Tp/gs Brunito -
311 S0004013002 Perno Rullino Pompaggio Gs -
312 S0002010169 Ruota Gomma D200 (model No. Ea200bh-65a Lifter) +cuscinetti -
S0004010186 Ruota Nylon D200+cuscinetti -
S0014010233 Ruota Poly.c/all D200x50 + Cusc.6204 -
313 S0004015008 Spillo Valvola Massima Gs -
314 G001104 Molla De8 F.1,7x22 P.3,5 Molata -
315 G022501 Vite Stei 5923 14.9 M10x12 Eslok -
316 S0004015007 Vite Crocera Zincata Gs -
317 G091101 Parapolvere Ruote Tp 47x20 Sp3.9 -
318 S000003901 Pedalino Spillo Di Apertura '07 Gs -
319 S0004018002 Bronzina Corpo Pompa Gs (20x22x10) -
320 S0004015015 Asse Ruote Gs/hl10e -
321 S0004010206 Corpo Pompa Gs (ricambio) Valido per macchine con matricola fino a 657540
P0PP00006 Corpo Pompa Gs'02 (ricambio) Valido per macchine con matricola da 657541
322 S0004018003 Serbatoio Olio Transpallet Gs -
323 S0004018001 Tappo Serbatoio Olio Transpallet Gs -
324 S0004018005 Protezione Serbatoio Gs (corta) -
325 S0004011026 - Valido per macchine prodotte fino al 19/07/1998
S0014011030 Crocera Gs/cat Lavorata Valido per macchine prodotte dal 20/07/1998
326 G010220 Cuscinetto 6012 Rs(60-95-18) -
327 S0004011024 Boccola Ghisa Gs (lavorata) -
328 S0004010235 Tirante Completo Maniglia Gs Valido per macchine con matricola fino a 716301
P0TT00001 Tirante Completo+leva Maniglia Gs (ø3.3 Valido per macchine con matricola da 716302
329 S0004036022 Distanziale Leva Discesa Gs -
330 G001126 Molla Leva Discesa Gs -
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - [Link] This document was printed on 13 Luglio 2010
Functional Group Functional Group Number Table Number Revision
Gruppo comando 1 - 0 (05-2007)
GS-25-S4-1150x525 - Machine code: GFB41000000 Spare Parts Catalogue GS-25-S4-1150x525 - Revision: 0 (5/2007)
Position Part Number Description Notes
331 S0004018006 Leva Discesa Transpallet Gs -
332 S0004030215 Maniglia Pompaggio Gs (verniciata) -
333 S000003019 Gruppo Idr. Gs-gs Usa '02 [Link].+ Ruote Gomma Valido per macchine prodotte dal 31/03/2003
S000003007 Gruppo Idr. Gs 2200kg + Ruote Gomma Valido per macchine prodotte dal 26/11/2002 al 31/03/2003
334 G032301 Dado Normale 5588 65 Cl8 M6 Zn -
335 G016104 Sfera 5/16" (mm7,938)" -
336 G016103 Sfera 9/16" (mm14,288) Sfera 2" -
337 G042501 Anello Arresto Rs 7434 D10 -
338 G022112 Vite Tcei 5931-67 8.8 M8x20 Zn -
339 G044319 Spina Elastica Spirol 8748 D4x30 -
340 G042120 Seeger Esterno 7435 E 20 -
341 G034401 Dado Basso Autobl. 7474 M8 Zn -
342 G023102 Vite Stei 5923 M6x25 Inox -
343 G022006 Vite Te 5739 65 8.8 M6x35 Zn -
344 G022220 Vite Te 5737 65 8.8 M8x50 Zn -
345 G042160 Seeger Esterno 7435 E 60 -
346 G044318 Spina Elastica Spirol 8748 D 4x40 -
999 S0004030243 Maniglia Pompaggio Completa Gs Basic '08 -
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - [Link] This document was printed on 13 Luglio 2010
Functional Group Functional Group Number Table Number Revision
Valvola aspirazione completa 2 - 0 (05-2007)
GS-25-S4-1150x525 - Machine code: GFB41000000 Spare Parts Catalogue GS-25-S4-1150x525 - Revision: 0 (5/2007)
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - [Link] This document was printed on 13 Luglio 2010
Functional Group Functional Group Number Table Number Revision
Valvola aspirazione completa 2 - 0 (05-2007)
GS-25-S4-1150x525 - Machine code: GFB41000000 Spare Parts Catalogue GS-25-S4-1150x525 - Revision: 0 (5/2007)
Position Part Number Description Notes
200 S0004010035 Rubinetto Aspirazione [Link] (ricambi) -
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - [Link] This document was printed on 13 Luglio 2010
Functional Group Functional Group Number Table Number Revision
Valvola aspirazione completa 2 - 0 (05-2007)
GS-25-S4-1150x525 - Machine code: GFB41000000 Spare Parts Catalogue GS-25-S4-1150x525 - Revision: 0 (5/2007)
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - [Link] This document was printed on 13 Luglio 2010
Functional Group Functional Group Number Table Number Revision
Valvola aspirazione completa 2 - 0 (05-2007)
GS-25-S4-1150x525 - Machine code: GFB41000000 Spare Parts Catalogue GS-25-S4-1150x525 - Revision: 0 (5/2007)
Position Part Number Description Notes
P3VA00003 Opening Pin Kit Gs Replacement -
201 G001102 Molla De13 F.1,6x18 P5 Mola-zincate -
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - [Link] This document was printed on 13 Luglio 2010
Functional Group Functional Group Number Table Number Revision
Rubinetto di tenuta 3 - 0 (05-2007)
GS-25-S4-1150x525 - Machine code: GFB41000000 Spare Parts Catalogue GS-25-S4-1150x525 - Revision: 0 (5/2007)
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - [Link] This document was printed on 13 Luglio 2010
Functional Group Functional Group Number Table Number Revision
Rubinetto di tenuta 3 - 0 (05-2007)
GS-25-S4-1150x525 - Machine code: GFB41000000 Spare Parts Catalogue GS-25-S4-1150x525 - Revision: 0 (5/2007)
Position Part Number Description Notes
400 S0004010036 Rubinetto Tenuta Completo Gs (ricambi) -
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - [Link] This document was printed on 13 Luglio 2010
Functional Group Functional Group Number Table Number Revision
Telaio 4 - 0 (05-2007)
GS-25-S4-1150x525 - Machine code: GFB41000000 Spare Parts Catalogue GS-25-S4-1150x525 - Revision: 0 (5/2007)
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - [Link] This document was printed on 13 Luglio 2010
Functional Group Functional Group Number Table Number Revision
Telaio 4 - 0 (05-2007)
GS-25-S4-1150x525 - Machine code: GFB41000000 Spare Parts Catalogue GS-25-S4-1150x525 - Revision: 0 (5/2007)
Position Part Number Description Notes
100 G056103 Rullino Avvio Forca Tp/e-gs -
101 S0003020146 Bilanciere Gs Verniciato L=520 -
102 S0003005055 Boccola Interna Forcella Biella Ck Zinc -
103 S0002270525 Biella Gs'01 L=1150 25q Verniciata -
104 V0001010208-PRAMAC Telaio Gs 1150x525 Verniciato -
105 S0002205040 Perno Riferimento Gs -
106 S0003015038 Asse Bilanciere Gs 520 -
107 G020501 Vite Te 5737 10.9 M12x45 Zn -
108 G032312 Dado Alto 5587 88 Cl10 M12 Zn -
109 G044341 Spina Elastica Spirol 8748 D 6x32 -
110 G032308 Dado Normale 5588 65 Cl8 M8 Zn -
111 G022307 Vite Stei 5925 12.9 M8x20 Zn -
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - [Link] This document was printed on 13 Luglio 2010
Functional Group Functional Group Number Table Number Revision
Rullo portante 5 - 0 (05-2007)
GS-25-S4-1150x525 - Machine code: GFB41000000 Spare Parts Catalogue GS-25-S4-1150x525 - Revision: 0 (5/2007)
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - [Link] This document was printed on 13 Luglio 2010
Functional Group Functional Group Number Table Number Revision
Rullo portante 5 - 0 (05-2007)
GS-25-S4-1150x525 - Machine code: GFB41000000 Spare Parts Catalogue GS-25-S4-1150x525 - Revision: 0 (5/2007)
Position Part Number Description Notes
700 S0012050170 Rullo Poly.i D82x60 + Cuscinetti
S0002010132 Rullo Nylon D82x60 + Cuscinetti
702 G056104 Rullo Avvio Scarpetta Nylon D38 Gs -
704 S0002205039 Perno Attacco Tandem Gs -
705 S0002205038 Perno D16x113 Gs -
706 S0002201027 Scarpetta Doppia Gs (lavorata) -
707 S000003005 Portarulli Tandem Gs'01 Zincato Valido per macchine prodotte dal 01/09/2001
S0012011025 Portarulli Tandem Gs (passivato Nero) Valido per macchine prodotte fino al 31/08/2001
708 S0012035029 Distanziale Rullo Tandem Gs -
709 S0012030178 Tandem Completo Rulli Poly.i Gs
S0012030177 Tandem Completo Rulli Nylon Gs
710 G020272 Vite Te 5739 65 8.8 M12x20 Zn -
711 G044319 Spina Elastica Spirol 8748 D4x30 -
